INSTALLATION MANUAL
Varifocal IR Bullet Camera
ST-BT1000IR2812-G
v1.0 8/4/14
1
1.
Image Sensor
1/3” CCD
2.
Scanning System
NTSC
3.
Horizontal Resolution
1000TV Lines
4.
Synchronization
Internal, Negative Sync
5.
Minimum Illumination
0 lux B&W
6.
Auto Electronic Shutter
1/60s~1/100,000s
7.
Lens
2.8-12mm Manual Zoom
8. S/N Ratio
>50dB
9. IR LED
φ 5x42PCS
10. IR Distance
130ft
11. IR Power On
CDS Auto Control
12. Video Output
1.0Vp-p @ 75
13. Operating Temperature
14F - 113F
14. OSD
Yes
15. Power Requirements
200mA @ 12VDC
16. Dimensions
11”x3.75”x3”
17. Weight
2.2lbs
This package contains:
PACKAGE CONTENTS
One ST-BT1000IR2812-G varifocal infrared bullet color camera
Mounting Hardware
One installation manual
Note: The ST-BT1000IR2812-G requires a minimum 12VDC 200mA power supply such
as the ST-PS12VDC1A or ST-PS12VDC2A.
PRODUCT DESCRIPTION
The ST-BT1000IR2812-G is a varifocal infrared color bullet camera. The camera uses a 1/3” Color
CCD sensor providing 1000TV lines of resolution. The ST-BT1000IR2812-G has a 2.8mm-12mm lens
for optimal viewing. The 42 infrared LEDs support low light illumination down to 0 Lux.
ST-BT1000IR2812-G
Specifications (Typical)
SPECIFICATIONS
v1.0 8/4/14
2
INSTALLATION AND OPERATION
This symbol is intended to alert the user to the presence of important operating
CAUTION: To reduce the risk of electrical shock do not remove the cover or back of
this unit. No user serviceable parts are inside.
CAUTION: To prevent electric shocks and risk of fire hazards, do not use other
than specified power source.
1. UNPACKING and HANDLING
Each unit is shipped assembled and factory tested.
Ensure that all accessories are removed from the container before discarding packing material
2. MECHANICAL INSPECTION
Inspect the front and rear of the equipment for shipping damage. Make sure the equipment is
clean, and no connectors are broken, damaged, or loose. If equipment appears to be damaged or
defective please contact your distributor or SecurityTronix at 1-610-429-1511 for assistance.
3. SPECIAL ATTENTION
and maintenance (servicing) instructions.
This symbol is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electrical shock.
a. The installer must comply with electrical safety standards. There must be sufficient
space between the camera’s power supply and video line and any high voltage
equipment and/or cables.
b. To help ensure the camera’s life and proper operation do not point the camera
towards the sun or strong light.
c. Do not install the camera in an environment where the temperature is above 113 F.
d. Do not install the camera near a magnetic field or a high-power motor.
e. Do not mount the camera near a radiator or heater.
f. Only use a dry cloth to clean the camera. If there is dirt that is difficult to remove wipe
gently with a mild detergent. Never use strong or abrasive detergents.
g. This camera requires a 12VDC 200mA power supply. Using AC power or a power
supply other than specified will damage the camera.
h. Only qualified installers are allowed to install, test and disassemble the camera.
i. The camera is a low voltage product. If installed outdoors proper safety and
lightening grounding are required.
v1.0 8/4/14
3
4. WIRING CONNECTIONS
a. Connect the power supply’s DC plug to the camera’s power port.
b. Connect the camera to the monitor with a 75 coaxial video cable.
c. Connect power supply’s AC plug to a suitable AC power outlet.
d. Adjust the lens direction according to the required surveillance area and environment.
v1.0 8/4/14
4
OSD
LENS
ELC
DC
SHUTTER
AUTO，1/60,AFLK,1/250,1/350
,1/500,1/1K,1/2K,1/4K,1/5K,
1/10K,1/100K
BRIGHT D
1-100
BRIGHT H
0-100
LSC
OFF,ON
WHITE
ATW
PUSH
LOCK
PRESS SET
MANUAL
R GAIN
0-255
B GAIN
0-255
ANTI CR
DAY/NTGHT
EXT
AUTO
D-N DELAY
1-30
N-D DELAY
1-30
BURST
OFF,ON
SMART IR
OFF,ON
COLOR
BW
BURST
OFF,ON
BACKLIGHT
OFF
BLC
POSITION ADJUSTMENT
HLC
LEVEL
0-255
POSITION ADJUSTMENT
DWDR
LEVEL
0-8
FUNCTIONS
DNR
0-8
AGC GAIN
OFF,LOW,MID,HIGH
MIRROR
OFF,ON
MOTION
OFF
ON
SENSITIVITY 0-100
POSITION ADJUSTMENT
MASK
ACTIVE
PRIVACY
AREA
1-8
MODE
OFF,ON
COLOR
1--8
POSITION ADJUSTMENT
BPC
TH
0-255
DEFOG
OFF,ON
PICT ADJ.
SHARPNESS
0-100
BRIGHT
0-100
CONTRAST
0-100
COLOR
0-100
HUE
0-100
WB RED
0-100
WB BLUE
0-100
Y-GAMMA
0-100
C-GAMMA
0-100
CAMERA SET
CAM ID
0-255
CAM TITLE
PROTOCOL
PELCO-D,PELCO-C,PELCO-P
BAUD RATE
LANGUAGE
ENG,CHINESE
INITIAL
EXIT
SAVE
NO SAVE
5. OSD
v1.0 8/4/14
5
6. TROUBLESHOOTING
a. No picture after applying power – (i) check all plugs and cables are securely
connected to the proper connectors; (ii) ensure your power supply is providing the
correct voltage and current.
b. The picture has ripples – (i) check to see if the power supply is experiencing AC ripple, if
so a filter may be required; (ii) determine if the monitor is faulty; (iii) determine if other
peripheral equipment is causing ripple and if so make the necessary adjustments.
c. The picture background continuously changes color – a fluorescent lamp’s magnetic
field may cause color roll, therefore, reduce the number of fluorescent lamps or
increase the distance between the camera and the lamps.
d. The picture appears smeared – (i) the power supply voltage level may be unstable,
therefore, try another power supply; (ii) ensure the cables are correctly connected
and/or the cables are of the correct impedance.
e. Other interference may require a Securitytronix ground loop isolation filter.
f. Additional troubleshooting assistance can be found on-line at www.securitytronix.com in
addition to support from Securitytronix technicians at 1-800-688-9282, option 3, then
option 2.
v1.0 8/4/14
6
