Sealey AP1210, AP1535 Instruction Booklet

WORKBENCH
MODEL Nos:
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, W ARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/ OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
1.1 GENERAL SAFETY
 WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this bench.  Locate bench in a suitable working area.  Keep the work area clean, uncluttered and ensure there is adequate lighting.  Keep the bench clean and tidy in accordance with good workshop practice.  Keep children and unauthorised persons away from the working area.  DO NOT use the bench for any purpose other than that for which it is designed.  DO NOT use in damp work areas.DO NOT undertake work on the bench without the workpiece being adequately secured. Use clamps or a vice (not included) to secure the
workpiece. Available from your Sealey dealer.  WARNING! The warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be applied by the operator.
2. INTRODUCTION & SPECIFICATIONS
Fully painted steel frame with wooden worktop and shelf. No nuts and bolts, means no tools required to assemble. Workbench clips together in minutes.
Model No: AP1210 AP1535 Overall Size (W x D x H): 1210 x 610 x 900mm 1535 x 620 x 920mm Maximum Capacity / Shelf: 100kg 200kg
AP1210 & AP1535
Item Description AP1210 AP1535
1 Support Rack AP1210.01 AP1535.01 2 Cross Rail (Short) AP1210.02 AP1535.02 3 Cross Rail (Long) AP1210.03 AP1535.03 4 Feet AP1210.04 AP1535.04 5 Wooden Top AP1210.05 AP1535.05
AP1210
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product. WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim. INFORMATION: For a copy of our catalogue and latest promotions call us on 01284 757525 and leave your full name, address and postcode.
Sole UK Distributor
Sealey Group,
Bury St. Edmunds, Suffolk.
01284 757500
01284 703534
AP1535
www.sealey.co.uk
Web
sales@sealey.co.uk
email
AP1210, AP1535 Issue No: 1 - 24/07/08
