TECHNICAL SUPPORT
Secure Wireless 866-908-Tech
www.mysecurewireless.com
SLIM DOOR WINDOW SENSOR
ENROLLMENT /
6. Push ON/OFF to Save
REPLACING THE BATTERIES
ODEL
SW-NAP-SDW
FCC ID
QNP-SDW319
FREQUENCY
319.5 MHz
WARRANTY
Limited Life time
BATTERY
(2) CR2032 Replace
with Panasonic
MANUAL PART #
200-10003 Rev A
Alpha Chart
A - *0
C -*2
D - *3
F - *5
Mounting
Pop open the case
FCC Compliance
This device complies with Part 15 FCC Rules.
Operation complies with the following 2 conditions
(1) This device may not cause harmful interference
and (2) this device must accept any interference
received, including interference that may cause
undesired operation
using a coin. Replace
with new batteries. ( +
) or positive polarity
should be facing up
Replace Cover
SW-NAP-SDW
Slim Door Window Sensor
NAPCO COMPATIBLE
INSTALLATION MANUAL
length.
can be no longer than 12 Ft in
Wire run to the External Magnet
programming
External (Use Point 2 when
E - *4
¼ in from the sensor.
Mount the magnet no more than
sensor case
the 3 lines on the side of the
Align the Arrow on magnet with
when Programming )
Reed Switch (Use Point 1
easy installation.
Double Sided Tape is included for
magnet.
internal reed switch as well as the ability to use an external
The SW-NAP-SDW Door Window is equipped with an
DOOR WINDOW MOUTING / USAGE
B - *1
“:” on Serial ID)
tamper switch can be used.
for External )
5. ENTER POINT (1 for Internal Reed or 2
Enter Checksum ( digit after the
Enter serial Id listed on back)
To Manual Learn
Fault and Restore the device or the
Hit “Bypass”
To Auto-Learn
4. ENTER Serial ID ( Auto-learn or Manual)
3. ENTER Zone
2. ENTER PANEL PROGRAMMING
1. Pull Battery Tab
replacement for using the programming instructions.
should only be used as a reference and not as a
should be consulted for that panel. The below guide
For a detail programming guide, the instruction manual
external magnet .
internal reed switch as well as the ability to use as
The SW-NAP-SDW Door Window is equipped with an
PROGRAMMING
