Sealey VS7100 Instruction Booklet

INSTRUCTIONS FOR:
ENGINE OIL FUNNEL - BMW, MERCEDES, TOYOTA/LEXUS, VAG
MODEL No: VS7100
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY . NOTE THE SAFE OPERA TIONAL REQUIREMENTS, W ARNINGS AND CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
rWARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools. × DO NOT use tools if damaged.
üMaintain tools in a good, clean condition for best and safest performance. üWear approved eye protection. A full range of personal safety equipment is available from your Sealey dealer. üWear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair. ü Keep children and unauthorised persons away from the work area. üWhen not in use, store in a secure, childproof location.
2. INTRODUCTION & APPLICATIONS
A completely new design of oil funnel that fastens and seals into the engine ller. Hands free operation with no mess or spills.
Vehicle Applications:
Make Model Year
Audi A3 2006-2012 Audi A4 1996-2008 Audi A4 Quattro 1996-2009 Audi A5 Quattro 2008 Audi A6 Quattro 1995-2011 Audi A8 1997-1999 Audi A8 Quattro 1997-2012 Audi Allroad Quattro 2001-2005 Audi Q7 2007-2010 Audi R8 2008 Audi RS4 2007-2008 Audi RS6 2003 Audi S4 1992-2008 Audi S6 1995-2003 Audi S8 2001-2009 Audi TT 2000-2009 Audi TT Quattro 2004-2012 BMW 318i 1984-1996 BMW 318is 1991-1997 BMW 318ti 1995-1999 BMW 323i 1999-2002 BMW 325Ci 2001-2004 BMW 325i 1987-2005 BMW 325is 1987-1991 BMW 328i, 328is 1996 BMW 330i, 330Ci 2001-2004 BMW 540i 1997-2002 BMW 545i 2004 BMW 740i, 740iL 1993-1999 BMW 745i, 745Li 2002-2004 BMW 750iL 1988-2001 BMW 760i, 760Li 2003-2004 BMW X3 2004 BMW X5 2001-2004 BMW Z3 1996-2002 BMW Z4 2003-2004 BMW Z8 2000 Lexus CT200h 2011-2012 Lexus ES300 2000-2006 Lexus ES350 2007-2008, 2012 Lexus GS350, GS450h 2009-2011
Lexus GS430, GS300 2006 Lexus GS460, RX450h 2010-2012 Lexus GX470 2008-2009 Lexus HS250h 2010-2011 Lexus IS250 2007-2010 Lexus IS250 2006 Lexus IS350 2006-2012
Make Model Year
Lexus LS460, RX350 2007-2012 Lexus LS600h 2008-2012 Lexus LX450 1996-1997 Lexus LX470 1998-2001, 2006 Lexus LX570 2008-2011 Lexus RX300 1999-2006 Lexus RX400h 2006-2008 Lexus SC430 2008-2010 Mercedes E320 1996-2005 Mercedes ML320 1998-2000 Mercedes S320 1996-1999 Mercedes S500, SL500 1997-1999 Mercedes S600 1997-2002 Mercedes SL320 1996-1997 Mercedes SL600 1997-1999 Mercedes SLK230 1998-1999 Porsche Cayenne 2006-on Scion tC 2005-2007 Scion xB 2012 Scion xD 2008-2011 Toyota 4Runner 1993-2011 Toyota Avalon 2005-2009 Toyota Camry 1983-2012 Toyota Celica 1983-2005 Toyota Corolla 2003-2011 Toyota Echo 2000-2002 Toyota FJ Cruiser 2007-2012 Toyota Highlander 2001-2012 Toyota Land Cruiser 1972-2010 Toyota Matrix, Yaris 2010-2011 Toyota MR2 Spyder 2004 Toyota Prius 2006 Toyota RAV4 2005-2011 Toyota Sequoia 2004-2010 Toyota Sienna 1998-2006, 2008-2010 Toyota Solara 2000-2008 Toyota Supra 1997-1998 Toyota Tacoma 1995-2010 Toyota Tundra 2004-2011 Toyota Venza 2009-2011 VW Beetle 1973-2010 VW CC 2009-2012 VW Eos 2007-2008 VW EuroVan 1999-2003 VW Fox 2006-2007 VW Golf 1983-2010 VW Passat 2004-2006 VW Touareg 2004-2012
© Jack Sealey Limited
Original Language Version
VS7100 Issue: 1 - 03/07/13
3. INSTRUCTIONS
Locate and remove oil ller cap (if unsure, consult vehicle handbook for location) and lock VS7100 funnel in place using the bayonet
xing previously occupied by the ller cap.
VS7100
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a
recycling centre and disposed of in a manner which is compatible with the environment.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product. WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim. INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
Environmental Protection.
