INSTRUCTIONS FOR:
BOLT, STUD & SCREW EXTRACTOR SET
MODEL No: AK751
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERA TIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
7 Do not use the extractor set for any purpose other than for which it is designed.
3 Keep the set free from dirt and grime.
3 Ensure your work area is tidy, well lit and free from hazards.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that common sense and caution are factors which can not be built into
this product, but must be applied by the operator.
2. INTRODUCTION
Comprehensive set including Chrome Molybdenum screw and bolt extractors and Vanadium stud extractors. Screw type has left hand threads
for removing recessed bolts/studs. Bolt type features reverse spiral utes which bite down on rounded off bolts. Stud type includes 3 internal
rollers clamping down and gripping stud allowing removal/installation. Suitable for professional workshop. Supplied in storage case.
3. CONTENTS
Model No: .............................................................................AK751
Bolt Extractor Set (⅜” Sq Drive): .....................................10, 11, 12, 13 ,14, 15, 16, 17, 19mm
Screw Extractor Set:.......................................M14-M18, M11-M14, M8-M11, M6-M8, M3-M6
Stud Extractor Set (½” Sq Drive):......................................................6, 8, 10, 12mm
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
© Jack Sealey Limited
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling
centre and disposed of in a manner which is compatible with the environment.
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
Environmental Protection.
Original Language Version
01284 757500
01284 703534
www.sealey.co.uk
sales@sealey.co.uk
AK751 Issue: 1 - 04/0914
