Electronic Security
Hardware
HES | Securitron Product Catalog
18 6
Securitron TSB Touch Sense Bar
Dimensions
3"
[76m m]
2-3/4"
[70 mm]
Push Buttons & Egress Devices
Specifications
Certifications
• UL 294 Listed
• CSA-C22.2 No. 205 Listed
• CSFM—California State Fire Marshal Approved
• CE: EN 50091-1, EN 61000-6-2 Approved
Electrical
• 40 mA at rest; 25 mA releasing at 12 VDC or 24 VDC
Environmental
• Operating Temperature: 32˚ to 110˚F [0˚ to 43˚C]
• Indoor use
Shipping Weight
• 7 lbs [3.18kg] to 9 lbs [4.08kg] depending on length
34 -1/2 ", 4 0-1/ 2", 46-1/2 "
[870mm, 1022mm,1175mm]
How to Order
Connector Style Model Series Finish Special Features Bar Length
EL – TSB – CL T – 42
(blank) None TSB Touch Sense Bar BK Black Anodized T Trailing Edge Timer (blank) 36" Length
EL ElectroLynx CL Clear Anodized 42" 42" Length
48" 48" Length
NOTE: Not every combination above is possible. Please contact the factory if you need a combination of features not listed on this page.
US assaabloyesh.com | 800.626.7590 | customerservice.esh@assaabloy.com
Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com
Copyr ight © 2019, Hanche tt Entr y Systems , Inc., an A SSA ABLOY Group c ompany. All r ights re served . Reproduc tion
in whol e or in part w ithout the e xpress w ritten p ermissio n of Hanchet t Entry Sy stems, Inc . is prohibi ted.
Updated 5/31/19 Patent pending and/or patent www.assaabloydss.com/patents
Securitron® EMB
Electromechanical
Bar
Mechanical activation for
electronic lock release in a
reliable, durable exit bar
187
Push Buttons & Egress Devices
Use the Securitron
Electromechanical Bar
(EMB) on electronically
locked, non-firerated doors or as an
initiate device for a
delayed egress timer.
Pressing the bar activates internal mechanical
switches that release the lock. Optional
waterproof switches are available, which allow
the Securitron EMB to function in protected
outdoor applications. Meets "no special tools
or knowledge" criteria for code requirements.
Features
Standard Features
• Low profile design requires only 1/4"
[6.35mm] movement for activation
• Can be field cut to accommodate non-
standard openings up to 48" [1219mm]
• Uses same mounting pattern as
the Securitron TSB and DSB
• Direct retrofit for some
competitor footprints
• Mechanical action
activates a DPDT relay
• 5A rated output to allow free egress
or initiate an exit delay timer
• Redundant switches ensure
reliable, fault-tolerant operation
• All metal construction
• 16 ft. [4.8m] 22 AWG 6
conductor cable and armored
door cord included
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Optional Features
• 36 36" [914mm] Length
• 42 42" [1,067mm] Length
• 48 48" [1,219mm] Length
• W Weather-resistant upgrade
• Cover plates for retrofit
of competitor products (TCP-BK-CL)
