Sealey AK4042 Instruction Booklet

Butane Micro Heating torcH

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

model no: aK4042

thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.

Refer to

instructions

1. Safety

 Warning! ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this

equipment, make sure you know where the nearest fire extinguisher is.

 Warning! Always wear approved eye / face protection when operating the torch.
 Warning! do not use the torch if you notice damage to the workpiece or if there could be a gas leak from it.
 Warning! Butane gas is extremely flammable, handle with care.
 Warning! Always point the torch away from the eyes and body when igniting and during operation.
 Warning! Do not put the torch down when it is lit, do not leave it unattended.
 Warning! The ame is not easily visible in bright daylight.
 Warning! ensure the flame is completely extinguished after use. Do not use water to cool the torch down.
 Warning! only use in a well ventilated area.

8 Do not use the torch in an area where paint fumes, solvents or other flammable solids, liquids or gases pose a potential hazard.

Keep flammable material away from the torch when operating.

8 Do not operate the torch when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 Do not hold any workpiece by hand.
8 Do not touch the workpiece close to the heated area as it will be very hot. Allow to cool.
8 Do not operate the torch if it is damaged as this may cause failure and/or possible personal injury.
8 Do not touch the top of the torch during or immediately after use, as it will be very hot. Allow to cool.
8 Do not allow children to operate the torch.

9 After use, apply the safety lock, put the cap on and allow the torch to cool before storing it.
9 When not in use, store away from direct sunlight in a safe, dry, childproof location.

8 Do not store at over 40°C, such as in a car in hot weather.

2. introDuction

Professional micro design featuring piezoelectric ignition. Fitted with anti-ignition cap to prevent accidental operation. Unit produces ame of

up to 1300°C and will operate for up to 30 minutes on a single ll. Features adjustable ame control and continuous ame switch. Powered by

Butane (lighter fuel).

3. operation

3.1. to fiLL. (refer to fig.1)

Use standard butane fuel. Fill in a well ventilated area away from open
flame. Turn the torch off, make sure the flame is out, allow to cool down
for five minutes before filling, put the cap on.

3.1.1. Hold torch upside down and insert the filling can’s nozzle into the gas
filling valve. Press nozzle into the valve and release gas. once gas begins
to seep out around the edge of the nozzle, the gas tank is full. Remove
the filling can.

3.2. to uSe. (refer to fig.1)

3.2.1. Remove the cap and release the safety lock by turning anticlockwise.

3.2.2. Press the trigger to ignite, release the trigger to extinguish the flame.

3.2.3. The lock lever may be slid to “lock” after ignition to keep a continuous
burning flame, without holding down the trigger. Slide the lock lever to
“off” to extinguish the flame.

3.2.4. move Gas Volume Control lever to vary flame strength, + to increase,

- to decrease.

© Jack Sealey limited

Original Language Version

AK4042 Issue 2 12/04/18

environMent protection

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.

note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.

important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
