XRSuper6
www.BevanSecurity.com
User’s Guide
Silencing an Alarm
www.BevanSecurity.com
When the alarm bell or siren is sounding, enter your user code or present your
card to a keypad or reader during the Status List display.
All/Perimeter or Home/Sleep/Away System
CANCEL VERIFY displays.
• Ifaburglaralarmisvalid,pressVERIFYtosendavericationmessage
to the Central Station.
• Ifavalidalarmhasnotoccurred,pressCANCELtocancelthealarm
and send an Abort or Cancel message to the Central Station. The
keypad displays ALARM CANCELLED and the security system will be
disarmed.
What to do when a trouble tone is sounding
You can silence the trouble tone by pressing any key. This only silences the
keypad and does not correct the condition that originally caused the problem.
© 2008 Digital Monitoring Products, Inc.
Information furnished by DMP is believed to be accurate and reliable.
This information is subject to change without notice.
The XRSuper6 panel is UL listed for Standard Line Security Household Service and Commercial Burglary Service.
Security Command™ User’s Guide
www.BevanSecurity.com
for XRSuper6 Command Processor™ Panels
Table of Contents
Section Page Section Page
Silencing an Alarm ......................... Inside Front Cover
Keypad Shortcut Keys .................................................... 16
Introduction ..............................................................1
About Your Security System ............................................. 1
Emergency Evacuation Plans ............................................2
DMP Keypads .................................................................. 3
Keypad User Options ....................................................... 6
Special Keypad Tones ......................................................6
DMP Wireless ................................................................. 7
Special Wireless Displays ................................................ 8
Special Keypad Displays ...................................................8
Understanding Security System Terms .............................. 9
Arming and Disarming .............................................11
How Your System Operates ............................................ 11
Arming Functions .......................................................... 11
Key Fob Arming .............................................................12
Key Fob Disarming ........................................................ 12
All/Perimeter System Arming .......................................... 12
All/Perimeter System Disarming ...................................... 13
Home/Away System Arming ........................................... 14
Home/Away System Disarming ....................................... 15
XRSuper6 User’s Guide i
User Menu ...............................................................18
Accessing the User Menu ............................................... 18
User Menu Options ........................................................ 18
User Check-in ................................................................ 19
Zone Activity Check ....................................................... 19
Sensor Reset ................................................................. 20
Outputs On Off ............................................................ 20
Bypass Zones ................................................................ 21
Zone Monitor ................................................................ 21
Using the Zone Monitor Function .................................... 22
System Test .................................................................. 22
User Codes ................................................................... 23
Ambush Code ...............................................................25
Date and Time .............................................................. 26
Display Events ..............................................................26
Request Service ? .......................................................... 26
Section Page
www.BevanSecurity.com
Section Page
System Setup ..........................................................27
System Setup Record..................................................... 27
Outputs ........................................................................ 27
Key Fob Button Programming ........................................ 28
User Codes ................................................................... 28
Appendix A ..............................................................30
About the Display Events Section.................................... 30
Zone Activity Check Event Displays ................................. 30
Zone Bypass Event Displays ........................................... 30
Zone Event Displays ...................................................... 31
Arming and Disarming Event Displays ............................. 31
User Code Change Event Displays .................................. 31
User Check-in Event Displays ......................................... 32
Supervisory Event Displays ............................................ 32
System Monitor Event Displays ....................................... 32
Wireless Jamming Event Displays ................................... 32
Wireless Trouble Event Displays ...................................... 32
Appendix B ..............................................................33
DMP Wireless Description ............................................. 33
Appendix C ..............................................................34
Easy Entry™ User’s Guide .............................................. 34
Appendix D ..............................................................36
FA113 User’s Guide ....................................................... 36
Pager Direct™ User’s Guide ............................................ 36
PhoneAccess™ User’s Guide ........................................... 37
Common Keypad Displays .............................................. 38
Index .......................................................................39
Quick Reference Wallet Cards ................................. 41
ii XRSuper6 User’s Guide
Introduction
www.BevanSecurity.com
About Your Security System
Your system is designed with your safety and comfort in mind.
It uses the latest in computer technology to create the most
advanced,user friendly,security, re, andaccess control system
available.
The system combines ease of use with a simple to understand
keypad display to offer the full range of features requested by
today’s security system owners. Your security system can protect
both the interior and perimeter of your home or business while you
are away or just the perimeter when you are inside, giving you a
wall of security and peace of mind.
You can turn portions of your protection on or off at any time by
pressing a few keys. You can add, delete, and change personal user
codes at any time or check the status of all protection devices in
the system.
DMP Keypads
This is the device we have placed at certain locations throughout
the premises that allows you to turn the system protection on and
off using your personal user code.
Keypad User Menu
The keypad provides a simple User Menu containing all of the
functions you need to fully operate your system such as changing
the time of day or a personal user code.
A Note About False Alarms
One of the most important concerns facing the security industry
today is false alarms. The accidental dispatching of police and
re agencies places others in jeopardy by limiting the response
capability of those emergency service units.
As part of our commitment to reducing false alarms, we would like
to encourage you to read this guide thoroughly. All the information
contained here can help you quickly, and comfortably, learn the
Security Command™ system operation.
Note: There may be a 30-second alarm communication delay
pre-programmed at installation to allow disarming if a false alarm
occurs. This delay is optional and can be removed or increased to
45 seconds by your alarm dealer.
Test Your System Weekly
It is recommended that you test the burglary portion of your system
at least once each week. Testing should involve an active test of all
doors, windows, and motion detectors connected to your system.
Ifyoursystemalsohasreprotection,calltheservicedepartment
tondouthowthisportionofyoursystemshouldbetested.
Refer to the System Test section of this guide for instructions on
testing the burglary portion of your system.
Introduction XRSuper6 User’s Guide 1
Emergency Evacuation Plans
Second Floor
Building Front
Building Back
First Floor
Fire Escape
Window Ladder
www.BevanSecurity.com
Overview
The National Fire Protection Association recommends that you
establish an emergency evacuation plan to safeguard lives in the
eventofareorotheremergency.
Draw a floor plan of your home or business
On a clean sheet of paper, draw the walls, windows, doors, and
stairs. Also draw any obstacles that a person may encounter while
exiting the building such as large furniture or appliances.
Develop escape routes
Determine at least two routes the occupants in each room can
take to safely escape. One route can be the most obvious such
as the door. Another can be through an easily opened window.
If the window is high off the ground, an escape ladder should be
provided.
Draw arrows on theoor plan to show escaperoutes from each
room.
Decide where to meet
Prearrange a meeting place outside and away from where
emergency personnel are likely to be working. A neighbor’s house
or across the street in front of the house are good locations. Always
perform a head count to make sure all occupants safely exited.
NEVER ENTER A BURNING BUILDING. If the head count shows one
or more persons missing, give this information immediately to the
authorities. Never enter a building to look for someone.
Practice your escape plans
Devising an escape plan is only the beginning. For the plan to be
effective everyone should practice escape routes from each room.
Figure 1: Sample Escape Route Map
Early detection
The best way tosurvive a re or other emergency is to get out
early. A re alarm system installation, with smoke and carbon
monoxide detectors in each room, can greatly decrease your risk
of loss or injury.
2 XRSuper6 User’s Guide Introduction
AB C D E F G H I J K L
VWX
MN O
P Q R
ST U
Y Z
COMMA ND
90
1 234
5678
R
ABC PRINTING
FRI 2:51 AM
ARMED
32-Character Display
Armed LED
Power LED
Select Keys
Data Entry Digit keys
COMMAND Key
Back Arrow Key
!
32-Character Display
Armed LED
Power LED
Data Entry Digit keys
COMMAND Key
Back Arrow Key
Select Keys
1 2 3 4
9 0 CMD
5 6 7 8
ABC PRINTING
FRI 2:51 AM
Backlit Logo
and Proximity
Antenna
DMP Keypads
www.BevanSecurity.com
Your system may have one or more easy to use LCD keypads that
allow you to properly operate the system.
• Security Command™ Keypads
• Thinline™ or Aqualite™ Keypads
• Clear Touch™ Keypads
Security Command™, Thinline™, Aqualite™ Keypads
The Select keys
There are four keys under the display called the Select keys. These
keys are one of the features that make your system so easy to
operate. They allow you to make selections by pressing the Select
key under a choice shown in the display.
Note: For the purposes of this guide, when instructed to press
the rst Select key, press the far left Select key; the second
Select key is the second from the left; third Select key is second
from the right; and the fourth Select key is the far right key.
POWER LED
This LED indicates the panel Power status. It is recommended
you contact the service department when the Power LED is off or
blinks.
ARMED LED
This LED is ON steady anytime a burglary protection area is armed
and is OFF when ALL areas are disarmed.
Introduction XRSuper6 User’s Guide 3
LED Operation AC Battery
ON (Steady) OK OK
OFF Trouble N/A
BLINKS OK Trouble
Security Command™ Keypad
Thinline™/Aqualite™ Keypad
Clear Touch™ Keypads
AC Power/Armed LED
Three Panic Icons
32-Character
Display with
Four Touch
Select Areas
Data Entry
Digit Keys
COMMAND KeyBack Arrow Key
Logo
Icon
51
32-Character Display
Select Area 1
Select Area 2
Select Area 3
Select Area 4
www.BevanSecurity.com
Clear Touch™ Keypad
Clear Touch™ Select Areas — There are four Select Areas
in the display. These Select Areas are one of the features that
make your system so easy to operate. They allow you to make
selections by touching the area to choose the item in the display.
Note: For the purposes of this guide when using Clear Touch™
Keypads, when instructed to press the rst Select area, touch
Select Area 1; the second Select area touch Select Area 2; third
Select area touch Select Area 3; and the fourth Select area touch
Select Area 4.
AC Power/Armed LED
The LED indicates the Power and Armed status of the panel.
Depending on the operation, the LED displays in Red or Blue as
listed in the table.
Color and Activity LED Operation
Blue Steady Panel Disarmed, AC Power OK, Battery OK
Blue Blinking Panel Disarmed, AC Power OK, Battery Fault
No Light Panel Disarmed, AC Power Fault, Battery OK
Red Steady Panel Armed, AC Power OK, Battery OK
Red/Blue Alternate Panel Armed, AC Power OK, Battery Fault
Red Blinking Panel Armed, AC Power Fault, Battery OK
Common Keys on All Keypads
Data Entry Digit keys
These keys allow you to enter your user code when arming or
disarming or enter other information into the system.
Touch Select Areas
4 XRSuper6 User’s Guide Introduction
COMMAND (CMD) key
The COMMAND key allows you to advance through the keypad
displays, User Menu, or complete a data entry function.
Back Arrow
(<—) key
The Back Arrow (<—) key is used to go back through the keypad
displays while operating your system. You can press the Back Arrow
key to back up through the list of functions in the User Menu or to
erase the last character you entered.
Police Emergency Fire
Touch Select Areas
Panic Functions
Top Row Select Keys
Police EmergencyFire
!
Top Row Select Keys
PoliceEmergency
Fire
www.BevanSecurity.com
Your keypad may be set up to send a Panic, Emergency, or Fire
report to the central station. This function is optional. If this
option is programmed for your keypad, icons display below the top
row Select keys/areas.
Security Command™, Thinline™, Aqualite™ Keypads
Press and hold the two Select keys adjacent to the desired icon for
2 seconds, until a beep from the keypad is heard.
Clear Touch™ Keypads
Touch the icon for 2 seconds until a beep is heard.
Clear Touch™ Keypad Panic Icons
Security Command™ Keypad Panic Keys
Thinline™/Aqualite™ Keypad Panic Keys
Introduction XRSuper6 User’s Guide 5
Security Command™, Thinline™, Aqualite™ Keypads
7/0
Panic Function
Security Command™, Thinline™, and Aqualite™ Keypads may also be
programmed at installation to allow the user to initiate an optional
Panic alarm by simultaneously pressing and holding the 7 and 0
(zero) keys. When the 7 and 0 keys are pressed for a short time,
the keypad sends a Panic alarm report to the central station.
Note: The 7/0 Panic Function is not available on Clear Touch™
keypads.
Keypad User Options
www.BevanSecurity.com
The User Options allow you to make adjustments to your keypad to
besttyourenvironmentandneeds.
On Security Command™, Thinline™, or Aqualite™ keypads to
access the User Options portion of the keypad, press and hold
the Back Arrow and COMMAND keys for two seconds. The keypad
display changes to SET BRIGHTNESS. Press the COMMAND key to
display the next option or the Back Arrow key to exit.
On Clear Touch™ keypads to access User Options, touch and hold
the center of the logo icon for two seconds. The display changes
to SET BRIGHTNESS. Touch the COMMAND (CMD) key to display the
next option or touch the Back Arrow (<—) to exit the User Options
function.
Backlighting Brightness
At the SET BRIGHTNESS display, use the left Select key to lower
the keypad brightness. Use the right Select key to increase the
brightness.
Note: If the brightness level is lowered, it temporarily reverts back
to maximum intensity whenever a key is pressed.
On Security Command™, Thinline™, or Aqualite™ keypads this
sets the LCD display, AC LED, and the Green keyboard backlighting
brightness level.
On Clear Touch™ keypads the user selected brightness may be set
to off which allows the glass graphic display to turn off (clear glass).
Simply touch the glass anywhere and the backlight illuminates for
data entry. When the speaker is sounding, the backlight illuminates
at one-half (1/2) brightness.
Internal Speaker Tone
Set the tone of the keypad internal speaker. At the SET TONE
display, use the top left Select key to make the tone lower. Use
the right Select key to make the tone higher.
Volume level
Set the volume level of the keypad internal speaker for key presses.
During alarm, trouble, and prewarn conditions, the volume is
always at maximum level. At SET VOLUME LEVEL, use the left
Select key to lower the keypad volume. Use the right Select key
to raise the volume.
Model Number
Thekeypadmodelnumber,rmwareversion,anddatedisplay,but
cannot be changed.
Keypad Address
The current address assigned to the keypad displays, but cannot
be changed. Press the Back Arrow key to exit the User Options
function.
Special Keypad Tones
Your keypad also contains a small speaker that alerts you about
events as they occur on your system. For burglary alarms, your
system may be pre-programmed at installation to stop the tone
as the rstdigit key is pressed whenentering auser code. If a
valid user code is not entered within 5 seconds or an invalid user
code is entered, the tone begins sounding again. Below are brief
descriptions of the different tones you hear from the keypad.
Fire alert: An intermittent sweeping siren from LCD keypads only
thatcontinuouslyrepeatsuntiltherealarmissilenced.Thisisin
addition to the bell output from the alarm panel.
6 XRSuper6 User’s Guide Introduction
Burglary alert: A siren tone from LCD keypads only that continues
Connect Keyring or Lanyard Here
LED
2-Button Layout 1-Button Layout
4-Button Layout
TOP
TOP
TOP
BTM
BTM
LFT
RGT
www.BevanSecurity.com
until the alarm is silenced. This is in addition to the bell output
from the alarm panel.
Key press tone: A short beep as you press a key on the keypad.
Prewarn tone: A continuous pulsed tone that sounds when you
open an entry delay door on a system that is armed (turned on)
reminding you to disarm the burglary protection.
Your system may be pre-programmed at installation to silence the
toneas soonastherstusercode digitkeyispressed.If avalid
user code is not entered within 5 seconds or an invalid user code is
entered, the prewarn tone begins sounding again.
Exit tone: Your system may be pre-programmed at installation to
sound a continuous pulsing tone during the exit countdown just
after arming to remind you to exit the premise. At ten seconds
prior to the end of the countdown, the rate of pulsing increases.
Monitor tone: A pulsed tone that sounds one time for one second
each time a door or window is opened while you are using the zone
monitor function from the User Menu. See Zone Monitor.
Trouble tone: A steady tone indicating a trouble condition on your
system. Press a Select key to silence the trouble tone.
Zone Activity Check tone: A steady tone indicating no zone
activity has occurred on your system within the programmed period
of time. Press any key to silence the tone.
What to do when the trouble tone sounds
You can silence the trouble tone by pressing any key.
This only silences the keypad and does not correct the
condition that originally caused the trouble.
DMP Wireless
Your system may include DMP wireless devices such as key fob(s).
There are three types of DMP wireless key fobs available:
4-Button Model 1145 Key Fob
2-Button Model 1146 Key Fob
1-Button Model 1147 Key Fob
The drawing shows the button
layout for all three models for your
reference. Each button on the key
fob is programmed to perform a
specic action. The button names
are listed for your reference.
TOP = the Key Fob Top button
BTM = the Key Fob Bottom button
LFT = the Key Fob Left button
RGT = the Key Fob Right button
The button programming list for
the key fob(s) connected to your
system is located in the System
Setup section of this guide. Refer to
Appendix B for LED Status operation
information.Specicfunctionlabels
can be added to each button to
indicate button operation.
For best operation, allow the LED
to turn on and then turn off before
pressing another button. The key
fob may not complete sending the
signal for the button press if another
button is pressed too soon.
Key Fob Examples and
Button Names
Introduction XRSuper6 User’s Guide 7
Special Wireless Displays
www.BevanSecurity.com
Your system may use wireless transmitters to send alarm and
trouble information from the protection devices to the panel.
Wireless systems have a few unique keypad displays.
BACK DOOR -LOBAT - (Low Battery) The battery in a wireless
transmitter is low. (BACK DOOR is used as an example only.)
BACK DOOR -MISNG - (Missing) The panel is not receiving the
wireless transmitter periodic test report.
WIRELESS -TRBL - (Trouble) Some part of your wireless system is
operating improperly. Call the service department for assistance.
WIRELESS RECEIVER JAMMED -ALARM - Your system may be
programmed for wireless interference detection and, if displayed,
your wireless receiver has detected an interfering signal while the
system is armed.
WIRELESS RECEIVER JAMMED -TRBL - (Trouble) Your system may be
programmed for wireless interference detection and, if displayed,
your wireless receiver has detected an interfering signal while the
system is disarmed.
Special Keypad Displays
As you use your system, you may occasionally see a keypad display
that asks you to enter a user code or describes a condition on the
system. Below are some examples of the displays you may see.
ALARM
A24-hourzone,suchasareorpaniczone,oranarmedburglary
zone is faulted. Your system may sound bells or sirens.
ALARM NOT SENT
The alarm signal was aborted and was not sent to the central
station because a user code was entered to disarm the system
before the alarm signal was sent to the central station. Also, your
system may be pre-programmed at installation to send an Abort
signal to the Central Station. Refer to the Introduction section of
this guide.
ALARM CANCELLED
An Alarm signal just sent to the central station was cancelled
because a user code was entered after the alarm was sent. Also,
an Alarm Cancel signal is sent to the Central Station.
ALARM VERIFIED
Avalidburglaralarmhasoccurredandhasbeenmanuallyveried
by the user. The alarm system also transmits a VERIFY message to
the Central Station.
ENTER CODE
The system requires you to enter a personal user code. User codes
can be used for turning your system on (arming), turning your
system off (disarming), and other system options.
As you enter your user code, the keypad display shows an asterisk
(*) in place of each digit pressed. This prevents others from seeing
your user code on the display as you enter it.
TRY AGAIN
The user code you entered is not recognized by the system. Check
the user code and try again.
INVALID CODE
The user code you entered is considered invalid by the system.
8 XRSuper6 User’s Guide Introduction
TRBL (TROUBLE)
www.BevanSecurity.com
There is a problem with a protection device or system component.
This display is accompanied by a description of the problem.
SYSTEM TROUBLE or SERVICE REQUIRED
There is an electronic failure in your system. Contact the service
department as soon as possible.
TEST IN PROGRESS
The system is currently being tested by an installation or service
technician.
Understanding Security System Terms
Throughout this guide, and in some displays on your keypad, you
may see certain words or phrases that might be unfamiliar. Although
every effort has been made to use terms that are commonly known,
there are some for which there was no acceptable substitute.
The following terms may display on the keypad or be used in this
document.
Arming
This is the term used for turning on the burglary protection in one
or more areas of the system. Your system may require you to enter
a user code. When armed, the system can sound alarm bells or
sirens and, if monitored, send alarm reports to a central station
when a burglary zone is faulted.
Fire, panic, and other 24-hour devices are always turned on and do
not need to be armed.
Disarming
This means turning off one or more areas of the system. When
disarmed, the system does NOT sound alarms or send alarm reports
to a central station when a burglary zone faults.
Zone
A zone refers to one or more protected openings or pro tection
devices assigned the same zone number. Each door or window,
motion detec tor, smoke detector, or other device has a zone
number and a name.
Often, similar devices in the same general area share the same
zone. For example, the windows on the east side of the premises
can all be grouped together in a zone named E. WINDOWS.
Entry or Exit Zone
Almost all systems have one or more doors through which you can
enter or exit the premises. These doors are programmed with a
delay time to allow you to enter or exit while the system is armed
without setting off the alarm.
When you arm the system, activity on all burglary zones is ignored
until the programmed exit delay time expires. Once that time has
expired and the system is fully armed, opening the door causes the
panel to start the entry delay time. During the entry delay time,
enter a valid user code to disarm the system or an alarm occurs.
Instant Zone
Exterior windows and non-entry doors, or interior protection
devices, are typically not programmed with delay times. If these
zones fault while the system is armed, an alarm occurs instantly.
24-Hour Zone
A 24-hour zone is not turned on or off by arming or disarm ing your
system. Some examples of 24-hour zones are re zones, panic
zones, and temperature control zones.
Introduction XRSuper6 User’s Guide 9
Areas
www.BevanSecurity.com
An area is made up of burglary zones that can be armed or
disarmed together. The Perimeter area, for example, consists of
all the doors and windows on the outside of the building. When you
arm the Perimeter, these zones sound an alarm if tripped.
Central Station Monitoring
Your system can also be programmed to automatically send alarm,
trouble, and arming and disarming reports to a central station.
Operators at the central station can then dispatch the appropriate
authoritiesorcontactyouwiththespeciceventinformation.
Status
Status is a feature that automatically displays the system armed
or dis armed status on the keypads. Alarm or trouble con ditions
on a zone or a system monitor such as AC or battery trouble can
also display. There are two types of status information available:
Status List and Armed Status.
Status List
The keypad Status List displays any alarm or trouble condition on
a zone and any trouble condition that occurs with the AC power or
battery power. If your system contains any Panic zones, these do
not display on the keypad for security reasons.
Ifanalarmoccursonanon-re,24-hourzoneorasystemmonitor,
it remains in the Sta tus List until it re stores. If one or more armed
burglary zones trips, the last one to trip remains in the Status List.
The burglary zone alarm remains in the Status List for several
minutes or until it is cleared by disarming the system.
Armed Status
With Armed Status, the keypad displays the current armed condition
of areas within your security system.
The keypad displays When
HOME MODE ON The perimeter areas is armed in a
Home/Away system.
PERIMETER ON
ALL SYSTEM ON
SLEEP MODE ON The perimeter and interior areas are on
Also, for keypads that include an Armed LED, the Armed LED is ON
steady anytime a burglary protection area is armed and OFF when
ALL areas are disarmed.
Zone Status
To display the status of a particular zone, enter the zone number
followed by the COMMAND key when the keypad displays the Status
List.
Exit Error
This is an automatic panel function that prevents an alarm from
occurring if an exit door does not close all the way after the system
is armed.
For example, if the front door is left ajar upon exit and the exit
delay time expires, the system attempts to arm the front door zone
but recognizes the open condition. The system sounds the alarm
sirens for two seconds to alert you of the condition.
If the open condition is not corrected, the system sends an Exit
Error report to the central station and force arms the door. If the
door closes at a later time, it is included back into the system.
The Exit Error feature allows the central station to acknowledge
the arming error without dispatching the police on a false alarm.
The perimeter is armed in an All/
Perimeter system.
All areas are on.
but the bedroom area is off.
10 XRSuper6 User’s Guide Introduction
Arming and Disarming
www.BevanSecurity.com
How Your System Operates
Your system has been programmed to operate in one of two modes:
All/Perimeter or Home/Sleep/Away.
• All/Perimeter — Your burglary protection is divided into two
areas: Interior and Perimeter.
Perimeter arming is for when you are staying inside but want
the comfort of knowing the exterior doors and windows are
armed. Perimeter arming allows you to move freely about
inside without setting off any interior alarms.
All arms both the Perimeter and the Interior of the system. You
want to arm both of these areas when leaving the building and
no one is left inside.
• Home/Sleep/Away — Your burglary protection is divided into
two or three areas: Perimeter, Interior, and Bedrooms.
Home (Perimeter) arming is for when you are staying inside but
want the comfort of knowing the exterior doors and windows are
armed.
Sleep (Perimeter and Interior) arms all areas except those near
bedrooms and nighttime areas.
Away (Perimeter, Interior, and Bedrooms) arms all three areas
for when you leave the building and no one is left inside.
Regardless of which mode is programmed, much of the operation
is similar. Throughout this guide, any differences between the
systems are noted for your convenience.
Arming Functions
Arming:Duringarming,thesystemveriesthatalldoors,windows,
and other protection devices to be armed are in normal condition.
If everything is normal, the system arms. If there is a problem on
one or more burglary zones, the keypad displays the problem and
allows you to correct the problem or bypass those zones.
If the problem can be corrected by closing a door or window, do
not bypass the zone. Instead, correct the problem and try arming
again. If the problem cannot be corrected, you can bypass the zone
or wait until the zone can be repaired by a service technician. A
bypassed zone is ignored by the system during the armed period.
In some cases the keypad might display FRONT DOOR - FAULT.
The keypad may then display PRIORITY ZONE, which is a zone that
cannot be bypassed. The problem on the zone must be corrected
before the system can be armed.
After making your arming selection, the keypad displays any zones
that are currently bypassed. These zones remain bypassed until
the system is armed and then disarmed. Any 24-hour zones in a
faulted condition also display.
Armed Message: After completing all bypasses or correcting zone
After completing all bypasses or correcting zone faults, the areas
selected are armed.
ForAll/PerimetersystemsthekeypadbrieydisplaysALL SYSTEM
ON if all areas in the system are arming or PERIMETER ON if only
selected areas are arming.
For Home/Away or Home/Sleep/Away systems the keypad displays
ALL SYSTEM ON if all areas in the system are arming, HOME MODE
ON or SLEEP MODE ON if only selected areas are arming.
Arming and Disarming XRSuper6 User’s Guide 11
Exit Delay: The keypad then displays the exit delay time as it
www.BevanSecurity.com
counts down. Your system may be pre-programmed at installation
to beep the exit delay tone at eight-second intervals until the
last 10 seconds when the keypad beeps at three-second intervals.
After exiting the building, if you re-enter during the countdown the
exit countdown restarts, allowing additional time to then disarm
or again exit the building during the countdown. This restart
can occur only one time. When the exit delay time ex pires, all
disarmed zones are armed. If your system uses a keyswitch to arm
an area, the exit delay time does NOT count down on the keypad
display.
When you arm both the Perimeter and Interior to leave the building
but then you do not exit by the time the exit delay ends, the
system automatically arms but the interior area(s) will remain
disarmed because you have not exited.
Should you exit the building and the door does not close properly,
your system may be programmed so that when the exit delay
countdown ends, then the entry delay starts and the bell will sound
to alert you to the situation. Enter your user code to stop the bell
and disarm the system. Rearm the system, exit the building, and
make sure the door is securely closed.
DIALING . . . Message: If your system is monitored, it may be
programmed to wait for the arming report to be sent to the central
station before displaying the armed mes sage. (See Arming Report
below.)Thisveriesyourphonelinesareworkingproperly.While
the system waits, the display reads DIALING.... If the report is
received, the keypad buzzes for one second and displays the armed
message. If the report is not received, the keypad displays LOCAL
ALARM ONLY before displaying the armed message.
Arming Report: Your system may be pre-programmed at installation
to send arming or zone bypass reports to a central station.
12 XRSuper6 User’s Guide Arming and Disarming
Key Fob Arming
Press the key fob button programmed for Arming or Toggle (Arm/
Disarm) button. A Red LED two-second acknowledgement indicates
All System On. A Green/Red two-second acknowledgement
indicates System On with some areas armed.
Key Fob Disarming
Press the key fob button programmed for Disarming or Toggle
(Arm/Disarm) button. A Green LED two-second acknowledgement
indicates All System Off.
Note: Disarming authority needs to be enabled for the User Code
assigned to the Key Fob. Refer to Adding User Codes later in this
document.
All/Perimeter System Arming
Area Assignment: Your security system is divided into two
separate areas. Motion detectors, inside doors, and other interior
protection devices are assigned to the Interior area while windows
and exterior doors are assigned to the Perimeter area.
Perimeter or All: When arming an All/Perimeter system, the
keypad displays PERIM ALL. If you select ALL, you arm both the
Perimeter and the Interior of the system. You want to arm both of
these areas when leaving with nobody left inside. Selecting PERIM
arms only the Perimeter of the system. Perimeter arming is for
when you are staying inside but want the comfort of knowing the
exterior doors and windows are armed. Perimeter arming allows
you to move freely about inside without setting off any interior
alarms.
System Ready/System Not Ready Keypad Displays
www.BevanSecurity.com
When all zones in the system are in a normal condition, the keypad
displays SYSTEM READY. If there are one or more zones that
are not in a normal condition, the keypad displays SYSTEM NOT
READY. Pressing any Select key during this display shows the zone
name allowing you to investigate the problem.
Instant Arming
Instant: During the exit delay time, you can cancel the exit and
entry delays and cause all zones to be instant zones. Press the
far right select key under INSTNT while the exit delay displays.
This immediately arms the exit zones. However, no entry delay is
provided and an alarm immediately occurs should an entry door be
opened.
All/Perimeter Shortcut Key Arming
Arm Perimeter — Press 6 for 2 seconds.
Arm All— Press 1 for 2 seconds.
Arming an All/Perimeter System
1. Enter your code. The keypad displays PERIM ALL.
2. Select PERIM to arm the Perimeter area only.
3. Select ALL to arm both the Perimeter and Interior areas.
4. The keypad displays zones that have been bypassed prior to
arming and zones that are now in a faulted condition.
5. At this point you can force arm or bypass any faulted zones.
A zone that is force armed is restored into the system if it
later returns to normal. A bypassed zone remains bypassed
until the system is disarmed. See steps 5a through 5d.
5a. If a problem exists on any zones, the zone name and
problem display followed by: OKAY BYPASS STOP.
5b. Select OKAY to force arm the zone(s) before arming.
Arming and Disarming XRSuper6 User’s Guide 13
5c. Select BYPASS to bypass the zone(s) before arming.
5d. Select STOP to stop the system from arming. Correct
the zone problem(s) and return to step 1.
6. The keypad displays PERIMETER ON if only the perimeter is
being armed and ALL SYSTEM ON if both the perimeter and
interior are being armed.
7. The keypad next displays EXIT: ## INSTNT and begins to
count down the number of seconds remaining for you to exit.
When the delay expires, all zones are armed.
8. You can select INSTNT while EXIT: ## INSTNT displays to
immediately arm all zones and make them instant. The
keypad displays INSTANT. When you select INSTANT, any
entry/exit zone that trips immediately activates an alarm
and the exit delay countdown immediately stops.
9. When the system is fully armed, the keypad displays
PERIMETER ON for perimeter arming and ALL SYSTEM ON
for perimeter and interior arming.
All/Perimeter System Disarming
Disarming: While the system is armed, you can only enter the
premises through an entry/exit delay door without causing an
alarm. After opening the door, the keypad sounds a prewarn tone
to remind you to disarm the system. You must disarm the system
before the prewarn tone expires or an alarm on the door zone
occurs.
During the prewarn tone, the keypad displays ENTER CODE:. Enter
your user code to disarm the system.
Note: Your system may be pre-programmed at installation to
silencethetoneassoonastherstusercodedigitkeyispressed.
If a valid user code is not entered within 5 seconds or an invalid
user code is entered, the prewarn tone begins sounding again.
Alarm Display
www.BevanSecurity.com
that tripped or any transmission problems that occurred dur ing
the armed period. All burglary zones are then dis armed and any
by passed zones automatically reset.
Disarmed Message: The keypad displays ALL SYSTEM OFF after the
system disarms.
Central Sta tion Report: Your system may be pre-programmed at
installation to send a report of the system disarming to the central
sta tion.
Disarming an All/Perimeter System
1. During the entry delay time, the keypad displays ENTER
2. The keypad displays any zones that went into alarm and any
3. The keypad next displays ALL SYSTEM OFFtoconrmthe
Disarming During an Alarm
1. While the alarm bell or siren sounds, enter your user code to
silence the alarm.
For a burglary alarm, the keypad displays
CANCEL VERIFY.
This allows you to investigate the alarm prior to disarming
the system. This display remains on the keypad until a
selection is made, the Back Arrow is pressed, or the internal
system bell cutoff timer expires.
: After disarming, the keypad dis plays any zones
CODE:. Enter your user code.
communication problems that occurred during the armed
period.
system is disarmed.
2. If a valid alarm has not occurred, Select CANCEL to disarm
the system and cancel the alarm.
The keypad displays ALARM CANCELLED then ALL SYSTEM
OFFtoconrmthesystemisdisarmed.
OR
If the alarm is valid, select VERIFY to send a verify message
to the Central Station.
Home/Away System Arming
Area Assignment: Your security system is divided into two or three
separate areas. Motion detectors, inside doors, and other interior
devices are assigned to an Interior and possibly Bedroom area while
windows and exterior doors, are assigned to a Perimeter area.
Arming the system: When arming a Home/Away system, the
keypad displays HOME AWAY or HOME SLEEP AWAY. If you
select AWAY, you arm all areas of the system. You want to arm all
areas when leaving with nobody staying inside.
Selecting HOME arms only the system Perimeter. Perimeter arming
is for when you are staying inside but want the comfort of knowing
the exterior doors and windows are armed.
Selecting SLEEP arms the Perimeter and Interior devices but leaves
devices near bedrooms and other nighttime areas off.
System Ready/System Not Ready Keypad Displays
When all system zones are in a normal condition and can be armed
without bypassing, the keypad displays SYSTEM READY. If there
are one or more zones that are not in a normal condition, the
keypad displays SYSTEM NOT READY. Pressing any Select key
during this display shows the bad zone name.
14 XRSuper6 User’s Guide Arming and Disarming
Home/Sleep/Away Shortcut Key Arming
www.BevanSecurity.com
Arm Home — Press 3 for 2 seconds to arm the perimeter.
Arm Sleep — Press 7 for 2 seconds to arm the perimeter and
interior areas and leave the bedroom area off.
Arm Away — Press 1 for 2 seconds.
Arming a Home/Away System
1. Enter your user code. The keypad displays HOME AWAY or
HOME SLEEP AWAY (you may have three areas).
2. Select HOME to arm the Perimeter only.
3. Select SLEEP to arm the Perimeter and Interior.
4. Select AWAY to arm the Perimeter, Interior, and Bedroom.
5. The keypad displays zones that have been bypassed prior to
arming and zones that are in a faulted condition.
6. At this point you can force arm or bypass any faulted zones.
A zone that is force armed is restored into the system if it
later returns to normal. A zone that is bypassed remains
bypassed until the system is disarmed. See steps 6a through
6d.
6a. If a problem exists on any zones, the zone name and
problem display followed by: OKAY BYPASS STOP.
6b. Select OKAY to force arm the zone(s) before arming.
6c. Select BYPASS to bypass the zone(s) before arming.
6d. Select STOP to stop the system from arming. Correct
the zone problem(s) and return to step 1.
7. The keypad displays HOME MODE ON if you selected HOME,
or SLEEP MODE ON if you selected SLEEP, or ALL SYSTEM
ON if you selected AWAY.
Arming and Disarming XRSuper6 User’s Guide 15
8. The keypad next displays EXIT: ## INSTNT and begins to
count down the number of seconds remaining for you to exit.
When the delay expires, all zones are armed.
9. You can select INSTNT while EXIT: ## INSTNT displays to
immediately arm all zones and make them instant. The
keypad displays INSTANT. When you select INSTANT, any
entry/exit zone that trips immediately activates an alarm
and the exit delay countdown immediately stops.
10. When the system is armed, the keypad displays HOME MODE
ON for Perimeter arming, SLEEP MODE ON for Perimeter and
Interior arming, and ALL SYSTEM ON for all areas armed.
Home/Away System Disarming
Disarming: While the system is armed, you can only enter the
premises through an entry/exit delay door without causing an
alarm. After opening the door, the keypad sounds a prewarn tone
to remind you to disarm the system. You must disarm the system
before the prewarn tone expires or an alarm on the door occurs.
During the prewarn tone, the keypad displays ENTER CODE:. Enter
your code to disarm the system.
Note: Your system may be pre-programmed at installation to silence
thetoneassoonastherstusercodedigitkeyispressed.Ifavalid
user code is not entered within 5 seconds or an invalid user code is
entered, the prewarn tone begins sounding again.
Alarm Display:
that tripped or any communication problems that occurred dur ing
the armed period. All burglary zones are then dis armed and any
by passed zones automatically reset.
Disarmed Message: The keypad displays ALL SYSTEM OFF after the
system disarms.
After disarming, the keypad dis plays any zones
Central Sta tion Report: Your system may be pre-programmed at
1 2 3 4
9 0 CMD
5 6 7 8
A
C
B
D
F
E
G
I
H
J
L
K
V
X
W
S
U
T
P
R
Q
M
O
N
Y
Z
Away
All
Home
Monitor
(Chime)
Perimeter
Sleep
Check-in Report
(Latch Key)
Sensor Reset
(Fire Reset)
Easy Exit
www.BevanSecurity.com
installation to send a report of the system disarming to the central
sta tion.
Easy Exit™ Shortcut Key
Home/Sleep/Away Systems — While the system is armed, press 8
for 2 seconds to restart the exit delay time allowing you to exit the
premises without disarming the system. After the exit delay time
expires, the system rearms automatically. This feature allows you
to retrieve the paper, let your pet out, or leave for work without
having to disarm and then rearm the system.
You can also press the Easy Exit, shortcut key 8 again for 2 seconds,
to cancel the exit delay countdown. For example, the telephone
rings before you retrieve the newspaper so you press shortcut key
8 to rearm the system.
Disarming a Home/Away System
1. During entry delay, the keypad displays ENTER CODE:. Enter
your user code.
2. The keypad then displays any alarms or communication
problems that occurred during the armed period.
3. The keypad next displays ALL SYSTEM OFF to conrmthe
system is disarmed.
Disarming During an Alarm
1. While the alarm bell or siren sounds, enter your user code to
silence the alarm.
For a burglary alarm, the keypad displays
This allows you to investigate the alarm prior to disarming
16 XRSuper6 User’s Guide Arming and Disarming
CANCEL VERIFY.
the system. This display remains on the keypad until a
selection is made, the Back Arrow is pressed, or the internal
system bell cutoff timer expires.
2. If a valid alarm has not occurred, Select CANCEL to disarm
the system and cancel the alarm.
The keypad displays ALARM CANCELLED then ALL SYSTEM
OFFtoconrmthesystemisdisarmed.
OR
If the alarm is valid, select VERIFY to send a verify message
to the Central Station.
Keypad Shortcut Keys
Your LCD keypad provides one-button shortcut keys. Holding
down the selected
keypad button for
two seconds until
the tone re-sounds
allows you to
arm, monitor, or
reset your system.
These options can
still be accessed
through the User
Menu if desired.
Keypad Key Arming System Operation
Press Key 1 Arm Away for Home/Sleep/Away systems
Arm All for All/Perimeter systems
Press Key 2 Sensor (Fire) Reset on all systems
Press Key 3 Arm Home for Home/Sleep/Away systems
Press Key 4 Check-in Report on all systems
Press Key 5 Monitor (Chime) on all systems
Press Key 6 Arm Perimeter for All/Perimeter systems
Press Key 7 Arm Sleep for Home/Sleep/Away systems
Press Key 8 Easy Exit for Home/Sleep/Away systems
Keypad Shortcut Keys
Arming Function
www.BevanSecurity.com
System Operation: Home/Sleep/Away, or All/Perimeter.
You can use the Arming shortcut keys, 1, 3, 6, and 7 when the
system is disarmed. You may be prompted to enter your user code.
If any zones are faulted, select force arm or bypass. Refer to the
Arming Section for detailed arming operation.
Home/Sleep/Away Arming
Arm Home — Press 3 for 2 seconds to arm the perimeter.
Arm Sleep — Press 7 for 2 seconds to arm the perimeter and
interior areas and leave the bedroom area off.
Arm Away — Press 1 for 2 seconds.
All/Perimeter Arming
Arm Perimeter — Press 6 for 2 seconds.
Arm All— Press 1 for 2 seconds.
Sensor (Fire) Reset Function
System Operation: Area, Home/Sleep/Away, or All/Perimeter.
You can use the Sensor (Fire) Reset, shortcut key 2, when the
system is armed or disarmed. When pressed, detectors that have
latched due to an alarm condition are now restored and returned
to normal function. The keypad displays SENSORS ON and SENSORS
OFF to acknowledge the shortcut key press.
Note: You are prompted to enter your User Code on Area or All/
Perimeter systems.
Monitor (Chime) Function
System Operation: Area, Home/Sleep/Away, or All/Perimeter.
You can use the Monitor (Chime), shortcut key 5, when the system
is disarmed. When pressed, the Zone Monitor operation is initiated.
As needed, refer to the Zone Monitor section. The keypad displays
MONITOR ON and chimes or displays MONITOR OFF and no tone is
sounded.
Note: The Monitor (Chime) shortcut key applies to all Exit zones
in an Area system and to all zones assigned to the perimeter in a
Home/Sleep/Away or All/Perimeter system.
Check-in Report (Latch Key) Function
System Operation: Area, Home/Sleep/Away, or All/Perimeter.
You can use the Check-in Report (Latch Key), shortcut key 4, to
have a Check-in Report sent to your alpha or numeric pager. This
Shortcut Key does not operate if a pager is not programmed. Refer
to Appendix D for Pager Direct™ information.
Easy Exit™ Function
System Operation: Home/Sleep/Away.
You can use the Easy Exit, shortcut key 8, when the system is
armed, to restart the exit delay allowing you to exit the premises
without disarming the system. For example, to let a pet out or
retrieve the newspaper. After the exit delay time expires, the
system automatically rearms.
You can also press the Easy Exit, shortcut key 8 again, to cancel the
exit delay countdown. For example, the telephone rings before
you retrieve the newspaper so you press shortcut key 8 to rearm
the system.
Arming and Disarming XRSuper6 User’s Guide 17
User Menu
www.BevanSecurity.com
Many of your system features have been put into a User Menu that
you can access from any Security Command™ keypad. The menu
requires you to enter your user code. Only those functions to which
you have access display.
Accessing the User Menu
1. Press the COMMAND key until MENU? NO YES displays.
2. Select YES. The keypad displays ENTER CODE: — . Enter
your user code and press COMMAND. You can now scroll
down through the list of system features available to you.
User Menu Options
The following list shows the User Menu options in order:
Menu Option Description
USER CHECKIN Allows check-in with the system to
indicate arrival on premises.
ZONE ACTIVITY CHECK Allows you to monitor a zone for non-
activity.
SENSOR RESET
OUTPUTS ON/OFF
BYPASS ZONES
Resets smoke or glassbreak detectors
that have latched during an alarm
condition.
Allows you to turn on or off any of the
outputs described in the System Setup
section of this guide.
Allows you to Bypass a zone or reset an
already bypassed zone.
ZONE MONITOR
SYSTEM TEST
USER CODES
DATE AND TIME
DISPLAY EVENTS
SERVICE REQUEST
The following pages detail each User Menu item and provide
instructions on when and how to use them properly
Allows you to add or remove a zone from
the monitor mode.
Tests the system siren, communication
to the central station, and backup
battery.
Allows you to add, delete, or change
user codes and authority levels.
Allows you change the Day, Date, or
Time that is currently in the system.
Allows you to view the last 60 system
events that occurred on your system.
Allows you to send a message to the
Central Station requesting service on
the alarm system.
18 XRSuper6 User’s Guide User Menu
User Check-in
www.BevanSecurity.com
User Code Level: Master or Standard
Function: This feature allows you to monitor the arrival of children
from school or employees to work by having a special Check-in
Report sent to your alpha or numeric pager if programmed.
Appendix D describes the Pager Direct™ option. The last page
of this guide contains a Quick Reference card for your wallet or
purse.
Sending a Check-in Report
1. After disarming the system, access the User Menu.
2. At the USER CHECKIN? display, press any Select key. The
keypad displays USER CHECKIN: 12 (12 = user number).
3. The panel sends the Check-in Report containing your account
number and user number to the pager.
Check-in (Latch Key) Report Shortcut Key
All Systems — Press 4 for 2 seconds, then enter your user code to
send a Check-in Report.
Note: Shortcut Key 4 does not operate if a pager is not
programmed.
Zone Activity Check
User Code Level: Master or Standard
Function: Your security system may be pre-programmed at
installation for the Zone Activity Check feature allowing you to
monitor a person for non-activity.
When no activity is detected for the programmed time period, your
keypad sounds a steady tone for a set period of time and displays
PRESS ANY KEY. Pressing any key on the keypad, before the steady
tone stops, prevents your system from sending a “User Activity Not
Detected” report to the central station. Pressing the key also
restarts the zone activity timer.
This could be used for a person living alone to detect when they
have not tripped a disarmed zone within a programmed period of
time.
Selecting Zone Activity Check
1. At the ACTIVITY CHECK? display, press any Select key. The
keypad displays ENABLE? YES NO. The default is YES.
2. When NO is selected, the keypad displays CHECK DISABLED
for four seconds and then sends the Activity Check Disabled
message to the central station.
3. When YES is selected, the keypad displays CHECK ENABLED
for four seconds and then sends the Activity Check Enabled
message to the central station.
User Menu XRSuper6 User’s Guide 19
Sensor Reset
www.BevanSecurity.com
User Code Level: Master or Standard
Function: Resets smoke or glassbreak detectors. Also clears Fire
and Supervisory zone alarms and trouble keypad displays. Sensor
Reset also clears low battery displays if your system is using
wireless sensors.
Once smoke or glassbreak detectors trip, they must be reset before
they can detect any additional alarm conditions. When Sensor
Reset is selected, power to the detectors is temporarily removed
by the system allowing them to reset.
Make sure all smoke is cleared from around the area of the smoke
detectors before performing a Sensor Reset to prevent the alarm
from occurring again.
Resetting the Sensors
1. Access the User Menu.
2. When SENSOR RESET? displays, press any Select key. The
keypad displays SENSORS OFFforvesecondsfollowedby
SENSORS ON.
3. The keypad returns to the status display.
Sensor (Fire) Reset Shortcut Key
All Systems — Press 2 for 2 seconds, then enter your user code if
required, to reset the system.
Outputs On Off
User Code Level: Master or Standard.
Function: Allows you to turn the system outputs on and off.
This function is used to individually turn your system relay outputs
on and off. Your system may use these outputs to control interior
and exterior lighting, or heating, air conditioning, or other
appliances.
The system output names and numbers are located in the System
Setup section at the back of this guide.
Turning the Outputs On and Off
1. Access the User Menu.
2. Press the COMMAND key until OUTPUTS ON/OFF? displays.
3. Press any Select key.
4. The keypad displays OUTPUT: - ON OFF.
5. Enter the output number you want to turn on or off. The
output number appears in the display.
6. With the output number displayed, Select ON or OFF. The
output is then turned on or off, depending on your selection,
and remains in that state until you change it.
7. The system automatically removes the output number and a
new output number can be entered. Refer back to step 5.
To exit the Output menu option, press the Back Arrow key until you
return to the keypad Status List.
20 XRSuper6 User’s Guide User Menu
Bypass Zones
www.BevanSecurity.com
User Code Level: Master or Standard.
Function: Allows you to bypass a zone prior to arming the system.
Bypassing is usually done when a zone cannot be restored to normal
and you want to arm the system. Once bypassed, the system does
not respond to any activity on the zone.
A zone can be bypassed only while it is disarmed. Since Fire, Panic,
Emergency, and Supervisory zones are always armed, they can
never be bypassed.
The Bypass Zones function can also be used to restore a bypassed
zone back into the system. This can only be done while the zone
is disarmed.
Your system may be pre-programmed at installation to send a bypass
report to your central station when Bypass Zones is selected.
Using the Bypass Zones Function
1. Access the User Menu.
2. Press the COMMAND key until BYPASS ZONES? displays.
3. Press any Select key. The keypad displays ZONE - RST
BYPS.
4. To reset a zone, enter the zone number and Select RST.
5. To Bypass a zone, enter the zone number and Select BYPS.
User Menu XRSuper6 User’s Guide 21
Zone Monitor
User Code Level: Master and Standard.
Function: Allows the system to monitor selected disarmed zones
(doors, windows, or motion detectors). When a monitored zone
trips, the keypad sounds a tone and displays the zone name. This
is an ideal feature for monitoring door zones to tell when someone
comes in or goes out and for system testing.
You can place any combination of disarmed zones in Zone Monitor
but only the most recently tripped zone displays. The displayed
zone name clears automatically after a short time or when the
zone is armed. Zone Monitor does not function while the system
is armed but a zone placed into the Zone Monitor is still monitored
when the system is disarmed.
Using Zone Monitor as part of your weekly system test: After
using the System Test function, place all zones in Zone Monitor.
Starting at the front door, walk around and open and then close
each door and window. You should hear the keypad beep each
time. The keypad also displays the name of each zone as its device
is opened.
Once all protected doors and windows are tested, walk in front of
each motion detector and trip any other protection devices on the
system.Thekeypadshouldbeeptoconrmtheiroperation.Ifat
any time during your weekly testing a device does not cause the
keypad to beep, call the service department for assistance.
Monitor (Chime) Shortcut Key
All Systems — Press 5 for 2 seconds when the system is disarmed.
This initiates the Zone Monitor operation for all Exit zones in an
Area system or all zones assigned to the perimeter in a Home/
Sleep/Away or All/Perimeter system. The keypad displays MONITOR
ON and chimes or displays MONITOR OFF and no tone is sounded.
Using the Zone Monitor Function
www.BevanSecurity.com
1. Access the User Menu.
2. Press the COMMAND key until ZONE MONITOR? displays.
3. Press any Select key.
The keypad displays PERIM ALL NBR.
4. Select PERIM to place all disarmed perimeter zones into
Zone Monitor.
4a. The keypad displays PERIM? ADD RMV.
4b. Select ADD to add all perimeter zones to Zone Monitor.
4c. Select RMV to remove all perimeter zones.
5. Select ALL to place all disarmed zones into Zone Monitor.
5a. The keypad displays ALL? ADD RMV.
5b. Select ADD to add all disarmed zones to Zone Monitor.
5c. Select RMV to remove all disarmed zones.
6. Select NBR to enter a specic zone number for zone
monitor.
7. If NBR is selected, the keypad displays ZONE : - ADD RMV.
7a. Enter any zone number and select ADD to add this
zone.
7b. Enter any zone number and select RMV to remove the
zone.
8. The zone number automatically disappears and a new zone
number can then be entered. See step 7.
System Test
User Code Level: Master or Standard.
Function: System Test is used to test the battery, alarm bell
or siren, and central station communi cation. The System Test
function begins automatically as soon as you select it.
Using the System Test Function
1. Access the User Menu.
2. Press the COMMAND key until SYSTEM TEST? displays.
3. Press any Select key. The system test begins automatically
and the keypad displays:
1) BELL SOUNDING during a two second bell test, then:
2) BATTERY - OKAY or BATTERY - TRBL to indicate the
battery condition, then:
3) TRANSMIT TEST * and ATTEMPT NO : 1 during the
transmit test, then:
4) TRANSMIT OKAY or TRANSMIT FAILED to show the
transmit test results, then:
5) TEST END to indicate the System Test is complete.
6) Press the Back Arrow key to end the system test.
* The transmit test does not occur on local systems.
Testing your system burglary protection: The System Test function
should be part of your weekly testing and should be followed by
placing the burglary devices in Zone Monitor mode. This allows
you to open and then close each protected door and window while
listeningforthekeypadtobeepconrmingitsoperation.SeeZone
Monitor.
22 XRSuper6 User’s Guide User Menu
User Codes
www.BevanSecurity.com
User Code Level: Master only.
Function: Allows you to add or delete a user from the system or
change their user code or authority level.
User code characteristics: There are three characteristics
associatedwitheach user code thatdene itscapabilities within
the system.
Characteristic Example
User Number 12
User Code 3456
Authority Level Master
User Number - Your system supports 16 users. Each user is
numberedfrom1to16.Thisnumberidentiesthemtothesystem
and can be transmitted to the central station (if your system is
monitored) when they arm or disarm the system.
User Code - Users also have a 4-digit user code they enter into the
keypad when arming or disarming. This user code is kept secret
from other users and is not transmitted to the central station when
they arm or disarm.
Note: A User Code cannot begin with zero and cannot be left
blank.
Users enter only their own user code when operating the system.
Authority Level - The user is also assigned a level of authority
(Master or Standard) by the person administrating the system to
determine the functions the user can access.
The table below lists system functions users are allowed to access
based on the authority level assigned to their codes at the time
they are added to the system.
User Menu Option Standard Master
Arm and Disarm Y Y
User Checkin Y Y
Zone Activity Check Y Y
Sensor Reset Y Y
Outputs On/Off Y Y
Bypass Zones Y Y
Zone Monitor Y Y
System Test Y Y
User Codes Y
Set Time Y
Display Events Y Y
Service Request? Y
User Menu XRSuper6 User’s Guide 23
Adding User codes
www.BevanSecurity.com
User Code Level: Master only.
1. Access the User Menu.
2. Press the COMMAND key until USER CODES? displays.
3. Press any Select key. The keypad displays ADD DEL CHG.
4. Select ADD to add a new user code.
5. At the USER NUMBER: — prompt, enter a user number and
press COMMAND.
6. The displays changes to CODE NO:. Enter the four-digit user
code and press COMMAND.
This is the number the user enters each time they arm,
disarm, or make changes to the system.
Note: If the code you entered is already in use, or is a code used
internally by the system, the keypad displays ALREADY IN USE. You
must enter a different 4-digit user code.
7. The display changes to MASTER? NO YES. Select YES to
make this a Master user level with the authority to access all
User Menu functions.
Select NO to make this a Standard user level. The following
options can then be selected:
7a. TEMP CODE NO YES.
Select NO to make this a permanent user code.
Select YES to make this a temporary code. The keypad
displays TEMP DAYS: - . Enter the number of days
(1 to 250) that the temporary use code can operate.
Default is seven days. Temporary users are deleted
from the system at 12:00 AM on the last day. You can
delete a Temporary user code at any time before the
programmed period ends.
24 XRSuper6 User’s Guide User Menu
7b. ARM ONLY NO YES.
Select NO to allow this user to arm and disarm the
system and access all Standard level functions in the
User Menu.
Select YES to restrict this user to arming only.
The Arm Only user code can bypass zones not in a
normal condition at the time of arming.
8. After you complete your selections, the keypad displays
USER # ADDED.
9. Press the Back Arrow key once to add another user or twice
to exit the User Menu.
Changing User codes
www.BevanSecurity.com
User Code Level: Master only.
1. Access the User Menu.
2. Press the COMMAND key until USER CODES? displays.
3. Press any Select key. The keypad displays ADD DEL CHG.
4. Select CHG to change a user code.
5. At the USER NUMBER: — prompt, enter the user number to
change and press COMMAND.
6. The display changes to CODE NO: * * * *. Enter the new
user code.
If the code you entered is already in use, or is a code used
internally by the system, the keypad displays ALREADY IN
USE. You must enter a different 4-digit user code.
7. If you are changing a code other than your own, the keypad
next displays MASTER? NO YES.
Select YES if you want this user to have a Master authority
level.
Select NO if you want this user to have a Standard authority
level. If you select NO, refer to item number 7 in the Adding
User Codes section on the previous page.
Note: Changing a user code does not change the user number. User
number 2 may have their user code changed from 1234 to 5678 but
they are still user number 2.
Deleting User codes
User Code Level: Master only.
1. Access the User Menu.
2. Press the COMMAND key until USER CODES? displays.
3. Press any Select key. The keypad displays ADD DEL CHG.
4. Select DEL to delete a user code from the system.
5. At the USER NUMBER: — prompt, enter the user number you
want to delete and press COMMAND. The display changes to
USER # DELETED.
6. The display then changes back to USER NUMBER: — for you
to delete another user. Press the Back Arrow key twice to
exit the User Menu.
Ambush Code
Your system may be programmed to allow user number 1 to
be an Ambush code. The Ambush code functions identically to
other codes with the exception that it sends a silent alarm to the
central station. This silent alarm alerts the operator to a duress
situation at the premises and prompts immediatenotication of
the authorities.
Refer to the System Setup section of this guide to see if your
system is programmed for Ambush. If your system is programmed
for Ambush and you expect to use the Ambush function, the code
you enter for user number 1 is the Ambush code.
User Menu XRSuper6 User’s Guide 25
Date and Time
www.BevanSecurity.com
User Code Level: Master only.
Function: Allows you to change the current date and time displayed
on the keypad and used by the system for Display Events.
Setting the Date and Time
1. Access the User Menu.
2. Press COMMAND until TIME? displays. Press any Select key.
3. The keypad displays the current day and time. Press
the COMMAND key to display the current date. Press the
COMMAND key again to make any changes.
4. The keypad displays TIME DAY DATE. Select TIME to
change the time. The keypad displays – : AM PM. Enter
the current time and select AM or PM.
5. The display changes back to TIME DAY DATE.
6. Select DAY to change the day of the week. The keypad
displays SUN MON TUE WED. If the current day does not
display, press the COMMAND key. Select the correct day.
7. Select DATE to change the date. The keypad displays:
MONTH: - Enter up to two digits for the month.
Press COMMAND.
DAY: - Enter up to two digits for the day.
Press COMMAND.
YEAR: - Enter up to two digits for the year.
Press COMMAND.
The display returns to TIME DAY DATE. Press the Back Arrow
key to exit the User Menu.
Display Events
User Code Level: Master or Standard.
Function: Allows you to view up to 60 past events that occurred
on your system from any keypad. Any event older than 45 days
automatically clears from the system memory. Once the full 60
events are reached, any new event received clears the oldest event
from the list.
Refer to Appendix A for detailed Display Events information.
Request Service ?
User Code Level: Master only
Function: Allows you to send a Request for Service message to the
central station when there is a problem on your system.
After the Display Events option in the keypad User Menu, the
REQUEST SERVICE? option displays if a master code was used to
enter the menu.
If your system is monitored by a central station and you need to
send a Request for Service report to the central station, press any
Select key while REQUEST SERVICE? displays. After the Request
for Service report is sent, the keypad displays REQUEST MADE for
four seconds.
If there is a problem with the telephone line connected to the
system, you must contact our service department directly for
assistance.
26 XRSuper6 User’s Guide User Menu
System Setup
www.BevanSecurity.com
System Setup Record
This System Setup section is provided to allow you to track
the current status of programmable options on your Security
Command™ system. If you make changes to the system, you should
update the information contained on these pages.
Your system is monitored by a central station.
Yes No
C/S Name:
Address: _________________________________________
City/State: _______________________________________
Emergency Phone: _________________________________
Service Phone: ____________________________________
Service Manager: __________________________________
Your system sends Opening and Closing reports.
Yes No
Your system sends Zone Bypass reports.
Yes No
Your system sends Ambush reports.
Yes No
_______________________________________
Output Record
Your system has outputs that can be used for various functions. The
listbelowidentiestheoutputnumbersanddevicenames.
Output # What it Controls
___________ _______________________________________
___________ _______________________________________
___________ _______________________________________
___________ _______________________________________
___________ _______________________________________
___________ _______________________________________
___________ _______________________________________
___________ _______________________________________
Use the Output number in the User Menu when using the Outputs
On Off option to manually operate the relays.
System Setup XRSuper6 User’s Guide 27
Key Fob Button Programming
www.BevanSecurity.com
Enter the user name assigned to each key fob and the button
action programmed for each button in the table below. Refer to
the Introduction and Appendix B for more information.
Key Fob User Name Button Programmed Action
TOP
BTM
LFT
RGT
TOP
BTM
LFT
RGT
TOP
BTM
LFT
RGT
TOP
BTM
LFT
RGT
TOP
BTM
LFT
RGT
TOP
BTM
LFT
RGT
User Codes
Your system provides 16 user codes you can program for individual
users. As you add new users or change current user codes, you can
keep track of their name, user number, and other information here
in this section. Use a pencil to allow for changes in the table on
the next page.
28 XRSuper6 User’s Guide System Setup
User User Name Level Temp Code Arm Only
www.BevanSecurity.com
1
2 M S Y N Y N
3 M S Y N Y N
4 M S Y N Y N
5 M S Y N Y N
6 M S Y N Y N
7 M S Y N Y N
8 M S Y N Y N
9 M S Y N Y N
10 M S Y N Y N
11 M S Y N Y N
12 M S Y N Y N
13 M S Y N Y N
14 M S Y N Y N
M S Y N Y N
HOW TO FILL IN THIS TABLE
User - The User Number of the person
authorized to use the system.
Level - Master or Standard authority.
Temp Code - Is this code set to expire?
Arm Only - Is this user restricted to just
arming?
Refer to the User Codes section
of this User’s Guide for additional
information.
15 M S Y N Y N
16 M S Y N Y N Circle Your Selections
System Setup XRSuper6 User’s Guide 29
Appendix A
www.BevanSecurity.com
About the Display Events Section
While in the Display Events function, use the COMMAND and Back
Arrow keys to move forward or backward through the list of events.
To view more information about each display, press the Select key
as directed in the explanations below.
Note: This section shows the User’s Guide Display Events items for
both 16-character (single line) and 32-character keypad displays.
Using the Display Events Function
1. Access the User Menu.
2. Press the COMMAND key until DISPLAY EVENTS? displays.
Press any Select key.
3. The keypad displays FIRST LAST.
Select FIRST to view events starting from the oldest to the
newest. If you select FIRST, use the COMMAND key to scroll
up through the events displays.
Select LAST to view events starting from the newest to the
oldest. If you select LAST, use the Back Arrow key to scroll
down through the event displays.
Display Events allows you to view up to 60 past events that
occurred on your system from any keypad. Any event older than 45
days automatically clears from the system memory. Once the full
60 events are reached, any new event received clears the oldest
event from the list.
Zone Activity Check Event Displays
This displays the date and time the Zone Activity Check was
enabled or disabled.
32-Character Display Description
MSG 5:18P 10/17
ACT DISABLED
Activity Check Event Types - There are three event types:
ACT DISABLED ACT ENABLED NO ZONE ACTIVITY
The Zone Activity Check
was disabled at 5:18 PM on
October 17.
Zone Bypass Event Displays
This displays the system zones bypassed.
32-Character Display Description
BYP 5:18P 10/17
EAST WINDOW
Bypass Event Types - There are three event types:
- Bypass RST - Restore FRC - Force Arm
BYP
Note: You may sometimes see the user as SWG. This is short for
Swinger Bypass which is an automatic function that allows the
system to bypass a zone.
The east window zone was
bypassed. Press any Select key
for the zone number and user
number.
30 XRSuper6 User’s Guide Appendix
Zone Event Displays
www.BevanSecurity.com
This section displays alarms, troubles, and other events that could
occur on your protection zones.
32-Character Display Description
ALR 10:23P 10/17
BASEMENT DOOR
Zone Type - There are seven possible zone types you may see
here.
FIRE -
Fire PANC - Panic BURG - Burglary
EMRG
- Emergency SUPV - Supervisory
AUX1 -
Auxiliary 1 AUX2 - Auxiliary 2
Event Types - There are seven event types you may see here:
- Alarm TBL - Trouble RST - Restore
ALR
FLT
- Zone Fault SVC - Service Smoke Detector
LOW
- Low battery MIS - Missing wireless transmitter
Note: LOW and MIS are for wireless systems only.
An alarm occurred on
October 17 at 10:23 PM. Press
any Select key to see the zone
number and zone type.
Arming and Disarming Event Displays
This displays any system areas arming or disarming.
32-Character Display Description
ARM 5:10P 10/17
WAREHOUSE
Arming Event Types - There are two event types you may see
here:
User armed the system DIS - User disarmed the system
ARM -
The warehouse area was armed
at 5:10 PM on October 17.
Press any Select key to display
the area number and user
number.
User Code Change Event Displays
This displays any user code additions, deletions, or changes.
32-Character Display Description
ADD 11:41A 10/17
US:19 BY US:12
User Code Event Types - There are three event types you may see here:
ADD -
User added DEL - User deleted
CHG - User code or authority level was changed.
At 11:41 AM User 12 added user
19.
Appendix XRSuper6 User’s Guide 31
User Check-in Event Displays
www.BevanSecurity.com
This shows when a user selected the pager Check-in feature from
the User Menu. See page 14 for more information.
32-Character Display Description
MSG 3: 31P 10/17
CHECKIN USER: 16
User 16 selected the Check-in
feature at 3:31 PM on
October 17.
Supervisory Event Displays
This displays the automatic test report date and time.
32-Character Display Description
MSG 11:58P 10/17
AUTO RECALL
The test report was sent to the
central station at the date and
time shown.
System Monitor Event Displays
This displays any problems with the system AC power or battery.
32-Character Display Description
TBL 11:41A 10/17
AC POWER
An AC failure occurred on
October 17 at 11:41 AM.
Wireless Jamming Event Displays
This displays wireless interference events that have occurred.
Keypad Display Description
ALR 11:41A 10/17
WIRELESS
Wireless Jamming Event Types - There are three event types:
TBL - Trouble (an interference event occurred when the panel
was disarmed)
ALR - Alarm (an interference event occurred when any area
was armed)
RST - Restore
The DMP wireless receiver
detected interference on October
17 at 11:41 AM.
Wireless Trouble Event Displays
This displays events when the wireless receiver was not
communicating with the panel.
Keypad Display Description
TBL 11:41A 10/17
WIRELESS
Wireless Trouble Event Types - There are two event types:
Trouble RST - Restore
TBL -
A DMP wireless receiver trouble
occurred on October 17 at 11:41
AM.
System Monitor Event Types - There are two event types:
TBL -
Trouble RST - Restore
System Monitor Event Names - There are two system monitors:
AC POWER BATTERY
32 XRSuper6 User’s Guide Appendix
Appendix B
www.BevanSecurity.com
DMP Wireless Description
If your system uses DMP Wireless devices and includes key fob(s),
refer to the following information. The DMP Wireless section
includes a brief discussion of key fob(s) and a drawing identifying
the key fob buttons. Refer to the System Setup section of this guide
to check the button programming list for key fob(s) connected to
your system.
For best operation, allow the LED to turn on and then turn off
before pressing another button. The key fob may not complete
sending the signal for the button press if another button is pressed
too soon.
LED Status Operation
Depending on the programmed action of a key fob button, the
Status LED lights to acknowledge a button press or to indicate the
armed state of the system.
• When the button is programmed for Panic, Panic 2,
Emergency, Emergency 2, Output, or Sensor Reset, a 1/2
second Green light displays to acknowledge the button
press.
• Whenthe button is programmed forArm,Disarm,Toggle
(Arm/Disarm), or Status, the system armed status is
received by the key fob and the LED lights once as shown
in the table below.
LED Color Duration Description
Red 2.0 Seconds All System On
Green 2.0 Seconds All System Off
Green/Red 2.0 Seconds
When a button is pressed that is not programmed, the LED does
not operate.
System On
(Some Areas Armed)
Appendix XRSuper6 User’s Guide 33
Appendix C
ABC SECURITY
MON 10:20 AM
ABC SECURITY
ARM DISARM
www.BevanSecurity.com
Easy Entry™ User’s Guide
This section of the user’s guide provides information on using the Security Command™ system Easy Entry™ access control capability. If
your system is not currently using any access control devices, disregard this section. The keypad displays for All/Perimeter or Home/Away
operation are dependent on how your keypad was programmed by your alarm dealer. Easy Entry™ is built into every Security Command
system and can be accessed using Easy Entry™ keypads.
There are three different operating modes: Door Strike, Arming and Disarming, and Entry Delay. All of the examples below assume that
your system requires a user code to arm and disarm the protection.
DOOR STRIKE
Area and All/Perimeter Door Strike — From the Status List, present your card to the
reader. When the card is validated by the system, the Door Strike relay activates for
5 seconds during which time you can open the door. Once you open the door, you
have 40 seconds to exit and close the door before the Zone 2 Soft-Shunt expires.
Home/Away systems only activate the Door Strike relay when arming and
disarming.
ARMING AND DIS A R M I N G A N A L L / P E R I M E T E R S Y S T E M
Press COMMAND. The keypad displays PERIM ALL (when arming) or DISARM?. Press
the Select key under the desired option. The keypad displays ENTER CODE: -.
Present your card to the reader. Once the system validates the card, if you choose
PERIM, only the perimeter arms. If you choose ALL, both areas arm. If programmed
on a 32-character keypad, ALL is automatically chosen for you after a short delay. All
armed areas disarm automatically.
™
34 XRSuper6 User’s Guide Appendix
ARMING AND DISARMING A HOME/AWAY SYSTEM
ABC SECURITY
ARM DISARM
ABC SECURITY
ENTER CODE: –
www.BevanSecurity.com
Present your card to the reader. If the system is armed, once the system validates the
card, all areas are disarmed and the keypad displays ALL SYSTEM OFF.
If the system is disarmed when you present your card, once the system validates the
card, HOME SLEEP AWAY displays. You can manually press the Select key under the
desired option or after short time all areas automatically arm in the AWAY mode.
ENTRY DELAY
All Systems - Once the protected door is opened and the entry
delay starts, the keypad displays ENTER CODE: - . Present your
card to the reader and, once validated, the system disarms all areas
and activates the Door Strike relay. The top line of 32-character
keypads displays the zone name. See Arming and Disarming above
and on the previous page.
Using the access reader for user menu access
You can also use a card reader to access the User Menu when
MENU? NO YES displays.
Appendix XRSuper6 User’s Guide 35
Appendix D
www.BevanSecurity.com
FA113 User’s Guide
These instructions guide you through the XRSuper6 Command
Processor system operation using the FA113 Wireless Keychain
Remote. The FA113 uses the audible output capability of the
Security Command™ keypad to sound conrmation tones. It is
recommended that you use the FA113 within hearing distance of
these keypads.
Arming a Home/Away or All/Perimeter System
1. Press the ON button once to arm the Perimeter burglary
protection. The Security Command™ keypads emit a single
beepto conrm arming.The Perimeterarms and allnon-
priority zones not in a normal condition are force armed.
2. After the single beep, press the ON button a second time
to arm the Interior burglary protection. The Security
Command™keypadsemittwobeepstoconrmarming.
3. After the two beeps, pressing the ON button in Home/
Sleep/Away systems arms in SLEEP MODE. When armed in
sleep mode the zones assigned to the bedroom area are not
armed. The Security Command™ keypads emit three beeps
toconrmarming.
Disarming a Home/Away or All/Perimeter System
Press the OFF button once. The Security Command™ keypads emit
asingle2-secondbeeptoconrmdisarming.
Using the ALERT Buttons
Pressing the two ALERT buttons simultaneously sends a Panic alarm
to the panel. If your system is monitored by a central station, the
properauthoritiesarenotiedofthealarm.
Pager Direct™ User’s Guide
For your reference a Pager Direct™ pocket guide is provided on the
last page of this User’s Guide.
Pager Direct uses your security system reporting capability to dial
your pager number and send reports in much the same way as
someone sending you a pager message would do. You can receive
reports of alarms, troubles, or system armings and disarmings and
know at a glance your system status.
The PagerDirect™ numeric message provides the account number,
type of message, the zone affected, and the user.
Whenever the system sends a message to your pager, it will always
sendtheaccountnumberrsttoidentifyitself.Aftertheaccount,
you may see:
Typical Zone Event Display Description
20002 001 NORTHWEST DOORS BURG *ALARM* SHIPPING
Account Zone Zone Name Zone Type Event Area Name
Zone Types - BURG, FIRE, SUPV (Supervisory), PANC (Panic), EMRG (Emergency), AUX1, or AUX2
Events - ALARM or TRBL (TROUBLE)
Typical Arming/Disarming Display Description
20002 ARMED 0016 01 EAST WAREHOUSE
Account Event User # Area # Area Name
Events - ARMED or DISARMED
36 XRSuper6 User’s Guide Appendix
User Checkin Display Description
www.BevanSecurity.com
20002 USER CHECKIN REPORT BY 0016
Account Function Performed User #
Functions - USER CHECKIN REPORT (An authorized user has selected Checkin from the User Menu)
Typical System Event Display Description
20002 LATE TO CLOSE
Account Event
Events - LATE TO CLOSE (The system has not been armed at its scheduled closing time)
ALARM CANCELLED (An alarm has been cancelled by an authorized user)
PhoneAccess™ User’s Guide
For your reference a PhoneAccess™ pocket guide is provided on the
last page of this User’s Guide.
This exciting feature allows you to call your XR20 system from any
outside touch-tone phone to arm and disarm protection areas or
turn panel relay outputs on or off. Faulted zones force arm when
the area arms.
How it works
Note: If your telephone system shares the phone line with a fax
machine or answering machine, call and let the phone ring once,
then hang up, and redial. The panel seizes the phone line so you
can check system status and arm or disarm the system.
1. From a touch tone phone, call the system phone number.
The XRSuper6 answers and sounds a short ready tone.
2. You now have eight seconds to enter a valid Master user
code. If the panel accepts the user code, you hear one or
more beeps indicating the system current armed status.
The following table identies the beeps and what they
represent.
If You will hear
All areas are armed 3 short beeps
Area 1 (Perimeter) is armed 1 short beep
Any area is armed 2 short beeps
All areas are disarmed 1 long beep
Note:Youcanalsondoutthesystemarmedstatusbypressing
the * key at any time.
3. If the user code is not accepted by the panel, you hear four
short beeps. Check the user code and try again. After three
unsuccessful attempts to enter the code, the panel locks
out PhoneAccess™ until a valid user code is entered at a
keypad.
4. Once the user code is accepted by the panel and the
armed status is given, you can enter arming and disarming
commands.
Press For this action You will hear
# then 1 Arm all 3 short beeps
# then 2 Arm Perimeter 1 short beep
# then 3 Arm Perimeter/Interior 2 short beeps
# then 0 Disarm all areas 1 long beep
#, 5, 4, 0, n* Toggles the output
Use outputs 1, 2, 3 or 4 in place of n. Enter output descriptions below.
*
1 short beep = on
1 long beep = off
4 short beeps = restricted
Note: Zones
in a faulted
condition
are force
armed
when the
area arms.
1. ________________________ 3. _________________________
2. ________________________ 4. _________________________
Appendix XRSuper6 User’s Guide 37
Common Keypad Displays
www.BevanSecurity.com
Listed below are several keypad messages you may see on the display. Follow the instructions in the Possible Solutions column to
correct the problem. In many cases, you need to call a service person to correct the problem. Displays not discussed here indicate
your service representative should be called.
Message
INVALID CODE No The user code you entered is not recognized by the system. Check the user code and try again.
AC TROUBLE Yes The system is not getting proper power.
BATTERY TROUBLE Ye s The battery is either low or missing. Contact your service person.
SYSTEM TROUBLE or
SERVICE REQUIRED
SYSTEM BUSY No The system is performing another task with a higher priority.
4-WIRE BUS TROUBLE No
TRANSMIT FAIL Yes
NON-POLLED ADDRESS
WIRELESS TROUBLE Yes
Tone at
Keypad
Yes There is a problem with one or more components in the system. Contact your service person.
There is not a supervised device on the bus.
Two devices share the same address.
The panel has attempted to communicate with the central
station ten times and has not succeeded.
770
Keypad
Keypad is set to an invalid address. Contact your service person.
The panel is unable to communicate with the wireless receiver.
The wireless receiver is missing.
Meaning Possible Solutions
Contact your service person if other electrical devices in your home
are working.
Wait a few moments for the system to complete the task.
Contact your service person if the problem remains.
Contact your service person.The voltage is low or there is an open yellow wire.
Make sure your telephone line is working properly.
Contact your service person if the problem remains.
Verify the receiver is properly connected to the panel.
Verify the correct House Code is programmed in System Options.
38 XRSuper6 User’s Guide Appendix
Symbols
www.BevanSecurity.com
2-Button Panic Keys 5
24-Hour Zone 9
7/0 Panic Function 5
A
Alarm Cancel 14, 16
ALARM display 8
Alarm Silence Inside Front Cover, 6, 14, 16
Alarm Verify 14, 16
All/Perimeter System 12
Alarm Silence Inside Front Cover
Arming 12
Disarming 14
Instant Arming 13
Shortcut Keys 13, 17
Ambush Codes 25
Aqualite™ Keypad 3
7/0 Panic Function 5
LEDs 3
Panic Keys 5
Area System
Alarm Silence Inside Front Cover
Armed LED 3
Arming 11
All/Perimeter 12, 34
Home/Away 14, 35
Instant 13
Key Fob 12
Shortcut Keys 13, 15, 17
Arming/Disarming Event Display 31
B
Backlighting 6
Index
Back Arrow (<—) Key 4
Bypassing zones 11, 15, 18, 21
C
Cancel Alarm Inside Front Cover, 14, 16
Central Station Monitoring 10
Changing User Codes 25
Check-in Report to Pager 17, 19
Clear Touch™ Keypad 4
Panic Icons 5
Power/Armed LED 4
COMMAND (CMD) Key 4
Common Keypad Displays 38
D
Data Entry Keys 4
Date and Time 26
Disarming
All/Perimeter 13, 34
During an Alarm 1
Home/Away 16, 35
Key Fob 12
Display Brightness 6
Display Events 26, 30
Arming and Disarming 31
Supervisory 32
System Monitor 32
User Events 32
Wireless Events 32
Zone Events 30, 32
DMP Wireless 33
E
Easy Entry™ User’s Guide 34
Easy Exit™ Shortcut Key 16, 17
4, 16
Emergency Evacuation Plans 2
ENTER CODE display 8
Entry Delay 35
Entry or Exit Zone 9
Event Displays 30
Arming and Disarming 31
Supervisory 32
System Monitor 32
User Check-In 32
User Code Change 31
Wireless Jamming 32
Wireless Trouble 32
Zone Activity check 30
Zone Bypass 30
Zone Events 31
Exit Error 10
F
FA113 User’s Guide 36
False Alarms 1
H
Home/Away System 14
Alarm Silence Inside Front Cover
Arming 15
Disarming 15
Easy Exit™ Shortcut Key 16
Shortcut Keys 15, 17
How Your System Operates 11
I
Instant Arming 11
Instant Zone
9
Index XRSuper6 User’s Guide 39
K
www.BevanSecurity.com
Keypad
2-Button Panic Keys 5
7/0 Panic Function 5
ALARM 8
Aqualite™ 3
Backlighting 6
Back Arrow (<—) Key 4
Clear Touch™ 3, 4
COMMAND (CMD) key 4
Data Entry Keys 4
LEDs 3, 4
Security Command™ 3
Select Areas 4
Select Keys 3
Shortcut Keys 16
SYSTEM TROUBLE 9
Thinline™ 3
Tones 6
Types 3
User Menu 1
User Options 6
Volume 6
Wireless Displays 8
Key Fob 7, 28, 33
Arming 12
Button Layout 7
Button Programming 28
Disarming 12
LED Operation 33
Status Table 33
User Record 28
L
LED Operation 3, 4, 33
40 XRSuper6 User’s Guide Index
N
Numeric Paging 41
O
Outputs On Off 20
P
Pager Direct™ 36, 41
PhoneAccess™ 37, 41
Power LED 3
R
Request Service? 26
Resetting the Sensors 17, 20
S
Security Command™ Keypad 1, 3
7/0 Panic Function 5
Displays 8
LEDs 3
Panic Keys 5
Tones 6
Security System Terms 9
Select Areas 4
Select Keys 3
Sensor Reset 20
Setting the Date and Time 26
Shortcut Keys 13, 15, 16, 19, 20, 21
Arming Function 13, 15, 17
Check-in (Latch Key) Report
Function 17, 19
Easy Exit™ Function 16, 17
Monitor (Chime) Function 17, 21
Sensor (Fire) Reset Function 17, 20
Silencing an Alarm Inside Front Cover, 7
Status List 10
Supervisory Event Display 32
System Monitor Even Display 32
System Ready/System Not Ready 13, 14
System Setup Record 27
System Test 22
T
Test Your System Weekly 1
Thinline™ Keypad 3
7/0 Panic Function 5
LEDs 3
Panic Keys 5
TROUBLE display 9
Trouble Tone Response Inside Front Cover, 7
U
User Check-In Event Display 32
User Codes 23
Ambush Codes 25
Authority Levels 23
Change Event Display 31
Changing 25
Deleting 25
Table 29
User Menu Options 18, 23
V
Verify Alarm Inside Front Cover, 14, 16
W
Wireless 7, 33
Event Displays 32
Z
Zone 9
Zone Activity Check 19
Zone Event Display 31
Quick Reference Wallet Cards
www.BevanSecurity.com
PhoneAccess™ Quick Commands
Press For this action You will hear
# then 1 Arm all 3 short beeps
# then 2 Arm Perimeter 1 short beep
# then 3 Arm Perimeter/Interior 2 short beeps
# then 0 Disarm all areas 1 long beep
#, 5, 4, 0, n* Toggles the output
Use outputs 1, 2, 3, or 4 in place of n. Enter output descriptions below.
*
1 short beep = on
1 long beep = off
4 short beeps = restricted
1. ________________________ 3. _________________________
2. ________________________ 4. _________________________
PhoneAccess™ Quick Commands
Press For this action You will hear
# then 1 Arm all 3 short beeps
# then 2 Arm Perimeter 1 short beep
# then 3 Arm Perimeter/Interior 2 short beeps
# then 0 Disarm all areas 1 long beep
#, 5, 4, 0, n* Toggles the output
Use outputs 1, 2, 3, or 4 in place of n. Enter output descriptions below.
*
1. ________________________ 3. _________________________
2. ________________________ 4. _________________________
1 short beep = on
1 long beep = off
4 short beeps = restricted
Note: Zones
in a faulted
condition
are force
armed
when the
area arms.
Note: Zones
in a faulted
condition
are force
armed
when the
area arms.
Area Names
Your system areas are listed below:
Area and Name Notes
1. PERIMETER (HOME) ________________________
2. INTERIOR (AWAY) __________________________
3. BEDROOMS (SLEEP) ________________________
Service Department Phone:____________________
Emergency Phone:
Central Station Phone: ________________________
___________________________
Pager Direct™
Security Command™
Numeric Paging
Cut along dotted lines.
Numeric Pager Display
00128-3012340010
Account
Number
Message IDAlways
Zero
Area
Number
Always
Zero
User
Number
www.BevanSecurity.com
Account Number
This number is programmed into your Security Command™
system as an identier. Whenever the system sends a
message to your pager, it always sends the account number
rsttoidentifyitself.
Message ID
This is always a single digit that describes the message.
= Zone Alarm 6 = User Check-in
1
2
= Zone Trouble 7 = Local Message
3 = Area(s) Arming
4 = Area(s) Disarming
Zone or Area Number
If this message is for a zone, the 1 to 2-digit zone number
displays.
If this message is for areas being armed or disarmed, the
area numbers display in sequential order. Example: 1 2.
User Number
Thisisa3-digitnumberthatidentiestheuser.
1. Call the panel phone number. The panel answers and sounds one
short tone.
2. Enter your code within eight seconds. One beep means the code
is good. Four short beeps means enter it again. You have three
tries.
3. Youhave30secondstoentertherstcommand(seeotherside)and
30 seconds for each additional command.
If You will hear
All areas are armed 3 short beeps
Area 1 (Perimeter) is armed 1 short beep
Any area is armed 2 short beeps
All areas are disarmed 1 long beep
1. Call the panel phone number. The panel answers and sounds one
short tone.
2. Enter your code within eight seconds. One beep means the code
is good. Four short beeps means enter it again. You have three
tries.
3. You have30secondstoentertherstcommand(seeotherside)and
30 seconds for each additional command.
If You will hear
All areas are armed 3 short beeps
Area 1 (Perimeter) is armed 1 short beep
Any area is armed 2 short beeps
All areas are disarmed 1 long beep
Cut along dotted lines.
www.BevanSecurity.com
.This page intentionally left blank.
www.BevanSecurity.com
LT-0622 1.01
8341
Loading...
