Seco-Larm E-941S-1K5-L User Manual

2016-M04B

E-941SA-1200

Standard lock, UL listed

E-941SA-1K2PQ

Bond sensor, status LED, UL listed

E-941SA-1K2PD

Bond sensor, status LED, 1~78 sec timer

LIFETIME

• 1,200-lb Holding force

LIMITED

WARRANTY

• 12 or 24 VDC Selectable operation

• No residual magnetism

• MOV surge protection

• Anodized aluminum housing (US28)

• Adjustable mounting and detachable faceplate

• Mounting brackets available (see page 3)

E-941SA-1K2PQ and E-941SA-1K2PD Only:

• Built-in dual-colored status LED and bond sensor to
show locking status

E-941DA-1K2Q

Double-door, standard lock, UL listed

E-941DA-1K2P

Double-door, bond sensor, status LEDs,
UL listed

E-941SA-600

Standard lock, UL listed

E-941SA-600PQ

Bond sensor, status LED, UL listed

• 600-lb Holding force

• 12 or 24 VDC Selectable operation

LIFETIME

LIMITED

WARRANTY

• No residual magnetism

• MOV surge protection

• Anodized aluminum housing (US28)

• Adjustable mounting and detachable faceplate

• Mounting brackets available (see page 3)

E-941SA-600PQ Only:

• Built-in dual-colored status LED and bond sensor to
show locking status

E-941DA-600Q

Double-door, standard lock, UL listed

E-941DA-600PQ

Double-door, bond sensor, status LEDs, UL listed

E-941SA-300

Standard lock, indoor/outdoor use

• 300-lb Holding force

• 12VDC Operation

• Weatherproof for indoor or outdoor use

• No residual magnetism

• MOV surge protection

• Stainless-steel housing

• 3ft (1m) Hookup wire

E-941SA-300RQ

Standard lock, indoor use

• 300-lb Holding force

• 12 or 24 VDC Selectable operation

• Magnet can be reversed in the housing for
right-hand or left-hand swinging doors

• No residual magnetism

• MOV surge protection

• Anodized aluminum housing (US28)

• Mounting brackets available (see page 3)

LIFETIME

LIMITED

WARRANTY

• 1,200-lb Holding force each door

• 12 or 24 VDC Selectable operation

• No residual magnetism

• MOV surge protection

LIFETIME

LIMITED

WARRANTY

• Anodized aluminum housing (US28)

• Adjustable mounting and detachable faceplate

• Mounting brackets available (see page 3)

E-941DA-1K2P Only:

• Built-in dual-colored status LEDs and bond sensors
to show locking status

1,500-lb Maglock

E-941SA-1K5Q Standard lock, indoor use

• 1,500-lb Holding force

• Anodized aluminum

• No residual magnetism

• MOV surge protection

• Mounting brackets available (see page 3)

• 12 or 24 VDC selectable
operation

• 600-lb Holding force each door

• 12 or 24 VDC Selectable operation

• No residual magnetism

• MOV surge protection

LIFETIME

LIMITED

WARRANTY

• Anodized aluminum housing (US28)

• Adjustable mounting and detachable faceplate

• Mounting brackets available (see page 3)

E-941DA-600PQ Only:

• Built-in dual-colored status LEDs and bond sensors
to show locking status

Magnetic Door Holders

DH-151SQ

Surface-mount with backbox, UL listed

DH-171SQ

Flush-mount, UL listed

DH-151SQ DH-171SQ

• For use with door closers to control the release and
closing of residential, commercial, and public doors

• Adjustable armature plate reduces installation time
and adjusts to door alignment changes

• Fail-safe operation

• Holding force – 33-lbs (15kg)

• Three voltages: 12VAC/VDC, 24VAC/VDC, 120VAC

• Extension bars available: ½”, ¾”, 1”, 2”

• Cast aluminum faceplate

• Built-in voltage spike suppressor

E-941SA-80Q

Standard lock, indoor use

LIFETIME

LIMITED

WARRANTY

• For small, low-security drawers or cabinets

• 80-lb Holding force @ 12VDC

• 110-lb Holding force @ 24VDC

• 12~24VDC Operation

• No residual magnetism

• MOV surge protection

E-941EC2-N1Q 2.3mm Wide-angle lens

• Seamlessly integrates with all 1,200-lb single or
double-door maglocks (see above)

• Wide-angle 2.3mm lens for discreetly monitoring
doorways and lobbies • 12VDC Operation

• See ”Maglock Camera” on page 13 for more info

2

Z Brackets

E-941S300R/ZQ For E-941SA-300RQ
E-941S-600/ZQ For 600-lb maglocks
E-941S-1K2/ZQ For 1,200-lb maglocks
E-941S-1K5/Z For 1,500-lb maglocks

• For mounting on in-swing doors

• Includes one L bracket
and one Z bracket

• Adjustable for exible
installation of armature
plate

• Includes cover plate
for hiding mounting screws to prevent tampering
(excludes E-941S300R/ZQ)

L Brackets

E-941S300R/LQ For E-941SA-300RQ
E-941S-600/LQ For 600-lb maglocks
E-941S-1K2/LQ For 1,200-lb maglocks
E-941S-1K5/L For 1,500-lb maglocks

• For offset mounting

• Includes one L bracket

• Can be used as angle
bracket

U Brackets

E-941S300R/UQ For E-941SA-300RQ
E-941S-600/UQ For 600-lb maglocks
E-941S-1K2/UQ For 1200-lb, 1500-lb maglocks

• For glass doors

• Includes one U bracket
and one armature
plate holder

• Adjustable for
9~13 mm glass

Plate Spacers

E-941S300R/PQ For E-941SA-300RQ
E-941S-600/PQ
E-941S-1K2/PQ
E-941S-1K5/P For E-941SA-1K5Q
E-941D-600/PQ For 600-lb double-door

E-941D-1K2/P For 1200-lb double-door

• Extends door stop to create

at surface mounting area

3

/16” for 600-lb series

1

/4” for 1200-lb series

E-942FC-1300

Surface mount, UL listed

E-946FC-1K2Q

Face and surface mount, UL listed

E-946FC-1K2Q

• For sliding or swinging gates

• 1,200-lb Holding force

• 12 or 24 VDC Selectable operation

• Weatherproof and vandal resistant

• Dual-threaded conduit tting

• 6½ft (2m) Hookup wire

• Mounting brackets available (see left)

E-942FC-1K3SQ

Face mount, weldable bracket

• Weld or bolt brackets directly to the gate

• 1,200-lb Holding force

• Brackets are corrosion resistant and zinc plated and

have a black nish to match most gates

• Weatherproof and vandal resistant

• 12 or 24 VDC Selectable operation

• Adapter and mounting hardware included

E-946FC-1K2SQ

Face and surface mount, weldable bracket

E-942FC-600

Surface mount, UL listed

E-946FC-600Q

Face and surface mount, UL listed

E-946FC-600Q

• For sliding or swinging gates

• 600-lb Holding force

• 12 or 24 VDC Selectable operation

• Weatherproof and vandal resistant

• Dual-threaded conduit tting

• 3ft (1m) Hookup wire

• Mounting brackets available (see left)

E-942FC-600SQ

Face mount, weldable bracket

• Weld or bolt brackets directly to the gate

• 600-lb Holding force

• Brackets are corrosion resistant and zinc plated and

have a black nish to match most gates

• Weatherproof and vandal resistant

• 12 or 24 VDC Selectable operation

• Adapter and mounting hardware included

L Brackets

E-942F-1300/L For E-942FC-1300
E-946F-1K2/LQ* For E-946FC-1K2Q
E-942F-600/L For E-942FC-600, E-946FC-600Q

• For offset mounting

• Each kit includes
two (2) L brackets

Armature Plate Holder

E-941S-600/HQ For 600-lb maglocks
E-941S-1K2/HQ For 1,200-lb, 1,500-lb maglocks

• For mounting the armature
plates to a metal-core
door or for non-standard
armature installations

• Provides extra security for
the armature plate

• Weld or bolt brackets directly to the gate

• 1,200-lb Holding force

• Brackets are corrosion resistant, zinc plated, and

have a black nish to match most gates

• Weatherproof and vandal resistant

• 12 or 24 VDC Selectable operation

• Adapter and mounting hardware included

* Only includes one (1) L bracket

Z Brackets

E-942F1300/ZQ
E-942F-600/Z

• For mounting on in-swing doors

• Adjustable for exible
installation of armature plate

For E-942FC-1300,
E-946FC-1K2Q
For E-942FC-600,
E-946FC-600Q

3

SD-994C

SD-995C

SD-997B-GBQ Fail-safe Operation, 12/24 VDC

• 12/24 VDC Operation

• For concealed mounting

• ⁄” (16mm) Bolt extension

• Narrow design –
7⁄”x1¼ ” (200x32 mm)

• Door-position monitoring output (NO/NC/COM)

SD-997SMB-AQ

Surface-mount bracket for Deadbolt
(SD-997B-GBQ)

SD-997UB-AQ

U-Bracket for glass doors for
Deadbolt (SD-997B-GBQ)

SD-997A-GBQ Fail-secure Operation, 12/24 VDC

• Similar to SD-997B-GBQ, but fail-secure

• Incorporates manual
lock/unlock cylinder to
operate lock if power
is lost (turn lock knob
from inside protected
premises and/or use
key from outside protected premises)

Electric Shear Lock

SD-993B-SS Fail-safe Operation

• 1,500-lb (680kg) Holding force

• 12/24 VDC Operation

• Fail-safe operation
– unlocks when power is lost

• Small size for use with most
metal door jambs

• Works with sliding, single-action, and double-action
doors and gates

SD-993S-SB

Surface-mount bracket set for
Shear Lock (SD-993B-SS)

SD-993S-UB

U-Bracket for glass doors for
Shear Lock (SD-993B-SS)

SD-997B-1SQ Fail-safe Operation

• 12VDC Operation

• Fail-safe operation
– unlocks when power is lost

• For cabinets or small doors

• For surface mounting

• ⁄” (14mm) Bolt extension

Electric Deadbolt

Cabinet Lock

SD-997C-GCQ

• 12/24 VDC Operation

• Electronically secure lockers,
cabinets, cases, and drawers

• Lock status sensor allows for
monitoring whether doors
are locked

• Current draw: 300mA@12VDC,
150mA@24VDC

Fail-safe/Fail-secure Operation

SD-994C 12VDC, for wooden doors
SD-994C24 24VDC, for dooden doors
SD-995C 12VDC, for metal doors
SD-995C24 24VDC, for metal doors

SD-994CSD-995C

• Field-programmable for fail-safe/fail-secure operation

• Reversible, non-handed design

• Shallow design • 2,000-lb Jaw strength

• Stainless steel lip

SD-996C-NUQ 12/24VDC, UL listed

• Includes three faceplates
for nearly any type of door

• Field-programmable
for fail-safe/fail-secure
operation

• Reversible non-handed

• 2,000-lb Jaw strength

• Tested to 1 million cycles

• UL 1034 Burglary

• Non-polarized connection

SD-995C-LE25 Lip Extender, 1” (25mm)
SD-995C-LE50 Lip Extender, 2” (50mm)
SD-995JA-11Q Frame Preparation Jig
SH-506Q 93dB Buzzer, 3~28VDC

• Compatible with SD-994C and SD-995C series, and
SD-996C-NUQ door strikes

Weatherproof

Door/Gate Strike

SD-995A-D3Q 12/24VDC Operation

• Weatherproof

• Fail-secure operation

• One piece cast body

• Low current draw:
280mA@12VDC,
140mA@24VDC

• Compatible with most locksets

• Extra wide keeper 1

5

”

/

8

Surface-Mount

Electric Rim Strike

SD-998C-NUQ 12/24 VDC Operation

• 1,500-lb Jaw strength

• ¾ ” (19mm) thick metal housing

• Accommodates up to
¾ ” Pullman latch

• Dynamic strength 70 ft-lb

• Field-programmable
for fail-safe/fail-secure operation

• Horizontal adjustment

• Metal or wood frame installation

Electric Door Strikes

with Vertical Adjustment

SD-996C-U1VQ
SD-996C-NUVQ

• Vertical adjustable deadbolt opening, sliding shim
keeper, and deadlatch ramp accommodates a wide
range of lock types

• Accommodates deadbolts up to 1”

• Field-programmable for fail-safe/fail-secure operation

• Reversible non-handed design

• 1,500-lb holding force

• Low current draw (250mA@12VDC)

12 VAC/VDC
12/24 VAC/VDC

5 Faceplates included

Electric Door Strike

with Horizontal Adjustment

SD-995A-A1Q Fail-secure Operation
SD-995RE-21Q Optional Faceplate

1



/4” Horizontal keeper adjustment compensates

for installation dif culties such as warped doors,

different-sized latch bolts, etc.

• Unique design  ts both wood and metal doors

• Reversible for right or left-handed doors

• Durable stainless-steel faceplate

• Operating voltage: 8~16 VAC/12VDC

• 1,000-lb Jaw strength

• Current draw: 750mA@12VDC

• ANSI Faceplate: 47/8”x11/4”x1/8” (124x32x3.2 mm)

• Optional ANSI Faceplate SD-995RE-21Q:
715/16”x11/4”x1/8” (202x32x3.2 mm)

SD-995RE-21QSD-995A-A1Q

Reversible Door Strikes

SD-994A-A1AQ Fail-secure, Asymmetrical
SD-994A-A1SQ Fail-secure, Symmetrical

• 8~16 VAC/12VDC Operation

• Fail-secure operation

• Powered by a solenoid

• Can be used on virtually
any mortise or cylindrical
door locking system

• Chrome faceplate (US26D)

• Miniature lock body for easier installation

SK-990AQ Fail-secure
SK-990BQ Fail-safe

• 10~14 VDC Operation

• For entrance doors

• For use in wood doors

• Baked painted  nish

SD-994A-A1AQ

4

SK-2323-SDQ Standard keypad
SK-2323-SPQ Keypad with proximity reader

SK-2323-SPAQ

• 1,010 Users

• Adjustable user
code length
(2~6 digits)

• 12~24 VAC/VDC
Operation

• Two relay outputs
(1A@30VDC)

• Relays have
programmable
output time (1~99
seconds or toggle)

• Weatherproof design – circuitry is potted with epoxy

• Backlit keys for easy nighttime use

• Two egress inputs, door sensor input

Piezoelectric keypad with
proximity reader

SK-2323-SPQ SK-2323-SPAQ

SK-1323-SDQ Standard keypad
SK-1323-SPQ Keypad with proximity reader

• 1,010 Users

• Adjustable user code length
(2~6 digits)

• 12~24 VAC/VDC Operation

• Two relay outputs
(1A@30VDC)

• Relays have programmable
output time (1~99 seconds
or toggle)

• Weatherproof design –
circuitry is potted with epoxy

• Backlit keys for easy
nighttime use

• Two egress inputs, door sensor input

SK-1323-SPQ

Split-Series Keypad

with Proximity Reader

SK-4131-SPQ

Built-in proximity card reader,
Keypad and control board

SK-1011-SDQ Standard keypad, 1 output
SK-1131-SPQ Keypad w/ proximity reader

SK-1131-SPQSK-1011-SDQ

• Up to 1,000 possible user codes

• 12~24 VAC/VDC Operation

• Up to 50 (01~50) possible temporary visitor codes,
programmable for one-time or limited-time use

• Output #1 Form C Relay, 1A@30VDC max.,
for door lock/unlock

• All outputs can be programmed to activate for up to
99,999 seconds (nearly 28 hours)

• Smart egress input

• Real time clock disables access at speci c times

SK-1131-SPQ Only:

• Up to 1,000 possible user codes and/or proximity
cards programmable for output #1, 100 for
output #2, 100 for output #3

• Built-in prox. card reader 125kHz (EM125)

• Output #2: Form C Relay, 1A@30VDC

• Output #3: Transistor ground, 100mA@24VDC

SK-3523-SDQ Outdoor Keypad
SK-3523-KEY Extra keys for faceplate lock

• 210 Users – Programmable 4~5 digits user code

• Rugged construction – heavy-duty stainless-steel
faceplate with a coated steel backing

• 12~24 VAC/VDC Operation

• Two relay outputs (12A@14VDC)

• Outputs have programmable output time
(1~99 seconds or toggle)

• Weatherproof design

• Backlit keys for nighttime use

• Egress input, tamper switch, door sensor input

Outdoor Access

Control Keypads

SK-1123-SPQ
SK-1123-SDQ 1,100 Users

SK-1123-SPQ SK-1123-SDQ

• 12~24 VAC/VDC Operation

• Up to 50 (01~50) possible temporary visitor codes,

• Output #1: Form C relay, 1A@30VDC max.

• Output #2: Form C relay, 1A@30VDC max.

• Outputs #1, #2 can be programmed to activate for
up to 99,999 seconds (nearly 28 hours)

• Duress code signals a silent alarm if an authorized
user is forced to open the door under duress

• Smart egress input

• Real time clock disables access at speci c times

• All features are programmed directly from the
keypad: No need for an external programmer

• IP66 Weatherproof Rating

• Door sensor input for anti-tailgating operation

SK-1123-SPQ Only:

• Built-in prox. card reader 125kHz (EM125)

Proximity Reader, 1,100 Users

Fingerprint Reader

and Keypad

SK-2611-SFSQ

• 500DPI Optical  ngerprint reader

• Form C relay output

• Pulse mode, Toggle mode

• Veri cation method: Fingerprint, PIN

• User capacity: 1000 users

(500  ngerprint users, 500 PIN users)

• PIN length: 4~6 digits

• 12VDC Operation

• Access control interface for 3rd party
electric lock, exit button, alarm

• Dimensions: 5
(150x68x25 mm)

7

1000 Users

/8”x25/8”x1”

Keypad Lock

SK-7814-DDQ 31 Users

• Split-Series keypad - keypad and control board are
separated for high security applications

• Built-in prox. card reader. 125kHz (EM125)

• 1,200 Users over 3 outputs. Code length 4-8 digits

• 12~24 VDC operation

• Built-in door chime

• 4 available programmable access modes for all
outputs: card only, code only, card and common
user code, card and unique user code

• Up to 50 possible temporary visitor codes

• Smart egress input

• Real time clock disables access at speci c times

Flush-Mount

Outdoor Access Keypad

SK-1123-FQ 110 Users

• 12~24 VAC/VDC Operation

• 4~8 digits user code

• 2 Outputs (#1: Form C Relay,
5A@30VDC, #2: Transistor
ground, 100mA@24VDC)

• Outputs have programmable
output time (1~999 sec. or toggle)

• Egress input, tamper switch,
door sensor input

• Veri cation method: PIN

• 1 Master code

• User capacity: 31 users

• PIN length: 3~11 digits

• 6VDC Operation (4x AA batteries)

• Battery life: 1 year

• Self-locking parameters: Door locks for 12 seconds
after four consecutive wrong password attempts

• Output time: 5 seconds or toggle

5

Microwave RTE Sensor

PR-312S-PQ Indoor use, 500 users

• Up to 5 super user cards,
plus 1 master card

• 10 Cards included (additional
cards available – sold
separately in packs of 10)

• 1~180 sec or toggle

• Status LEDs for operations and
programming

• Solid-state lock relay for longer
life, lower power consumption,
and shock/vibration resistance

PR-112S-A Indoor/outdoor use, 100 users

• 12VDC Operation

• 10 Cards included

• One relay output
(1A@30VDC)

• Outputs have programmable
output time (1~180 seconds
or toggle)

• Weatherproof design • Egress input

• Tri-color wave-shaped LED status bar indicates
proximity reader’s mode and status

PR-K1S1-A

Proximity cards

PR-K1K1-AQ

Proximity keyfobs

DP-236Q Complete Kit
DP-236-MQ Additional Monitor

• Remotely talk to visitor and unlock doors or gates

• Wireless – Up to 492ft (150m)

• Built-in IR LEDs for nighttime operation

• Connect up to 2 additional monitors

• PIR sensor activates camera and takes photos

• Camera uses 9~16 VAC/5-16VDC

• Adjustable viewing angle (120° wide angle)

Optional Accessories:

DP-236-BQ

Additional battery

DP-236-SQ

Charging stand

DP-234Q Complete Kit
DP-234-MQ Additional Monitor

SD-R400-BQ 12~27 VAC/VDC Operation

• Microwave technology, 24.125GHz

• Sensing range: 10’ (3m)

• Weatherproof for indoor or outdoor use (IP54)

• Adjustable sensing angle

• Black ABS housing

Timers

SA-025EQ Delayed egress timer

• 12~24 VAC/VDC Operation

• 3 Relock modes

• Programmable nuisance delay timer (0~3 seconds)

• Lock relay and remote alarm relay outputs
(Form C, 10A@24VDC)

• Local alarm output (transistor ground)

• Sold in packs of 10

• For use with all SECO-LARM Proximity Readers

Wireless Audio Door Phone

DP-A21Q 1 Premise system
DP-A22Q 2 Premise system

DP-A21Q

• Wireless frequency: 900 MHz

• Range: 650ft (200m)

• Outdoor station is 12VDC operation with power
adapter included (Battery operation via 3x AAA
batteries also available)

• Handset has attractive backlit LCD display

• Outdoor station has 1 Form “C” relay
(NO/NC/COM, 2A@12VDC) output

• Weatherproof for indoor and outdoor use (IP54)

• Unlimited number of handsets can work with up to
2 (two) outdoor stations

• Intercom between handsets

• Selectable audible, visible or vibrating alerts

• Handset is battery operated (3.7V lithium ion) with
recharging station (included)

• Handset indicates outdoor temperature

• Handset has out-of-range & low-battery indicator

• Built-in microphone on both the camera and monitor
– no handset needed

• Remotely unlock door

• Simple 2-wire connection

• Camera has built-in LEDs for nighttime operation

• Easily connect a second monitor (optional)

• DP-234-MQ also compatible with DP-222Q

DP-222Q Complete Kit
DP-222-MQ Additional Monitor

• Remotely and securely talk to visitors via
built-in handset

• Remotely unlock door

• Simple 2-wire connection

• Camera has built-in LEDs for nighttime operation

• Easily connect a second monitor (optional)

• DP-222-MQ also compatible with DP-234Q

SA-027HQ Programmable annual timer

• 12~24 VAC/VDC Operation

• Two Form C relays rated 10A@120VAC/28VDC

• Events can be set wekly, daily, or hourly, over the
course of an entire year

• Each relay can be programmed for 50 events for a
total of 100 events

• Manual operation of relays

• Block programming allows events to be repeated

• One egress input per relay

• Adjustable output time (1~99 seconds or toggle)

SA-027WQ Programmable 7-day timer

• 12~24 VAC/VDC Operation

• One Form C relay rated 10A@120VAC/28VDC

• Up to 60 programmable events

• Holiday function (up to 99 days)

• Adjustable output time (1~99 seconds or toggle)

• Programmable security code

• Egress input and manual mode button

6

Rim-Type Exit Devices

Door Closers

SD-962AR-36A

• Allows exit from inside while locked from outside

• Reversible non-handed design

• For metal or wood doors

• Stainless-steel ¾ ” (19mm) throw-latch bolt

• Fits doors 30”~48” (0.7~1.2m) wide

• Deadbolt latch

Standard device,
Stainless-steel, UL listed

SD-962AR-36M Modern fl at device, Aluminum

• Allows exit from inside while locked from outside

• Reversible non-handed design

• For metal or wood doors

• Stainless-steel ¾ ” (19mm) throw-latch bolt

• Fits doors 36”~48” (0.9~1.2m) wide

• Deadbolt latch

SD-962AR-36G Rugged device, Grade 1, UL listed

SD-961A-36 Push-to-Exit bar

• Rugged, heavy-duty construction

• For 36” (0.9m) doors, actual length is 34.5” (0.88m)

• Built-in dual-contact switches (5A@125VAC)

• Includes 1 Armored Door Cord (SD-969-A18)

SD-969-T15Q/S
SD-969-T15Q/B

SD-969-M15Q/S
SD-969-M15Q/B

• To access, remove cover. Door cord stays in place.
No need to remove door cord from the door

• Surface-mounted

• 15” (39cm) Stainless-steel armored cable

• Terminal blocks with pre-wired cables (8 connections)
for quick, easy, & secure installation (SD-969-T15Q)

Silver, Terminal Blocks
and removable covers
Bronze, Terminal Blocks
and removable covers

Silver, Removable Covers
Bronze, Removable Covers

SD-969-M15Q/BSD-969-T15Q/S

SD-969-S18 Die-cast aluminum end Caps
SD-969-A18 Plastic end caps

SD-C101-SGQ Door weight: 45~330-lb
SD-C101-SBAQ Door weight: 45~330-lb
SD-C101-SBBQ Door weight: 145~330-lb

SD-C101-SGQ

SD-C101-SBAQ

With Back Check

• Heavy-duty Grade 1 door closer for commercial use

• Adjustable sweep speed, latching speed, and
back check

• Forged steel arm (hold open arm optional)

• Non-handed installation

• ANSI Size 1~6

• ANSI 156.4 certi cation

• 2 million life cycles

• Max door width: 60” (1500 mm)

• Max door opening angle: 180° (SD-C101-SBAQ),
130° (SD-C101-SGQ and SD-C101-SBBQ)

SD-C101-SBAQ & SD-C101-SBBQ only:

• Adjustable spring force

• Concealing plastic cover

SD-C101-SBBQ

SD-C121-S Size 2, up to 100-lb (45kg)
SD-C131-SQ Size 3, up to 140-lb (65kg)

• Heavy-duty ANSI Grade 1 steel construction

• Allows exit from inside while locked from outside

• Reversible non-handed design

• For metal or wood doors

• Stainless steel ¾ ” (19mm) throw-latch bolt

• Fits doors 33”~48” (0.8~1.2m) wide

• Deadbolt latch

SD-962H-6LB Escutcheon lever trim, Grade 1

• Compatible with
SD-962AR-36G

• Grade 1, through-bolted design

• Rigid, non-clutch mechanism

• Non-handed design, easily  eld
reversible

SD-962HL-4A Locking door handle

• Compatible with:

- SD-962AR-36A

- SD-962AR-36G

• USD26D Finish

• Non-handed design

SD-969-S18 SD-969-A18

• Designed to house wiring to electric locks or
access control devices mounted in doors

• Surface-mounted

• 18” (46cm) Stainless-steel cable

Access Control Power Supplies

EAP-5D1Q 1 Output
EAP-5D5Q 5 Outputs

EAP-5D1MQ
PD-5PAQ

• 5A@12VDC / 2.5A@24VDC Supply current

• AC Power failure supervision relay with
programmable delay timer (5 secs, 5 mins, or 5 hrs)

• Automatically switch to backup battery

• Field selectable 12/24 VDC output

• Heavy-duty steel case and removable cover

Power supply board only
for EAP-5D1Q

5-Output power distribution
board only for EAP-5D5Q

SD-C121-S

SD-C131-SQ

• Reversible non-handed design

• Adjustable sweep speed and latching speed

• Anodized aluminum body

• Silver  nish

• Forged steel arms

• Includes mounting hardware

EAP-5D5Q

7

SD-7201GC-PEQ
SD-7201GCPE1Q

SD-7201GFPE1Q

• NO/NC
Contacts rated
5A@125VAC

• Stainless-steel
faceplate

SD-7201RCPE1Q

• Similar to SD-7201GCPE1Q,
but with red mushroom-cap
pushbutton

SD-7217GWQ

• NO/NC Contacts rated
5A@125VAC

• White plastic plate

SD-7202GC-PEQ Single-gang

English, Green button
English and Spanish,

Green button
English and Spanish, Green

button, DPDT Switch

SD-7201GC-PEQ SD-7201GCPE1Q

English and Spanish,
Red button

Blank, Green button

SD-7103GC-PEQ Slimline
SD-7223GW-LQ Single-gang, White plastic

SD-7202GC-PEQ SD-7103GC-PEQ SD-7223GW-LQ

• 2” Square illuminated green pushbutton with LED
for longer life

• NO/NC Contacts rated 10A@125VAC
(SD-7202GC-PEQ & SD-7223GW-LQ) or
5A@250VAC (SD-7103GC-PEQ)

• Switchable English, French, and Spanish messages

SD-7286-GWQ

• Large green 2” diameter pushbutton

• Flush mount, protrudes only ⁄” (15mm)

• Aluminum back plate

ts to single-gang box

• ABS plastic front cover
snaps to back plate

• DPDT Momentary switch,
5A@125VAC contact rating

Green button

SD-7275SGEX1Q
SD-7175SGEX1Q

• Illuminated (red/green)
pushbutton

• Vandal resistant design

• 1” Diameter pushbutton

• NO/NC Contacts rated
5A@250VAC

Single-gang
Slimline

SD-7202GC-PTQ Single-gang, Square
SD-7201GAPT1Q

Single-gang, Mushroom,
English and Spanish

SD-7103GC-PTQ Slimline

• Built-in timer, 1~180 seconds

• Illuminated green push­button (SD-7202GC-PTQ
& SD-7103GC-PTQ)
with LED for longer life

• NO/NC Contacts rated
10A@125VAC
(SD-7202GC-PTQ),
3A@24VDC (SD-7201GAPT1Q),
and 5A@250VAC (SD-7103GC-PTQ)

SD-7201GAPT1Q

SD-7103GC-PTQ

SD-7204SGEX1Q Single-gang plate
SD-7104SGEX1Q Slimline plate

• Vandal-resistant

• 1” Diameter pushbutton

• NO/NC Contacts rated
5A@250VAC

SD-7623-GSTQ

• Built-in LED, Field
programmable (red/green)

• Built-in timer, 1~180 sec.

• 12/24 VDC Operation

• NO/NC Contacts rated
3A@24VDC

SD-7217-GSBQ

• Built-in buzzer with adjustable
sound level

• Built-in LED

• 12/24 VDC Operation

• NO/NC Contacts rated
10A@125VAC

RTE plate with dual-color
LED and timer

RTE plate with LED and
adjustable buzzer

SD-7213-GSP
SD-7213-RSP
SD-7113-GSP*
SD-7273-SSP*
SD-7173-SSP*

• Built-in pneumatic timer
requires no external power

• NO/NC Contacts rated
5A@125VAC

• Timer adjustable from
1~60 seconds

* Special order item

SD-6276-SS1Q
SD-6176-SS1Q

SD-6276-SSVQ
SD-6176-SSVQ

• Piezoelectric pushbutton
has no moving parts

• Field-programmable color,
red or green

• Weather resistant (IP65)

• Built-in timer, 1~30
seconds or toggle

SD-7201KBQ
SD-7101KBPE1Q
SD-7101RAEX1Q

• Pushbutton has stainless­steel ring guard

SD-7201KBQ and
SD-7101KBPE1Q Only:

• N.C. Contact rated
1A@125VAC

Single-gang
Slimline

Single-gang,
Manual override button

Slimline,
Manual override button

Single-gang, N.C., Black button
Slimline, N.C., Black button
Slimline, N.O., Red button

SD-8202GT-PEQ
SD-8201GTPE1Q
SD-8103GT-PEQ

• For hard-to-wire
installations

• Built-in RF transmitter
(similar to
SK-919TD1S-UP;
see page 18 for
compatible receivers)

Single-gang, Green
mushroom pushbutton

Single-gang, Red mushroom
pushbutton

Slimline, Green mushroom
pushbutton

Single-gang, Stainless-steel
pushbutton

Slimline, Stainless-steel
pushbutton

SD-7213-GSP

SD-6276-SSVQ

SD-7201KBQ

2” Square, Green,
Illuminated Pushbutton
Green Mushroom
Pushbutton
Slimline, small square
Illuminated Pushbutton

SD-8202GT-PEQ

SD-7113-GSP

SD-6176-SS1Q

SD-7101RAEX1Q

SD-8103GT-PEQ

8

Mini RTEs

SD-5SMG01 Green button, N.O.
SD-5SFS06

SD-5SMG01 SD-5SFS06

• Contacts rated 3A@36VDC

• Large metal buttons

• Surface-mount with backbox

• 21/16”x21/16”x1” (53x53x25 mm)

Surface-mount button, SPDT switch

SD-5RMR03 Red mushroom pushbutton, N.O.
SD-5RFS04
SD-5RFS05

• Contacts rated 3A@36VDC

• Surface-mount with backbox

1

• 3

/8”x13/16”x15/16” (80x30x24 mm)

Surface-mount button, SPDT switch
Illuminated push button,
SPDT switch

SD-5RMR03 SD-5RFS04 SD-5RFS05

SD-5RMG02 Flush-mount

• Contacts rated 3A@36VDC

• Large green metal mushroom button

• N.O. Button

1

• 4

/2”x11/2”x1” (115x40x25 mm)

Rocker Switches

SD-5STW10
SD-5STW07
SD-5STW08
SD-5RTW09

Surface-mount with backbox,
211/16"x211/16"x11/16" (69x69x27 mm)
Surface-mount with backbox,
33/8"x33/8"x1" (86x86x25 mm)
Flush-mount,
33/8"x33/8"x3/4" (86x86x20 mm)
Surface-mount,
33/8"x13/4"x1/2" (86x43x13 mm)

All key locks are patented

SS-090 Series

Key removable in both
ON and OFF positions

SS-090-1H0 Key removable in OFF position

• Two terminals, shunt SPST

• Maintained ON/OFF

• N.O. Turn to close

SS-095 Series

• Two terminals, momentary SPST

• Maintained OFF,
springs back from ON

• N.O. Turn to close

Key removable from
OFF position only

SS-090KN Series Extra keys

• Specify number when ordering (1300 - 1310)

Remote Plates

SS-299Q Single-gang
SS-199Q Slimline

• Stainless steel plate

3

/4” D-hole

with

SS-299Q SS-199Q

SD-72051-V0
SD-71051-V0

SD-72002-V0
SD-71002-V0

• N.C. (Normally Closed)

• Turn to open

• Pre-wired switch

SD-72081-6MQ

• Keyed mortise cylinder (Inc. 2 keys)

• Cylinder removable for easy keying

• DPDT Momentary switch, 5A@125VAC
contact rating, color-coded wires

• Stainless-steel cover conceals screws

Single-gang,
shunt ON/momentary OFF

Slimline, shunt ON/momentary OFF
Single-gang, Maintained ON/OFF
Slimline, Maintained ON/OFF

SD-72002-V0 SD-71002-V0

Single-gang, Mortise Switch

SD-927PKC-NEQ English
SD-927PKC-NSQ Spanish
SD-927PKC-NFQ French

White plate, English,

SD-927PWCQ

• No touch – just wave a hand in front of the sensor

• Sensing range up to 4” (10cm), 12VDC

• Attractive “ring” illuminator turns from red to green
or green to red (selectable)

• Reduces the risk of cross contamination

• Reliable IR technology senses motion

SD-9263-KSVQ
SD-9163-KSVQ

Spanish, and French
Messages Included

SD-927PKC-NSQ SD-927PWCQSD-927PKC-NEQ

Single-gang, English,
Mechanical override

Slimline, English,
Mechanical override

SD-9263-KSQ Single-gang, English
SD-9163-KSQ Slimline, English
SD-9263-KS1Q Single-gang, Spanish
SD-9163-KS1Q Slimline, Spanish

SD-9263-KSVQ SD-9163-KSVQ

• No touch – just wave a hand in front of the sensor

• Weatherproof for outdoor use

• Adjustable sensing range up to 7” (18cm)

• Attractive “ring” illuminator turns from red to green or
green to red (selectable)

• Reduces the risk of cross contamination

• Reliable IR technology senses motion

• 12/24VDC operation

SD-5STW10

SD-5STW08

• Contacts rated 3A@36VDC

• Rocker switch

• SPDT Switch (NO/NC/COM)

SD-5STW07

SD-5RTW09

SD-7428-GSEQ

• 2” Square illuminated
green pushbutton

• Programmable nuisance
delay timer (0~3 seconds)

• Programmable pre-delay
timer (1~30 seconds)

• Form C relay outputs for
lock relay and remote alarm

• Built-in 100dB buzzer • 12~24 VDC Operation

• Fits in standard double-gang backbox

Delayed Egress RTE Plate

SD-9963-KSGQ Post-mount No-Touch Sensor

• “Goose-neck” mounting

• No touch – just wave a
hand in front of the sensor

• Weatherproof for indoor or
outdoor use

• Adjustable sensing range
up to 7” (18cm)

• 12/24 VDC Operation

• Adjustable output time

• Manual override button

9

IP Fixed Rollerball Camera IP Fixed Bullet Camera

EV-N2236-MW4Q

½   ” Sony 2.43 Megapixel
CMOS, 1080p

• 1080p Resolution

• 2.8~12mm 3M Lens

• ½   ” Sony 2.43 Megapixel CMOS

• H.264 Support, dual streams

• Weatherproof for indoor and outdoor use (IP65)

• WDR (Wide Dynamic Range) for clear images in

strong backlight

• 3D-NR (3D Digital Noise Reduction) for cleaner

images in low light

• ONVIF Pro le S

• 18 IR LEDs

• 12VDC and PoE 802.3af Operation

360° IP Camera

EV-N6206-ZW4Q

⁄” 6 Megapixel CMOS,
1080p

EV-N2206-2W4Q

½   ” Sony 2.43 Megapixel
CMOS, 1080p

• 1080p Resolution

• 2.8mm Lens

• ½   ” Sony 2.43 Megapixel CMOS

• H.264 Support, dual streams

• Weatherproof for indoor and outdoor use (IP65)

• ICR Module

• ONVIF Pro le S

• 36 IR LEDs

• 12VDC and PoE 802.3af Operation

IP Varifocal

Rollerball Camera

EV-N2206-MW4Q

½   ” Sony 2.43 Megapixel
CMOS, 1080p

EV-N1206-2W4Q

½   ” Sony 2.12 Megapixel
CMOS, 1080p

• 1080p Resolution

• 2.8mm Lens

• ½   ” Sony 2.12 Megapixel CMOS

• H.264 Support, dual streams

• Weatherproof for indoor and outdoor use (IP65)

• ONVIF Pro le S

• Single IR III LED

• 12VDC and PoE 802.3af Operation

• Cables concealed in bracket to prevent tampering

EV-N1206-MW4Q

½   ” Sony 2.43 Megapixel
CMOS, 1080p

• 1080p Resolution

• ⁄” 6 Megapixel Ambarella S2 CMOS

• 360-Degree vantage point with no blind spots

• Day/Night operation: 0 Lux with LEDs ON,

0.02 Lux with LEDs OFF

• Cables concealed in bracket to prevent tampering

• 3D-DNR (3D Digital Noise Reduction) for clear

images in low light

• Heavy-duty vandal-resistant design

• 12VDC and PoE 802.3af Operation

EV-N4206-2S4Q

• 1080p Resolution

• 2.9mm Lens

• ½   ” Megapixel CMOS

• Designed to easily  t corners in of ce buildings,
elevators, and more

• Weatherproof for indoor and outdoor use (IP66)

• 10/100Mbps Ethernet interface

• ONVIF Support

• 12VDC and PoE 802.3af Operation

½   ” Megapixel CMOS,
1080p

• 1080p Resolution

• 2.8~12mm Varifocal lens

• ½   ” Sony 2.43 Megapixel CMOS

• H.264 Support, dual streams

• Weatherproof for indoor and outdoor use (IP65)

• ICR Module

• ONVIF Pro le S

• 12VDC and PoE 802.3af Operation

• 36 IR LEDs

DRN-104Q 4 Channels
DRN-108Q 8 Channels
DRN-116Q 16 Channels

• ONVIF Pro le S

• High-de nition recording – up to 1920x1080

• H.264 Compression

• Free CMS software and free P2P service

• Remote monitoring via Internet Explorer, Firefox,
Safari, and Chrome

• Supports EXT alarm

• Supports 4 channel inputs, 1 channel alarm output

• Up to 16 channels of 1080p playback @400/480 FPS

• 1080p Resolution

• 2.8~12mm Varifocal lens

• ½   ” Sony 2.43 Megapixel CMOS

• H.264 Support, dual streams

• Weatherproof for indoor and outdoor use (IP65)

• ONVIF Pro le S

• Dual Array IR LEDs (equivalent to 48 LEDs),

40~50m IR range

• 12VDC and PoE 802.3af Operation

• Cables concealed in bracket to prevent tampering

• VGA and HDMI output

• RS-485 Port for PTZ control

• 2 USB Ports

• PC and Mac compatible

• Programmable features such as motion detection,
events, and more

• Easy and convenient  rmware upgrade via USB

• Available without HDD, or with 1TB, 2TB, or 4TB

• Supports up to two 4TB drives

10
