Sealey tSt10 Instruction Booklet

instructions for

I

MPORTANT:

PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

temporary puncture repair kit

model no: tSt10

thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.

refer to

instruction

manual

1. SaFety

 WarninG! ensure Health & safety, local authority, and general workshop practice regulations are adhered to when using this tool.

  WarninG! this kit contains glue. if you require a safety data sheet, contact your sealey dealer.

 WarninG! familiarise yourself with the specific applications and limitations of the kit, as well as any potential hazards.
9 this kit should be used in conjunction with inspection maintenance procedures recommended in the vehicle manufacturer’s manual.
9 ensure that the kit is correct for the task.
9 Wear the appropriate personal protective equipment for the task. A full range is available from your sealey dealer.

8 Do not use the kit for any purpose other than that for which it is designed.

9 ensure that the vehicle is properly supported with axle stands before working under the vehicle.
9  ensure there is adequate lighting prior to using the kit. A range of inspection lamps are available from your sealey dealer.
9 Keep children and unauthorised persons away from the working area.

8  Do not use the kit if any parts are damaged or missing, as this may cause failure and/or personal injury.
8  Do not use the kit when you are tired, or under the influence of alcohol, drugs or intoxicating medication.

9 After use, store in a safe, dry childproof area.

2. introDuction

Ideal for repairing punctures on tubeless tyres tted to agricultural and off road vehicles. Can also be used as a temporary/emergency x on cars

and commercial vehicles. Allows tyre to be repaired without removing the tyre from the wheel. not to be used as a permanent repair for road
vehicles.

3. SpeciFication

model no: .................................................................... tst10

contents:...rasp, insertion needle, repair strips x30, glue 20g

4. operation

4.1. remove object (causing puncture) from tyre if required.

4.2. Fit collar onto insertion needle by using hex key to undo grub screw, (see g.1).

4.3. clean/widen puncture hole with rasp.

4.4. fit strip in the middle of the insertion needle, with 50% protruding from each end.

4.5. cover the strip with glue.

4.6. Push the strip most of the way through the tyre with the insertion needle, leave 20mm of the strip sticking out.

4.7. As you pull the insertion needle back out, use your other hand to push down the collar, so that the tool nips on the strip and the strip is
pulled back out of the tyre.

4.8. there will now be a loop and 2 ends protruding from tyre, that need to be cut off.

4.9. clean items in the kit and remove protector from insertion needle. store kit in a safe, childproof location.

© Jack sealey limited

Original Language Version

tst10 | issue:3 (l) 06/01/17

Fig.1

parts support is available for this product. to obtain a parts listing and/or diagram,

please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.

important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which will be required for any claim.

© Jack sealey limited

recycle unwanted materials instead of disposing of them as waste. all tools, accessories and packaging should be

sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.

When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)

into approved containers and dispose of the product and the fluids according to local regulations.
