For assistance with assembly contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
www.seidal.com
KA980100TX “CELTIC”
BAKERS RACK
Assembly Instructions
A Upper Back Frame Quantity
of 1
B Lower back Frame Quantity
of 1
C. Lower side panel Quantity
of 2
D. Upper side panel Quantity
of 2
E. Lower shelf frame Quantity
of 2
F. Lower middle shelf frame Quantity
of 1
G．．．．Upper shelf
frame
Quantity
of 2
1．．．．Long Bolt Quantity
of 16
1/4”*1-1/4”
2．．．．Middle Bolt Quantity
of 4
1/4”*3/4”
3．．．．
Short Bolt
Quantity
of 10
1/4”*1/2”
4．．．．Allen Wrench Quantity
of 1
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew
the finish . Avoid rubbing or scratching the
For replacement parts or questions, please
Call Customer Service at 1-800-633-5096
Do not return product to store, please call
Manufacturer for assistance, questions or
Parts.
“
CELTIC
” BAKERS
RACK
Parts List
Please review all parts and hardware before disposing of any packaging. Call Customer
Service if missing hardware. Do not return to store/retailer. crews shown in actual size. Using
a screw that is too long will cause damage. Before beginning assembly, separate each type of
screw. Carefully study the screw diagrams below (SHOWN ACTUAL SIZE). You may receive
extra hardware with your unit.
Assembly Tool Required
No.2 Phillips Screwdriver (Not Included)
Figure 1
Assembly Instructions:
Unpack and lay parts on clean,
padded surface like carpet or
blanket. Check that you have all
parts indicated on the front page.
Please insert Upper back panel(A)
into lower back panel(B) and then
Insert 2pcs Short bolt (3) through
holes on back Frame(A) to attach
bottom back Frame(B)
Insert 4pcs long bolt (1) through
holes on lower back frame (B) to
attach 2pcs lower side panel(C)
Insert 2pcs long bolt (1) through
holes on Upper back frame (A) to
attach 2pcs Upper side panel(D),
then inser 2pcs short bolt(3)
through holes on Upper side
panel(D) to attach 2pcs Bottom
side panel(C)
“
CELTIC
” BAKERS RACK
Assembly Instructions
Figure 2
Insert 4pcs long bolt (1) through
holes on lower side panel (C) to
attach the 2pcs lower shelf (E),
and insert 4pcs Middle bolt (2)
through holes on lower back
Frame (B) to attach the 2pcs
lower shelf (E)
Insert 2pcs long bolt (1) through
holes on lower side panel (C) to
attach the lower middle shelf(F
)
and Insert 2pcs short bolt (3)
through holes on middle shelf (F)
to attach the lower back Frame(B)
Insert 4pcs long bolt (1) through
holes on upper side panel (D) to
attach the 2pcs upper shelf (G)
and Insert 4pcs short bolt (3)
through holes on small wire shelf
(G) to attach the Upper back
Frame(A)
“
CELTIC
” BAKERS RACK
Assembly Instructions
Figure 3
Customer Service 1-800-633-5096
service@seidal.com
Southern Enterprises Inc.
2915 Merrell Road
Dallas, Texas 75229
Missing or damaged hardware and/or parts will be replaced free of charge. We do not sell parts. Southern
Enterprises Inc. will provide replacement parts for only those items purchased within the last 9 months. If
this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation
to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled.
Parts will be sent if available from SEI
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style number:
Style No Parts Letter Parts Description Quantity Needed
KA980100TX -
Parts Replacement Form
