CESSNA 152
ASSEMBLY MANUAL
MS: 174
Specications:
Wing span ------------------------------79.9in (203cm).
Wing area -----------------911.4sq.in (58.8sq dm).
Weight ----------------------------------9.9lbs (4.5kg).
Length ------------------------------57.5in (146.0cm).
Engine ------------------ ----0.75-0.91cu.in -2-stroke.
0.91-1.25cu.in -4-stroke.
Radio ------------------- 5 channels with 8 servos.
Electric conversion: optional
“Graphics and specications may change without notice”.
Page 2
CESSNA 152
Instruction Manual.
2
ank you for choosing the CESSNA 152 ARTF by SEAGULL MODELS COMPANY LTD,.
e CESSNA 152 was designed with the intermediate/advanced sport yer in mind. It is a semi
scale airplane which is easy to y and quick to assemble. e airframe is onventionally built using
balsa, plywood to make it stronger than the average ARTF, yet the design allows the aeroplane
to be kept light. You will nd that most of the work has been done for you already. e motor
mount has been tted and the hinges are pre-installed. Flying the CESSNA 152 is simply a joy.
is instruction manual is designed to help you build a great ying earoplane. Please read
this manual throughly before starting assembly of your CESSNA 152. User the parts listing
below to indentify all parts.
Please be awere that this aeroplane is not a toy and if assembley or used incorrectly it is
capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & REPONSIBILITY.
If you are inexperianced with basic R/C ight we strongly recommend you contact your R/C
supplier and join your local R/C model Flying Club. R/C Model Flying Clubs oer a variety
of training procedures designed to help the new pilot on his way to successful R/C ight.
ey will also be able to advise on any insurance and safety regulations that may apply.
INTRODUCTION.
WARNING.
KIT CONTENTS
3
5
6
2
2
1
74
11
3
10
Page 3
WWW.SEAGULLMODELS.COM
3
KIT CONTENTS.
ADDITIONAL ITEMS REQUIRED.
0.75- 0.91 2-stroke.
0.91-1.25 4-stroke.
Computer radio with 7 servos.
Glow plug to suit engine.
Propeller to suit engine.
Protective foam rubber for radio
system.
TOOLS & SUPPLIES NEEDED.
ick cyanoacrylate glue.
30 minute epoxy.
5 minute epoxy.
Hand or electric drill.
Assorted drill bits.
Modelling knife.
Straight edge ruler.
2mm ball driver.
Phillips head screwdriver.
220 grit sandpaper.
90° square or builder’s triangle.
Wire cutters.
Masking tape & T-pins.
read-lock.
Paper towels.
HINGING THE FLAP
.
.
M2x10 mm
M2x10 mm
SEA17401 Fuselage
SEA17402 Wing Set
SEA17403 Tail Set
SEA17404 Fiberglass Cowling
SEA17405 Main Landing Gear
SEA17406 Nose Landing Gear
SEA17407 Windshield and Window set
SEA17408 Decal
SEA17409 Pushrod Set
SEA17410 Wing tube
SEA17411 Fiberglass Wheel Pants
Page 4
CESSNA 152
Instruction Manual.
4
HINGING THE AILERON.
e control surfaces, including the ailerons, elevators, and rudder, are prehinged with hinges in stalled, but the
hinges are not glued in place. It is imperative that you properly adhere the
hinges in place per the steps that follow using a high-quality thin C/A glue.
Note :
1) Carefully remove the aileron from one
of the wing panels. Note the position of the
hinges.
2) Remove each hinge from the wing panel
and aileron and place a T-pin in the center of
each hinge. Slide each hinge into the aileron
until the T-pin is snug against the aileron.
is will help ensure an equal amount of
hinge is on either side of the hinge line when
the aileron is mounted to the wing panel.
3) Slide the aileron on the wing panel until
there is only a slight gap. e hinge is nowcentered on the wing panel and aileron. Remove the T-pins and snug the aileron against
the wing panel. A gap of 1/64” or less should
be maintained between the wing panel and
aileron.
T-pin
Hinge.
4) Deect the aileron and completely saturate each hinge with thin C/A glue. e ailerons front surface should lightly contact the
wing during this procedure. Ideally, when
the hinges are glued in place, a 1/64” gap or
less will be maintained throughout the lengh
of the aileron to the wing panel hinge line.
e hinge is constructed of a special
material that allows the C/A to wick
or penetrate and distribute
throughout the hinge, securely
bonding it to the wood structure of
the wing panel and aileron.
Note :
C/A glue
Page 5
WWW.SEAGULLMODELS.COM
5
HINGING THE ELEVATOR.
5) Turn the wing panel over and deect the
aileron in the opposite direction from the
opposite side. Apply thin C/A glue to each
hinge, making sure that the C/A penetrates into both the aileron and wing panel.
6) Using C/A remover/debonder and a paper towel, remove any excess C/A glue that
may have accumulated on the wing or in the
aileron hinge area.
7) Repeat this process with the other wing
panel, securely hinging the aileron in place.
8) Aer both ailerons are securely hinged,
rmly grasp the wing panel and aileron to
make sure the hinges are securely glued and
cannot be pulled out. Do this by carefully applying medium pressure, trying to separate
the aileron from the wing panel. Use caution
not to crush the wing structure.
Work the aileron up and down several times to “work in” the hinges
and check for proper movement.
Note :
Glue the elevator hinges in place using the
same techniques used to hinge the ailerons.
HINGING THE RUDDER.
Glue the rudder hinges in place using the
same techniques used to hinge the ailerons.
Hinge.
INSTALL THE AILERONS CONTROL
HORN.
Fiberglass control horn
Epoxy
Page 6
CESSNA 152
Instruction Manual.
66
.
.
.
.
INSTALL FLAP CONTROL HORN.
.
.
Aileron control horn.
Epoxy
Install the ap control horn using the same
method as same as the aileron control horns.
Fiberglass control horn.
Epoxy
Aileron control horn.
Epoxy
INSTALL ELEVATOR CONTROL HORN.
Fiberglass control horn.
Epoxy
Aileron control horn.
Epoxy
INSTALL RUDDER CONTROL HORN.
Repeat steps to install the rudder control
horn as same as steps done for ailerons.
Page 7
WWW.SEAGULLMODELS.COM
77
.
.
Epoxy
Rudder control horn.
ENGINE MOUNT INSTALLATION.
1) Locate the items necessary to install the
engine mount included with your model.
4x30 mm
2) Use four 4x30mm head bolts and four
4mm washers to attach the engine mount
rails to the rewall. Tighten the screws .
Make sure to use threadlock on the screws to
help prevent them from vibrating loose.
read locker glue.
INSTALLING THE S TOPPER
ASSEMBLY
1) Using a modeling knife, carefully cut o
the rear portion of one of the 3 nylon tubes
leaving 1/2” protruding from the rear of the
stopper. is will be the fuel pick up tube.
2) Using a modeling knife, cut one length of
silicon fuel line. Connect one end of the line
to the weighted fuel pick up and the other
end to the nylon pick up tube.
Page 8
CESSNA 152
Instruction Manual.
88
Fuel tank.
Vent tube.
Fuel fill tube.
Fuel tank.
Vent tube.
Fuel pick up tube.
Fuel fill tube.
Balsa.
3) Carefully bend the second nylon tube up
at a 45º angle. is tube is the vent tube.
4) Test t the stopper assembly into the tank.
It may be necessary to remove some of the
ashing around the tank opening using a
modeling knife. If ashing is present, make
sure none falls into the tank.
5) With the stopper assembly in place, the
weighted pick-up should rest away from the
rear of the tank and move freely inside the
tank. e top of the vent tube should rest just
below the top of the tank. It should not touch
the top of the tank.
6) When satised with the alignment of the
stopper assembly tighten the 3 x 20mm machine screw until the rubber stopper expands
and seals the tank opening. Do not overtighten the assembly as this could cause the
tank to split.
FUEL TANK INSTALLATION.
You should mark which tube is the vent
and which is the fuel pickup when you attach
fuel tubing to the tubes in the stopper. Once
the tank is installed inside the fuselage, it may
be dicult to determine which is which.
7) Slide the fuel tank into the fuselage. Guide
the lines from the tank through the hole in
the rewall.
A
8) Use plywood template to hold in place the
fuel tank with C/A glue to secure the fuel
tank inside the fuselage.
Fuel pick up tube.
9) Connect the lines from the tank to the engine and muer. e vent line will connect
to the muer and the line from the clunk to
the carburetor.
Page 9
WWW.SEAGULLMODELS.COM
99
.
Elevator servo.
Rudder servo.
.
.
Blow through one of the lines to ensure
the fuel lines have not become kinked inside
the fuel tank compartment. Air should ow
through easily.
INSTALLING THE FUSELAGE SERVOS.
Because the size of servos dier, you may
need to adjust the size of the precut opening
in the mount. e notch in the sides of the
mount allow the servo lead to pass through.
1) Install the rubber grommets and brass
collets onto the throttle servo. Test t the
servo into the aileron servo mount.
2) Secure the servos with the screws provided with your radio system.
rottle servo.
THROTTLE SERVO ARM INSTALLA-
TION.
Install adjustable servo connector in the
servo arm as same as picture below:
Loctite secure.
Adjustable Servo
connector.
Servo arm.
1 PCS
Rudder servo arm.
rottle servo arm.
Elevator servo arm.
INSTALLING THE SWITCH.
Install the switch into the precut hole in
the side, in the fuselage.
3/32” Hole.
Trim and cut
Switch
Page 10
CESSNA 152
Instruction Manual.
10
wheel collar.
wheel.
Axle.
Washer.
M3.
M3.
C/A glue.
Landing Gear.
wheel Pant.
Axle.
Locker glue.
wheel Pant.
wheel.
M3.
M3.
wheel collar.
nut.
Washer.
WHEELS AND WHEEL PANTS.
1) Assemble and mounting the landing gear,
wheels to the wheel pants as shown inthe following pictures.
2) Follow diagram below for wheel pant installation:
3) A drop of C/A glue on the wheel collar
screws will help keep them from coming lose
during operation.
Repeat the process for the other wheel.
Page 11
WWW.SEAGULLMODELS.COM
1111
.
INSTALLING THE MAIN LANDING
GEAR.
1) e blind nuts for securing the landing
gear are already mounted inside the fuselage.
2) Using the hardware provided, mount the
main landing gear to the fuselage.
MOUNTING THE ENGINE.
1) Position the engine with the drive washer
(150mm) forward of the rewall as shown.
2) Use a pin drill and 4mm drill bit to drill a
small indentation in the mount for the engine mounting screw.
4x20 mm
150mm
3) Use a drill to drill the four holes in the
engine mount rails.
4) On the re wall has the location for the
throttle pusshrod tube (pre-drill).
5) Slide the pushrod tube in the rewall and
guide it through the fuel tank mount. Use
medium C/A to glue the tube to the rewall
and the fuel tank mount.
6) Connect the Z-bend in the 600mm throttle pushrod to the outer hole of the carburetor arm.
7) Slide the throttle pushrod wire into
the tube. Position the engine between the
mounts. Use four M4x30mm machine
screws to secure the engine to the mount as
shown.
4 mm
Pushrod tube hole.
Machine screw M4x30mm
Pushrod tube hole.
Page 12
CESSNA 152
Instruction Manual.
1212
Drill 4mm.
8) Move the throttle stick to the closed position and move the carburetor to closed. Use
a 2.5mm hex wrench to tighten the screw
that secures the throttle pushrod wire. Make
sure to use threadlock on the screw so it does
not vibrate loose.
LANDING GEAR INSTALLATION.
A. NOSE GEAR:
1)Locate the items necessary to attach the
nose landing gear that are included with
your model.
read locker glue.read locker glue.
Page 13
WWW.SEAGULLMODELS.COM
1313
4mm hole.
Axle.
wheel collar.
wheel.
Screw.
2)Install landing gear at the top Fuselage.
Page 14
CESSNA 152
Instruction Manual.
14
Trim and cut.
Trim and cut.
Screw.
Drill hole 4mm.
COWLING
1) Slide the berglass cowl over the engine
and line up the back edge of the cowl with
the marks you made on the fuselage then
trim and cut as shown.
Install lights at the top Cowling
M3 lock nut
.
M3 clevis.
225 mm
M3
Pushrod.
Page 15
WWW.SEAGULLMODELS.COM
15
Epoxy.
Because of the size of the cowl, it may be necessary to use a needle valve extension for the
high speed needle valve. Make this out of sufcient length 1.5mm wire and install it into
the end of the needle valve. Secure the wire in
place by tightening the set screw in the side of
the needle valve.
.
2) While keeping the back edge of the cowl
ush with the marks, align the front of the
cowl with the cranksha of the engine. e
front of the cowl should be positioned so the
cranksha is in nearly the middle of the cowl
opening. Use the spinner backplate as a
guide. Hold the cowl rmly in place using
pieces of masking tape.
3) Install the muer and muer extension
onto the engine and make the cutout in the
cowl for muer clearance. Connect the fuel
and pressure lines to the carburetor, muer
and fuel ller valve. Secure the cowl to fuselage using the M3x10mm screws.
Needle valve
Machine screw M3x10mm
ELECTRIC POWER CONVERSION.
1) Locate the items neccessary to install
the electric power conversion included
with your model.
2) Recommendation EP parts as shown
(not included with your model).
- Model size: .60 size models
- Motor: 50mm 310 rev per volt
- Propeller: 14x10 ~ 15x10
- ESC: 60A
- Lipo Batteries: 8 cell 5200mA
3) Attach the electric motor box to the
rewall suitable with the cross lines
drawn on the electric motor box and
rewall. Using epoxy and balsa stick
to secure the motor box to the rewall.
Please see pictures below.
Page 16
CESSNA 152
Instruction Manual.
16 16
M4x20mm
4) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M3x15mm hex head bolts to secure the motor. Please see picture shown.
4mm
Blind nut.
M3x15mm
150mm
Balsa stick.
Ep ox y.
Electric motor.
Page 17
WWW.SEAGULLMODELS.COM
17
Battery.
INSTALLING THE SPINNER.
Install the spinner backplate, propeller and
spinner cone.
e propeller should not touch any part
of the spinner cone. If it does, use a sharp
modeling knife and carefully trim away the
spinner cone where the propeller comes in
contact with it.
5) Attach the speed control to the side
of the motor box using two-sided tape
and tie wraps. Connect the appropriate
leads from the speed control to the motor. Make sure the leads will not interfere
with the operation of the motor.
Speed control.
INSTALLING THE AILERON - FLAP
SERVOS.
Servos.
Small weight.
Thread.
Because the size of servos dier, you may
need to adjust the size of the precut opening in
the mount. e notch in the sides of the mount
allow the servo lead to pass through.
1) Using a small weight (Weighted fuel pickup works well) and string, feed the string
through the wing as indicated.
Page 18
CESSNA 152
Instruction Manual.
18
.
.
2) Place the servo between the mounting
blocks and space it from the hatch. Use a
pencil to mark the mounting hole locations
on the blocks.
3) Use drill bit in a pin vise to drill the mouting holes in the blocks.
4) Apply 2-3 drops of thin C/A to each of the
mounting holes. Allow the C/A to cure without using accelerator.
5) Use dental oss to secure the connection
so they cannot become unplugged.
6) Secure the servo to the aileron hatch using
Phillips screwdriver and the screws provided
with the servo.
7) Apply 1-2 drops of thin C/A to each of the
mounting tabs. Allow the C/A to cure without using accelerator.
8) A string has been provided in the wing
to pull the aileron lead through to the wing
root. Remove the string from the wing at
the servo location and use the tape to attach
it to the servo extension lead. Pull the lead
through the wing and remove the string.
Page 19
WWW.SEAGULLMODELS.COM
1919
9) Set the aileron hatch in place and use a
Phillips screw driver to install it with four
wood screws.
M3 lock nut.
M3 clevis.
100mm.
.
M2 lock nut.
AILERON PUSHROD HORN
INSTALLATION.
Aileron
Wing
INSTALLING THE FLAP SERVO.
Repeat the procedure for the aileron servo.
Page 20
CESSNA 152
Instruction Manual.
20 20
M2 lock nut.
M3 lock nut.
M3 clevis.
90mm.
Flap
Wing
INSTALLING THE HORIZONTAL STA-
BILIZER.
1) Using a ruler and a pen, locate the centerline of the horizontal stabilizer, at the trailing
edge, and place a mark. Use a triangle and
extend this mark, from back to front, across
the top of the stabilizer. Also extend this
mark down the back of the trailing edge of
the stabilizer.
Draw center line.
2) Using a modeling knife, carefully remove
the covering at mounting slot of horizontal
stabilizer ( both side of fuselage).
Cut
3) Slide the stabilizer into place in the precut
slot in the rear of the fuselage. e stabilizer
should be pushed rmly against the front of
the slot.
4) With the stabilizer held rmly in place,
use a pen and draw lines onto the stabilizer
where it and the fuselage sides meet. Do this
on both the right and le sides and top and
bottom of the stabilizer.
Pen
5) Remove the stabilizer. Using the lines you
just drew as a guide, carefully remove the
covering from between them using a modeling knife.
Page 21
WWW.SEAGULLMODELS.COM
21
Trim and cut
When cutting through the covering to
remove it, cut with only enough pressure to
only cut through the covering itself. Cutting
into the balsa structure may weaken it.
6) Using a modeling knife, carefully remove
the covering that overlaps the stabilizer
mounting platform sides in the fuselage. Remove the covering from both the top and the
bottom of the platform sides.
Epoxy
7) When you are sure that everything is
aligned correctly, mix up a generous amount
of 30 Minute Epoxy. Apply a thin layer to the
top and bottom of the stabilizer mounting
area and to the stabilizer mounting platform
sides in the fuselage. Slide the stabilizer in
place and realign. Double check all of your
measurements once more before the epoxy
cures. Hold the stabilizer in place with T-pins
or masking tape and remove any excess epoxy
using a paper towel and rubbing alcohol.
INSTALLING VERTICAL FIN.
1) Using a modeling knife, remove the covering from over the precut hinge slot cut into
the lower rear portion of the fuselage.
Remove covering
Fill epoxy.
2) While holding the vertical stabilizer rmly in place, use a pen and draw a line on each
side of the vertical stabilizer where it meets
the top of the fuselage.
Page 22
CESSNA 152
Instruction Manual.
22
Epoxy.
90º
Vertical
Stabilizer.
Horizontal
Stabilizer.
.
Fill epoxy
3) Slide the vertical stabilizer back in place.
Using a triangle, check to ensure that the vertical stabilizer is aligned 90º to the horizontal
stabilizer.
4) When you are sure that everything is
aligned correctly, mix up a generous amount
of Flash 30 Minute Epoxy. Apply a thin layer to the mounting slot and to bottom of
the vertical stabilizer mounting area. Apply epoxy to the bottom and top edges of
the ller block and to the lower hinge also.
Set the stabilizer in place and realign. Double check all of your measurements once
more before the epoxy cures. Hold the stabilizer in place with T-pins or masking
tape and remove any excess epoxy using
a paper towel and rubbing alcohol. Allow
the epoxy to fully cure before proceeding.
ELEVATOR PUSHROD HORN INSTAL-
LATION.
1) Install the elevator control horn using
the same method as with the aileron control
horns.
2) Position the elevator control horn on the
both side of elevator.
Elevator control horn
Elevator control horn
3) read one clevis and M2 lock nut on to
each elevator control rod. read the horns
on until they are ush with the ends of the
control rods.
4) Elevator and rudder pushrods assembly as
pictures below.
Page 23
WWW.SEAGULLMODELS.COM
23
M2 lock nut.
M2 clevis.
810mm.
.
Elevator pushrod.
Elevator pushrod.
M2 lock nut.
M2 clevis.
810mm.
820 mm
RUDDER PUSHROD HORN
INSTALLATION.
Rudder control horn
M2 lock nut.
M2 clevis.
810mm.
M2 lock nut.
M2 clevis.
.
840 mm
810 mm
Rudder pushrod.
INSTALLATION PILOT AND CANOPY.
1) Locate items necessary to install pilot and
canopy.
2) A scale pilot is included with this ARF.
e Seagull Pilot included tting well
to the cockpit. (or you can order others
scale pilot gures made by Seagull factory. ey are available at Seagull factory.
ey are available at Seagull distributors.)
If you are going to install a pilot gure,
please use a sanding bar to sand the base of
the gure so that it is at.
3) Position the pilot gure on the canopy
oor as show. Locate the oval shaped on the
canopy oor and remove the covering. Use
epoxy to glue this into the base of the pilot
gure and glue the cockpit panel in place
with C/A glue, please see pictures as shown.
Page 24
CESSNA 152
Instruction Manual.
24
Epoxy.
Epoxy.
C/A glue.
4) Position the canopy onto the fuselage.
Trace around the canopy and onto the fuselage using a felt-tipped pen.
.
.
C/A glue
APPLY THE DECALS.
1) If all the decals are precut and ready to
stick. Please be certain the model is clean and
free from oily ngerprints and dust. Position
decal on the model where desired, using the
photos on the box and aid in their location.
2) If all the decals are not precut, please use
scissors or a sharp hobby knife to cut the
decals from the sheet. Please be c ertain the
model is clean and free from oily ngerprints
and dust. Position decal on the model where
desired, using the photos on the box and aid
in their location.
INSTALLING THE BATTERY-
RECEIVER.
1) Plug the ve servo leads and the switch
lead into the receiver. Plug the battery pack
lead into the switch also.
2) Wrap the receiver and battery pack in the
protective foam rubber to protect them from
vibration.
3) Route the antenna in the antenna tube inside the fuselage and secure it to the bottom
of fuselage using a plastic tape.
Receiver.
Battery.
M4x15 mm
Page 25
WWW.SEAGULLMODELS.COM
2525
Wing tube.
ATTACHMENT WING-FUSELAGE.
Attach the aluminium tube into fuselage.
Insert two wing panels as pictures below.
Wing bolt.
Antennas.
Installation Antenas.
INSTALLATION WING- FUSELAGE
STRUTS.
Wing.
Remove covering.
Page 26
CESSNA 152
Instruction Manual.
26
Wing.
26
Wing.
M3x25mm.
Fuselage.
M3x25mm.
BALANCING.
1) It is critical that your airplane be balanced correctly. Improper balance will
cause your plane to lose control and
crash. THE CENTER OF GRAVITY IS
LOCATED 110 MM BACK FROM THE
LEADING EDGE OF THE WING AT
THE WING ROOT.
2) Mount the wing to the fuselage. Using
a couple of pieces of masking tape, place
them on the top side of the wing 110 mm
back from the leading edge of the wing at
the wing root.
Page 27
WWW.SEAGULLMODELS.COM
27
3) Turn the airplane upside down. Place
your ngers on the masking tape and
carefully li the plane .
Accurately mark the balance point on the
top of the wing on both sides of the fuselage. e balance point is located 110 mm
back from the leading edge of the wing at
the wing root. is is the balance point
at which your model should balance for
your rst ights. Later, you may wish to
experiment by shiing the balance up
to 10mm forward or back to change the
ying characteristics. Moving the balance forward may improve the smoothness and arrow- like tracking, but it may
then require more speed for take o and
make it more dicult to slow down for
landing. Moving the balance a makes
the model more agile with a lighter and
snappier ”feel”. In any case,please start at
the location we recommend .
With the wing attached to the fuselage, all parts of the model installed
( ready to y), and empty fuel tanks,
hold the model at the marked balance point with the stabilizer level.
Li the model. If the tail drops when you
li, the model is “tail heavy” and you
must add weight* to the nose. If the nose
drops, it is “nose heavy” and you must
add weight* to the tail to balance.
*If possible, rst attempt to balance the
model by changing the position of the receiver battery and receiver. If you are unable to obtain good balance by doing so,
then it will be necessary to add weight to
the nose or tail to achieve the
proper balance point.
110MM
CONTROL THROWS.
Ailerons:
High Rate :
Up : 18 mm
Down : 18 mm
Low Rate :
Up : 12 mm
Down : 12 mm
Elevator:
High Rate :
Up : 20 mm
Down : 20 mm
Low Rate :
Up : 15 mm
Down : 15 mm
Rudder:
High Rate :
Right : 30 mm
Left : 30 mm
Low Rate :
Right : 25 mm
Left : 25 mm
Flap:
Mid : 35 mm
Full : 25 mm
Page 28
CESSNA 152
Instruction Manual.
28 28
FLIGHT PREPARATION. PREFLIGHT CHECK.
Check the operation and direction of the
elevator, rudder, ailerons and throttle.
A) Plug in your radio system per the
manufacturer’s instructions and turn everything on.
B) Check the elevator rst. Pull back
on the elevator stick. e elevator halves
should move up. If it they do not, ip the
servo reversing switch on your transmitter
to change the direction.
C) Check the rudder. Looking from behind the airplane, move the rudder stick to
the right. e rudder should move to the
right. If it does not, ip the servo reversing
switch on your transmitter to change the
direction.
D) Check the throttle. Moving the throttle stick forward should open the carburetor barrel. If it does not, ip the servo
reversing switch on your transmitter to
change the direction.
E) From behind the airplane, look at the
aileron on the right wing half. Move the
aileron stick to the right. e right aileron should move up and the other aileron
should move down. If it does not, ip the
servo reversing switch on your transmitter
to change the direction.
1) Completely charge your transmitter and
receiver batteries before your rst day of ying.
2) Check every bolt and every glue joint in
the CESSNA 152 to ensure that everything is
tight and well bonded.
3) Double check the balance of the airplane. Do this with the fuel tank empty.
4) Check the control surfaces. All should
move in the correct direction and not bind
in any way.
5) If your radio transmitter is equipped
with dual rate switches double check that
they are on the low rate setting for your rst
few ights.
6) Check to ensure the control surfaces are
moving the proper amount for both low and
high rate settings.
7) Check the receiver antenna. It should be
fully extended and not coiled up inside the
fuselage.
We wish you many safe and enjoyable ights
with your CESSNA 152.
8) Properly balance the propeller. An out of
balance propeller will cause excessive vibration which could lead to engine and/or airframe failure.
Page 29
WWW.SEAGULLMODELS.COM
29
Safety,Precautions and Warnings
As the user of this product, you are solely responsible for operating it in a manner that does not endanger
yourself and others or result in damage to the product or the property of others. Carefully follow the directions and warnings for this and any optional support equipment (chargers, rechargeable battery packs, etc.)
that you use.
is model is controlled by a radio signal that is subject to interference from many sources outside your
control. is interference can cause momentary loss of control so it is necessary to always keep a safe distance in all directions around your model, as this margin will help to avoid collisions or injury.
• Always operate your model in an open area away from cars, trac or people.
• Avoid operating your model in the street where injury or damage can occur.
• Never operate the model out into the street or populated areas for any reason.
• Never operate your model with low transmitter batteries.
• Carefully follow the directions and warnings for this and any optional support equipment (chargers, re-
chargeable battery packs, etc.) that you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Moisture causes damage to electronics. Avoid water exposure to all equipment not specically designed
and protected for this purpose.
Warranty Period:
Exclusive Warranty- Horizon Hobby, Inc., (Horizon) warranties that the Products purchased (the “Product”) will be free from defects in materials and workmanship at the date of purchase by the Purchaser.
Limited Warranty
(a) is warranty is limited to the original Purchaser (“Purchaser”) and is not transferable. REPAIR OR
REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
PURCHASER. is warranty covers only those Products purchased from an authorized Horizon dealer. ird party transactions are not covered by this warranty. Proof of purchase is required for warranty
claims. Further, Horizon reserves the right to change or modify this warranty without notice and disclaims
all other warranties, express or implied.
(b) Limitations- HORIZON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT NONINFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE OF THE PRODUCT. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE
DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.
(c) Purchaser Remedy- Horizon’s sole obligation hereunder shall be that Horizon will, at its option, (i) repair or (ii) replace, any Product determined by Horizon to be defective. In the event of a defect, these are
the Purchaser’s exclusive remedies. Horizon reserves the right to inspect any and all equipment involved
in a warranty claim. Repair or replacement decisions are at the sole discretion of Horizon. is warranty
does not cover cosmetic damage or damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or modication of or to any part of the Product. is warranty does not cover damage due to
improper installation, operation, maintenance, or attempted repair by anyone other than Horizon. Return
of any goods by Purchaser must be approved in writing by Horizon before shipment.
Damage Limits:
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES,
LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH
THE PRODUCT, WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE,
OR STRICT LIABILITY. Further, in no event shall the liability of Horizon exceed the individual price of the
Product on which liability is asserted. As Horizon has no control over use, setup, nal assembly, modication or misuse, no liability shall be assumed nor accepted for any resulting damage or injury. By the act of
use, setup or assembly, the user accepts all resulting liability.
FOR USA MARKET ONLY.
Page 30
CESSNA 152
Instruction Manual.
30
If you as the Purchaser or user are not prepared to accept the liability associated with the use of this Product,
you are advised to return this Product immediately in new and unused condition to the place of purchase.
Law: ese Terms are governed by Illinois law (without regard to conict of law principals).
Safety Precautions:
is is a sophisticated hobby Product and not a toy. It must be operated with caution and common sense
and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the Product or other property. is Product is not intended for use
by children without direct adult supervision. e Product manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual,
prior to assembly, setup or use, in order to operate correctly and avoid damage or injury.
Questions, Assistance, and Repairs:
Your local hobby store and/or place of purchase cannot provide warranty support or repair. Once assembly,
setup or use of the Product has been started, you must contact Horizon directly. is will enable Horizon to
better answer your questions and service you in the event that you may need any assistance. For questions
or assistance, please direct your email to [email protected], or call 877.504.0233 toll free
to speak to a service technician.
Inspection or Repairs
If this Product needs to be inspected or repaired, please call for a Return Merchandise Authorization
(RMA). Pack the Product securely using a shipping carton. Please note that original boxes may be included, but are not designed to withstand the rigors of shipping without additional protection. Ship via a
carrier that provides tracking and insurance for lost or damaged parcels, as Horizon is not responsible for
merchandise until it arrives and is accepted at our facility. A Service Repair Request is available at www.
horizonhobby.com on the “Support” tab. If you do not have internet access, please include a letter with
your complete name, street address, email address and phone number where you can be reached during
business days, your RMA number, a list of the included items, method of payment for any non-warranty
expenses and a brief summary of the problem. Your original sales receipt must also be included for warranty consideration. Be sure your name, address, and RMA number are clearly written on the outside of
the shipping carton.
Warranty Inspection and Repairs
To receive warranty service, you must include your original sales receipt verifying the proof-of-purchase
date. Provided warranty conditions have been met, your Product will be repaired or replaced free of charge.
Repair or replacement decisions are at the sole discretion of Horizon Hobby.
Non-Warranty Repairs
Should your repair not be covered by warranty the repair will be completed and payment will be required without notication or estimate of the expense unless the expense exceeds 50% of the retail purchase cost. By submitting the item for repair you are agreeing to payment of the repair without notication.
Repair estimates are available upon request. You must include this request with your repair. Non-warranty
repair estimates will be billed a minimum of ½ hour of labor. In addition you will be billed for return
freight. Please advise us of your preferred method of payment. Horizon accepts money orders and cashiers
checks, as well as Visa, MasterCard, American Express, and Discover cards. If you choose to pay by credit
card, please include your credit card number and expiration date. Any repair le unpaid or unclaimed
aer 90 days will be considered abandoned and will be disposed of accordingly. Please note: non-warranty
repair is only available on electronics and model engines.
Electronics and engines requiring inspection or repair should be shipped to the following address:
Horizon Service Center
4105 Fieldstone Road
Champaign, Illinois 61822
All other Products requiring warranty inspection or repair should be shipped to the following address:
Horizon Product Support
4105 Fieldstone Road
Champaign, Illinois 61822
Please call 877-504-0233 with any questions or concerns regarding this product or warranty.
Loading...
