instructions for
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Hot air gun 2000w 3-speed 50/420/650°c
model no: Hs100
thank you for purchasing a sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear ear
protection
1. saFetY
1.1. electrical safety
warning! it is the user’s responsibility to check the following:
check all electrical equipment and appliances to ensure that they are safe before using. inspect power supply leads, plugs and
all electrical connections for wear and damage. sealey recommend that an rcd (residual current device) is used with all electrical
products. You may obtain an rcd by contacting your local sealey dealer.
if the used in the course of business duties, it must be maintained in a safe condition and routinely PAt (Portable Appliance test)
tested.
electrical safety information, it is important that the following information is read and understood.
9 ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
9 Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse - see
fuse rating in these instructions.
8 do not pull or carry the appliance by the power cable.
8 do not pull the plug from the socket by the cable. Remove the plug from the socket by maintaining a rm grip on the plug.
8 do not use worn or damaged cables, plugs or connectors. ensure that any faulty item is repaired or replaced immediately by a
qualied electrician.
This product is tted with a BS1363/A 13 Amp 3 pin plug.
if the cable or plug is damaged during use, switch the electricity supply and remove from use.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualied electrician.
class ii products are wired with live (brown) and neutral (blue) only are marked with the class ii symbol;
A) Connect the BROWN live wire to the live terminal ‘L’.
B) Connect the BLUE neutral wire to the neutral terminal ‘N’.
c) After wiring, check that there are no bare wires and ensure that all wires have been correctly connected.
ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
do not connect either wire to the earth terminal.
Sealey recommend that repairs are carried out by a qualied electrician.
1.2. General safety
9 disconnect the gun from the mains power before changing accessories, servicing or performing other maintenance.
9 maintain the hot air gun in good condition, use an authorised service agent.
9 use recommended accessories only. unapproved accessories can be hazardous and will invalidate your warranty.
9 Wear appropriate protective clothing and equipment. Work gloves and eye protection are mandatory. Protect long hair and remove
loose fitting garments and jewellery. Maintain correct balance and footing and wear non-slip shoes.
9 evaluate your work area before using the hot air gun. i.e. ceiling, floors and enclosures may contain flammable materials.
9 Keep the work area clean, uncluttered and well lit. use the hot air gun only in a well ventilated area.
9 ensure that small or irregular shaped objects are secured in a vice or clamps before you work on them.
9 stay alert! Always pay attention to the work in hand when operating this hot air gun.
9 Guard against electric shock by not contacting grounded surfaces, i.e. pipes, radiators, etc. when using electric hand tools.
9 Keep the hot air gun handle dry, clean and free from oil and grease. clean any paint or varnish from the nozzle after use.
9 Allow the hot air gun to cool before storing (only store when cold). store the gun in a safe, dry place out of the reach of children.
8 do not direct the hot airflow at yourself, others, animals or plants and do not allow children to operate the hot air gun.
8 do not use the hot air gun in rain or in a wet environment, or in areas of high humidity and damp (i.e. bathrooms, steam rooms, etc.).
8 do not obstruct the hot airflow by blocking or covering the air outlet.
8 do not touch the nozzle during, or after, use as it becomes extremely hot.
8 do not leave the hot air gun running unattended. Always turn off the power supply.
8 do not use the hot air gun on a task it is not designed for.
8 do not use the hot air gun in combination with chemical strippers.
© Jack sealey limited
Original Language Version
Hs100 | issue 1 30/09/16
recommended fuse rating
13 Amp
8 do not operate the hot air gun when you are tired or under the influence of alcohol, drugs or intoxicating medication.
▲ danger! do not use tHe Hot Air Gun As A HAir drYer.
Lead paint warning! Paint once contained lead as a traditional ingredient. Paint particles, resulting from the removal of such
paint, are toxic and ingestion/inhalation must, therefore, be avoided. the following action must be taken before using this tool:
the operator must determine potential hazard relating to age of paint to be removed (modern paints do not have lead content).
9
dAnGer! Keep all persons and pets away from the work area. the following are particularly vulnerable to the effects of lead paint
▲
dust: expectant women, babies and children.
We recommend personal protection by using the following safety items: Paint spray respirator, Pe coated Hooded coverall, latex
9
Gloves.
take adequate measures to contain the paint dust, flakes, and scrapings.
9
9 When task is complete continue to wear safety equipment as in 1.3.3. and thoroughly clean all areas. ensure paint waste is disposed
of in sealed bags or containers.
warning: the warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. it must be understood that common sense and caution are factors which cannot be built into this product, but
must be applied by the operator.
2. introduction
features three speed and temperature control. suitable for paint stripping, soft soldering, removing sticky labels and defrosting frozen pipes.
Supplied with 4 nozzels and a scraper, making various tasks possible. Gun is designed to stand vertically, allowing use as a safe Bunsen
burner alternative. Fitted BS approved 3-pin safety plug
3. speciFication
model no ..................................................................... Hs100
Power ..........................................................................2000W
supply ............................................................................230V
temperature range ......................................... 50/420/650°c
Airflow .....................................................250, 400, 650ltr/min
4. operation
4.1. preparing the hot air gun for use
4.1.1. Before plugging into the mains ensure the gun switch is in the ‘Off’ position.
4.1.2. When ready to start work, set power switch to the required temperature setting i (low), ii (medium) or iii (High). Allow time to heat up.
note: When new, the hot air gun may generate smoke which will decrease with use.
warning! KEEP HANDS AWAY FROM THE IMMEDIATE NOZZLE AREA. IF LEAD PAINT IS BEING REMOVED FOLLOW THE
SAFETY WARNING AT THE BEGINNING OF THIS MANUAL. AlWAYs WeAr GloVes And eYe Protection.
4.2. paint and varnish removal
the easy removal of paint and varnish requires practice. follow these simple working techniques to achieve the required result.
note: the heat gun is designed to remove both oil and latex based paints and varnishes from surfaces. it will not remove stains or
primer coats that have impregnated the surface.
4.2.1. Attach the required nozzel.
4.2.2. switch the hot air gun on and allow it to reach its operating temperature.
4.2.3. Always test on a small non-critical area first.
Hold the hot air gun nozzle 3” (75mm) to 4” (100mm) from the paint to be removed.
4.2.4. After a short time the paint will soften and begin to blister.
8 do not overheat the paint as this will cause it to burn which makes it more difficult to remove. Wear eye protection, especially
when stripping paint from overhead. if lead paint is being removed, refer to the warning at the beginning of this manual.
4.2.5. Begin scraping the paint off. Work from top to bottom. Use a scraper with smooth even strokes, warming the surface in front of the
scraper by moving the gun slightly from side to side.
4.2.6. if the correct temperature has been applied to the paint, thick, even layers can be removed in a single pass (paint should be removed
in strips equal in width to the scraper blade). Scrape paint as soon as it becomes soft, as it will re-harden very quickly.
4.2.7. Keep the scraper blade edge clean and sharp to prevent paint peelings from building up.
4.2.8. After softening, shaped or profiled surfaces may be stripped by using a wire brush.
4.2.9. To protect surrounding surfaces from the heat, cover with a non-flammable material.
8 do not concentrate the heat gun on glass as the glass may crack.
g.1
5. Maintenance
5.1. unplug the hot air gun from power supply before performing any maintenance.
5.2. Keep the air intake and outlet openings clean and free from dirt and peelings.
5.3. use only a damp cloth and mild household cleaning agent to wipe the hot air gun clean. do not use turpentine, paint thinner,
gasoline or similar substances to clean the hot air gun.
5.4. check the hot air gun, power lead and nozzles for damage before storage.
5.5. store the hot air gun in a safe, dry, childproof area.
© Jack sealey limited
Original Language Version
Hs100 | issue 1 30/09/16
