TECHNICAL SUPPORT
Secure Wireless 866-908-Tech
www.mysecurewireless.com
GLASS BREAK ENROLLMENT PROGRAMMING
A - *0
C - *2
E - *4
B - *1
D- * 3
F - * 5
Plate
1/8 in to ¼ in
Tempered
1/8 in to ¼ in
Sealed Insulating
1/8 to ¼ in
REPLACING THE BATTERY
MODEL
SW-NAP-GB
FCC ID
QNP-GB319
FREQUENCY
319.5 MHz
WARRANTY
Limited Life Time
BATTERY
(2) CR123A Panasonic
MANUAL PART #
200-10008 Rev C
MOUNTING INSTRUCTIONS
Remove the detector from the base by turning
counterclockwise. Replace with 2 CR123A batteries.
Observe the polarity when replacing the batteries
FCC Compliance
This device complies with Part 15 FCC Rules. Operation
complies with the following 2 conditions (1) This device
may not cause harmful interference and (2) this device
must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
SW-NAP-GB
Glass Break
NAPCO COMPATIBLE
INSTALLATION MANUAL
essed. The green
conds and release,
indicate the glass breaking.
will flash green first then will flash LED to
up to the alignment mark and turn clockwise
The test button should be facing the floor
being protected (Distance 15 Ft maximum)
opposite wall or adjacent wall to the window
mode for 90 seconds.
LED will blink twice to indicate that the unit is in RF test
The LED will flash while the button is pr
Push and hold the test button for 5 se
WIRELESS RANGE TEST:
Glass Type and Thickness
Alpha Chart
1. Use a glass break simulator to test the unit. LED
mode for 90 seconds.
LED will blink once to indicate that the unit is in auto test
red LED will light while the button is pressed. The green
Push the test button for 2 seconds and then release. The
FUNCTIONAL TEST:
3. When attaching the detector to the base, match
2. Attach to the wall using the supplied screws.
1. Place the Glass Break Detector base on the
6. Push On/Off to Save
5. ENTER Point “3” – for Glass Break
Serial ID
back on unit. Digit that follows “:” on the
4. ENTER Check sum (0-9 ; A-F) (located on
of unit)
3. ENTER 6 Digit Id Number ( located on back
2. SELECT Zone #
1. ENTER Panel Programming
replacement for using the programming instructions.
should only be used as a reference and not as a
should be consulted for that panel. The below guide
For a detail programming guide, the instruction manual
