I
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Model no: tp80
thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
Refer to
instructions
1. Safety
WarnInG! This pump must be used in accordance with Health & Safety, government, local authority, and water authority rules and
regulations.
9 Familiarise yourself with application and limitations, as well as the potential hazards peculiar to the pump.
9 Maintain the pump in good condition. Keep the pump clean.
9 Replace or repair damaged parts (use an authorised service agent). Use genuine parts only. Non authorised parts may be dangerous
and will invalidate the warranty.
8 do not operate the pump if any parts are damaged or missing as this may cause failure and/or personal injury.
8 do not use the pump for any purpose other than for which it is designed.
8 do not operate pump out of liquid. The pump pick up area must be completely submerged during operation.
8 do not operate the pump during freezing temperatures. do not leave the pump in liquid that may freeze.
8 do not carry the pump by its outlet pipe.
9 When not in use rinse pump, drain out any liquid and store in a frost free, safe location.
WarnInG! do not allow uncontrolled discharge of contaminated water/harmful chemicals thus polluting the environment.
2. IntroductIon
easily transfers uid from 5, 10 & 20ltr Sealey jerry cans. Compatible for use with diesel, kerosene and water. Hook storage design allows
pump to attach onto jerry can and features a height adjustable control to accommodate different sized containers. Fitted with auto-stop feature
to prevent overlling. Suitable for the full range of Sealey jerry cans and other compatible brands. Operated by an electric motor powered by 2
x AA batteries (not included).
3. SpecIfIcatIon
model no: ..................................................................... tp80
Hose length: ..............................................................700mm
Flow Rate: ..................................................................9ltr/min
Battery: ................................................. 2 x AA (not included)
Weight .........................................................................0.28kg
g.1
g.2
4. battery fIttInG
4.1. Slide battery compartment open as in g.1.
4.2. Insert 2 x AA batteries as in g.2, observing the correct polarity.
4.3. Replace sliding cover.
4.4. Removal of the batteries is the reverse of 4.1 to 4.3.
© Jack Sealey limited
Original Language Version
TP80 Issue 3 (2) 05/03/19
5. operatIon
g.3
g.4
g.5
5.1. Remove the pump from the holder (g.3), which may be hooked onto the handle of the jerry can using the hanging hook provided
(g.4).
5.2. lower the pump stem into the jerry can until it rests on the base of the can.
5.3. Place the delivery nozzle into the receiving container; the nozzle may be either wedged or clipped in place using the attached
moulded spigot, (see g.5.1)
5.4. To start the pump, slide the switch (g 5.2).
5.5. The pump will switch off automatically when the dispensed liquid reaches the stop line (g.5.3) or manually at any point before
then.
5.6. The pump is tted with an anti-vacuum valve to prevent syphoning.
8 do not leave the pump unattended whilst it is running
envIronment protectIon
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Weee reGulatIonS
dispose of this product at the end of its working life in compliance with the eU directive on Waste electrical and electronic equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
battery removal See SectIon 4
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk business park, bury St edmunds, Suffolk. Ip32 7ar
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
