94
Securitron M62 Magnalock
Dimensions
Electromagnetic Locks
3"
[76mm]
1-3/4"
[44 mm]
1/2 "
[12m m]
8"
[20 3mm]
6"
[152mm]
2-3/4"
[70 mm]
Specifications
Certifications
• UL 10C Listed
• CAN4-S104, CAN/ULC-S533 Listed
• ANSI/UL 294 Listed
• CSA-C22.2 No.205 Listed
• ANSI/BHMA A156.23, Grade 2;
E08501-1000 Compliant
• CSFM—California State Fire Marshal Approved
• CE:EN 50081-1(92), EN 61000-6-2(99) Approved
• Environmental Product Declaration
• Health Product Declaration
Electrical
• 250 mA at 12 VDC
• 150 mA at 24 VDC
Holding Force
• 1,200 lbs [544kg]
Operating Temperature
• -40˚ to 140˚F [-40˚ to 60˚C]
• Indoor or Outdoor use
Shipping Weight
• 11 lbs [5kg]
How to Order
Model Series Mounting Method Monitoring Options Strike Plate Options
M62 FG BD – SASM
M62 1,200 lbs (blank) Direct Mount (blank) No Monitoring (blank) Standard Strike
F Face Drilled B BondSTAT Monitor OS Offset Strike
G Gate Conduit D Door Position Switch SS Split Strike
BD BondSTAT and DPS SASM Shock Absorbing Strike Mount
US assaabloyesh.com | 800.626.7590 | [email protected]
Canada assaabloydss.ca | 800.461.3007 | [email protected]
Copyr ight © 2019, Hanche tt Entr y Systems , Inc., an A SSA ABLOY Group c ompany. All r ights re served . Reproduc tion
in whol e or in part w ithout the e xpress w ritten p ermissio n of Hanchet t Entry Sy stems, Inc . is prohibi ted.
Updated5/31/19 Patent pending and/or patent www.assaabloydss.com/patents
Page 3
Securitron®
M82 Magnalock
1,800 lbs holding force
direct mounted Magnalock
95
Electromagnetic Locks
®
Industrial strength
hold for challenging
indoor/outdoor
environments.
The Securitron M82 electromagnetic lock
offers unsurpassed magnetic holding strength,
durability and ease of maintenance for
interior, perimeter and exterior access control
applications in high-risk environments. With
unsurpassed durability, the Securitron M82 will
last long after most buildings wear out. Flexible
mounting options are available for higher
security locations and other environments
where extreme forces may be encountered.
Features
Standard Features
• Efficient, low power usage
• Automatic dual-voltage
—no field adjustment required
• Fully sealed for weatherproof
operations
• Rust resistant—all ferrous metal
surfaces plated for durability
• Instant release circuit
—no residual magnetism
• Noise suppression with built-in MOV
• 10 ft [3.05m] of jacketed,
stranded conductor cable
• Ultra-secure collapsing blind
nuts mount to door frame for
strength and reliability
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Optional Features
• F Face drilled
• G Gate conduit
• B Patented BondSTAT
magnetic bond sensor
• D Integrated Door
Position Switch (DPS)
• SS Split Strike
• OS Offset Strike
