Sealey ap2513b.V3, ap22513bb.V2 Instruction Booklet

instructions for
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
topchest & rollcab combination 13 drawer with ball bearing runners
MoDEL no: ap2513b.V3, ap22513bb.V2
thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance.
1. safety
warning! Ensure Health & Safety, local authority, and general workshop practice regulat ions ar e adher ed t o when us ing t his Topchest
& Rollcab combination.
9 Locate the topchest & rollcab combination in a suitable working area. 9 Keep the work area clean, uncluttered and ensure there is adequate lighting. 9 Keep the topchest & rollcab combination clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the working area. 8 do not use the topchest & rollcab combination for any purpose other than that for which it is designed. 8 do not move the topchest & rollcab combination with drawers open. 8 do not open more than one drawer at the same time. 8 do not step on the drawers. 8 do not use in damp work areas.
warning! the warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and situations
that may occur. it must be understood that common sense and caution are factors which cannot be built into this product, but must be applied by the operator.
2. assembly
1.
Lift the main rollcab body off the base and topchest.
2.
remove the 4 screws on the bottom of the topchest assembly, then remove the base from the bottom of the topchest.
3. reattach the base to the bottom of the rollcab ensuring it is the correct way up and secure with the supplied
xings.
© Jack sealey Limited
Original Language Version
AP2513B.V3, AP22513BB.V2| issue 1 07/11/16
4 & 5.
in each corner of the base attach the
castor and tighten the fixings.
6.
Attach the topchest side handles using the
2 x bolts. Insert the side handle into the rollcab and attach using 4 x bolts and
washers.
3. maintenance
3.1. Periodically lubricate castors and tighten all hardware.
recycle unwanted materials instead of disposing of them as waste. all tools, accessories and packaging should be sorted,
environmental protection
taken to a recycling centre and disposed of in a manner which is compatible with the environment.
when the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
important: no liability is accepted for incorrect use of this product. warranty: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
© Jack sealey Limited
sole uK Distributor, sealey Group. Kempson Way, suffolk Business Park, Bury st. Edmunds, suffolk. iP32 7Ar
Original Language Version
01284 757500 01284 703534
www.sealey.co.uk
web
sales@sealey.co.uk
AP2513B.V3, AP22513BB.V2| issue 1 07/11/16
