Dimensions:

EV-6680-N3WQ

EV-6681-N3WQ

Type

Covert PIR C amera

CCD 1/3” Sony Super HAD II

1

/3” Sony EXview HAD II

Resolution

700 TV Lines

Video output form at

NTSC

Effective pixel s

976x494 pixels

DNR (2D-NR)

Yes

DWDR

Yes

OSD Control

Yes

960H*

Yes

Video output

1.0Vp-p Composite video, 75Ω

Lens

3.7mm

# of IR LEDs

N/A

18 (940nm)

IR Range

N/A

50ft (15m)

Minimum
illumination

LEDs OFF

0.1 Lux

LEDs ON

N/A

0 Lux

Gamma correcti o n

0.45

S/N Ratio

>48dB

Operating v oltage

12VDC

Current
draw

LEDs OFF

70mA

LEDs ON

N/A

230mA

Operating temperature

14°~122° F (-10°~50° C)

Dimensions

41/8”x23/8”x13/8” (105x60x35 mm)

Weight

3.9-oz (110g)

Covert PIR Cameras

EV-6680-N3WQ Motion-activated LED

Features:

Specifications:

41/8”

Front View

Side View

2”

(52mm)

13/8”

23/8”

(60mm)

EV-6681-N3WQ

EV-6680-N3WQ

(Non-functioning PIR)

EV-6681-N3WQ Invisible 940nm IR LEDs

• Camera is covertly hidden in a non-functioning PIR

• 3.7mm Lens

• 700 TV Lines

• 960H High resolution

sensor housing

• OSD (On-Screen Display) for programming special features
such as 2D-NR and DWDR

• DWDR (Digital Wide Dynamic Range) for clear images in
strong backlight

• 2D-NR (2D Digital Noise Reduction) for clear images in
low light

EV-6680-N3WQ Only:

1

•

/3” Sony Super HAD II

• Motion-activated LED to simulate a real PIR sensor

EV-6681-N3WQ Only:

•

• 18 Invisible 940nm IR LEDs

1

/3” Sony EXview HAD II

Motion-activated LED
is programmable from the
OSD menu, simulating a
real PIR sensor.

Invisible 940nm IR LEDs
provide infrared light for
the camera to view at
night, but are invisible to
the human eye.

*In order to take full advantage of 960H resolution, the camera m ust be used wit h a 960H DV R.

(35mm)

(105mm)
