Sega INITIAL D DELUXE TYPE User Manual
1ST PRINTING June ‘03
www.seuservice.com
Version 2 Twin
Owner’s Manual
SEGA ENTERPRISES, INC. USA
MANUAL NO. 999-1797
Game Code: TOT
VISIT OUR WEBSITE!
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain the safety:
To ensure the safe usage of the product, be sure to read the following before using the product. The
following instructions are intended for the users, operators and the personnel in charge of the operation of the product. After carefully reading and sufciently understanding the warning displays and
cautions, handle the product appropriately. Be sure to keep this manual nearby the product or elsewhere convenient for referring to it when necessary.
Herein, explanations which require special attention are enclosed with dual lines. Depending on the
potentially hazardous degrees, the terms of WARNING, CAUTION, etc. are used. Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the product by disregarding this warning
will cause a potentially hazardous
WARNING!
situation which can result in death
or serious injury.
CAUTION!
Indicates that mishandling the product
by disregarding this caution will cause
a slight hazardous situation which can
result in personal injury and or material
damage.
For the safe usage of the product, the following pictographs are used:
Indicates “HANDLE WITH CARE.” In order to protect the human body an equipment,
this display is attached to places where the Owner’s Manual and or Service Manual should
be referred to.
Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention. Failing to
perform work as per the instructions can cause accidents. In the case where only those who have technical expertise should perform the work to avoid hazardous situation, the instructions herein state that the
serviceman should perform such work.
Be sure to turn off power before working on the machine.
To prevent electric shock, be sure to turn off power before starting the work in which the worker touches
the interior of the product. If the work is to be performed in the power-on status, the Instruction Manual
herein always states to that effect.
Be sure to ground the Earth Terminal (this, however, is not required in the case where a power cord
with earth is used).
This product is equipped with the Earth Terminal. When installing the product, Connect the Earth Terminal to the “accurately grounded indoor earth terminal” by using an earth wire. Unless the product is
grounded appropriately, the user can be subject to electric shock. After performing repair, etc. for the
Control equipment, ensure that the Earth Wire is rmly connected to the Control equipment.
Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is not
equipped with the Earth Leakage Breaker can cause a re when earth leakage occurs.
Be sure to use fuses which meet the specied rating. (only for the machines which use fuses).
Using fuses exceeding the specied rating can cause a re and electric shock.
Specication changes (removal of equipment, conversion and addition) not designated by SEGA
are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc. It is
very hazardous to operate the product by removing parts and or modifying the circuits. Should doors,
lids and protective parts be damaged or lost, refrain from operating the product, and contact where the
product was purchased from or the ofce herein stated. SEGA shall not be held responsible for any
accidents, compensation for damage to a third party, resulting from the specications not designated by
SEGA.
Ensure that the product meets the requirements of appropriate Electrical Specications.
Before installing the product, check for Electrical Specications. SEGA products have a nameplate
on which Electrical Specications are described. Ensure that the product is compatible with the power
supply voltage and frequency requirements of the location. Using any Electrical Specications different
from the designated Specications can cause a re and electric shock.
Install and operate the product in places where appropriate lighting is available, allowing warning
labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially hazardous situation are applied to places where accidents can be caused. Ensure that where the product is operated
has sufcient lighting allowing the warnings to be read. If any label is peeled off, apply it again immediately. Please place an order with where the product was purchased from or the ofce herein stated.
When handling the Monitor, be very careful. (Applies only to the product w/monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after running off power, some
portions are still subject to high tension voltage sometimes. Monitor repair and replacement should be
performed only be those technical personnel who have knowledge of electricity and technical expertise.
Be sure to adjust the monitor (projector) properly. (Applies only to the product w/monitor.)
Do not operate the product leaving on-screen ickering or blurring as it is. Using the product with the
monitor not properly adjusted may cause dizziness or a headache to an operator, a player, or the customers.
When transporting or reselling this product, be sure to attach this manual to the product.
In the case where commercially available monitors and printers are used in this product, only the contents relating to this product are explained herein. Some commercially available equipment has functions and reactions not stated in this manual. Read this manual together with the specic Instruction
Manual of such equipment.
•
Descriptions herein contained may be subject to improvement changes without notice.
•
The contents described herein are fully prepared with due care. However, should any question arise or
errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION.
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately after
transporting to the location. Nevertheless, an irregular situation may occur during transportation. Before
turning on power, check the following points to ensure that the product has been transported in a satisfactory status.
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are Casters and Adjusters, damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct direction,
connector connections can not be made accurately. Do not insert connectors forcibly.
Do power cords have cuts and dents?
Do the fuses used meet specied rating? Is the Circuit Protector in an energized status?
Are all accessories available?
Can all Doors and Lids be opened with the Accessory keys? Can Doors and Lids be rmly closed?
TABLE OF CONTENTS
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
TABLE OF CONTENTS
INTRODUCTION OF THE OWNER’S MANUAL
1. HANDLING PRECAUTIONS .......................................................................................
2. PRECAUTIONS CONCERNING INSTALLATION LOCATION ...............................
3. OPERATION ..................................................................................................................
4. NAME OF PARTS .........................................................................................................
5. ACCESSORIES ..............................................................................................................
6. ASSEMBLING AND INSTALLATION ........................................................................
7. CARD READER/WRITER ............................................................................................
8. PRECAUTIONS TO BE HEEDED WHEN MOVING THE MACHINE .....................
9. GAME DESCRIPTION ..................................................................................................
10. EXPLANATION OF TEST AND DATA DISPLAY .....................................................
10 - 1 SWITCH UNIT AND COIN METER ..........................................................
10 - 2 SYSTEM TEST MODE ................................................................................
10 - 3 GAME TEST MODE ....................................................................................
11. CONTROL PANEL (ASSY HANDLE MECHA) ............................................................
11 - 1 REMOVING THE CONTROL PANEL .......................................................
11 - 2 ADJUSTING/REPLACING THE V.R. ........................................................
11 - 3 GREASING ...................................................................................................
12. SPEED SHIFTER (SHIFT LEVER)...............................................................................
13. ACCEL & BRAKE ...........................................................................................................
13 - 1 ADJUSTING AND REPLACING THE V.R. ................................................
13 - 2 GREASING ....................................................................................................
14. COIN SELECTOR ...........................................................................................................
15. MONITOR ........................................................................................................................
16. REPLACING THE FLOURESCENT LAMP, AND LAMPS .........................................
17. PERIODIC INSPECTION TABLE .................................................................................
15. TROUBLESHOOTING ..................................................................................................
19. GAME BOARD ..............................................................................................................
19 - 1 REMOVING THE GD-ROM DRIVE .........................................................
19 - 2 REMOVING THE GAME BOARD ............................................................
19 - 3 COMPOSITION OF GAME BOARD .........................................................
20. COMMUNICATION PLAY ............................................................................................
21. DESIGN RELATED PARTS ..........................................................................................
22. PARTS LIST ...................................................................................................................
23. WIRE COLOR CODE TABLE ......................................................................................
21. WIRING DIAGRAM .....................................................................................................
1 - 2
3 - 4
5 - 8
9
10 - 12
13 - 28
29 - 32
33 - 34
35 - 42
43 - 61
44
45
46 - 61
62 - 66
63
64 - 65
66
67
68 - 69
68 - 69
69
70 - 71
72 - 74
75 - 77
78 - 79
80 - 86
87 - 90
87 - 88
89
90
91
92
93 - 112
113
XXX
SPECIFICATIONS
Installation Space : 74.3 inches width X 73 inches
Height : 71.75 inches
Width : 80 inches
Length : 68 inches
Weight : 1565 lbs
Power, maximum current : 1200 W 10 A (AC 120V 60 Hz AREA)
MONITOR : 29 inch supplied by Sanwa
Monitor Part# 998-0162
Chassis Part# 998-0161
INTRODUCTION OF THE OWNERS MANUAL
This Owner's Manual is intended to provide detailed descriptions together with all the
necessary information covering the general operation of electronic assemblies, electromechanicals, servicing control, spare parts, etc. as regards the product,
SEGA INITIAL “D” Ver.2 TYPE TWIN.
This manual is intended for the owners, personnel and managers in charge of operation
of the product. Operate the product after carefully reading and sufciently understanding the instructions. If the product fails to function satisfactorily, non-technical personnel
should under no circumstances touch the internal system. Please contact where the product was purchased from.
Use of this product is unlikely to cause physical injuries or damages to property. However,
where special attention is required this is indicated by a thick line, the word "IMPORTANT"
and its sign in this manual.
Indicates that mishandling the product by disregarding this display can cause the
STOP
product's intrinsic performance not to be obtained, resulting in malfunctioning.
IMPORTANT!
SEGA AMUSEMENTS USA, INC. /CUSTOMER SERVICE
45133 Industrial Drive, Fremont, California 94538, U.S.A.
Phone : (415) 701-6580
Fax : (415) 701-6594
DEFINITION OF LOCATION MAINTENANCE MAN AND SERVICEMAN
LISTED
U
L
®
5K92
AMUSEMENT MACHINE
Non-technical personnel who do not have technical knowledge and expertise should
refrain from performing such work that this manual requires the location's main-
WARNING!
Ensure that parts replacement, servicing & inspections, and troubleshooting are performed by the
location's maintenance man or the serviceman. It is instructed herein that particularly hazardous work
should be performed by the serviceman who has technical expertise and knowledge.
The location's maintenance man and serviceman are herein dened as follows:
"Location's Maintenance Man" :
Those who have experience in the maintenance of amusement equipment and vending machines, etc.,
and also participate in the servicing and control of the equipment through such routine work as equipment assembly and installation, servicing and inspections, replacement of units and consumables, etc.
within the Amusement Facilities and or locations under the management of the Owner and Owner's
Operators of the product.
tenance man or a serviceman to carry out, or work which is not explained in this
manual. Failing to comply with this instruction can cause a severe accident such
as electric shock.
Activities of Location's Maintenance Man :
Assembly & installation, servicing & inspections, and replacement of units & consumables as regards
amusement equipment, vending machines, etc.
Serviceman :
Those who participate in the designing, manufacturing, inspections and maintenance service of the
equipment at an amusement equipment manufacturer.
Those who have technical expertise equivalent to that of technical high school graduates as regards
electricity, electronics and or mechanical engineering, and daily take part in the servicing & control
and repair of amusement equipment.
Serviceman's Activities :
Assembly & installation and repair & adjustments of electrical, electronic and mechanical parts of
amusement equipment and vending machines.
Serial No. Display
Electrical Specifications Display
CONCERNING THE STICKER DISPLAY CONCERNING WARNING DISPLAYS
SEGA product has Stickers describing the product
manufacture No. (Serial No.) and Electrical
Specications. Also it has a Sticker describing where to
contact for repair and for purchasing parts.
When inquiring about or asking for repair, mention
the Serial No. and Name of Machine indicated on the
Sticker. The Serial No. indicates the product register.
Identical machines could have different parts depending
on the date of production. Also, improvements
and modications might have been made after the
publication of this Manual. In order to meet the above
situations, mention the Serial No. when contacting the
applicable places.
SEGA product has warning displays on Stickers, Labels
and or printed instructions adhered / attached to or
incorporated in the places where a potentially hazardous
situation can arise. The warning displays are intended
for accident prevention for the customers and for
avoiding hazardous situation relating to maintenance
and servicing work. There are some portions in the
Cabinet, which are subject to high tension voltage, etc.
where accidents can be caused merely by touching.
When performing the servicing work , be very careful
of the warning displays. Especially, any complex repair
and replacement work not mentioned herein, should
be performed by those technical personnel who have
knowledge of electricity and technical expertise.
For the prevention of accidents, caution any customer
whose act runs counter to the warnings, as to the effect
that he must stop the act.
440-WS0141-EG
440-WS0142-EG
440-CS0186-EG
440-DS0013XEG
440-WS0002XEG
* NOTE: ILLUSTRATIONS MAY DIFFER FROM ACTUAL PRODUCT
1. HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary matters herein stated can cause personal injury or damage to the machine.
Before performing work, be sure to turn power off. Performing the work
without turning power off can cause an electric shock or short circuit. In the
WARNING!
case work should be performed in the status of power on, this manual always
states to that effect.
To avoid electric shock or short circuit, do not plug in or unplug quickly.
To avoid electric shock, do not plug in or unplug with a wet hand.
Do not expose Power Cords and Earth Wires on the surface, (oor, passage,
etc.). If exposed, the Power Cords and Earth Wires are susceptible to damage.
Damaged cords and wires can cause electric shock or short circuit.
To avoid causing a re or electric shock, do not put things on or damage
Power Cords.
When or after installing the product, do not unnecessarily pull the power cord.
If damaged, the power cord can cause a re or electric shock.
In case the power cord is damaged, ask for replacement through where the
product was purchased from or the ofce herein stated. Using the cord as is
damaged can cause re, electric shock or leakage.
Be sure to perform grounding appropriately. Inappropriate grounding can
cause an electric shock.
Be sure to use fuses meeting specied rating. Using fuses exceeding the
specied rating can cause a re or electric shock.
Completely make connector connections for IC BD and others. Insufcient
insertion can cause an electric shock.
Specication changes, removal of equipment, conversion and/or addition, not
designated by SEGA are not permitted.
• Failure to observe this may cause a re or an electric shock. Non-compliance
with this instruction can have a bad inuence upon physical conditions of the
players or the lookers-on, or result in injury during play.
• SEGA shall not be held responsible for damage, compensation for damage to
a third party, caused by specication changes not designated by SEGA.
Be sure to perform periodic maintenance inspections herein stated.
1
www.seuservice.com
3
www.seuservice.com
STOP
IMPORTANT!
For the IC board circuit inspections, only the logic tester is allowed. The use
of a multiple-purpose tester is not permitted, so be careful in this regard.
The Projector is employed for this machine. The Projector's screen is
susceptible to damage, therefore, be very careful when cleaning the screen.
For details, refer to PROJECTOR.
Static electricity from your body may damage some electronics devices on the
IC board. Before handling the IC board, touch a grounded metallic surface so
that the static electricity can be discharged.
Some parts are the ones designed and manufactured not specically for
this game machine. The manufacturers may discontinue, or change the
specications of, such general-purpose parts. If this is the case, Sega cannot
repair or replace a failed game machine whether or not a warranty period has
expired.
PRODUCTION DATE
This SEGA product was produced in the year of:
2003
This signies that this work was disclosed in 2002.
www.seuservice.com
2
2.
PRECAUTIONS CONCERNING INSTALLATION LOCATION
This product is an indoor game machine. Do not install it outside. Even indoors,
avoid installing in places mentioned below so as not to cause a re, electric shock,
WARNING!
injury and or malfunctioning.
Places subject to rain or water leakage, or places subject to high humidity in
the proximity of an indoor swimming pool and or shower, etc.
Places subject to direct sunlight, or places subject to high temperatures in the
proximity of heating units, etc.
Places lled with inammable gas or vicinity of highly inammable/volatile
chemicals or hazardous matter.
Dusty places.
Sloped surfaces.
Places subject to any type of violent impact.
Vicinity of anti-disaster facilities such as re exits and re extinguishers.
The operating (ambient) temperature range is from 5ºC to 30ºC.
LIMITATIONS OF USAGE REQUIREMENTS
Be sure to check the Electrical Specications.
Ensure that this product is compatible with the location's power supply, volt-
WARNING!
age and frequency requirements.
A plate describing Electrical Specications is attached to the product.
Non-compliance with the Electrical Specications can cause a re and electric
shock.
This product requires the Breaker and Earth Mechanisms as part of the loca-
tion facilities. Using them in a manner not independent can cause a re and
electric shock.
Ensure that the indoor wiring for the power supply is rated at 10 A or higher
(AC single phase 100 ~ 120 V area). Non-compliance with the Electrical
Specications can cause a re and electric shock.
Be sure to independently use the power supply equipped with the Earth Leak-
age Breaker. Using a power supply without the Earth Leakage Breaker can
cause an outbreak of re when earth leakage occurs.
Putting many loads on one electrical outlet can cause generation of heat and a
re resulting from overload.
When using an extension cord, ensure that the cord is rated at 10 A or higher
(AC 100 ~ 120 V area). Using a cord rated lower than the specied rating can
cause a re and electric shock.
3
www.seuservice.com
5
www.seuservice.com
6 in.
73 in.
28 in. over
Vent approx. 8 in.
74.3 in.
Operation Area
For the operation of this machine, secure a minimum area of 74.3 in.
WARNING!
Be sure to provide sufcient space so as to allow this product's ventilation
SEGA shall not be held responsible for damage, compensation for damage
(W)×73 in. (D). In order to prevent injury resulting from the falling down
accident during game play, be sure to secure the minimum area for operation.
fan to function efciently. To avoid machine malfunctioning and a re, do
not place any obstacles near the ventilation opening.
to a third party, resulting from the failure to observe this instruction.
STOP
IMPORTANT!
Electric current consumption
For transporting the machine into the location's building, the minimum necessary
dimensions of the opening (of doors, etc.) are 40 in. (W) and
67 in. (H).
MAX. 10 A (AC 120 V 60 Hz)
www.seuservice.com
FIG. 2
4
3. OPERATION
PRECAUTIONS TO BE HEEDED BEFORE STARTING THE OPERATION
To avoid injury and trouble, be sure to constantly give careful attention to the behavior and manner of the visitors and players.
In order to avoid accidents, check the following before starting the operation:
To ensure maximum safety for the players and the customers, ensure that
WARNING!
where the product is operated has sufcient lighting to allow any warnings
to be read. Operation under insufcient lighting can cause bodily contact
with each other, hitting accident, and or trouble between customers.
Be sure to perform appropriate adjustment of the monitor (projector). For
operation of this machine, do not leave monitor's ickering or deviation as
is. Failure to observe this can have a bad inuence upon the players' or the
customers' physical conditions.
It is suggested to ensure a space allowing the players who feel sick while
playing the game to take a rest.
Check if all of the adjusters are in contact with the surface. If they are not,
the Cabinet can move and cause an accident.
Ensure that all of the SUPPORT
BRACKET are in contact
with the oor.
Ensure that all of the Adjusters are in contact
with the oor.
5
www.seuservice.com
7
www.seuservice.com
Do not put any heavy item on this product. Placing any heavy item on the
product can cause a falling down accident or parts damage.
WARNING!
CAUTION!
PRECAUTIONS TO BE HEEDED DURING OPERATION (PAYING ATTENTION TO CUSTOMERS)
Do not climb on the product. Climbing on the product can cause falling down
accidents. To check the top portion of the product, use a step.
To avoid electric shock, check to see if door & cover parts are damaged or
omitted.
To avoid electric shock, short circuit and or parts damage, do not put the fol-
lowing items on or in the periphery of the product.
Flower vases, owerpots, cups, water tanks, cosmetics, and receptacles/
containers/vessels containing chemicals and water.
To avoid injury, be sure to provide sufcient space by considering the potentially crowded situation at the installation location. Insufcient installation
space can cause making bodily contact with each other, hitting accidents, and or
trouble between customers.
To avoid injury and trouble, be sure to constantly give careful attention to the behavior and manner of the visitors and players.
To avoid injury and accidents, those who fall under the following categories
WARNING!
A player who has never been adversely affected by light stimulus might expe-
Instruct those who feel sick during play to have a medical examination.
To avoid injury resulting from falling down and electric shock due to spilled
To avoid electric shock and short circuit, do not allow customers to put hands
To avoid falling down and injury resulting from falling down, immediately
are not allowed to play the game.
• Those who need assistance such as the use of an apparatus when walking.
• Those who have high blood pressure or a heart problem.
• Those who have experienced muscle convulsion or loss of consciousness when
playing video game, etc.
• Those who have a trouble in the neck and or spinal cord.
• Intoxicated persons.
• Pregnant women or those who are in the likelihood of pregnancy.
• Persons susceptible to motion sickness.
• Persons whose act runs counter to the product's warning displays.
rience dizziness or headache depending on his physical condition when playing the game. Especially, small children can be subject to those conditions.
Caution guardians of small children to keep watch on their children during
play.
drinks, instruct the player not to place heavy items or drinks on the product.
and ngers or extraneous matter in the openings of the product or small openings in or around the doors.
stop the customer's leaning against or climbing on the product, etc.
www.seuservice.com
6
To avoid electric shock and short circuit, do not allow the customers to unplug
the power plug without a justiable reason.
WARNING!
This product is intended for 1 Player only per seat. Playing the game by 2 or
Caution lookers-on so as not to
Caution the player so as not to
more Players riding on the seat together can cause falling down and collision
accidents by striking head, hand, or elbow.
touch the operating unit while
in play. Failure to observe this
may cause bodily contact with
the player and trouble between
the customers.
hold a child in her/his lap to
play. Failure to observe this
may cause the child to be
caught between the Control
Panel and the player and fall
down.
CAUTION!
Immediately stop such violent acts as hitting and kicking the product. Such
violent acts can cause parts damage or falling down, resulting in injury due to
fragments and falling down.
Instruct the Player to adjust the seat before playing the game. Playing the
game in a forcible posture can cause a contingent accident.
7
www.seuservice.com
9
www.seuservice.com
PRECAUTIONS TO BE HEEDED BEFORE STARTING THE OPERATION (CARD SYSTEM)
STOP
IMPORTANT!
If the card reader/writer has not been set as being unused, you will be unable to select any game
mode with use of cards while the game will be in progress.
Thus, for the card reader/writer, deal with the player, paying attention to the following points:
Even if the player requests the system for use of cards when you have set the machine so that
the card reader/writer is not used, the request is rejected.
When an unjust act is performed, no written data is backed up mechanically.
The following acts may be judged to be unjust acts.
Since it also becomes a defect of operation and the cause of parts damage, caution
the player not to perform the following acts.
•Use of cards bent or deformed
•Use of cards adhered seals or extraneous matter on
•Use of a card mixed two sheets
•Use of cards other than dedicated cards
•When a card is extracted quickly
WARNING: HAZARD TO EPILEPTICS.
A very small portion of the population has a condition which may cause them
WARNING!
www.seuservice.com
to experience epileptic seizures or have momentary loss of consciousness when
viewing certain kinds of ashing lights or patterns that are present in our daily
environment. These persons may experience seizures while watching some
kinds of television pictures or playing certain video games. People who have
not had any previous seizures may nonetheless have an undetected epileptic
condition.
If you or anyone in your family has experienced symptoms linked to an epi-
leptic condition (e.g., seizures or loss of awareness), immediately consult your
physician before using any video games.
We recommend that parents observe their children while they play video
games. If you or your child experience the following symptoms: dizziness,
altered vision, eye or muscle twitching, involuntary movements, loss of awareness, disorientation, or convulsions, DISCONTINUE USE IMMEDIATELY
and consult your physician.
8
4. NAME OF PARTS
FIG. 4 a OVERVIEW
FIG. 4 b REAR VIEW
TABLE 4 Dimensions and Weights
Width x Length x Height Weight
CABINET 1 44 in x 68 in x 71.75 in 865 LB
CABINET 2 36.75 in x 68 in x 71.75 in 700 LB
ASSY POP 30 in x 22 in x 14 in 1 LB
When assembled 80.75 in x 68 in x 71.75 in 1565 LB
9
www.seuservice.com
11
www.seuservice.com
5. ACCESSORIES
When transporting the machine, make sure that the following parts are supplied.
Magnetic cards for the recording of play results, and cleaning kits for cleaning the head of the card
reader/writer are sold separately. Subsequent purchases of these items can be made by contacting
the ofce listed on this Owner's Manual or the dealer from whom the product was originally purchased. Be sure to provide the part number(s), name(s), and required number of items.
Cleaning Kit
601-11050 CLEANING CARD: Package of 30 sheets
Magnetic Cards
601-11136-01 CARD PACKAGE TOF ENG: Package of 200 Magnetic Cards
TABLE 5 a ACCESSORIES
DESCRIPTION OWNER'S MANUAL
Part No. (Qty.) 999-1797
Notes
Figures
Parts not labeled with part numbers are as yet
unregistered or cannot be registered. Be sure to
handle all parts with care, as some parts are not
available for purchase separately.
NAOMI NETWAORK SYSTEM SERVICE
MANUAL
420-6660-01 (1)
Instruction Manual for the Game Board
CLEANING CARD
601-11050 (1)
For the periodic maintenance. See Sections 7 and 10.
(30 sheets of Cleaning Card)
KEY MASTER
9301A (2)
For opening/closing
the doors
TAMPERPROOF
WRENCH
T-27 Torx 1/4-20 (1)
T-25 Torx 10/32 (1)
T-20 Torx M4 (1)
T-15 Torx 8/32 (1)
Tool
KEY
(2)
For the CASHBOX DOOR
The Keys are inside the Coin
Chute Door at the time of shipment from the factory.
CARD PACKAGE TOT ENG
601-11237-01 (2)
Cards for card reader/writer
*Picture not available at this time.
www.seuservice.com
10
CARTON BOX
601-11044 (1)
Used for transporting the Game Board. See Fig. 5a.
The following Table 5b lists the parts that are separately marketed but are necessary when
booting this product's software. When having unpacked the shipping crate, make sure that all the
parts in this Table 5b are in the crate. If not so, contact where you have obtained the product.
TABLE 5 b (XKT-0833 : GD-ROM DRIVE KIT)
GD-ROM DRIVE
XKT-0833
Device that loads the software in a GD-ROM disc.
see 5 of Section 6.
GD-ROM DRIVE CARTON BOX
(1)
Used for transporting the GD-ROM DRIVE.
See FIG. 5 b.
This carton box is a standard accessory of the
GD-ROM drive.
TABLE 5 c (GD-ROM KIT TOT ENG EXP)
GD ROM KIT TOT
CUSHION SPONGE
601-11137 (1)
GD-ROM Disc Protector
KEY CHIP (1)
See 3 of Section 6.
NAOMI2 GDROM TOT ENG
(1)
.
11
www.seuservice.com
13
www.seuservice.com
HOW TO USE THE CARTON BOX (GD-ROM DRIVE)
When you want to order for replacing or repairing service of the GD-ROM
STOP
IMPORTANT!
drive that is used by the product, pack it in a carton box as instructed below,
and then deliver the carton box to a service agent. If you do not observe the
instruction, your order may not be accepted or may be charged additionally. If
you handle the GD-ROM drive differently from the following instructions, its
components may be damaged.
• Contain the GD-ROM drive in a dedicated carton box. Do not disassemble
it or remove any part from it unless otherwise instructed.
• Before containing the GD-ROM drive in a dedicated carton box, attach the
GD-ROM drive lid (DISC LID) onto the drive and x the lid with a screw.
• Before containing the GD-ROM drive in a dedicated carton box, remove
the GD-ROM disk from the drive. Do not attempt to move the GD-ROM
drive with a GD-ROM disk inside.
• Before containing the GD-ROM drive in a dedicated carton box, remove
the GD-ROM drive bracket. Carefully keep the GD-ROM drive bracket
and the 4 set screws, because they will be reused.
• When inserting the GD-ROM drive into a dedicated carton box, be careful
about an inserting direction as illustrated below.
• The packing materials in a carton box are used as a cushion. Use them
always when inserting the GD-ROM drive into a dedicated carton box. Do
not bend them.
Remove the GD drive bracket.
FIG. 5 b
www.seuservice.com
12
6. ASSEMBLING AND INSTALLATION
Perform assembly work by following the procedure herein stated. Failing to
comply with the instructions can cause electric shock hazard.
WARNING!
Perform assembling as per this manual. Since this is a complex machine,
erroneous assembling can cause an electric shock, machine damage and or not
functioning as per specied performance.
When assembling, be sure to use plural persons. Depending on the assembly
work, there are some cases in which working by one person alone can cause
personal injury or parts damage.
Ensure that connectors are accurately connected. Incomplete connections can
cause electric shock hazard.
Be careful not to damage the wires. Damaged wires may cause electric shock
or short circuit or present a re risk.
This work should be performed by the Location's Maintenance Man or
Serviceman. Performing work by non-technical personnel can cause a severe
accident such as electric shock. Failing to comply with this instruction can
cause a severe accident such as electric shock to the player during operation.
Provide sufcient space so that assembling can be performed. Performing
work in places with narrow space or low ceiling may cause an accident and
assembly work to be difcult.
To perform work safely and avoid serious accident such as the cabinet's
falling down, do not perform work in places where step-like grade differences,
a ditch, or slope exist.
CAUTION!
Handle molded parts with care. Undue weight or pressure may cause them to
break and the broken pieces may cause injury.
To perform work safely and securely, be sure to prepare a step which is in
a secure and stable condition. Performing work without using the step can
cause violent falling down accidents.
Make sure that the GD cable connector is inserted parallel to the plug.
Improper insertion may cause damage to the connector and present a re risk.
When carrying out the assembling and installation, follow the following 6-item sequence.
INSTALLING THE POP AND THE POP CARD
1
SECURING IN PLACE(ADJUSTER ADJUSTMENT)
2
3
INSTALLING THE GD-ROM DRIVE(SETTING GD-ROM DISC)
POWER SUPPLY, AND EARTH CONNECTION
4
TURNING POWER ON
5
ASSEMBLING CHECK
6
13
www.seuservice.com
15
www.seuservice.com
Tools such as a Phillips type screwdriver, wrench, socket wrench and Ratchet Handle are
required for the assembly work.
24mm
WRENCH
1
Phillips type screwdriver
INSTALLING THE POP AND POP CARD
Install the POP Holder on the top
of the Billboard by using the 4
screws. For performing this work,
be sure to prepare a step.
POP HOLDER
SOCKET WRENCH,RATCHET HANDLE
SCREW (4)
M6×16,w/at and spring washers
PHOTO 6. 1 a
* Note: Picture may differ from actual unit.
www.seuservice.com
For performing work, prepare a step.
14
Attach the POP to the POP Holder.
Slide the POP cut-out so that the edges t into
the protruding portions of the POP Holder.
POP CUT-OUT
Attach Billboard Sash R with 2 Truss screws.
Use 2 Truss screws to attach Billboard Sash L
to the opposite side in the same manner.
POP
PHOTO 6. 1 b
Note: Part will Differ from Image.
TRUSS SCREW (2)
chrome
BILLBOARD SASH R
PHOTO 6. 1 c
Note: Part will Differ from Image.
15
www.seuservice.com
17
www.seuservice.com
2
SECURING IN PLACE (ADJUSTER ADJUSTMENT)
Make sure that all of the adjusters are in contact with the oor. If they are not, the
cabinet can move and cause an accident.
WARNING!
This product has 8 casters and 8 Adjusters. (FIG. 6. 2 a) When the installation position is
determined, cause the adjusters to come into contact with the oor directly, make adjustments
in a manner so that the casters will be raised approximately 5 mm from the oor and make sure
that the machine position is level.
Transport the product to the
installation position.
Have all of the Adjusters make contact
with the oor. Adjust the Adjuster's
height by using a wrench so that the
machine position is kept level.
After making adjustment, fasten the
Adjuster Nut upward and secure the
height of Adjuster.
FIG. 6. 2 a BOTTOM VIEW
* Note:Picture may differ from actual unit.
FIG. 6. 2 b ADJUSTER
www.seuservice.com
16
6 in.
73 in.
28 in. over
Vent approx. 8 in.
74.3 in.
FIG. 6. 2 e
Provide ventilation space for the ventilation
opening.
Allow more than 28 in. of space for customer
trafc.
17
www.seuservice.com
19
www.seuservice.com
3
INSTALLING THE GD-ROM DRIVE (SETTING GD-ROM DISC)
STOP
IMPORTANT!
Unpack the shipping crate, and take out the GD-ROM drive, GD-ROM drive bracket, and GD-
ROM disc.
Carefully handle the GD-ROM drive so as not to contaminate the disc and the
readout lens with stains and dust particles.
Do not continue to use the scratched GD-ROM disc. The scratched GD-ROM
disc may cause the system to malfunction.
Set the GD-ROM disc onto the GD-ROM drive with its labeled side facing
upward.
The key chip is a precision device. Handle it carefully and avoid exposure to
heat, shock and static electricity, as these may cause damage to the device.
The key chip is contained in the GD-ROM disc case. Always use them as a
set.
GD DRIVE BRACKET GD-ROM DRIVE
PHOTO 6. 3 a
Use the 4 tapping screws to x the GD-ROM drive bracket onto the GD-ROM drive. Be careful
about a xing direction.
TAPPING SCREW (4)
M4×8
GD DRIVE BRACKET
FIG. 6. 3 b
CAUTION for U. S. A., Europe, and Australia:
GD-ROM DRIVE
Attach the 2 caution stickers for a laser ray onto
the GD-ROM drive.
FIG. 6. 3 a
www.seuservice.com
18
Remove the 1 truss head screw that
xes the GD-ROM drive lid (DISC
LID). And turn clockwise the lid to
remove.
TRUSS SCREW (1)
M3×8
PHOTO 6. 3 b
Set the GD-ROM disc onto the GD-ROM drive with its labeled side facing upward.
Return the lid to its original place, and x it with 1 truss head screw. Be careful not to fasten the
screw too tightly.
PHOTO 6. 3 c
TRUSS SCREW (1)
M3×8
19
www.seuservice.com
21
www.seuservice.com
Undo the lock on the side of the unit base and remove the Truss screws.
Turn the knob to open the lock, and lower the seat towards the backrest. Slowly lower the
backrest until it touches the oor to prevent damage to the seat components. Put a drop cloth on
the oor to prevent damaging the surface of the seat components.
UNLOCK
TRUSS SCREW (2),
black
FIG. 6. 3 b
Attach the GD-ROM drive with 3 screws.
DROP CLOTH TO PREVENT DAMAGE
TO SURFACE OF PARTS
* Note Figure may appear different then actual product.
www.seuservice.com
PHOTO 6. 3 d
20
SCREW (3) M4×16,
w/at & spring washers
Connect the GD cable connector (for data communication) to the DIMM board.
GD CABLE CONNECTOR
PHOTO 6. 3 e
Insert both the GD cable connector (for data communication) and the power cord connector into
the GD-ROM drive. Be careful about an inserting direction in this instance. Make sure that the
connectors are inserted rmly and completely. Secure the cable with the cord clamp.
GD-ROM DRIVE
GD Cable connector
Power Cord connector
Secure the cable.
PHOTO 6. 3 f
21
www.seuservice.com
23
www.seuservice.com
Paying attention to the direction of the
Place the Sticker on the side of the
PROJECTION
KEY CHIP
Key Chip, insert it securely into the
NAOMI DIMM Board Case.
DIMM Board Case as shown in the
gure.
KEY CHIP
STICKER
Sticker Position
FIG. 6. 3 c
www.seuservice.com
22
Loading...
