Cal. 6R20
INSTRUCTIONS (P. 3)
BEDIENUNGSANLEITUNG (S. 25)
INSTRUCTIONS (P. 47)
ISTRUZIONI (P. 69)
INSTRUCCIONES (P. 91)
INSTRUÇÕES (P. 113)
(135 )
You are now the proud owner of a SEIKO Automatic Watch Cal. 6R20. To ensure its optimum
performance, please read the instructions in this booklet carefully before using it. Please keep this
manual handy for ready reference.
Sie sind jetzt stolzer Besitzer einer SEIKO Automatikuhr Kal. 6R20. Lesen Sie diese
English
Bedienungsanleitung vor der Verwendung aufmerksam durch, um ihre optimale Nutzung zu
gewährleisten. Heben Sie diese Bedienungsanleitung gut auf, um jederzeit wieder nachlesen zu
können.
Vous voici l'heureux propriétaire d'une montre automatique SEIKO Cal. 6R20. Pour en obtenir des
performances optimales, veuillez lire attentivement cette brochure avant d'utiliser la montre.
Conservez ce manuel pour vous y référer en cas de besoin.
Congratulazioni per l’acquisto di questo nuovo Orologio Automatico SEIKO Cal. 6R20. Per poter
utilizzare l’orologio al massimo delle sue prestazioni leggere attentamente questo manuale di
istruzioni prima di passare all’uso dell’orologio stesso, e conservarlo poi per qualsiasi eventuale
futura consultazione.
Usted es ahora el orgulloso propietario de un Reloj Automático de SEIKO Cal. 6R20. Para asegurar
el óptimo rendimiento de su reloj, sírvase leer cuidadosamente las instrucciones contenidas en este
manual antes de su uso. Guarde este manual en un lugar muy accesible para la rápida referencia.
Você poderá agora sentir-se orgulhoso de possuir um Relógio Automático SEIKO Cal. 6R20. Para
garantir o seu excelente rendimento, leia atentamente as instruções contidas neste opúsculo antes
de usá-lo. Conserve este manual para consultas futuras.
歡迎購買精工 6R20 機型自動手錶。為保證在最佳狀態下操作手錶，請在使用手錶之前仔細
閱讀本手冊內的各項使用說明。並妥善保管本使用手冊以備今後參考。
2
CONTENTS
Page
CHARACTERISTICS OF A MECHANICAL WATCH .................................................... 4
NAMES OF THE PARTS ............................................................................................. 5
HOW TO USE ............................................................................................................. 7
HOW TO SET THE TIME, DAY AND DATE ................................................................ 9
HOW TO READ THE POWER RESERVE INDICATOR ................................................ 12
TO PRESERVE THE QUALITY OF YOUR WATCH ...................................................... 14
PLACES TO KEEP YOUR WATCH .............................................................................. 18
NOTES ON OVERHAUL .............................................................................................. 19
NOTES ON GUARANTEE AND REPAIR ..................................................................... 19
TROUBLESHOOTING. ................................................................................................ 20
ACCURACY OF MECHANICAL WATCHES ................................................................ 21
SPECIFICATIONS ........................................................................................................ 23
ENGLISH
3
CAL. 6R20
CHARACTERISTICS OF A MECHANICAL WATCH
English
(self-winding type, automatic winding type)
● This mechanical watch operates using power obtained from a mainspring.
● If the watch is completely stopped, manually turn the crown approximately 20
times to wind up the mainspring to start the watch.
● While loss/gain of a quartz watch is indicated by a monthly or annual rate,
accuracy of a mechanical watch is normally indicated by a daily rate (loss/gain per
day).
● Normal usage accuracy of a mechanical watch varies according to conditions of
use (time period that the watch is worn on the wrist, temperature environment,
hand movement, and winding state of the mainspring).
● When the watch is affected by strong magnetism, it temporarily gains or loses
time. If the watch encounters a strong magnetic field, the parts of the watch may
be magnetized. In this case, repairs such as removal of magnetism are required.
Contact the retailer from whom the watch was purchased.
4
NAMES OF THE PARTS
English
Hour hand
Power reserve
indicator
Second hand
CROWN
a)
Normal position : winding up the mainspring (manual operation)
First click position : day and date settings
b)
c) Second click position : time settings
Minute hand
Date
CROWN
abc
Day
5
● Check the type of the crown of your watch
English
Turn the
crown
clockwise.
* If your watch has a screw-lock crown, the crown will screw into the watch case for
added protection.
• After completing all settings of the watch, screw the crown in again by
turning it clockwise while pressing it.
• If the crown turns out to be too stiff to be screwed up, turn the crown
counterclockwise once and then give another try.
• Do not screw it in by force as it may damage the slots of the crown.
6
The crown
turns.
The crown
does not
turn.
The crown of your watch is
*the screw lock type.
To set the watch
Unscrew the crown by turning it
counterclockwise.
Unscrew.
Screwup.
Go to
"HOW TO
USE"
HOW TO USE
This watch is an automatic watch equipped with a manual winding mechanism.
• When the watch is worn on the wrist, the motion of the wearer's arm winds the
mainspring of the watch.
• If your watch is completely stopped,
the mainspring by turning the crown.
it is recommended that you manually wind
● How to manually wind the mainspring by turning the crown
1. Slowly turn the crown clockwise (the 12
o’clock direction) to wind the mainspring.
* Turning the crown counterclockwise (the 6
o’clock direction) does not wind the
mainspring.
2. Wind the mainspring until the power reserve
indicator shows
second hand will start moving.
3. Set the time, day and date before putting
your watch on the wrist.
a full-wound state. The
English
7
* To check the winding state of the mainspring, refer to "HOW TO READ THE POWER
RESERVE INDICATOR " on page 12.
* There is no need to turn the crown further when the mainspring is fully wound. But
English
the crown can be turned without damaging the watch mechanism.
* Once the watch is wound up fully, it operates for about 45 hours.
* If the watch is used without being wound up fully, gain or loss of the watch may
result. To avoid this, wear the watch for more than 10 hours a day. If the watch is
used without wearing on the wrist; if it is used on the desk like a clock, for example;
be sure to wind it up fully every day at a fixed time.
* If you use a watch that has stopped with the mainspring unwound, winding the
mainspring with the crown will not start the watch immediately. That is because the
mainspring torque (force) is low at the beginning of its winding due to the
characteristics of mechanical watches. The second hand starts to move when a
certain degree of strong torque is reached after the mainspring has been wound up.
However, swinging the watch from side to side to forcibly turn the balance can start
the watch sooner.
8
HOW TO SET THE TIME, DAY AND DATE
• Check that the watch is operating, and then set the time, day and date.
• The watch is provided with a day and date function and is so designed that the day
and date changes once every 24 hours. The date changes around 12 o’clock
midnight, and the day around 2:00 a.m. If AM/PM is not properly set, the date will
change around 12 o’clock noon, and the day around 2:00 p.m.
1. Pull out the crown to the first click. (The second
hand continues moving and the accuracy of the
watch is unimpaired.)
2. The day can be set by turning the crown clockwise.
3. The date can be set by turning the crown
counterclockwise. Turn it until the previous day’s
date appears.
Ex.) If today is the 6th of the month, first set the date
to “5” by turning the crown counterclockwise.
CAUTION
• Do not set the date between 10:00 p.m. and 1:00 a.m. If you do, the date
may not change properly / it may cause a malfunction.
English
9
4. Pull out the crown to the second click when the second hand is at the 12 o’clock
position. (The second hand stops on the spot.)
Turn the crown to advance the hands until the date changes to the next. The time
is now set for the a.m. period. Advance the hands to set the correct time.
English
5. Push the crown back in to the normal position in accordance with a time signal.
CAUTION
• The mechanism of mechanical watches is different from that of quartz
watches.
When setting the time, be sure to turn back the minute hand a little behind
the desired time and then advance it to the exact time.
10
● Date adjustment at the beginning of the month
It is necessary to adjust the date on the first day after a month that has less than 31
days.
Ex.) To adust the date in the a.m. period on the first day of a month following a 30-day
month.
1. The watch displays “31” instead of “1”. Pull out the crown to the first click.
2. Turn the crown to set the date to “1” and then push the crown back into the normal
position.
CAUTION
• Do not set the date between 10:00 p.m. and 1:00 a.m. If you do, the date
may not change properly / it may cause a malfunction.
English
11
HOW TO READ THE POWER RESERVE INDICATOR
• The power reserve indicator lets you know the winding state of the mainspring.
• Before removing the watch from your wrist, observe the power reserve indicator
English
to check if the watch has enough power stored to keep running until the next time
you wear it. If necessary, wind the mainspring. (To prevent the watch from
stopping, wind the mainspring to store the excess power that will allow the watch
to run for extra time.)
Power
Reserve
Indicator
The winding
12
state of the
mainspring
The number
of hours the
watch can run
Fully wound
Approximately
45 hours
1/3 wound Unwound
Approximately
15 hours
The watch either stops
or is running down.
* When the mainspring is fully wound, the crown can be turned further without
damaging the mainspring itself. The mainspring of the watch employs a slipping
mechanism to prevent the mainspring from over-winding.
* The orientation of “the power reserve indicator” may slightly vary depending on
the model.
English
13
TO PRESERVE THE QUALITY OF YOUR WATCH
English
●
14
CAUTION
CARE OF YOUR WATCH
• The case and band touch the skin directly. Keep the case and band clean
at all times. This will help to extend the life of the watch and will reduce the
risk of skin irritations.
• When you take the watch off, wipe off moisture, sweat or soil with a soft
dry cloth as soon as possible. This will help to extend the life of the case,
band and gasket.
<Leather strap>
• Gently blot up the moisture using a soft dry cloth. Do not rub the leather,
as this may cause abrasions or discoloration.
<Metal bracelet>
• To keep the bracelet clean, use a soft toothbrush dipped in clean or soapy
water. Be careful not to get water on the case.
CAUTION
● RASH AND ALLERGIC REACTION
Adjust the band to allow a little clearance around your wrist to ensure proper
•
airflow.
• Prolonged and/or repeated contact with the band may cause skin irritation
or dermatitis for those susceptible.
• Possible causes of dermatitis
• Allergic reaction to metals or leathers
• Rust, contamination or perspiration accumulated on the watch case or
band.
• If you should develop any allergic symptoms or skin irritation, immediately stop wearing the watch and seek medical attention.
● WATER RESISTANCE
● Non-water resistance
If “WATER RESISTANT” is not inscribed on the case back,
your watch is not water resistant, and care should be taken
not to get it wet as water may damage the movement. If the
watch becomes wet, we suggest that you have it checked by
the retailer from whom the watch was purchased or your
SERVICE CENTER.
English
15
● Water resistance (3 bar)
If “WATER RESISTANT” is inscribed on the case back, your
English
5
bar WR
10/15/20
bar WR
* Before using a water resistant 5, 10, 15 or 20 bar watch in water, make sure the
crown is pushed in completely.
Do not operate the crown when the watch is wet or in water. If used in sea water,
rinse the watch in fresh water and dry it completely.
16
watch is designed and manufactured to withstand up to 3 bar,
such as accidental contact with splashes of water or rain, but it
is not designed for wearing while swimming or diving.
● Water resistance (5 bar)*
If “WATER RESISTANT 5 BAR” is inscribed on the case back,
your watch is designed and manufactured to withstand up to 5
bar and is suitable for wearing while swimming, yachting and
taking a shower.
● Water resistance (10 bar/15 bar/20 bar)*
If “WATER RESISTANT 10 BAR”, “WATER RESISTANT 15 BAR”
or “WATER RESISTANT 20 BAR” is inscribed on the case back,
your watch is designed and manufactured to withstand up to 10
bar/15 bar/20 bar, respectively, and is suitable for wearing while
taking a bath or shallow diving, but not for scuba diving. We
recommend that you wear a SEIKO Diver’s watch while scuba
diving.
* When taking a shower while wearing a water resistant 5 bar watch, or
taking a bath while wearing a water resistant 10, 15 or 20 bar watch, make
sure to observe the following:
• Do not operate the crown when the watch is wet with soapy water or
shampoo.
• If the watch is left in warm water, a slight time loss or gain may be caused.
This condition, however, will be corrected when the watch returns to
normal temperature.
NOTE:
Pressure in bar is a test pressure and should not be considered as corresponding
to an actual diving depth since swimming movements tend to increase the
pressure at a given depth. Care should also be taken when diving with the watch
into water.
PRECAUTIONS ON WEARING YOUR WATCH
• Exercise care when you hold an infant or small child while wearing the
watch on your wrist, as the infant or child may be injured or develop an
allergic reaction caused by direct contact with the watch.
• Avoid undue shocks such as dropping or scratching against hard surfaces
or playing active sports, which may cause temporary malfunctions.
• There is a possibility of injury caused by wearing the watch on your wrist
especially if you fall down or bump into other people or objects.
English
17
PLACES TO KEEP YOUR WATCH
● Do not leave the watch in a place where the temperature drops below 5°C or rises
above 35°C for a long time.
English
● Do not leave the watch in a place where it will be subjected to strong magnetism
(for example, near television sets, loudspeakers or magnetic necklaces) or static
electricity.
● Do not leave the watch where there is strong vibration.
● Do not leave the watch in dusty places.
● Do not expose the watch to chemical substances or gases.
(Ex.: Organic solvents such as benzine and thinner, gasoline, nail polish, cosmetic
sprays, detergents, adhesives, mercury, and iodine antiseptic solution.)
● Do not leave the watch in close contact with hot spring water.
18
NOTES ON OVERHAUL
● The watch is a precision device with a lot of moving parts lubricated with special
oils. If the parts run short of oil or get worn out, the watch may lose time or stop
its operation. In such a case, have the watch overhauled.
NOTES ON GUARANTEE AND REPAIR
● Please contact the retailer the watch was purchased from or SEIKO CUSTOMER
SERVICE CENTER for repair or overhaul.
● Within the guarantee period, please present the certificate of guarantee to receive
repair services.
● Guarantee coverage is provided in the certificate of guarantee. Please read
carefully and retain it.
English
19
TROUBLESHOOTING
Problem
The watch stops
English
operating.
Even though you wear the
watch every day,
the power reserve indicator
does not move up.
The watch gains/loses
temporarily.
The day and date change
at 12 o’clock noon.
The glass is blurred and
the blur persists for a
long time.
*For the solution of troubles other than listed above, contact the retailer from whom the watch was purchased.
20
Possible causes
The power supplied by the
mainspring has been
consumed.
The watch is worn on your
wrist only for a short period
of time, or the amount of
arm movement is small.
The watch has been left in
extremely high or low
temperatures for a long time.
The watch was brought into
close contact with a
magnetic object.
You dropped the watch, hit it against
a hard surface or wore it while
playing active sports. The watch was
exposed to strong vibrations.
The watch has not been
overhauled for more than 3 years.
AM/PM is not properly set.
Water got inside the watch
due to the deterioration of
the gasket, etc.
Turn the crown or swing the watch to wind it up. The
watch will start operating. If the watch does not start,
consult the retailer from whom the watch was purchased.
Wear the watch for an extended period of time, or when
taking off the watch, turn the crown to wind the
mainspring if the remaining power shown by the power
reserve indicator is not sufficient for the next use.
Normal accuracy will resume when the
watch returns to normal temperature.
Normal accuracy will resume when the watch is kept away from
close contact with the magnetic source. If this condition persists,
consult the retailer from whom the watch was purchased.
Normal accuracy will not resume.
Consult the retailer from whom the
watch was purchased.
Consult the retailer from whom the
watch was purchased.
Advance the hands by 12 hours.
Consult the retailer from whom the
watch was purchased.
Solutions
ACCURACY OF MECHANICAL WATCHES
● The accuracy of mechanical watches is indicated by the daily rates of one week or
so.
● The accuracy of mechanical watches may not fall within the specified range of
time accuracy because of loss/gain changes due to the conditions of use, such as
the length of time during which the watch is worn on the wrist, arm movement,
and whether the mainspring is wound up fully or not, etc.
● The key components in mechanical watches are made of metals, which expand or
contract depending on temperatures due to metal properties. This exerts an effect
on the accuracy of the watches. Mechanical watches tend to lose time at high
temperatures while they tend to gain time at low temperatures.
● In order to improve accuracy, it is important to regularly supply energy to the
balance that controls the speed of the gears. The driving force of the mainspring
that powers mechanical watches varies between when fully wound and immediately
before it is unwound. As the mainspring unwinds, the force weakens.
Relatively steady accuracy can be obtained by wearing the watch on the wrist
frequently for the self-winding type and winding up the mainspring fully everyday
at a fixed time to move it regularly for the wind-up mechanical type.
English
21
● When affected by a strong magnetism from outside, the mechanical watch may
loss/gain time temporarily. The parts of the watch may become magnetized
depending on the extent of the effect. In such a case, consult the retailer from
whom the watch was purchased since the watch requires repair including
English
demagnetizing.
22
SPECIFICATIONS
1 Features ............................................................ 6 hands, time display (Hour, minute and second hands),
2Vibrations per hour ............................................ 28,800
3 Loss/gain (daily rate) ......................................... +25 – 15 s econds at normal temperature range
4 Continuous operating time ................................ More than approx. 45 hours
5 Driving system .................................................. Automatic winding type with manual winding
6 Jewels ............................................................... 29 jewels
* The accuracy above is factory adjusted.
** Due to the characteristics of mechanical watches, any actual daily rate may not fall within the range of
time accuracy specified above dependent on the conditions of use, such as the length of time during
which the watch is worn on the wrist, temperature, arm movement, and whether the mainspring is
wound up fully or not, etc.
day and date display, power reserve indicator
(between 5°C and 35°C)
mechanism
English
23
Loading...
