Page 1
Electronic Security
Hardware
HES | Securitron Product Catalog
Page 2
178
178
Securitron®
MK Mortise
Push Buttons & Egress Devices
Push Buttons & Egress Devices
Keyswitch
Turns standard mortise cylinder
into full featured keyswitch
The Securitron MK
Mortise Keyswitch
supports electric
lock control, alarm
panel arming, reset
and override when
paired with any
mortise cylinder
1-1/8" to 1-1/2".
Features
Standard Features
• 12 or 24 VDC
• Bi-color LED
• Backing bracket permits integration
with any 1-1/4" [32mm] or 1-1/8" [28mm]
mortise cylinder (not included)
• Support for 1-1/2" [38mm] cylinder
using spacer ring and backset
• Additional switch position on
backing bracket allows another
switch to be activated by turning
the key in the opposite direction
• 5A rated plunger switch
• Includes anti-tamper screws
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Optional Features
• Momentary or Alternate
• SPDT or DPDT relay
• Narrow Stile, Single- or Double-Gang
• Local annunciation via Piezo sounder
• Additional switch add on
• 1-1/8" [28.5mm] Key Cylinder,
26D Finish, SC keyway
How to Order
Model Series Switch Type Mounting Method Switch/Sounder
MK A N 2
MK Mortise
Key Switch
(blank)
Momentary Switch
A
Alternate Switch
NOTE: Not every combination above is possible. Please contact the factory
(blank) Single Gang P Piezo Sounder
Z Double Gang 2 DPDT — Double
N Narrow Gang
if you need a combination of features not listed on this page.
Pole, Double
Throw
US assaabloyesh.com | 800.626.7590 | customerservice.esh@assaabloy.com
Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com
Copyr ight © 2019, Hanche tt Entr y System s, Inc., a n ASSA ABLOY Gro up company. A ll right s reserv ed. Repro duction
in whol e or in part w ithout th e express w ritten p ermissio n of Hanchet t Entry Sy stems, I nc. is prohib ited.
Updated 6/7/19 Patent pending and/or patent www.assaabloydss.com/patents
Page 3
Securitron®
KP1 Tubular
Keyswitch
Simple solution for exit, door
release, manual override or reset
179
179
Push Buttons & Egress Devices
Push Buttons & Egress Devices
The Securitron KP1
Keyswitch supports
electric lock control;
alarm panel arming,
reset and override
when paired with
any tubular cylinder
1-1/8" to 1-1/2".
Features
Standard Features
• Stainless steel face plates
• 12/24 VD bi-color LED tubular
style keyswitches
• Momentarily turning the key
changes the state of the contacts
• Includes anti-tamper screws
• Includes two keys
• MagnaCare
no-fault, no questions asked warranty
Optional Features
• Momentary or Alternate
®
lifetime replacement,
Specifications
Electrical
• 7A rated SPDT switch
• 40mA at 12 or 24VDC
How to Order
Model Series Switch Type
KP1 A
KP1 Tubular Key Switch (blank) Momentary Switch
A Alternate Switch
