Seco-Larm EB-P101-20VQ User Manual

Passive Video, Power, and Data Balun

Note: Products with model numbers that end with “Q” or that have a round green “Q” sticker are RoHS compliant.

Installation Manual

 Transmits up to 1,300ft (400m) color

video or up to 1,950ft (600m) B/W video

 Transmits power for 12/24 VAC/VDC

cameras (see pg. 3 for details)

 Transmits data up to 984ft (300m)
 High immunity from interference
 Includes DC plug and DC jack

 Pigtails for flexible installation
 Uses low-cost Cat5e/6 cable

instead of costly coaxial cable

 RJ45 Jack for easy installation
 Passive operation – No external

power required

 Built-in surge protection

EB-P101-20VQ

ENFORCER Passive Video, Power, and Data Balun

Specifications:

Overview:

Dimensions:

Data

BNC Connector

DC Jack
DC Plug

Note: Do not connect both the DC jack and DC plug. Damage to the balun and camera will occur.

RJ45

Overcurrent/Overload

Status LED

Power

Status LED

Parts List:

1x Passive Video, Power, and

Data Balun

1x Manual

Use

only

one

*Shorter range may occur when used with a DVR.

Note: Pigtail length is 5” (127mm).

11/8”

(30mm)

15

/16”

(24mm)

23/8” (61mm)

5

/8”

(16mm)

13

/16”

(21mm)

Video

Range*
B/W

1,950’ (600m)

Color

1,300’ (400m)

Video format

NTSC, PAL, SECAM

Maximum input

1.1Vp-p

Insertion loss

<2dB per pair from DC~6MHz

Return loss

>15dB from DC~6MHz

Frequency response

DC~6MHz

Common mode rejection

>40dB, 15kHz~6MHz

Connections

Wire type

UTP (Unshielded Twisted Pair) 24~16 AWG

Wire category

Cat2~Cat6

Camera side
Video in

BNC

Power out

DC Plug or DC jack

Data out

2 Wires

Cable side
Video out

RJ45

Power in

RJ45

Data in

RJ45

BNC Connection

Silver plated

Attenuation

DC~6MHz, 6.6dB max.

Impedence
Coax, male BNC

75Ω@1MHz

RJ45

100Ω@1MHz

Other

Max. amperage

1.1A@12VDC

Power range*

656’ (200m)@12/24 VAC/VDC

Data range*

984’ (300m)

DC Loop resistance

52Ω/1000’ (52Ω/305m)

Differential capacitance

19pF/ft max. (62pF/m max.)

Power

No power required

Operating temperature

32 ~131 F (0 ~55 C)

Storage temperature

-4 ~158 F (-20 ~70 C)

Humidity range

0~95 % (Non-condensing)

Case

ABS Plastic

Weight

2.3-oz (65g)

Cable length

5” (127mm) (longest cable)

Dimensions

23/8”x11/8”x13/16” (61x15x21 mm)

2 SECO-LARM U.S.A., Inc.
