Sears 005735-0, 005734-0 User Manual
GP Series Portable Generator
COMMERCIAL • INDUSTRIAL • RESIDENTIAL
MODELS: 005734-0 (15,000 Watt)
005735-0 (17,500 Watt)
Owner’s
Manual
• SAFETY
• ASSEMBLY
• OPERATION
• TROUBLESHOOTING
• WARRANTY
AUTHORIZED DEALER SUPPORT:
www.generac.com
or
1-888-436-3722
Table of Contents
OWNER'S MANUAL
Introduction ..............................................................................1
Read This Manual Thoroughly .................................................1
Safety Rules ............................................................................2
Standards Index ...............................................................................3
Section 1 – General Information ..............................................4
1.1 Unpacking ................................................................................4
1.2 Assembly .................................................................................4
Section 2 – Operation ..............................................................6
2.1 Know The Generator ................................................................6
2.2 Hourmeter ...............................................................................7
2.3 Cord Sets and Connection Plugs ..............................................7
2.4 How To Use The Generator ......................................................8
2.5 Don’t Overload The Generator ..................................................9
2.6 Wattage Reference Guide .........................................................9
2.7 Before Starting The Generator ................................................10
2.8 To Start The Engine ................................................................10
2.9 Stopping The Engine ..............................................................11
2.10 Automatic Idle Control ............................................................11
2.11 Cold Weather Operation/De-Icer .............................................11
2.12 Low Oil Pressure Shutdown System .......................................11
2.13 Charging a Battery .................................................................12
Section 3 – Maintenance .......................................................12
3.1 Maintenance Schedule ...........................................................12
3.2 Product Specifications ...........................................................12
3.3 General Recommendations ....................................................13
3.4 Service Air Cleaner ................................................................14
3.5 Clean Spark Arrestor Screen ..................................................14
3.6 Adjusting Valve Clearance ......................................................15
3.7 General ................................................................................15
3.8 Long Term Storage.................................................................15
3.9 Other Storage Tips .................................................................16
Section 4 – Troubleshooting ..................................................17
4.1 Troubleshooting Guide ............................................................17
Section 5 – Warranty .............................................................18
MANUAL DEL PROPIETARIO .................................21
Introducción .................................................................................. 23
Lea este manual completamente ................................................ 23
Reglas de seguridad .................................................................... 24
Índice de estándares ..............................................................................25
Sección 1 – Información General ............................................. 26
1.1 Desempaque ................................................................................. 26
1.2 Ensamble ...................................................................................... 26
Sección 2 – Operación .............................................................28
2.1 Conozca el generador ................................................................... 28
2.2 Medidor de horas .......................................................................... 29
2.3 Juego de cuerdas y conectores .................................................... 29
2.4 Cómo usar el generador ............................................................... 30
2.5 No sobrecargue el generador ....................................................... 31
2.6 Guía de referencia de potencias ................................................... 31
2.7 Antes de arrancar el generador .................................................... 32
2.8 Arranque del motor .......................................................................33
2.9 Detener el motor ...........................................................................33
2.10 Control automático de espera (idle) .............................................. 34
2.11 Operación en clima frío / descongelador ...................................... 34
2.12 Sistema de apagado por baja presión de aceite .......................... 34
2.13 Cargar una batería ........................................................................ 34
Section 3 – Mantenimiento ....................................................... 35
3.1 Programa de mantenimiento ......................................................... 35
3.2 Especificaciones del producto ....................................................... 35
3.3 Recomendaciones generales ........................................................ 35
3.4 Servicio al limpiador de aire .......................................................... 36
3.5 Limpieza de la pantalla de supresión de chispa ........................... 37
3.6 Ajuste de claridad de la válvula .................................................... 37
3.7 General ....................................................................................... 38
3.8 Almacenamiento a largo plazo ...................................................... 38
3.9 Otros consejos para almacenamiento........................................... 38
Sección 4 – Detección de problemas .....................................39
4.1 Guía de detección de problemas .................................................. 39
Sección 5 – Garantía ................................................................. 40
MANUEL D'ENTRETIEN..........................................43
Introduction ............................................................................45
Lire attentivement ce manuel ................................................45
Règles de sécurité .................................................................46
Index des normes ..........................................................................47
Section 1 – Informations générales .......................................48
1.1 Déballage ...............................................................................48
1.2 Montage ................................................................................48
Section 2 – Fonctionnement ..................................................50
2.1 Bien connaître le générateur ...................................................50
2.2 Horomètre..............................................................................51
2.3 Cordons et connecteurs .........................................................51
2.4 Utilisation du générateur .........................................................52
2.5 Ne pas surcharger le générateur .............................................53
2.6 Guide de référence de wattage ...............................................53
2.7 Avant le démarrage du générateur ..........................................54
2.8 Démarrage du moteur ............................................................55
2.9 Arrêt du moteur......................................................................55
2.10 Commande de ralenti automatique .........................................56
2.11 Fonctionnement par temps froid / dégivreur ............................56
2.12 Système d'arrêt de basse pression d'huile ..............................56
2.13 Chargement de la batterie.......................................................56
Section 3 – Maintenance .......................................................57
3.1 Programme de maintenance ...................................................57
3.2 Caractéristiques techniques des produits ................................57
3.3 Recommandations générales .................................................57
3.4 Filtre à air ...............................................................................58
3.5
Nettoyage de l'
3.6 Réglage du jeu des soupapes.................................................59
3.7 Généralités .............................................................................60
3.8 Stockage à long terme ...........................................................60
3.9 Autres conseils de stockage ...................................................60
Section 4 – Dépannage ..........................................................61
4.1 Guide de dépannage ..............................................................61
Section 5 – Remarques .........................................................62
Section 6 – Garantie ..............................................................64
écran pare-étincelles .........................................59
INTRODUCTION
Thank you for purchasing this model by Generac Power Systems, Inc.®
This model is a compact, high performance, air-cooled, engine driven
generator designed to supply electrical power to operate electrical loads
where no utility power is available or in place of utility due to a power
outage.
READ THIS MANUAL THOROUGHLY
If any portion of this manual is not understood, contact the nearest
Authorized Dealer for starting, operating and servicing procedures.
Throughout this publication, and on tags and decals affixed to the
generator, DANGER, WARNING, CAUTION and NOTE blocks are used to
alert personnel to special instructions about a particular operation that
may be hazardous if performed incorrectly or carelessly. Observe them
carefully. Their definitions are as follows:
DANGER
After this heading, read instructions that, if not strictly
complied with, will result in serious personal injury,
including death and/or property damage.
After this heading, read instructions that, if not strictly
complied with, may result in serious personal injury
and/or property damage.
After this heading, read instructions that, if not strictly
complied with, could result in damage to equipment
and/or property.
NOTE:
After this heading, read explanatory statements that require special
emphasis.
These safety warnings cannot eliminate the hazards that they indicate.
Common sense and strict compliance with the special instructions while
performing the service are essential to preventing accidents.
Four commonly used safety symbols accompany the DANGER, WARNING
and CAUTION blocks. The type of information each indicates is as
follows:
This symbol points out important safety information
that, if not followed, could endanger personal safety
and/or property of others.
This symbol points out potential explosion
hazard.
This symbol points out potential fire hazard.
This symbol points out potential electrical shock
hazard.
The operator is responsible for proper and safe use of the equipment.
We strongly recommend that the operator read this manual and
thoroughly understand all instructions before using the equipment.
We also strongly recommend instructing other users to properly start
and operate the unit. This prepares them if they need to operate the
equipment in an emergency.
DANGER
Using a generator indoors WILL KILL YOU IN
MINUTES. Exhaust contains carbon monoxide, a
poison gas you cannot see or smell.
NEVER use in the home, or in partly enclosed areas
such as garages. ONLY use outdoors and far from
open windows, doors, vents, and in an area that will
not accumulate deadly exhaust gas.
Always disconnect the spark plug wire and place
the wire where they cannot contact the spark plug
to prevent accidental starting when setting up,
transporting, adjusting or making repairs to the
generator.
The generator produces dangerously high voltage that can cause •
extremely hazardous electrical shock. Avoid contact with bare wires,
terminals, etc. Never permit any unqualified person to operate or
service the generator.
Never handle any kind of electrical cord or device while standing •
in water, while barefoot or while hands or feet are wet. Dangerous
electrical shock will result.
The National Electric Code requires the frame and external electrically •
conductive parts of the generator be properly connected to an
approved earth ground. Local electrical codes may also require
proper grounding of the generator. Consult with a local electrician for
grounding requirements in the area.
Do not use worn, bare, frayed or otherwise damaged electrical cord •
sets with the generator.
Operate generator only on level surfaces and where it will not be •
exposed to excessive moisture, dirt, dust or corrosive vapors.
Gasoline is highly • FLAMMABLE and its vapors are EXPLOSIVE. Do
not permit smoking, open flames, sparks or heat in the vicinity while
handling gasoline. Avoid spilling gasoline on a hot engine. Comply with
all laws regulating storage and handling of gasoline.
Never add fuel while unit is running. Allow unit to
cool entirely before adding fuel.
Do not overfill the fuel tank. Always allow room for
fuel expansion. If tank is over-filled, fuel can overflow
onto a hot engine and cause FIRE or an EXPLOSION.
Never store generator with fuel in tank where gasoline vapors might •
reach an open flame, spark or pilot light (as on a furnace, water heater
or clothes dryer). FIRE or EXPLOSION may result.
Generator exhaust gases contain • DEADLY carbon monoxide gas. This
dangerous gas, if breathed in sufficient concentrations, can cause
unconsciousness or even death. Operate this equipment only in the
open air where adequate ventilation is available.
1
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS – The manufacturer suggests that these rules for safe operation be copied and posted near the unit's
installation site. Safety should be stressed to all operators and potential operators of this equipment.
Never start or stop the unit with electrical loads connected to •
receptacles AND with connected devices turned ON. Start the engine
and let it stabilize before connecting electrical loads. Disconnect all
electrical loads before shutting down the generator.
Do not insert objects through unit's cooling slots.•
Never operate generator: • Indoors or in any enclosed compartment; in
rain; if connected electrical devices overheat; if electrical output is lost;
if engine or generator sparks; if flames or smoke are observed while
unit is running; if unit vibrates excessively.
NOTE:
This generator is equipped with a spark arrestor muffler. The spark
arrestor must be maintained in effective working order by the owner/
operator. In the State of California, a spark arrestor is required by law
(Section 4442 of the California Public Resources Code). Other states
may have similar laws. Federal laws apply on federal lands.
Study these SAFETY RULES carefully before installing, operating or
servicing this equipment. Become familiar with this Owner’s Manual and
with the unit. The generator can operate safely, efficiently and reliably only
if it is properly installed, operated and maintained. Many accidents are
caused by failing to follow simple and fundamental rules or precautions.
WARNING
:
The engine exhaust from this product contains
chemicals known to the state of California to cause
cancer, birth defects or other reproductive harm.
WARNING
This product contains or emits chemicals
known to the state of California to cause
cancer, birth defects or other reproductive harm.
The manufacturer cannot anticipate every possible circumstance that
might involve a hazard. The warnings in this manual, and on tags and
decals affixed to the unit are, therefore, not all-inclusive. If using a
procedure, work method or operating technique the manufacturer does
not specifically recommend, satisfy yourself that it is safe for others. Make
sure the procedure, work method or operating technique chosen does not
render the generator unsafe.
Despite the safe design of this generator, operating
this equipment imprudently, neglecting its
maintenance or being careless can cause possible
injury or death. Permit only responsible and capable
persons to operate or maintain this equipment.
Potentially lethal voltages are generated by these
machines. Ensure all steps are taken to render the
machine safe before attempting to work on the
generator.
Parts of the generator are rotating and/or hot during
operation. Exercise care near running generators.
Never operate in an enclosed area or indoors.•
For safety reasons, the manufacturer recommends that the maintenance •
of this equipment is carried out by an Authorized Dealer.
The engine exhaust fumes contain carbon monoxide, which can be •
DEADLY. This dangerous gas, if breathed in sufficient concentrations,
can cause unconsciousness or even death. This exhaust system must
be properly maintained. Do nothing that might render the exhaust
system unsafe or in noncompliance with any local codes and/or
standards.
Keep hands, feet, clothing, etc., away from drive belts, fans, and other •
moving or hot parts. Never remove any drive belt or fan guard while
the unit is operating.
Adequate, unobstructed flow of cooling and ventilating air is critical •
to correct generator operation. Do not alter the installation or permit
even partial blockage of ventilation provisions, as this can seriously
affect safe operation of the generator. The generator MUST be operated
outdoors.
When working on this equipment, remain alert at all times. Never work •
on the equipment when physically or mentally fatigued.
Inspect the generator regularly, and contact the nearest Authorized •
Dealer for parts needing repair or replacement.
Before performing any maintenance on the generator, disconnect its •
battery cables to prevent accidental start up. Disconnect the cable
from the battery post indicated by a NEGATIVE, NEG or (–) first.
Reconnect that cable last.
Never use the generator or any of its parts as a step. Stepping on the •
unit can stress and break parts, and may result in dangerous operating
conditions from leaking exhaust gases, fuel leakage, oil leakage, etc.
DANGER
GENERAL HAZARDS
2
IMPORTANT SAFETY INSTRUCTIONS
ELECTRICAL HAZARDS
All generators covered by this manual produce dangerous electrical •
voltages and can cause fatal electrical shock. Utility power delivers
extremely high and dangerous voltages as does the generator when it
is in operation. Avoid contact with bare wires, terminals, connections,
etc., while the unit is running. Ensure all appropriate covers, guards
and barriers are in place before operating the generator. If work must
be done around an operating unit, stand on an insulated, dry surface
to reduce shock hazard.
Do not handle any kind of electrical device while standing in water, while •
barefoot, or while hands or feet are wet. DANGEROUS ELECTRICAL
SHOCK MAY RESULT.
The National Electrical Code (NEC) requires the frame and external •
electrically conductive parts of the generator to be connected to an
approved earth ground. Local electrical codes also may require proper
grounding of the generator electrical system.
In case of accident caused by electric shock, immediately shut down •
the source of electrical power. If this is not possible, attempt to free the
victim from the live conductor. AVOID DIRECT CONTACT WITH THE
VICTIM. Use a non-conducting implement, such as a rope or board,
to free the victim from the live conductor. If the victim is unconscious,
apply first aid and get immediate medical help.
Never wear jewelry when working on this equipment. Jewelry can •
conduct electricity resulting in electric shock, or may get caught in
moving components causing injury.
EXPLOSION HAZARDS
Do not smoke around the generator. Wipe up any fuel or oil spills •
immediately. Ensure that no combustible materials are left on or
near the generator, as FIRE or EXPLOSION may result. Keep the area
surrounding the generator clean and free from debris.
Gasoline is extremely EXPLOSIVE. •
STANDARDS INDEX
In the absence of pertinent standards, codes, regulations and laws,
the published information listed below may be used as a guideline for
operation of this equipment. Always reference the latest revision available
for the standards listed.
1. NFPA No. 70, NFPA HANDBOOK OF NATIONAL ELECTRIC CODE.
2. Article X, NATIONAL BUILDING CODE, available from the American
Insurance Association, 85 John Street, New York, N.Y. 10038.
3. AGRICULTURAL WIRING HANDBOOK, available from the Food and
Energy Council, 909 University Avenue, Columbia, MO 65201.
4. ASAE EP-3634, INSTALLATION AND MAINTENANCE OF FARM
STANDBY ELECTRICAL SYSTEMS, available from the American
Society of Agricultural Engineers, 2950 Niles Road, St. Joseph, MI
49085.
5. NFPA No. 30, FLAMMABLE AND COMBUSTIBLE LIQUIDS CODE.
FIRE HAZARDS
For fire safety, the generator must be operated and maintained properly. •
Operation must always comply with applicable codes, standards, laws
and regulations. Adhere strictly to local, state and national electrical
and building codes. Comply with regulations the Occupational Safety
and Health Administration (OSHA) has established. Also, ensure that
the generator is operated in accordance with the manufacturer’s
instructions and recommendations. Do not alter the construction of the
generator or change controls which might create an unsafe operating
condition.
Keep a fire extinguisher near the generator at all times. Extinguishers •
rated “ABC” by the National Fire Protection Association are appropriate
for use on the standby electric system. Keep the extinguisher properly
charged and be familiar with its use. If there are any questions
pertaining to fire extinguishers, consult the local fire department.
Avoid spilling gasoline on a hot engine. NEVER add fuel while the unit is •
running. Allow unit/engine to cool entirely before adding fuel. DO NOT
overfill the fuel tank. Always allow room for fuel expansion. NEVER fill
fuel tank indoors.
3
Section 1 – General Information
1.1 UNPACKING
Set the palleted carton on a rigid flat surface.•
Remove staples along bottom of carton that fasten carton to pallet. •
Open carton from top.
Remove all packaging material.•
Remove separate accessory box.•
Lift carton off the generator.•
Remove generator from shipping pallet by removing bolts through the •
shipping brackets (Figure 1).
Figure 1 - Bracket Removal
Shipping
Bracket (x4)
1.2 ASSEMBLY
The generator requires some assembly prior to using it. If problems arise
when assembling the generator, please call the Generator Helpline at
1-888-436-3722.
1.2.1 ASSEMBLING THE WHEEL KIT
The wheel kit is designed to greatly improve the portability of the
generator. A socket wrench with a 9/16” socket, a 1/2” socket, a 1/2”
wrench and a pair of pliers are the tools that will be needed for assembly
of the wheel kit.
NOTE:
The wheel kit is not intended for over-the-road use.
Refer to Figure 2 and install the wheel kit as follows:•
Place the generator on a hard flat surface.•
Stand at the engine end of the unit and gently tilt the generator forward, •
high enough to place wooden blocks beneath the cradle. This will allow
space to install the wheel assemblies.
Attach an axle bracket assembly with attached sleeve to either side of •
the frame. Ensure the sleeve faces outward.
Slide the axle through the sleeves on the axle brackets.•
Slide one wheel with flat washer to the outside and a spacer to the •
inside onto each end of the axle. Make sure the air inflation valve on
the wheel is facing outward.
Insert retaining pins and using pliers, bend out the ends to prevent the •
pins from falling out of the axle. Remove the wooden blocks.
1.1.1 ACCESSORY BOX
Check all contents. If any parts are missing or damaged locate an
authorized dealer at 1-888-436-3722.
Contents include:
Wheel Axle • Bolt-on tubular handle•
2 – Washers • 2 – Pneumatic Wheels•
2 – Wheel Spacers • 2 – Axle Bracket Assemblies•
2 – Cotter Pins • Bolt-on Foot•
2 – Spark Plugs • Spark Plug Wrench•
Air Filter • Oil Filter•
Pre-cleaner • Battery Charge Cable•
6 – Carriage Bolts, Washers, • Nuts
1.2.2 ASSEMBLING THE HANDLE
Attach the handle by aligning one side of the handle on the cradle, then •
spread the handle around the cradle and let it spring into place. Secure
the handle to the frame using the 5/16’ hex head bolts provided. Check
each fastener to ensure that it is secure.
Using the handle, lift the unit high enough to place wooden blocks •
under the unit. Attach the front support foot to the underside of the
cradle using the 3/8” carriage bolts provided.
Remove the shipping brackets from the cradle, if it has not already •
been done.
4
4
Section 1 - General Information
Figure 2 - Handle Assembly
1.2.3 BATTERY CONNECTION
The battery shipped with the generator has been provided fully charged. •
Caution must be taken when connecting the battery.
NOTE:
A battery may lose some of it’s charge when not in use for prolonged
periods of time.
Cut the tie wrap cable holding the RED and BLACK battery cables to •
the stator.
Connect the RED battery cable to the battery Positive terminal (+). •
After making sure that the connection is tight, slip the rubber boot over
the terminal connection.
Connect the BLACK battery cable to the battery Negative terminal (–). •
Make sure the connection is tight.
Double check all connections to ensure they are in the correct location •
and secure. See Figure 3.
Figure 3 - Battery Connections
Negative
Cable
5
Positive
Cable
5
Loading...
