INSTRUCTIONS FOR
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
RECHARGEABLE 360° LITHIUM - POLYMER
INSPECTION LAMP 2W COB + 1W LED
MODEL NO: LED3601.V2 SERIES
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
Refer to
instructions
1. SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9 Ensure the lamp is fully charged before initial use.
8 DO NOT charge in damp conditions.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°).
Replace only with the battery pack designated for this product.
Recycle or dispose of used battery as stipulated by local regulation.
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTIONS
Mini, lightweight lamp with exclusive patented design owned and registered to Sealey. Unique and innovative 360° swivel and tilt function
enables the light source to be positioned in any direction. Featuring a super bright 2W COB LED light source, which gives an even and
constant spread of light. Produces up to 220 lumens with a CRI-80 rating. Recessed lens for added protection. 1W High power LED located
in top of the lamp for directional torch use, produces up to 100 lumens. Rubber covered magnet in base and swivel hook for hands-free
operation. Hook doubles as pocket/belt clip for easy carrying when not in use. High quality rechargeable 3.7V 1.5Ah li-polymer battery for
longer life, no memory effect and a much slower discharge than traditional Ni-MH batteries. Micro USB charging port. Supplied with high
quality braided USB cable.
3. SPECIFICATION
Model No ...................................................... LED3601 Series
Battery ......................................................3.7V 1.5Ah Li-Poly
LED Quantity ...........................................................1+1xCOB
Lumen Output Side/Top ........................................ 220/100lm
CRI Rating Side ................................................................. 80
Operating Time Side/Top ................................................ 3/6hr
Charging Time ...................................................................3hr
Minimum Length ......................................................... 160mm
Maximum Length ........................................................ 170mm
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances
we will not replace the battery regardless of whether it is less than one year old.
Note: The lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without
another charge.
© Jack Sealey Limited
Original Language Version
LED3601Series.V2 | Issue:2(I) 25/10/17
Page 2
4. OPERATION
4.1. Connect the USB cable into the charge socket on back of the lamp. Plug into power supply and turn on, the charging LED on the
lamp will light RED to show charging has commenced.
4.2. When the battery has fully charged the LED will turn GREEN.
4.3. Direct the lens away from your eyes before switching on.
4.4. Toggle the lamp between 1W end and 2W COB using the push switch.
4.5. Suspend the lamp by the hanging hook. When the light is hanging from the hook it can be rotated through 360° for more precise
positioning.
4.6. Alternatively use the magnet on the base to attach the lamp to any ferrous surface.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Remove the 4 screws on the back of the lamp. Remove the back casing and disconnect the wiring from the circuit board.
Remove the battery. Dispose of according to local government guidelines Under the Waste Batteries and Accumulators Regulations
2009, Jack Sealey Ltd are required to inform potential purchasers of products containing batteries (as defined within these regulations),
that they are registered with Valpak’s registered compliance scheme. Jack Sealey Ltd’s Batteries Producer Registration Number (BPRN)
is BPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
© Jack Sealey Limited
Original Language Version
LED3601Series.V2 | Issue:2(I) 25/10/17
