User Manual
USER’S MANUAL
D6000 Series
DVR
Digital Video Recorder
0
User Manual
Contents
Chapter 1: DVR Features ........................................................................................................................................ 3
DVR Feature ...................................................................................................................................................... 3
Chapter 2: Overview ................................................................................................................................................ 3
2.1 Front Panel ................................................................................................................................................... 3
2.2 Rear Panel .................................................................................................................................................... 1
2.3 Remote Control(just for reference) .............................................................................................................. 1
Chapter 3: Installation ............................................................................................................................................. 2
3.1 Install Hard Disk .......................................................................................................................................... 2
3.2 Connecting Camera and Monitor ................................................................................................................. 2
3.3 VGA Output (optional) ................................................................................................................................. 2
3.4 Connecting Power Supply ............................................................................................................................ 2
Chapter 4: Starting the DVR ................................................................................................................................... 2
4.1 Firmware Version ......................................................................................................................................... 2
4.2 Detecting Installed Hard Drive ..................................................................................................................... 3
4.3 Format Hard Drive ....................................................................................................................................... 3
Chapter 5: DVR Menu System ................................................................................................................................ 3
5.1 Navigating the Menus .................................................................................................................................. 3
5.2 Menu Overview ............................................................................................................................................ 3
5.3 Camera Setup ............................................................................................................................................... 4
5.4 Record Setup ................................................................................................................................................ 4
5.5 Record Frame Rate ....................................................................................................................................... 5
5.6 Video Quality ............................................................................................................................................... 5
5.7 Record Schedule ........................................................................................................................................... 5
5.8 Sensor Setup ................................................................................................................................................. 6
5.9 H/W Sensor Setup ........................................................................................................................................ 6
5.10 Motion Detector Setup ............................................................................................................................... 7
5.11 Hard Drive Setup ........................................................................................................................................ 7
5.12 Miscellaneous Setup - Change Password ................................................................................................... 8
5.13 Miscellaneous Setup - Set Time ................................................................................................................. 8
5.14 Miscellaneous Setup - Hidden Channel ..................................................................................................... 9
5.15 Miscellaneous Setup - Audio Port Setup .................................................................................................... 9
5.16 Miscellaneous Setup - PTZ Setup .............................................................................................................. 9
5.17 Miscellaneous Setup - Image Parameters ................................................................................................. 10
5.18 Miscellaneous Setup - Password Enable .................................................................................................. 10
5.19 Miscellaneous Setup - Keypad Tones .......................................................................................
5.20 Miscellaneous Setup - VGA Setup ........................................................................................................... 11
5.21 Network Setup .......................................................................................................................................... 11
5.22 Language .................................................................................................................................................. 15
5.23 Video Backup (For Optional USB Memory Stick Backup) ..................................................................... 15
5.24 Reset Menu ............................................................................................................................................... 17
5.25 NTSC/PAL Output select ......................................................................................................................... 17
Chapter 6: Record .................................................................................................................................................. 17
6.1 Start Recording ........................................................................................................................................... 17
6.2 Audio Recording ........................................................................................................................................ 18
................ 11
1
1
1
1-1
1-1
1-2
1
User Manual
6.3 Stop Recording ........................................................................................................................................... 18
6.4 Estimated Recording Length ...................................................................................................................... 18
Chapter 7: Playback ............................................................................................................................................... 19
7.1 Playback Control ........................................................................................................................................ 19
Chapter 8: USB Progamming (optional) .......................................................................................... .................... 19
8.1Driver Installation: ...................................................................................................................................... 19
8.2 Program Interface ....................................................................................................................................... 20
8.3 Program Running ....................................................................................................................................... 20
Chapter 9: Specification ........................................................................................................................................ 24
Chapter 10: Appendix ............................................................................................................................................ 25
10.1 System connection diagram ...................................................................................................................... 25
10.2Accessories ................................................................................................................................................ 25
2
User Manual
DVR Feature
z MPEG4 compression
z 4-Channel: 4 BNC Camera Inputs - 2 BNC Video Outputs
9-Channel: 9 BNC Camera Inputs - 1 BNC Video Output
z 4-Channel: 2 Audio Inputs - 2 Audio Outputs
9-Channel: 1 Audio Input -1 Audio Output
z System Format : NTSC /PAL
z Motion Detection with Sensitivity and Area Settings
z Time Schedule, Alarm and Motion Triggered Recording Modes
z Hard Disk Support up to 500GB
z Supports PTZ Control via RS485 Port
z View and Operate over Network (Broadband Connection Required)
Chapter 1: DVR Features
z Built-in USB2.0 Port for Backup to Computer or
USB Memory stick Backup (Optional)
z VGA Output (Optional)
Chapter 2: Overview
2.1 Front Panel
2.1.1 4-ch DVR front panel(just for reference)
1. Power switch
2. Power LED
3. IR receiver
4. HDD LED
5. CH 1
6. CH2
7. CH3
8.CH 4
9.QUAD:view all channels
10.REW:rewind
11.PAUSE
12.PLAY
13.FWD:forward
14.STOP
15.REC:record
16.MENU/ESC/LEFT
3
1
User Manual
17.UP
18.SEL/EDIT/RIGHT
2.1.2 9-channel DVR front panel(just for reference)
19.DOWN
20.PTZ: enter PTZ mode
1.Power switch
2.Power LED
3.IR receiver
4.HDD LED
5.Search
6.MUTE: turn on/off audio output
7.CH-: view previous channel
8.CH+: view next channel
9.ALL: view all channels
10.REW: rewind
11.PAUSE
12.PLAY
13.FWD: forward
14.STOP
15.REC: record
16.MENU/ESC/LEFT
17.UP
18.SEL/EDIT/RIGHT
19.DOWN
20.PTZ:enter PTZ mode
2.2 Rear Panel
2.2.1 4-channel DVR real panel( just for reference)
1.FAN
2.Audio outputs
3.Audion inputs
4.Video outputs
5.CH2:video input
6.CH1:video input
7.VGA output (Optional)
8.USB port
9. LAN: Ethernet port
10.CH4:video input
11.CH3:video input
12.RS485/Sensor/Alarm
13.DC Power Input Jack
1
1-1
User Manual
2.2.2 9-channels DVR rear panel(just for reference)
1.FAN
2. Audio input
3. Video output
4.CH4: video input
5. CH3: video input
6. CH2: video input
7.CH1: video input
8. VGA output (Optional)
9. USB port
2.3 Remote Control(just for reference)
1-9 Channel Select 1-9
0 Number
ALL Display all Channels
Menu Enter or Exit Menu
▲
▼
SEL Select /Modify Item
●
■
Audio Search or switch the audio channels
Mute Turn on/off audio output
Move Up/Left
Move Down/Right
Rewind
Play Recording
Fast Forward
Record
Pause
Stop Recording/Playback
10. LAN: ethernet port
11. Audio output
12. CH9: video input
13. CH8: video input
14. CH7: video input
15. CH6: video input
16. CH5: video input
17. RS485/Sensor/Alarm
18. DC Power input jack
1-2
1
User Manual
Chapter 3: Installation
3.1 Install Hard Disk
NOTICE: Don’t take out HDD when DVR is running.
Make sure the HDD is set to be MASTER according to the hard drive manual.
(1) Remove the screws around the top cover;
(2) Remove the top cover carefully;
(3) Connect the power cord and data cable to hard disk carefully;
(4) Use the provided screws to fix hard disk on the rack inside and then replace the top cover of the case.
3.2 Connecting Camera and Monitor
There are 4/9 camera inputs and 2/1 Monitor outputs with BNC connectors (Refer to 2.2 Rear Panel).
3.3 VGA Output (optional)
There is 1 CRT or LCD monitor output with VGA port.
3.4 Connecting Power Supply
Please only use the power adapter supplied with the DVR.
Chapter 4: Starting the DVR
4.1 Firmware Version
V1.9
V-EN-BG
2008.2.23
After connecting the power adapter
and turning on the power button, the system
will boot-up and display the version and
released date of the DVR firmware.
2
User Manual
4.2 Detecting Installed Hard Drive
CHECKING HDD……
MASTER [WDC WD3200AAJB-00T]
SLAVE……
4.3 Format Hard Drive
DVR will detect the installed hard drive and
display the hard drive information.
CHECKING HDD……
MASTER [WDC WD3200AAJB-00T]-NEW-DVR
FORMAT HDD CONFIRM
(SELECT) FORMAT / (MENU) CANCEL?
Chapter 5: DVR Menu System
5.1 Navigating the Menus
CAMERA SETUP
RECORD SETUP
RECORD FRAMERATE
VIDEO QUALITY NORMAL
RECORD SCHEDULE
SENSOR SETUP
HARD DRIVE SETUP
MISCELOLANEOUS SETUP
NETWORK SETUP
LANGUAGE E NGL ISH
VIDEO BACKUP
RESET MENU
( )MOVE (SEL)SELECT (MENU)EXIT
MAIN MENU
When the DVR detects a new hard drive,
you will be prompted to format the hard drive
before using the DVR.
Press [SEL] to format or press [MENU]
to cancel.
When the DVR detects a new hard drive,
you will be prompted to format the hard drive
[MENU]: enters Main Menu
before using the DVR.
[▲, ▼, ◄ and ►]: move the cursor
Press [SEL] to format or press [MENU] to
[SEL]: select/modify settings
cancel.
[MENU]: press again to exit or go
Note: if DVR supports USB memory stick,
back to previous menu.
“VIDEO BACKUP” item is available.
Otherwise, there’s no this item in main menu
5.2 Menu Overview
3
User Manual
Menu Directory
Camera Setup
Record Setup
Record Frame rate
Video Quality
Change Password
Record Schedule
Sensor Setup
Main Menu
Hard Drive Setup
Set Time
Hidden Channel
Audio Port Setup
Miscellaneous Setup
Network Setup
Language
Video Backup
Reset Menu
5.3 Camera Setup
1 ON 2 ON
CAMERA SETUP
3 ON 4 ON
( )MOVE (SEL) SELECT (MENU)EXIT
PTZ Setup
Image Parameters
Password Enable
Keypad Tones
VGA Setup
Camera Setup allows you to turn
cameras on or off.
Press [▲, ▼, ◄ and ►] buttons to
select a channel and then press [SEL] to
modify the setting ON or OFF.
Note：If a camera channel is set to OFF ,it will not be recorded(Refer to 6.4
Record Setup)
5.4 Record Setup
1 ON 2 NOCAM
RECORD SETUP
3 ON 4 ON
( )MOVE (SEL) SELECT (MENU)EXIT
Record Setup allows you to set up
recording channels.
Press [▲, ▼, ◄ and ►] buttons to select
a channel, and then press [SEL] to modify the
setting to ON or OFF.
If a channel is disabled in Camera Setup, it
will not record and the DVR will display
“NOCAM” on screen.
4
User Manual
5.5 Record Frame Rate
1 3FPS 2 5FPS
RECORD FRAMERATE
TOTAL 36FPS
3 25FPS 4 3FPS
( )MOVE (SEL) + ( ■ )- (MENU)EXIT
The total frame rate is 50fps (PAL) or
60fps (NTSC). You can set the frame rate
for the channel which you selecte to
record. If the sum of the frame rate you
select for all cameras is more than 50fps
(PAL)/60fps(NTSC), the DVR will
automatically adjust the largest frame rate
value to a smaller value.
Press [▲, ▼, ◄ or ►] button to select a channel, and then press [SEL] to
increase the value or press [
■STOP] to reduce the value.
Note: Higher frame rate shows smooth images, but requires more hard drive
space.
5.6 Video Quality
CAMERA SETUP
RECORD SETUP
RECORD FRAMERATE
VIDEO QUALITY NORMAL
RECORD SCHEDULE
SENSOR SETUP
HARD DRIVE SETUP
MISCELOLANEOUS SETUP
NETWORK SETUP
LANGUAGE ENGLISH
VIDEO BACKUP
RESET MENU
( )MOVE (SEL)SELECT (MENU)EXIT
MAIN MENU
Video Quality has 4 different settings:
Highest, High, Normal and Low.
The higher the video quality, the
better quality of Images, however higher
quality images require more hard drive
space.
[SEL] to change the quality
Press
setting.
5.7 Record Schedule
Setting the Record Schedule allows you to customize the type of recording
depending on the time of day.
( )MOVE (SEL)SELECT (MENU)EXIT
RDCORD SCHEDULE
AM PM
0… 3… 6… 9… 0… 3…. 6… 9…
NO-RECORD
NORMAL-RECORD
S
SENSOR-RECORD
The time line indicates 24 hours of a
day based on AM/PM (0 = 12).
Press [▲, ▼, ◄ or ►] button to
select a time point, press [SEL] to modify
the recording mode.
5
User Manual
NO-RECORD [ white]: DVR will not record during the time.
NORMAL-RECORD [ red]: DVR will record continuously.
SENSOR-RECORD [S]: DVR will record when sensor or motion is triggered.
NOTE: In order to activate the record schedule, press the [] record button when
viewing the cameras. After pressing the [] record button, if schedule is set to
“NORMAL-RECORD” , the DVR will start to record immediately; if the schedule is
set to be “SENSOR-RECORD” , the DVR will not start recording until a motion is
detected by the DVR or an installed sensor is triggered.
5.8 Sensor Setup
SENSORED SETUP
SENSORED RECORD TIME 30
ALARM ON TIME OFF
H/W SENSOR SETUP
MOTION DETECTOR SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
CONT: Continuous alarm until any key is pressed..
OFF: No alarm
Note: Sensored Record Time and Alarm On Time are measured in seconds
Sensor Record Time indicates how
long the recording time is when the
motion or sensor is triggered.
Alarm On Time indicates whether the
buzzer will sound when motion is
detected.
5.9 H/W Sensor Setup
Note: Sensors and extension alarm are not included with the DVR system and
may be purchased separately.
Note: For 4-ch DVR, there are 4CH inputs of the sensor;
For 9-ch DVR, there are 8CH inputs of the sensor.
H/W SENSOR SETUP
CHANNEL-1 TYPE:NORMAL-OPEN
CHANNEL-2 NOT INSTALLED
CHANNEL-3 NOT INSTALLED
CHANNEL-4 NOT INSTALLED
( )MOVE (SEL)SELECT (MENU)EXIT
HARDWARE SENSOR SETUP:
There are 3 different modes for sensor setting:
NOT INSTALLED, NORMAL-CLOSE and
NORMAL-OPEN. Consult the alarm
purchased for more details on which setting is
required.
6
User Manual
5.10 Motion Detector Setup
This section allows you to set up motion detection options for each camera.
MOTION DETECTOR SETUP
CH1 ON LEVEL1 AREA
CH2 ON LEVEL2 AREA
CH3 ON LEVEL2 AREA
CH4 ON LEVEL2 AREA
( )MOVE (SEL)SELECT (MENU)EXIT
MOTION DETECTOR SETUP:
ON/OFF: Enable or disable motion detection
recording.
LEVEL: Sensitivity for motion detection.
There are 3 levels sensitivity:
Level 1-low,
3- highest
AREA: Select detectable area on the screen.
Area Selection:
Press [▲, ▼, ◄ or ►] button to
select a block, and press [SEL] button to set
the block to detect motion. The area is
detectable when it is clear, the area is not
detectable when it is covert by shadow.
Press “stop” button to disable all areas, press “All” button to enable all areas
5.11 Hard Drive Setup
This section will display the current hard drive status and usage options
( )MOVE (SEL)SELECT (MENU)EXIT
HARD DRIVE SETUP
OVERWRITE ENABLED [ ON ]
ST3160215A
MASTER HDD SIZE 160133MB
MASTER HDD USED 124931MB 78%
MASTER HDD FORMAT
SLAVE HDD SIZE N/A
SLAVE HDD USED N/A
SLAVE HDD FORMAT
HDD SIZE: indicates the total capacity of the hard drive installed in the DVR.
HDD USED: indicates the space used in the hard disk drive for recording and the
percent used.
OVERWRITE ENABLED:
ON: overwrite oldest video when hard drive
is full.
OFF: stop recording when hard drive is full.
7
User Manual
HDD FORMAT: will erase all video and data on the installed hard drive and make it
readable by the DVR
Note: You will be prompted for the password when formatting a hard drive. The
default password is “111111”
5.12 Miscellaneous Setup - Change Password
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 4 ]
[ CH4 ]
[ OFF ]
[ ON ]
[800*600 60HZ]
CURRENT PASSWORD
NEW PASSWORD
CONFIRM PASSWORD
[- - - - -]
[- - - - -]
[- - - - -]
This option allows you to change the
system password. The password must be
composed with six characters.
All keys can be used as password key
except the [MENU] key, which is used to
exit.
Enter the current password first, and
then enter six characters as your new
password, repeat the new password to
confirm.
If you forget your password, please
contact technical support for assistance.
5.13 Miscellaneous Setup - Set Time
( )MOVE (SEL)SELECT (MENU)EXIT
SET TIME
2008/11/11 17:50:01
The system date and time format is
YYYY/MM/DD and HH:MM: SS.
Press [◄] or [►] button to select the data
to modify, press [SEL] to modify. Press
[MENU] to save and return to previous
menu.
8
User Manual
:
ssign a
your speed dome
.
5.14 Miscellaneous Setup - Hidden Channel
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 4 ]
[ CH4 ]
[ OFF ]
[ ON ]
800*600 60HZ
The system provides a function to hide a
channel in monitoring mode. The selected
channel can still be recorded while it’s hidden;
the hidden picture is viewable during playing
back.
Press [SEL] to select a channel to hide.
5.15 Miscellaneous Setup - Audio Port Setup
AUDIO PORT1-VIDEIO CHANNEL
AUDIO PORT1-RECORD
AUDIO PORT2-VIDEO CHANNEL
AUDIO PORT2-RECORD
( )MOVE (SEL)SELECT (MENU)EXIT
AUDIO PORT SETUP
[ 1 ]
[ OFF ]
[ 2 ]
[ ON ]
You can select the audio recording
function to ON or OFF, and select the
video channel that you like to record the
audio on.
Note: For 4-ch DVR, there are 2 audio inputs;
For 9-ch DVR, there are only 1 audio input.
5.16 Miscellaneous Setup - PTZ Setup
SPEED [4800]
PROTOCOL [PELCO-D]
CAMERA- [ 1 ] ID [ 1 ]
( )MOVE ( )CAM ID
(SEL)SELECT (MENU)EXIT
PTZ SETUP
Press [SEL] to select the camera, press[
SPEED: Set the baud rate (4800，9600，
19200，38400) match to your speed dome.
PROTOCOL: Supports “PELCO-D” and
“PELCO-P”. Select the protocol
according to your speed dome’s protocol.
CAMERA: select the camera channel
which is connected with the speed dome.
A
ID
] and [ ] buttons to assign the ID.
n ID to
Note: the ID must be unique．
9
User Manual
5.17 Miscellaneous Setup - Image Parameters
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 1 ]
[ CH4 ]
[ OFF ]
[ ON ]
[800*600 60HZ]
You can adjust the image parameters
according to your needs.
Move the cursor to this selection and
press [◄] or [►] button to select a channel
you want to adjust, then press [SEL] button
to edit parameters.
CON: Contrast
BRI: Brightness
HUE: Hue
SAT: Saturation
Press [▲] or [▼] to select the item，
and then press [
adjust the value.
5.18 Miscellaneous Setup - Password Enable
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 1 ]
[ CH4 ]
[ OFF ]
[ ON ]
800*600 60HZ
The password will be required to
control the DVR when this option is set to
“ON”, and the password is not required
when this option is set to “OFF”.
] and [ ] buttons to
10
User Manual
5.19 Miscellaneous Setup - Keypad Tones
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 4 ]
[ CH4 ]
[ OFF ]
[ ON ]
800*600 60HZ
This function allows you to enable
/disable buzzer sound when pressing a
button. Press [SEL] to select ON or
OFF.
5.20 Miscellaneous Setup - VGA Setup
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 4 ]
[ CH4 ]
[ OFF ]
[ ON ]
800*600 60HZ
Select a VGA resolution to match your
CRT or LCD monitor.
NOTE: VGA video output is an
optional function and may not be
available on all models.
5.21 Network Setup
Network Setup allows you to prepare the DVR for viewing over the internet or
local network.
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
IMPORTANT: This setting should only be changed if multiple DVRs are being setup on the same
MAC ADDRESS: In a local area network(LAN)，
the MAC (Media Access Control) address is
your computer’s unique hardware identity
code(On an Ethernet LAN，it is the same as
your Ethernet address).When you are connected
to the Internet from your computer (or host as
the Internet protocol thinks of it ) ， a
corresponding table relates your IP address to
your computer’s physical (MAC) address on the
LAN.
11
User Manual
network and the first code “00” must not to be changed.
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[DHCP]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
IP ALLOCATION: DVR supports DHCP and
Static IP modes. If your modem/router supports
DHCP function, you can use DHCP mode. When
using STATIC mode, you will be required to setup
your IP settings manually.
Note: After setting the DVR to DHCP mode restart
the unit.
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
IP Address: In a local network, the IP
address is a unique designated address for your
DVR recognized by your router. Ensure this
number is within the range usable by your
modem/router. Use the UP “▲” and DOWN
“▼” buttons to move the cursor and use the
“SELECT” button to change the numbers. Once
you have finished the changes restart your DVR.
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
SUBNET MASK: Subnet Mask is used to
determine what subnet an IP address belongs to.
A number that is used to identify a sub network
so that IP addresses can be recognized on a local
area network. Consult your modem/router for
your LAN’s subnet mask.
12
User Manual
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
GATEWAY: Set this number to the gateway
set by your modem/router.
NOTE: To adjust the IP ADDRESS，SUBNET MASK and GATEWAY value, only when the
[STATIC] mode is being selected.
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
MAC ADDRESS
IP ALLOCA TION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
( )MOVE (SEL)SELECT (MENU)EXIT
USER SETUP
ADMIN ID …… [admin]
ADMIN PASSWORD [admin]
USER ID
USER PASSWORD
[ ]
[ ]
DNS ADDRESS: This code should be provided
by your local ISP.
HTTP PORT: This port number is used to
communicate with PC Client. The default value is
80(Can be changed from 1024 to 49151)
USER SETUP: When accessing the DVR
from a remote location you will be prompted
for a login and password. The default is
“admin” for full administrator rights. Set “User
ID” and password to setup a user with limited
rights to prevent tampering.
13
User Manual
DDNS PROVIDER
DDNS USER NAME
DONS PASSWORD
( )MOVE (SEL)SELECT (MENU)EXIT
DDNS SETUP
[WWW.DynDNS.com ]
[ ]
[ ]
DDNS SETUP：If you require an external
service to maintain a dynamic IP address enter
the user information here.
LAN-DVR Connection
See the diagram below for steps to connect your DVR to a local area network or the internet.
For remote monitoring from your computer，you must have a LAN connection available or
broadband Internet access.
You need to register a www.dyndns.org to get a free account .After registration，you will have a
username and password. You can also register your domain name on the website. Please refer to
Chapter 5 “Network Setup” for more details. There you will learn how to input the Dyndns
username，password，and domain name. You can log in from anywhere by using Internet Explorer
and entering your DVR’s domain name.
z
14
User Manual
5.22 Language
MAIN MENU
CAMERA SETUP
RECORD SETUP
RECORD FRAMERATE
VIDEO QUALITY NORMAL
RECORD SCHEDULE
SENSOR SETUP
HARD DRIVE SETUP
MISCELOLANEOUS SETUP
NETWORK SETUP
LANGUAGE E NGL ISH
VIDEO BACKUP
RESET MENU
( )MOVE (SEL)SELECT (MENU)EXIT
the default English to other languages, if
your DVR supports multi-languages.
5.23 Video Backup (For Optional USB Memory Stick Backup)
This function is only available for the model which supports USB memory stick
device. If your DVR is with PC-link USB interface, please refer Charter 8 for video
backup.
You can change the OSD language from
EVENT LIST
00003 T 2008/08/22 19:42:25
00002 T 2008/08/22 17:30:19
00001 T 2008/08/22 16:20:22
00000 T 2008/08/21 17:12:43
VIDEO BACKUP
VIEW EVENTS
START: 2008/08/22 16:20:22
END: 2008/08/22 16:48:28
SIZE: [197] MB
FILE NAME: [VID000.MCG]
BACKUP TO CD/DVD
BACKUP TO USB DEVICE
( )MOVE (SEL)SELECT (MENU)EXIT
Move the cursor to “VIEW EVENTS”,
press [SEL] to enter event list. Press [▲]
or [▼] button to move the cursor, and
then press [SEL] to select the event you
like to backup and return to previous
menu.
The DVR system already indicated the
start & end time of the recording event.
Move the cursor to “SIZE”, DVR will
automatically indicate the size of the
video you like to backup to USB memory
stick.
15
User Manual
BACKUP STARTING TIME
2008/08/22 16:20:22
( )MOVE (SEL)SELECT (MENU)EXIT
BACKUP FILE NAME
VIDOOO.MCG
0
1
2
3
4
5
6
( ) CHANGE ( )MOVE ( SEL )SELECT
( CH )NUMBER ( )DELETE ( ) INSERT
7
(MENU)EXIT
VIDEO BACKUP
VIEW EVENTS
START: 2008/08/22 16:20:22
END: 2008/08/22 16:48:28
SIZE: [197] MB
FILE NAME: [VID000.MCG]
BACKUP TO CD/DVD
BACKUP TO USB DEVICE
( )MOVE (SEL)SELECT (MENU)EXIT
You can directly select the start& end
time of a recording video to backup.
Move the cursor to “START” or “END”;
press [SEL] to enter the interface. Press
[◄] or [►] button to move the cursor, and
then press [SEL] to modify the value.
Press [MENU] back to previous menu.
You can rename the backup file. Press
[◄] or [►] button to select the character
you want to modify, press [▲] or [▼]
button to select a character from the
given character list, and then press
[SEL] to enter.
Please note that the name must be ended
with
“.MCG”.
Insert your USB memory stick
device into DVR’s USB port.
Move the cursor to “BACKUP TO
USB DEVICE”, press [SEL] button.
BACKUP TO USB DEVICE
Check USB devives
(MENU)EXIT
DVR will check your USB device as left
picture showed and then start to copy the
backup file.
16
User Manual
Please read Charter 8 on how to play back your backup file.
5.24 Reset Menu
If you select this item, the system will restore all your settings to factory default
values. You need to enter your password to reset the menu.
5.25 NTSC/PAL Output select
Change the jumper JS1 to select NTSC
or PAL video output format according to the
silkscreen on the PCB.
Chapter 6: Record
6.1 Start Recording
Press [●] record button to start recording according to the record schedule you
have set. System will display some information on screen.
17
User Manual
[●]: the red pot next to the channel name indicates that the channel is being
recorded.
[A-REC]: indicates the current record schedule is set to NORMAL-RECORD mode.
[S-REC]: indicates the current record schedule is set to SENSOR-RECORD mode.
[N-REC]: indicates the current record schedule is set to NO-RECORD mode.
[39%]: indicates the percentage of hard disk space used.
[M]: HDD info ([M] Master Hard Disk)
6.2 Audio Recording
[ ]: indicates this video channel is bundled with an audio port, and the audio
output is on.
]: indicates the audio output is off.
[
]: indicates the audio is being recorded and the audio output is on.
[
For 9-channel, you could press [MUTE] button on front panel to be mute mode
for audio output. The audio input can be still recorded while the output is mute.
For 4-channel, you could press [DOWN] button on front panel to be mute mode
for audio output. The audio input can be still recorded while the output is mute.And
You could press [UP] button to switch one of the two audio inputs to live output
6.3 Stop Recording
Press [■] stop button will stop recording. If password protection function is
enabled, system will prompt you to input password. Only correct password can stop
recording process.
6.4 Estimated Recording Length
Estimated rec ord time based on 160GB HDD
Standard Quality 60fps 48fps 32fps 16fps 1fps
Highest 62 78 116 232 3720
NTSC
Standard Quality 50fps 36fps 24fps 12fps 1fps
PAL
High 88 110 165 330 5280
Normal 107 134 201 401 6420
Lower 120 150 225 450 7200
Highest 64 89 133 267 3200
High 90 125 188 375 4500
Normal 110 153 229 458 5500
Lower 123 171 256 513 6150
Unit: Hour
18
User Manual
Chapter 7: Playback
7.1 Playback Control
Press the [►] PLAY button goes into PLAYBACK mode. The newest record
event will be played.
SEARCH VIDEO
DISK:MASTER SLAVE [NONE]
08/09/19 11:16:31 - 08/09/19 15:05:48
TYPE:EVENT TIME
PLAY:EVENTS
00006 T 2008/09/19 15:07:40
00006 T 2008/09/19 14:07:40
00006 T 2008/09/19 13:07:40
00006 T 2008/09/19 12:07:40
00006 T 2008/09/19 11:07:40
00006 T 2008/09/19 10:07:40
00006 T 2008/09/19 09:07:40
( )MOVE (SEL)SELECT (MENU)EXIT
SEARCH VIDEO
DISK:MASTER SLAVE [NONE]
08/09/19 11:16:31 - 08/09/19 15:05:48
TYPE:EVENT TIME
PLAY:00006 T 2008/09/19 15:07:40
( )MOVE (SEL)SELECT
( )PLAY (MENU)PREV MENU
Press the [MENU] button during PLAYBACK
mode，then the system will list all the recorded
events. The latest record will be on top of the list.
Press the ［▲UP］or [▼DOWN］ button to selecte
the event and then press [►] to play the event.
Another way to search video is directly input time
period. Press the [MENU] button then use [◄] or
[►] button to select the TIME search mode. Use
[SEL] button to edit time value, press [►] to play
the video. If the time you selected has no record
event, it will indicates “NO EVENTS” on the
screen when you press [►] play
Chapter 8: USB Progamming (optional)
8.1Driver Installation:
(1) Insert driver CD in your CD-ROM Drive.
(2) Open CD directory.
(3) Double click on the install applications.
(4) Run “Install” program.
(5) Follow the setup wizard to finish the
installation.
19
User Manual
8.2 Program Interface
Button functions:
13
12 11 10
1.PTZ Control 11.Convert Streams to AVI file
2.Zoom in，Zoom Out 12.Back One Frame
14
16
1
2
3
4
5
6
7
8
9
18
17
1
5
19
20
3.HDD Play Mode 13.Record
4.File Play Mode 14.Stop
5.Net Play Mode 15.Play
6.Event List 16.Pause
7.Control Panel 17.Fast Forward
8.Remote DVR Control
9.Change Storage Device 19.Playback Slider
10.Capture Image 20.Audio Slider
18.Forward One Frame
8.3 Program Running
8.3.1 HDD play mode
System will detect the HDD automatically when you connect the USB cable to
your PC.
An USB icon“
screen).
” will appear in the system tray (right bottom corner of the
20
User Manual
After you’ve seen the USB icon, double click “ ” icon on your desktop to run
the program.
Note: if you do not follow above steps, the program will fail to detect HDD
Press
to open the video event lists.
Press to configure the program local settings
21
User Manual
Press to play video.
8.3.2 FILE play mode: (only when you plug a USB Memory Stick into your PC)
Press “
” to open a folder and select the file you want play.
Double click the file.
22
User Manual
8.3.3 NET play mode:
This mode allows you to remote control your DVR via Internet or Intranet.
Press “
” to pop up the login window.
Fill in Host Name, Host Port, User Name and Password of the DVR that you want
remotely access and then press Login to enter the main page.
23
User Manual
Chapter 9: Specification
4 / 9-Channel DVR
Items Descriptions
Video Standard NTSC/PAL
Video Input/Output 4 Channels/2 Channels，9 Channels/1 Channel
Audio Input/Output 2 Channels/2 Channels，1 Channel/1 Channel
NTSC:720X480@30fps(Each Ch)
PAL:720X576@25fps(Each Ch)
NTSC:720X240@60fps(4/9Ch.Total)
PAL:720X288@50fps(4/9Ch.Total)
Variable Frame Rate/Variable QL per
Channel
Monitoring
Recording
Resolution
Features Full-D1，1-CH/4-CH/9-CH Display
Resolution
Features
Quality 4-Level(Highest, High, Normal, low)
Audio ADPCM2 CODEC
Video MPEG4
Motion Detection Settable Window/Level
Microprocessor 32-bit RISC Processor
Network Interface TCP/IP(RJ45)
Network Monitor IE(Internet Explorer)
PTZ Interface RS485
USB Interface USB2.0
VGA Output Optional
Remote control IR remote control
24
User Manual
Chapter 10: Appendix
10.1 System connection diagram
Sensor
DVR
Camera
USB
TV or Monitor
LAN(RJ-45)Port on DVR
Alarm
PC(Optional)
VCR
10.2Accessories
Power Cord
Design may vary depending
on country
Power Adaptor
Software CD
Remote Controller
User’s Manual
USB Cable (For
PC Backup Only)
25
_
User Manual
China prints 2008.4
V1.0
The material in this document is the intellectual property of our
departmen t .
No part of this manual may be reproduced, copied, translated,
transmitted, or published in any form or by any means without our
department prior written permission.
Our products are under continual improvement and we reserve the right to
make changes without notice. But no guarantee is given as to the correctness
of its contents.
We do not undertake any responsibility for the harms cause by using our
product.
The model of the products in the user's manual only f recognition, but
these names also perhaps are belong to other company's registered
tra d emark or the c o pyright.
The product picture may differ from the actual product, only for your
reference. The accessories will probably be different according to the
differ ent selli ng areas. For detail s of accessories, plea se refer to your local
distri butor.
Copyright reserved
Product Registration Card
Product Name:____________________ Product Model NO.: _________________________
Date of Purchase: __________________Invoice NO.: _______________________________
User Name :______________________ FAX:______________________________________
Telephone: _________________________________________________________________
Address:____________________________________________________________________
E-MAIL: _________________________________________________________
Franchiser or exclusive sales agent: ______________________________________________
_________
26
Loading...
