Page 1
Electronic Security
Hardware
HES | Securitron Product Catalog
Page 2
228
228
Securitron® SEPT
Power Transfers
Power Transfers
Square-Cut Electrical
Power Transfer
Square tabs, medium length
for flexible power & data transfer
Concealed, secure
conduit for power and
data transfer between
a frame and door.
This unit is designed with a stamped steel
housing and spring steel conduit to protect
power and data wires. The square mounting
tabs provide easier installation for recessed
installation. The Securitron SEPT can be used
on swing doors with butt hinges, continuous
hinges or pivots with less than 3/4" offset.
Square mounting
tabs simplify recessed
prep on any door
Features
Standard Features
• Heavy duty design
• Installs in the door and frame edges
• Flexible steel shield protects wires
– 1/4" [6.3mm] inside diameter
• Works with almost any type of
butt hinge or continuous hinge
• MagnaCare
no-fault, no questions asked warranty
Optional Features
• SEPT-10 includes 8–22 AWG
wires plus 2–18 AWG wires
for higher current devices
• SEPT-C5E CAT5E compatible
with 9-22 AWG wire stranded
conductor, Molex connectors
• EL-SEPT ElectroLynx
with 12-22 AWG Wires,
ElectroLynx connectors
®
lifetime replacement,
®
compatible
Specifications
Certifications
• UL 10C Listed
• CAN4-S104 Listed
• ANSI A250.13 (+/- 150 psi)
• Windstorm Listed
Shipping Weight
• 0.85 lbs [0.39kg]
Dimensions
• Interior Flex Shield:
1/4" [6.3mm]
13"
[330 mm]
1"
[25.4m m]
US assaabloyesh.com | 800.626.7590 | [email protected]
Canada assaabloydss.ca | 800.461.3007 | [email protected]
How to Order
Wire Connectors Shape Number of Wires
EL – SEPT – C5E
(blank) No Connectors SEPT Square Cut
EL ElectroLynx Connectors 10 10 W ires
NOTE: Not every combination is possible. Please contac t factory if you need a combinat ion of features not listed above .
Copyr ight © 2019, Hanche tt Entr y System s, Inc., a n ASSA ABLOY Gro up company. A ll right s reserv ed. Repro duction
in whol e or in part w ithout th e express w ritten p ermissio n of Hanchet t Entry Sy stems, I nc. is prohib ited.
Power Transfer
Updated 6/7/19 Patent pending and/or patent www.assaabloydss.com/patents
(blank) 12 W ires
C5E 9 Wires
Page 3
Securitron® EPT
Electrical Power
Transfer
Concealed, tamper resistant,
flexible power and data transfer
229
229
229
Power
Power Transfers
Power Transfers
The Securitron EPT
Electric Power Transfer
provides concealed,
secure power and
data conduit between
a frame and door,
transmitting power
to electrified locks,
exit bars and more.
Its durable stamped steel housing and
flexible spring steel conduit make the
Securitron EPT suitable for most types of
swinging doors with butt or continuous
hinges or pivot hinges up to 3/4" offset.
The Securitron EPT-SC accommodates
swing-clear hinges and most pivot hinges.
Features
Standard Features
• Installs in the door and frame edges
• Flexible steel shield protects wire
bundles up to 5/16" [8mm] thick
• Works with almost any type
butt hinge, continuous hinges
and some pivot hinges.
• Rounded mounting tabs
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Optional Features
• EPT for standard hinges and pivot
hinges less than 3/4" [19mm] offset
• EPTL for extended length
up to 5" center to center
• EPT-SC for swing-clear hinges or
pivot hinges with larger of fset; not
for use with center pivot doors
• EL Models are ElectroLynx
compatible including 12–22 AWG
wires, ElectroLynx connectors
NOTE: Not every combination is possible.
Please contact factory if you need a
combination of features not listed above.
®
