SealerSales CS-2020
Semi-Automatic Uniform Carton
Sealer w/ Side Drive Belts
Product Spec Sheet
Page 2
SIDE BELT ADJUSTABLE CARTON SEALER
Excellent for low profile, small, lightweight boxes
Model: CS-2020
The CS-2020 Semi-Automatic Uniform Carton Sealer with
Easy Manual Carton Size Adjustment has a side-drive belt
design and features our new tape head with “Easy Thread
Design.” The machine comes complete with adjustable
height legs, power cord and plug.
The operator simply folds the top flaps of the corrugated
carton and feeds it into the machine. The CS-2020 applies
a single tape strip to both the top and bottom of the case
simultaneously. This two belt drive design is a heavy duty
versatile machine designed for dependable performance
and easy operation. The CS-2020 can be easily adjusted
in only seconds to process a different size carton.
Excellent for low profile, small, lightweight boxes.
Standard Features:
• Tape Head with “Easy Thread” Design
• Interchangeable Tape Heads
• Side Pressure Rollers to Close Box Top
• 2 Side Belts for Positive Feed
• Fully Adjustable Legs
Optional Features:
• 3” (72mm) Tape Heads
• Infeed Conveyor
• Exit Conveyor
*Shown with optional infeed and discharge roller conveyors and casters
SPECIFICATIONS
CARTON SIZE
LENGTH: 6” TO INFINITE
WIDTH: 4.5” MIN TO 20” MAX
HEIGHT: 4” MIN TO 20” MAX
MACHINE SIZE: 36”L X 27”L X 53”H
MACHINE SPEED: 75FT./MIN UP TO 2,000 CARTONS PER HOUR
PRODUCTION RATE DPENDS ON CARTON SIZE AND OPERATOR DEXTERITY
ELECTRICAL: 110V, 1 PHASE, 10 AMP
• Stainless Steel Frame
• Heavy Duty Locking Casters
27”
53”
23”
36”
72”
18”
WEIGHT: 320-LBS (SHIPPING WEIGHT: 370-LBS)
MAX BOX WEIGHT: 65-LBS
TAPE HEAD SPECS: 2” (48MM) WIDE – 1,000 YARD OR 1,500 YARD ROLLS
8820 Baird Avenue • Northridge, CA 91324 • T: 818-718-8818 • F: 818-718-8857
Updated 12/05/16. Do not reproduce without permission
Page 3
SIDE BELT ADJUSTABLE CARTON SEALER
Model: CS-2020
Patented “Easy Thread” Tape Design
with Adjustable Box Side Guides
Heavy Duty Side Drive Belts for
Positive Grip Pressure
Patented Tape Head
Height Adjustment
Crank
Spring Loaded Inner
Mast Assembly
Allows Tape Head to Float
for Oversized Boxes
Top Flap
Compression Rollers
Dual Drive Motors
Side Drive Belt
Assemblies (2)
• Self Centering
• Belt Speed (76 FPM)
• (2) ¼ HP Motors
Width Adjustment Crank
Adjustable Friction
Brake Drum
Emergency Stop
Centrally Located for
Easy Access
Easily Installed
Replacement Belts
New Tape Head Features an Easy
Thread Design with Optimizer Arm
Graduated Inner Legs for Easy
Bed Height Adjustment
Panel Mounted On/Off Switch
MyBinding.com
5500 NE Moore Court
Optional Casters
Locking / Swivel
Spring Loaded Side Drive Belts
Compensate for Box Width
Variations Automatically as Box is
Toll Free: 1-800-944-4573
Local: 503-640-5920
Optional Infeed /
Exit Conveyors
Pulled Through
Hillsboro, OR 97124
Updated 12/05/16. Do not reproduce without permission
