Features of your new Refrigerator
KEY FEATURES OF YOUR NEW REFRIGERATOR
Your Samsung French Door Refrigerator comes equipped with various innovative storage and energy-efficient
features.
• Twin Cooling System
The Refrigerator and Freezer have separate evaporators. Due to this independent cooling system,
the Freezer and Refrigerator cool more efficiently.
Additionally, this separate air flow system prevents food odor of one compartment from seeping into
other compartments.
• Cool Select Pantry
TM
The Cool Select pantryTM is a full-width drawer with adjustable temperature control.
• Bigger & Wider Space
The wide shelf area and pantry provide enough space for larger items like a pizza box, etc.
The wide freezer drawer also provides enough space for 2~3 turkeys.
• Secure Auto Close
The Secure Auto Close feature will automatically close a door that is slightly open.
• Compact Ice Maker
The Ice maker can dispense cubed or crushed ice.
• Digital Display and Temperature Control
• Water Filtration System
• Door Alarm
A helpful beeper alerts you if door is ajar.
• Tilting Pocket
The Tilting pocket can be used to store up to a 16” pizza.
• Auto Pull Out Drawer
The upper drawer in the freezer comes out automatically as you just open the freezer door.
• Easy Handle
Freezer door can be opened with less effort.
• Energy Star
Energy star labeled this product could save your energy costs.
2_ Features
For easy future reference, write the model and serial
number down. You will find your model number and
serial number on the left side of the refrigerator.
Model #
Serial #
Safety Information
SAFETY INFORMATION
Before using your new Samsung French Door Refrigerator, please read this manual thoroughly to
ensure that you know how to safely and efficiently operate the features and functions that your
new appliance offers.
Because the following instruction covers various models, the characteristics of your Refrigerator
may differ slightly from the Refrigerator described in this manual. If you have any question, contact
us at 1-800-SAMSUNG or find help and information online at www.samsung.com.
What the icons and signs in this user manual mean :
WARNING
Hazards or unsafe practices that may result in severepersonalinjuryordeath.
CAUTION
Hazards or unsafe practices that may result in minorpersonalinjuryorproperty
damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when using your
refrigerator, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Thesewarningsignsareheretopreventinjurytoyouandothers.
Pleasefollowthemexplicitly
Keepthismanualinasafeplaceforfuturereference.
SEVERE WARNING SIGNS
Do not plug several appliances into the same power receptacle.
•
Large appliances draw a lot of power. Powering more than one appliance or machine from a single power source
could cause overheating and cause a fire.
Make sure that the power plug is not kinked or damaged by the back of the Refrigerator.
• A damaged power plug may overheat and cause a re.
Do not spray water directly into or on the outside of the Refrigerator/Freezer drawer.
• Water could get into the interior machine parts and cause electric shock.
Do not use aerosols near the Refrigerator.
• Aerosols used near the Refrigerator may cause an explosion or re.
Safety Information _3
Do not putA undue stress on the power cord or place heavy articles on it.
• Placing heavy articles on the power cord create the risk of explosion or fire.
Do not insert the power plug with wet hands.
• It may cause electric shock.
Do not put a container filled with water on the Refrigerator.
• If it spills, it may cause fire or electric shock.
Do not install the Refrigerator in a damp place or place where it may come in contact
with water.
• Wet and/or deteriorated insulation of the internal electrical parts may cause electric shock or fire.
Do not store volatile or flammable substances in the Refrigerator.
• Storing benzene, thinner, alcohol, ether, LP gas and other such products may cause explosions.
Do not disassemble or repair the Refrigerator by yourself.
• You run the risk of fire, appliance malfunctions and/or personal injury. Call your nearest service center for
help from a qualified service technician.
Unplug the Refrigerator before changing the interior light.
• Changing the light while the Refrigerator is plugged in may cause electric shock.
If you wish to dispose of the Refrigerator, remove the doors and seals before throwing
it away.
• The doors(and their seals) can entrap a child if they climb into the Refrigerator.
Make sure that the doors are off, and ensure that no one is suffocated by being locked inside.
The Refrigerator must be safely grounded
• Always make sure that you have grounded the Refrigerator before attempting to investigate or repair any
part of the appliance. Power leakages can cause severe electric shock.
Never use gas pipes, telephone lines or other potential lightning attractors as an
electrical ground.
• Improper use of the grounding plug can result in a risk of electric shock. If it is necessary to use an
extension cord to power the Refrigerator, use only a 3-wire extension cord that has a 3-blade ground
plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extention
cord should be AC 115V~120V, 10A, or more. Additionally, if a grounding adapter is used, make sure the
receptacle box is also fully grounded.
Safety Information
4_ Safety Information
CAUTION SIGNS
Use good judgment when filling the Refrigerator with food and drinks.
• In an overfull Refrigerator, heavy, fragile, bulky or breakable items may fall out and cause personal injury
and/or damage to surrounding objects.
Do not put bottles or glass containers in the Freezer drawer.
• When the contents freeze and then expand, the glass may break and cause personal injury or leave
dangerous glass shards in the Freezer.
If the electrical wall socket is loose, do not insert the power plug.
• There is a risk of electric shock or fire. Have the plug looked at by a licensed electrician.
Never unplug your Refrigerator by pulling on the power cord.
• Always grip the power cord firmly and pull straight out from the outlet. Yanking or pulling on the power
cord may cause a short-circuit, fire and/or electric shock.
• A damaged power cord must be replaced by the manufacturer, a certified service agent or qualified service
personnel.
Do not store articles on the top of the appliance.
• When you open or close the door, the articles may fall and cause personal injury and /or damage to
surrounding objects.
Do not store pharmaceutical products, scientific materials and temperature-sensitive
products in the refrigerator.
• Products that require exact temperature controls should not be stored in the Refrigerator.
Do not allow children to climb, stand or hang on shelves and handles of the
Refrigerator. they could damage the Refrigerator and seriously injure themselves.
Do not sit on the freezer door. the door may break.Do not allow children to climb into
the freezer basket.
if you notice a chemical or burning plastic smell or see smoke, unplug the Refrigerator
immediately and contact your samsung Electronics service Center.
After your Refrigerator is in operation, do not touch the cold surfaces in the Freezer
compartment. Particularly when hands are damp or wet, skin may adhere to these
extremely cold surfaces.
• Skin may stick to the surface and you may get frostbite.
Do not put your hands under the appliance.
• Any sharp edges may cause personal injury.
Safety Information _5
CAUTION
Neverputngersorotherobjectsintothewaterdispenserholeoricechute.
• It may cause personal injury and/or material damage.
IftheRefrigeratorwillnotbeusedforalongperiodoftime(forexample,over
severalmonths),unplugthepowerfromthewall.
• Over time, deterioration in the power cord insulation may cause re.
Donotuseawetordampclothwhencleaningtheplug.
Removeanydustorforeignmatterfromthepowerplugpins.
• A Dirty power plug can increase the risk of re.
IftheRefrigeratorisdisconnectedfromthepowersupply,youshouldwaitfor
atleastveminutesbeforepluggingitbackin.
Donotplacetheequipmentdirectlyinsunlight.
Theappliancemustbepositionedforeasyaccesstopowersource.
Ifthepowercordisdamaged,itmustbereplacedbythemanufacturer,a
certiedserviceagentorqualiedservicepersonnel.
Ifyouhavealongvacationplanned,emptytheRefrigeratorandturnitoff.
• Wipe excess moisture from the inside and leave the doors open to keep odor and mold from
developing.
ServicewarrantyandModication
• Any changes or modications performed by a 3rd party on this nished appliance is not covered
under Samsung warranty service, nor can Samsung be responsible for safety issues that result
from 3rd party modifications.
ChildrencangettrappedinsideRefrigerators.
BeforeyouthrowawayyouroldRefrigeratororFreezer,makesurethatyou;
• Take off the doors.
• Leave all shelves in places so that children may not easily climb inside and shut the door while they
are inside.
Thisapplianceisnotintendedforusebysmallchildrenorinrmpersonswithout
capable,adultsupervision.Smallchildrenshouldbesupervisedwhenusingthe
appliance.
Donotblockairholes
• If the air holes are blocked, especially with plastic bag, refrigerator can be over cooled.
If this cooling period lasts long, water filter will be broken and cause water leakage.
Safety Information
6_ Safety Information
CAUTION
Contents
SETTINGUPYOUR
FRENCHDOORREFRIGERATOR
08
OPERATINGYOURSAMSUNG
FRENCHDOORREFRIGERATOR
21
TROUBLESHOOTING
37
WARRANTY
38
08 Getting ready to install the refrigerator
09 Removing the refrigerator doors
12 Reattaching the refrigerator doors
15 Adjusting the doors
16 Making minor adjustments between doors
17 Adjusting the freezer drawer level
18 Checking the water dispenser line
19 Installing the water line
21 Setting up the refrigerator
22 Using the control panel
23 Using the digital display
24 Controlling the temperature
25 Using the ice and cold water dispenser
26 Parts and Features
27 Storing food
29 Using the Cool Select Pantry™
30 Removing the refrigerator accessories
32 Removing the freezer accessories
33 Cleaning the refrigerator
34 Changing the interior lights
35 Changing the water filter
36 Using the doors
37 Troubleshooting
38 Warranty
Contents _7
Setting up your French Door Refrigerator
GETTING READY TO INSTALL THE REFRIGERATOR
Congratulations on your purchase of the Samsung French Door Refrigerator. We hope you enjoy the state-of-art
features and efficiencies that this new appliance offers.
SelectingthebestlocationfortheRefrigerator
• A location with easy access to the water supply.
• A location without direct exposure to sunlight.
• A location with level (or nearly level) ooring.
• A location with enough space for the Refrigerator doors to
open easily.
• Allow sufcient space for air circulation of the internal
cooling system.
If the Refrigerator does not have enough space, the internal
cooling system may not work properly.
8_ Setting Up
First thing! Make sure that you can easily move your Refrigerator to its final location by measuring doorways
(both width and height), thresholds, ceilings, stairways, etc.
The following chart details the exact height and depth of Samsung French Door Refrigerator.
• Allow clearance to the right, left, back and top when installing. This will help reduce power consumption and keep
your energy bills lower.
• Do not install the Refrigerator where the temperature will go below 50 ºF (10 ºC).
Depth
MODEL
Capacity(Cu.Ft)
Dimension (inch)
Width
Case Height
with Hinge
without Hinge
with Door
without Door
29
35 ¾
69 ⅞
68 ⅝
35 ¾
29 ⅛
CAUTION
When installing, servicing, or cleaning behind the
refrigerator, be sure to pull the unit straight out and
push back in straight after finishing.
Also, make sure your floor supports the full-load
regrigerator.
Otherwise, it may cause floor damage.
RFG297AA
Setting Up _9
01 SETTING UP
Disassemble the Refrigerator doors
1. With the door opened, remove the Top Table cap
(
1
)with a Flat head screwdriver, and close the
door.
Remove the 3 screws holding down the Top Table
and remove the Top Table(
2
).
2
1
2. Disconnect the electrical connector (
3
) above
the upper right door hinge and the 3 electrical
connectors (
4
) above the upper left door hinge.
Disconnect the water tube (
5
) by pulling the tube
fitting (
6
) apart as shown in the picture.
5
6
4
3
REMOVING THE REFRIGERATOR DOORS
If the Refrigerator is too large to pass through your doorway easily, you can remove the refrigerator doors.
Tools you will need
Philips screwdriver Flat-blade screwdriver Wrench Pliers Allen wrench(3/16”)
SETTING UP THE REFRIGERATOR
Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and
functions of the appliance. By completing the following steps, your Refrigerator should be fully operational.
1. Place the Refrigerator in an appropriate location with reasonable clearance between the wall and the
Refrigerator. Refer to installation instructions in this manual.
2. Once the Refrigerator is plugged in, make sure the interior light comes on when you open the doors.
3. Set the Temperature control to the coldest temperature and wait for an hour. The Freezer will get slightly
chilled and the motor will run smoothly.
4. After powering the Refrigerator, it will take a few hours to reach the appropriate temperature. You can
store food and drinks in the Refrigerator after the temperature is sufficiently cool.
Check the accessory list below.
Water filter
(DA29-00003B)
Hex wrench
(DA80-00002C)
Compression fitting
(DA62-00305A)
Compression nut
(DA74-00070B)
Fastener
(DA60-00143B)
Setting up your French Door Refrigerator
10_ Setting Up
3. Remove the 3 hex head bolts (
7
) attached
to the upper left and right door hinges with a
Wrench(10mm).
With a Philips head screwdriver, remove the
ground screw (
8
) attached to the upper left and
right door hinges.
Remove the upper left and right door hinges (
9
).
4. Lift the door straight up to remove.
5. With a Philips head screwdriver, remove the two
screws (
10
) attached to the lower left and right
door hinges.
With an Wrench(10mm), remove the two hex
head bolts (
11
) attached to the lower left and
right door hinges.
Remove the lower left and right door hinges (
11
).
9
7
8
12
10
11
Slot
Slot
Setting Up _11
01 SETTING UP
4. Remove four 10mm hex-head bolts from both sides.
5. Lift the freezer door up from the rails.
2. Remove the tilting pocket(
1
) by pulling on both brackets(
2
)
upward at the same time.
3. Take out the lower basket(
3
) by lifting the basket up from
rail system.
1. Push the upper drawer until it reaches to the cabinet rear wall.
DISASSEMBLE THE FREEZER DRAWER
1
2
3
Slot
Slot
12_ Setting Up
3. Insert the upper hinges (
9
) into the holes at the top of
the doors.
With a Wrench(10mm), insert and tighten the 3 hex
head bolts (
7
) into the upper left and right door
hinges.
With a Philips head screwdriver, insert and tighten the
ground screw (
8
) into the upper left and right door
hinges.
12
7
8
9
10
11
2. Place the hole in the bottom of the door over the lower
hinge(
12
).
Be careful not to miss the hinge cap because it can
be easily taken off.
12
Setting up your French Door Refrigerator
Assemble the Refrigerator doors
1. Reattach the lower left and right door hinges(
12
) .
With a Philips head screwdriver, insert and tighten the
2 screws (
10
) into the lower left and right door hinges.
With a Wrench(10mm), insert and tighten the 2 hex
head bolts (
11
) into the lower left and right door hinges.
REATTACHING THE REFRIGERATOR DOORS
Loading...
