instructions for:
I
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Universal cable ejection tool set
model no: vs9201.v2
thank you for purchasing a sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
refer to
instruction
manual
Warning:
electricity
Wear
protective
clothing
Wear
eye
protection
1. saFetY
8 Do not use cable ejection tools on 240V circuits, the tools are intended for use on 12/24V automotive wiring systems only.
9 ensure that the vehicle ignition is turned off before releasing connectors.
WarninG! use extreme caution when working near ignition coils, distributor caps, ignition wires and spark plugs. these components
create hazardous voltages when the engine is running.
9 remove personal metallic items such as rings, bracelets, necklaces and watches. A battery can
produce a short-circuit current which is high enough to weld such items to the vehicle and cause
severe burns.
9 ensure that hands and clothing are clear of fan blades, belts and other moving or hot parts of the
engine. remove ties and contain long hair.
9 Wear safety eye protection and protective clothing. if working near a battery avoid touching eyes.
9 Wash immediately with soap and water if battery acid contacts skin or clothing.
9 if acid enters eye, flush eye immediately with cool, clean running water for at least 15 minutes and
seek immediate medical attention.
8 Do not smoke or allow a spark or flame when in the vicinity of a battery or engine.
9 ensure that the cable release tools are in good condition before use. Do not use if damaged.
9 Keep tools and other items away from the engine and ensure that you can see the battery and
working parts of engine clearly.
9 Keep children and unauthorised persons away from the work area.
8 Do not use the cable ejection tools for a task for which they are not designed.
WarninG: the warnings, cautions and instructions discussed in this manual cannot cover all possible conditions and situations that may
occur. it must be understood that common sense and caution are factors which cannot be built into this product, but must be applied by
the operator.
2. i introDUction
reduce time spent on, and damage to, vehicle electrical systems with these connector tools. set consists of cable extraction, contact ejection
and contact dismantling tools. covers a wide range of connectors, including Kabelex. Vehicle coverage: BmW, daimler/chrysler, fiat, ford, mAn,
mazda, Porsche, PsA, renault, saab, seat, skoda, VAG, Vauxhall/opel. supplied in a blow moulded storage case.
© Jack sealey limited
Original Language Version
Vs9201.V2 issue 1 15/01/18
3.
tool no. description Application
ce01 (+11) ejection tool for contact sizes Ø1.5mm BmW, daimler/chrysler, fiat, mAn, Porsche, seat, skoda, Vauxhall/opel,
VW/Audi
ce02 (+12) ejection tool for contact sizes Ø3.5mm BmW, daimler/chrysler, fiat, mAn, Porsche, seat, skoda, Vauxhall/opel,
VW/Audi
ce05 (+15) ejection tool for contact sizes Ø3.5mm ford, opel, PsA, renault
ce11 dismantling sleeve (use with ce01) BmW, daimler/chrysler, fiat, mAn, Porsche, seat, skoda, Vauxhall/opel,
VW/Audi
ce12 dismantling sleeve (use with ce02) BmW, daimler/chrysler, fiat, mAn, Porsche, seat, skoda, Vauxhall/opel,
VW/Audi
ce15 dismantling sleeve (use with ce05) ford, PsA, renault, Vauxhall/opel
ce53 cable extractor tool for plugs with one
release channel 2.8 and 5.8mm
ce54 cable extractor tool for plugs with one
release channel 2.8 and 5.8mm
ce56 cable extractor tool micro-timer ii and iii
one release contact Ø1.6mm
ce57 for at plug sockets with asymmetrical
latches in terminals with 2 release channels
ce58 for at plug sockets with asymmetrical
latches in terminals with 2 release channels
ce59 cable extractor tool for maxi-Power timer
contacts 9.5mm
ce62 cable extractor tool for Pit-Pod contacts All vehicle makes
ce74 cable extractor tool for micro-timer 1
contacts and ABs plug-in housing Ø1.6mm
ce91 cable extractor tool for plugs with two
release channels 2.8 & 5.8mm
BmW, daimler/chrysler, ford, mAn, Porsche, PsA, renault, seat, skoda,
Vauxhall/opel, VW/Audi
BmW, PsA, renault
daimler/chrysler, Porsche, PsA, renault, saab, seat, skoda, Vauxhall/
opel, VW/Audi
seat, skoda, VW/Audi
seat, skoda, VW/Audi
daimler/chrysler, VW/Audi
fiat, ford, mazda, PsA, renault, saab, Vauxhall/opel, VW/Audi
BmW, daimler/chrysler, fiat, ford, mAn, PsA, renault, saab, Vauxhall/
opel, VW/Audi
note: it is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
environMent Protection
recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
sealey Group, Kempson Way, suffolk business Park, bury st edmunds, suffolk. iP32 7ar
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Original Language Version© Jack sealey limited
Vs9201.V2 issue 1 15/01/18
