SecurityTronix CT-PA-924B, CT-PA-944B, CT-PA-948, CT-PLB-41E-B Specsheet

Flush Mount
LED TV Mounts
…competitive technologies with compelling value
CT-LED-024 LED TV Bracket Mount For 23"-37" LED
• Easy mounting design
• Built in bubble level
• Universal mounting patterns
• Max. VESA: 400 x 400
• TV to wall: 14.5mm
• Easy connection for cables
• Loading Capacity: 50kg/110lbs
CT-LED-026 LED TV Bracket Mount For 32"-50" LED
• Easy mounting design
• Built in bubble level
• Universal mounting patterns
• Max.VESA: 600 x 600
• TV to wall: 14.5mm
• Easy connection for cables
• Loading Capacity: 50kg/110lbs
With Integrated Bubble Level
CT-LED-028 LED TV Bracket Mount For 32"-63" LED
• Easy mounting design
• Built in bubble level
• Universal mounting patterns
• Max.VESA: 800 x 800
• TV to wall: 14.5mm
• Easy connection for cables
• Loading Capacity: 50kg/110lbs
CT-LCD-M03 Motorized IR Remote Control Wall Bracket Mount For 23-42 inch screens
• Universal mounting patterns
• Max. hole pattern 16.75” (425mm) wide and 17.7” (450mm) high
• Slim wall distance: 0.5” (12mm)
• Two memory settings
• Four individual motors for specific, powerful positioning
• Tilt: 0º ~-15º
• Swivel: 60º
• Load Capacity: 77 lbs (35kgs)
Email: sales@securitytronix.com Web: www.securitytronix.com
Cantilever Arm
…competitive technologies with compelling value
TV Wall Mount Brackets
With Integrated Bubble Level
CT-PA-924 Single Arm Cantilever LCD/PDP Wall Bracket Mount
• For 23-37 inch screen
• Universal mounting patterns
• Tilt: 10º down
• Swivel: 180º
• Max. hole pattern: 16.5” (420mm) wide and
9.3” (237mm) high
• Profile: 3.75” (95mm) - 22.65” (575mm)
• Bubble level integrated
• Color: Black
• Load capacity: 40kg/88lbs
CT-PA-944 Single Arm Cantilever LCD/PDP Wall Bracket Mount
• For 32-47 inch screen
• Universal mounting patterns
• Tilt: 10º down
• Swivel: 180º
• Max. hole pattern: 16.5” (420mm) wide and
16.15” (410mm) high
• Profile: 3.75” (95mm) - 22.65” (575mm)
• Bubble level integrated
• Color: Black
• Load capacity: 45kg/99lbs
CT-PA-948 Double Arm Cantilever LCD/PDP Wall Bracket Mount
• For 32-63 inch screen
• Universal mounting patterns
• Tilt: 10º down
• Swivel: 180º
• Max. hole pattern 32.25” (820mm) wide and
16.15” (410mm) high
• Profile: 3.75” (95mm) - 22.65” (575mm)
• Bubble level integrated
• Color: Black
• Load capacity: 60kg/132lbs
Email: sales@securitytronix.com Web: www.securitytronix.com
Ultra-Thin LED/LCD
…competitive technologies with compelling value
TV Wall Mount Brackets
With Integrated Bubble Level
CT-PLB-40E Ultra-thin LCD/PDP Wall Bracket Mount
• For 23-37 inch screens
• Universal mounting pattern
• Max. hole pattern: 16.7” (424mm) wide and
9.05” (230mm) high
• < 3/4” (19mm) TV to wall
• Bubble level integrated
• Color: Black
• Loading capability: 45kg/99lbs.
CT-PLB-40M Ultra-thin LCD/PDP Wall Bracket Mount
• For 32-42 inch screens
• Universal mounting pattern
• Max. hole pattern: 16.7” (424mm) wide and 16.15” (410mm) high
• < 3/4” (19mm) TV to wall
• Bubble level integrated
• Color: Black
• Loading capability: 55kg/121lbs.
CT-PLB-41E Ultra-thin LCD/PDP Wall Bracket Mount
• For 32-63 inch screens
• Universal mounting pattern
• Max. hole pattern: 32.45” (824mm) wide and 16.15” (410mm) high
• < 3/4” (19mm) TV to wall
• Bubble level integrated
• Color: Black
• Loading capability: 65kg/132lbs.
Email: sales@securitytronix.com Web: www.securitytronix.com
Ultra-Thin LED/LCD
…competitive technologies with compelling value
TV Wall Mount Brackets
CT-PLB-324 Extreme Ultra-thin LCD/PDP Wall Bracket Mount
For 23-37 inch screens
• Universal mounting pattern
• Max. hole pattern: 16.5” (420mm) wide and 9.45” (240mm) high
• < 0.32” (8mm) TV to wall
• Color: Black
• Loading capability: 45kg/99lbs
CT-PLB-344 Extreme Ultra-thin LCD/PDP Wall Bracket Mount
For 32-42 inch screens
• Universal mounting pattern
• Max. hole pattern: 16.7” (424mm) wide and 9.06” (230mm) high
• < 0.32” (8mm) TV to wall
• Color: Black
• Loading capability: 55kg/121lbs
CT-PLB-348 Extreme Ultra-thin LCD/PDP Wall Bracket Mount
For 32-63 inch screens
• Universal mounting pattern
• Max. hole pattern: 32.3” (820mm) wide and 16.15” (410mm) high
• < 0.32” (8mm) TV to wall
• Color: Black
• Loading capability: 65kg/132lbs
Email: sales@securitytronix.com Web: www.securitytronix.com
…competitive technologies with compelling value
CT-LCD-141 LCD Bracket Mount For 10"-23" LCD
Tilt: 15 degree up/down, Swivel: 180 degree
• VESA: 75x75/100x100
• TV to Wall: 3.47” (88mm) - 16.06” (408mm)
• Loading Capacity: 15kg/33lbs.
Tilting & Swiveling
TV Wall Mount Brackets
• Aluminum Material
• Tilt & Swivel
• Cable Management
CT-LCD-141A LCD Bracket Mount For 10"-32" LCD
Includes VESA Adaptor
• Tilt: 15 degree up/down, Swivel: 180 degree
• VESA: 75x75/100x100/200x100/200x200
• TV to Wall: 3.82” (97mm) - 16.42” (417mm)
• Loading Capacity: 20kg/44lbs.
• Lock System on choice
• Fast,Simple Wall Mounting
• Black Finish
CT-LCD-142 LCD Bracket Mount For 10"-23" LCD
Tilt: 15 degree up/down, Swivel: 180 degree
• VESA: 75x75/100x100
• TV to Wall: 3.47” (88mm) - 9.77: (248mm)
• Loading Capacity: 15kg/33lbs.
CT-LCD-143 LCD Bracket Mount For 10"-23" LCD
Tilt: 15 degree up/down, Swivel: 30 degree
• VESA: 75x75/100x100
• TV to Wall: 3.47” (88mm)
• Loading Capacity: 15kg/33lbs.
CT-LCD-142A LCD Bracket Mount For 10"-32" LCD
Includes VESA Adaptors
• Tilt: 15 degree up/down, Swivel: 180 degree
• VESA: 75x75/100x100/200x100/200x200
• TV to Wall: 3.82” (97mm) - 10.12” (257mm)
• Loading Capacity: 20kg/44lbs.
CT-LCD-143A LCD Bracket Mount For 10"-32" LCD
Tilt: 15 degree up/down, Swivel: 30 degree
• VESA: 75x75/100x100/200x100/200x200
• TV to Wall: 3.82” (97mm)
• Loading Capacity: 20kg/44lbs.
Email: sales@securitytronix.com Web: www.securitytronix.com
