Seagate ST9160314AS, ST9250315AS, ST9320325AS, ST9320325ASG, ST980313AS User Manual

Product Manual

Momentus® 5400.6 SATA

Standard models

ST9500325AS
ST9320325AS
ST9250315AS
ST9160314AS
ST9120315AS
ST980313AS

ST9500325ASG
ST9320325ASG
ST9250315ASG
ST9160314ASG
ST9120315ASG
ST980313ASG

100528359
Rev. G
December 2012

© 2012 Seagate Technology LLC. All rights reserved.
Publication number: 100528359, Rev. G December 2012

Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or
other countries. Momentus and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its
affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply
product endorsement by NIST, the U.S., or Canadian governments. All other trademarks or registered trademarks are the property of
their respective owners.

No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.
Call 877-PUB-TEK1(877-782-8351) to request permission.

When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your
computer’s operating system may use a different standard of measurement and report a lower capacity. In addition, some of the listed
capacity is used for formatting and other functions, and thus will not be available for data storage. Actual quantities will vary based on
various factors, including file size, file format, features and application software. Actual data rates may vary depending on operating
environment and other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S.
Department of Commerce, Bureau of Industry and Security (for more information, visit www.bis.doc.gov), and controlled for import
and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.

CONTENTS

SEAGATE TECHNOLOGY SUPPORT SERVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.0 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.1 ABOUT THE SERIAL ATA INTERFACE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.0 DRIVE SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.1 SPECIFICATION SUMMARY TABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.2 FORMATTED CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2.1 LBA mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.3 DEFAULT LOGICAL GEOMETRY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.4 PHYSICAL ORGANIZATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.5 RECORDING AND INTERFACE TECHNOLOGY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.6 PHYSICAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.7 SEEK TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.8 START/STOP TIMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.9 POWER SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.9.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.9.2 Deferred spinup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.9.3 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.9.4 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.9.5 Power-management modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.10 ENVIRONMENTAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.10.1 Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.10.2 Temperature gradient. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.10.3 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.10.4 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.10.5 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.10.6 Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.11 ACOUSTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.12 ELECTROMAGNETIC IMMUNITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.13 RELIABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.13.1 Free Fall Protection feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.14 AGENCY CERTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.14.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.14.2 Electromagnetic compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.14.3 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.15 ENVIRONMENTAL PROTECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.15.1 European Union Restriction of Hazardous Substances (RoHS) . . . . . . . . . . . . 20

2.15.2 China Restriction of Hazardous Substances (RoHS) Directive . . . . . . . . . . . . . 20

2.16 CORROSIVE ENVIRONMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.0 CONFIGURING AND MOUNTING THE DRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.1 HANDLING AND STATIC-DISCHARGE PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.2 CONFIGURING THE DRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.3 SERIAL ATA CABLES AND CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.4 DRIVE MOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.0 SERIAL ATA (SATA) INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.1 HOT-PLUG COMPATIBILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.2 SERIAL ATA DEVICE PLUG CONNECTOR PIN DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.3 SUPPORTED ATA COMMANDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.3.1 Identify Device command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.3.2 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.3.3 S.M.A.R.T. commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G I

FIGURES

Figure 1. Typical +5V only startup and operation current profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 2. Serial ATA connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 3. Attaching SATA cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Figure 4. Mounting dimensions—top, side and end view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G II

Seagate Technology Support Services

For information regarding online support and services, visit
Available services include:

• Presales & Technical support

• Global Support Services telephone numbers & business hours

• Authorized Service Centers

For information regarding Warranty Support, visit
For information regarding data recovery services, visit
For Seagate OEM and Distribution partner portal, visit
For Seagate reseller portal, visit

http://spp.seagate.com

http://www.seagate.com/support/warranty-and-returns

http://www.seagate.com/www/en-us/about/contact_us/

http://www.seagate.com/services-software/data-recovery-services/
https://direct.seagate.com/portal/system

Momentus 5400.6 SATA Product Manual, Rev. G 1

1.0 INTRODUCTION

This manual describes the functional, mechanical and interface specifications for the following Seagate
Momentus® 5400.6 SATA model drives:

STANDARD MODELS FREE-FALL PROTECTION MODELS

• ST9500325AS • ST9500325ASG

• ST9320325AS • ST9320325ASG

• ST9250315AS • ST9250315ASG

• ST9160314AS • ST9160314ASG

• ST9120315AS • ST9120315ASG

• ST980313AS • ST980313ASG

These drives provide the following key features:

• 5400-RPM spindle speed.

• 8-Mbyte buffer.

• Free Fall Protection (on ST9500325ASG, ST9320325ASG, ST9250315ASG, ST9160314ASG, ST9120315ASG, and
ST980313ASG models only)

• Quiet operation. Fluid Dynamic Bearing (FDB) motor.

• High instantaneous (burst) data-transfer rates (up to 3.0 Gbits/sec).

• Perpendicular recording technology.

• State-of-the-art cache and on-the-fly error-correction algorithms.

• Native Command Queuing (NCQ) with command ordering.

• Full-track multiple-sector transfer capability without local processor intervention.

• 1000 Gs nonoperating shock and 350 Gs of operating shock.

• SeaTools diagnostic software performs a drive self-test that eliminates unnecessary drive returns.

• The 3D Defense System™, which includes Drive Defense, Data Defense and Diagnostic Defense, offers the industry’s
most comprehensive protection for disc drives.

• Support for S.M.A.R.T. drive monitoring and reporting.

• Support for Read Multiple and Write Multiple commands.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 2

1.1 ABOUT THE SERIAL ATA INTERFACE

The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages
include:

• Easy installation and configuration with true plug-and-play connectivity. It is not normally necessary to set any jumpers or
other configuration options.

• Thinner and more flexible cabling for improved enclosure airflow and ease of installation.

• Scalability to higher performance levels.

In addition, Serial ATA makes the transition from parallel ATA easy by providing legacy software support. Serial ATA was
designed to allow you to install a Serial ATA host adapter and Serial ATA disc drive in your current system and expect all of
your existing applications to work as normal.

The Serial ATA interface connects each disc drive in a point-to-point configuration with the Serial ATA host adapter. There is
no master/slave relationship with Serial ATA devices like there is with parallel ATA. If two drives are attached on one Serial
ATA host adapter, the host operating system views the two devices as if they were both “masters” on two separate ports.
This essentially means both drives behave as if they are Device 0 (master) devices.

Note. The host adapter may, optionally, emulate a master/slave environment to host software where two devices on

separate Serial ATA ports are represented to host software as a Device 0 (master) and Device 1 (slave)
accessed at the same set of host bus addresses. A host adapter that emulates a master/slave environment man­ages two sets of shadow registers. This is not a typical Serial ATA environment.

The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide backward
compatibility with existing host systems and software. The Command and Control Block registers, PIO and DMA data
transfers, resets, and interrupts are all emulated.

The Serial ATA host adapter contains a set of registers that shadow the contents of the traditional device registers, referred
to as the Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how
Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The
specification can be downloaded from http://www.serialata.org.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 3

2.0 DRIVE SPECIFICATIONS

Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For
convenience, the phrases the drive and this drive are used throughout this manual to indicate the Momentus 5400.6 SATA
models.

2.1 SPECIFICATION SUMMARY TABLE

The specifications listed in this table are for quick reference. For details on specification measurement or definition, see the
appropriate section of this manual. .

Table 1 Drive specifications for 500, 400 and 320 GB models

Drive specification

Formatted Gbytes (512 bytes/sector)* 500 320
Guaranteed sectors 976,773,168 625,142,448
Bytes per sector 512
Physical read/write heads 4 3
Discs 2 2
Cache (Mbytes) 8
Recording density in BPI (bits/inch avg) 1490k
Track density TPI (tracks/inch avg) 265k
Areal density (Gbits/inch2 avg) 394
Spindle speed (RPM) 5400
Average latency (msec) 5.6
Internal transfer rate (Mbits/sec max) 1175
I/O data transfer rate

(Mbytes/sec max)
ATA data-transfer modes supported SATA 1.0, Serial ATA Revision 2.6

Height (max) 9.5 +/- 0.2 mm (0.374 +/- .0079 inches)
Width (max) 69.85 mm +/- 0.25 mm (2.75 +/- 0.0098 inches)
Length (max) 100.35 + 0.20 / - 0.25 mm (3.957 + 0.0079 / - 0.0098 inches)
Weight (max) 98.8 grams (0.218 lb)
Power-on to ready (sec typical) 3.6
Power-on to ready (sec max) 3.8
Standby to ready (sec typical) 1.8
Standby to ready (sec max) 2
Track-to-track seek time, read (msec typical) 1
Average seek, read (msec typical) 14
Full-stroke seek, read (msec max) 30
Startup current, +5V (max) 1 amp
Seek power (typical) 1.54 watts
Read/write power (typical) Read: 1.40 watts; Write: 1.78 watts
Idle mode, low power (typical) 0.67 watts
Standby mode 0.20 watts (typical)***
Sleep mode 0.20 watts (typical)***
Voltage tolerance (including noise) +5V ± 5%
Ambient temperature 0° to 60°C (operating), –40° to 70°C (nonoperating)
Temperature gradient

(°C per hour max)

ST9500325AS
ST9500325ASG

300

PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6

20°C (operating)
35°C (nonoperating)

ST9320325AS
ST9320325ASG

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 4

Table 1 Drive specifications for 500, 400 and 320 GB models

Drive specification

Relative humidity 5% to 95% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature

(°C max)
Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft)
Altitude, nonoperating

(meters below mean sea level, max)
Shock, operating (Gs max at 2 msec) 350
Shock, nonoperating (Gs max at 2 msec) 800
Shock, nonoperating (Gs max at 1 msec) 1000
Shock, nonoperating (Gs max at 0.5 msec) 600
Vibration, operating 1.0 G (0 to peak, 5–500 Hz)
Vibration, nonoperating 5.0 Gs (0 to peak, 5–500 Hz)
Drive acoustics, sound power (bels)
Idle** 2.4 (typical)

Performance seek 2.6 (typical)

Nonrecoverable read errors 1 per 10
Annualized Failure Rate (AFR) 0.48%
Load/Unload (U/UL) cycles

25°C, 50% relative humidity

32°C, 80% relative humidity
5°C, 80% relative humidity
5°C, 10% relative humidity
55°C, 16% relative humidity

Warranty For information regarding Warranty Support, visit:

Supports Hotplug operation per Serial ATA
Revision 2.6 specification

ST9500325AS
ST9500325ASG

5% to 95% (nonoperating)

37.7 (operating)
40 (nonoperating)

–304.8 m to 12,192 m (–1000 ft to 40,000+ ft)

2.6 (max)

2.7 (max)

14

bits read

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

http://www.seagate.com/support/warranty-and-returns

Yes (requires COMRESET from host after a hotplug event)

ST9320325AS
ST9320325ASG

see notes after Table 3.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 5

Table 2 Drive specifications for 250 and 160 GB models

Drive specification

Formatted Gbytes (512 bytes/sector)* 250 160
Guaranteed sectors 488,397,168 312,581,808
Bytes per sector 512
Physical read/write heads 2
Discs 1
Cache (Mbytes) 8
Recording density in BPI (bits/inch avg) 1490k 1238k
Track density TPI (tracks/inch avg) 265k 210k
Areal density (Gbits/inch2 avg) 394 269
Spindle speed (RPM) 5400
Average latency (msec) 5.6
Internal transfer rate (Mbits/sec max) 1175
I/O data transfer rate

(Mbytes/sec max)
ATA data-transfer modes supported SATA 1.0, Serial ATA Revision 2.6

Height (max) 9.5 +/- 0.2 mm (0.374 +/- .0079 inches)
Width (max) 69.85 mm +/- 0.25 mm (2.75 +/- 0.0098 inches)
Length (max) 100.35 + 0.20 / - 0.25 mm (3.957 + 0.0079 / - 0.0098 inches)
Weight (max) 93.5 grams (0.206 lb) 105 grams (0.23 lb)
Power-on to ready (sec typical) 3.6
Power-on to ready (sec max) 3.8
Standby to ready (sec typical) 1.8
Standby to ready (sec max) 2
Track-to-track seek time, read (msec typical) 1
Average seek, read (msec typical) 14
Full-stroke seek, read (msec max) 30
Startup current, +5V (max) 1 amp
Seek power (typical) 1.54 watts
Read/write power (typical) Read: 1.40 watts; Write: 1.78 watts
Idle mode, low power (typical) 0.67 watts
Standby mode 0.20 watts (typical)*** 0.22 watts (typical)***
Sleep mode 0.20 watts (typical)*** 0.22 watts (typical)***
Voltage tolerance (including noise) +5V ± 5%
Ambient temperature 0° to 60°C (operating), –40° to 70°C (nonoperating)
Temperature gradient

(°C per hour max)
Relative humidity 5% to 95% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature

(°C max)
Altitude, operating –304.8 m to 3,048 m (–1,000 ft to 10,000+ ft)
Altitude, nonoperating

(meters below mean sea level, max)
Shock, operating (Gs max at 2 msec) 350
Shock, nonoperating (Gs max at 2 msec) 800

ST9250315AS
ST9250315ASG ST9160314AS ST9160301AS

300

PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6

20°C (operating)
35°C (nonoperating)

5% to 95% (nonoperating)

37.7 (operating)
40 (nonoperating)

–304.8 m to 12,192 m (–1000 ft to 40,000+ ft)

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 6

Table 2 Drive specifications for 250 and 160 GB models

Drive specification

Shock, nonoperating (Gs max at 1 msec) 1000
Shock, nonoperating (Gs max at 0.5 msec) 600
Vibration, operating 1.0 G (0 to peak, 5–500 Hz)
Vibration, nonoperating 5.0 Gs (0 to peak, 5–500 Hz)
Drive acoustics, sound power (bels)
Idle** 2.4 (typical)

Performance seek 2.6 (typical)

Nonrecoverable read errors 1 per 10
Annualized Failure Rate (AFR) 0.48%
Load/Unload (U/UL) cycles

25°C, 50% relative humidity

32°C, 80% relative humidity
5°C, 80% relative humidity
5°C, 10% relative humidity
55°C, 16% relative humidity

Warranty For information regarding Warranty Support, visit:

Supports Hotplug operation per Serial ATA
Revision 2.6 specification

ST9250315AS
ST9250315ASG ST9160314AS ST9160301AS

2.6 (max)

2.7 (max)

14

bits read

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

http://www.seagate.com/support/warranty-and-returns

Yes (requires COMRESET from host after a hotplug event)

2.0 (typical)

2.2 (max)

2.5 (typical)

2.6 (max)

see notes after Table 3.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 7

.

Table 3 Drive specifications for 120 and 80 GB models

Drive specification

Formatted Gbytes (512 bytes/sector)* 120 80
Guaranteed sectors 234,441,648 156,301,488
Bytes per sector 512
Physical read/write heads 1
Discs 1
Cache (Mbytes) 8
Recording density in BPI (bits/inch avg) 1490k
Track density TPI (tracks/inch avg) 265k
Areal density (Gbits/inch2 avg) 394
Spindle speed (RPM) 5400
Average latency (msec) 5.6
Internal transfer rate (Mbits/sec max) 1175
I/O data transfer rate

(Mbytes/sec max)
ATA data-transfer modes supported SATA 1.0, Serial ATA Revision 2.6

Height (max) 9.5 +/- 0.2 mm (0.374 +/- .0079 inches)
Width (max) 69.85 mm +/- 0.25 mm (2.75 +/- 0.0098 inches)
Length (max) 100.35 + 0.20 / - 0.25 mm (3.957 + 0.0079 / - 0.0098 inches)
Weight (max) 93.5 grams (0.206 lb)
Power-on to ready (sec typical) 3.6
Power-on to ready (sec max) 3.8
Standby to ready (sec typical) 1.8
Standby to ready (sec max) 2
Track-to-track seek time, read (msec typical) 1
Average seek, read (msec typical) 14
Full-stroke seek, read (msec max) 30
Startup current, +5V (max) 1 amp
Seek power (typical) 1.54 watts
Read/write power (typical) Read: 1.40 watts; Write: 1.78 watts
Idle mode, low power (typical) 0.67 watts
Standby mode 0.20 watts (typical)***
Sleep mode 0.20 watts (typical)***
Voltage tolerance (including noise) +5V ± 5%
Ambient temperature 0° to 60°C (operating), –40° to 70°C (nonoperating)
Temperature gradient

(°C per hour max)
Relative humidity 5% to 95% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature

(°C max)
Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft)
Altitude, nonoperating

(meters below mean sea level, max)
Shock, operating (Gs max at 2 msec) 350
Shock, nonoperating (Gs max at 2 msec) 800

ST9120315AS
ST9120315ASG

300

PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6

20°C (operating)
35°C (nonoperating)

5% to 95% (nonoperating)

37.7 (operating)
40 (nonoperating)

–304.8 m to 12,192 m (–1000 ft to 40,000+ ft)

ST980313AS
ST980313ASG

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 8

Table 3 Drive specifications for 120 and 80 GB models

Drive specification

Shock, nonoperating (Gs max at 1 msec) 1,000
Shock, nonoperating (Gs max at 0.5 msec) 600
Vibration, operating 1.0 G (0 to peak, 5–500 Hz)
Vibration, nonoperating 5.0 Gs (0 to peak, 5–500 Hz)
Drive acoustics, sound power (bels)
Idle** 2.4 (typical)

Performance seek 2.5 (typical)

Nonrecoverable read errors 1 per 10
Annualized Failure Rate (AFR) 0.48%
Load/Unload (U/UL) cycles

25°C, 50% relative humidity

32°C, 80% relative humidity
5°C, 80% relative humidity
5°C, 10% relative humidity
55°C, 16% relative humidity

Warranty For information regarding Warranty Support, visit:

Supports Hotplug operation per Serial ATA
Revision 2.6 specification

ST9120315AS
ST9120315ASG

2.6 (max)

2.6 (max)

14

bits read

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

http://www.seagate.com/support/warranty-and-returns

Yes (requires COMRESET from host after a hotplug event)

ST980313AS
ST980313ASG

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.
**During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational

levels.

***Typical notebooks will pull power to the drive when entering S3 and S4; while in the S3 and S4 states, drive sleep and drive standby modes will not

contribute to battery power consumption.

2.2 FORMATTED CAPACITY

Model Formatted capacity* Guaranteed sectors Bytes per sector

ST9500325AS and ST9500325ASG 500 Gbytes 976,773,168
ST9320325AS and ST9320325ASG 320 Gbytes 625,142,448
ST9250315AS and ST9250315ASG 250 Gbytes 488,397,168

512

ST9160314AS and ST9160314ASG 160 Gbytes 312,581,808
ST9120315AS and ST9120315ASG 120 Gbytes 234,441,648
ST980313AS and ST980313ASG 80 Gbytes 156,301,488

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.

2.2.1 LBA mode

When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the
number of guaranteed sectors as defined above.

See Section 4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-bit addressing
support of drives with capacities over 137 Gbytes.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 9

2.3 DEFAULT LOGICAL GEOMETRY

CYLINDERS READ/WRITE HEADS SECTORS PER TRACK

16,383 16 63

LBA mode

When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the
number of guaranteed sectors as defined above.

2.4 PHYSICAL ORGANIZATION

DRIVE MODEL READ/WRITE HEADS NUMBER OF DISCS

ST9500325AS and ST9500325ASG 4 2
ST9320325AS and ST9320325ASG 3 2
ST9250315AS, ST9250315ASG,

ST9160314AS and ST9160314ASG
ST9120315AS, ST9120315ASG,

ST980313AS and ST980313ASG

2 1

1 1

2.5 RECORDING AND INTERFACE TECHNOLOGY

ST9500325AS, ST9500325ASG,
ST9320325AS, ST9320325ASG,
ST9250315AS, ST9250315ASG
ST9160314AS, ST9160314ASG,
ST9120315AS, ST9120315ASG,
ST980313AS, ST980313ASG

Interface Serial ATA (SATA)
Recording method Perpendicular
Recording density BPI (bits/inch avg) 1490k
Track density TPI (tracks/inch avg) 265k

2

Areal density (Gbits/inch
Spindle speed (RPM) (± 0.2%) 5400
Maximum Internal transfer rate (Mbits/sec) 1175
I/O data-transfer rate (Mbytes/sec max) 300
Interleave 1:1
Cache buffer 8 Mbytes (8192 kbytes)

avg)

394

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 10

2.6 PHYSICAL CHARACTERISTICS

DRIVE SPECIFICATION

Height (mm)

(inches)

Width (mm)

(inches)

Length (mm)

(inches)

Weight (max)

ST9500325AS
ST9500325ASG
ST9320325AS
ST9320325ASG

ST9250315AS
ST9250315ASG
ST9160314AS
ST9160314ASG
ST9120315AS
ST9120315ASG
ST980313AS
ST980313ASG

9.5 +/-0.2

0.374 +/-0.0079

69.85 +/-0.25

2.75 +/-0.0098

100.35 +0.20 / -0.25

3.957 +0.0079 / -0.0098

98.8 grams

0.218 pounds

93.5 grams

0.206 pounds

2.7 SEEK TIME

Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive
diagnostics. The specifications in the table below are defined as follows:

• Track-to-track seek time is an average of all possible single-track seeks in both directions.

• Average seek time is a true statistical random average of at least 5000 measurements of seeks between random tracks,
less overhead.

Table 4 Typical seek times

SEEK TIMES (MSEC) READ

Track-to-track (typical) 1
Average (typical) 14
Full-stroke (max) 30
Average latency 5.56

Note. These drives are designed to consistently meet the seek times represented in this manual. Physical seeks,

regardless of mode (such as track-to-track and average), are expected to meet the noted values. However, due
to the manner in which these drives are formatted, benchmark tests that include command overhead or measure
logical seeks may produce results that vary from these specifications.

2.8 START/STOP TIMES

TIME TO READY TYPICAL MAX @ 25°C

Power-on to Ready (sec) 3.6 3.8
Standby to Ready (sec) 1.8 2

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 11

2.9 POWER SPECIFICATIONS

The drive receives DC power (+5V) through a native SATA power connector.

2.9.1 Power consumption

Power requirements for the drives are listed in the table on page

12. Typical power measurements are based on an average

of drives tested, under nominal conditions, at 25°C ambient temperature.

• Spinup power

Spinup power is measured from the time of power-on to the time that the drive spindle reaches operating speed.

• Seek mode

During seek mode, the read/write actuator arm moves toward a specific position on the disc surface and does not execute
a read or write operation. Servo electronics are active. Seek mode power is measured based on three random seek
operations every 100 msecs. This mode is not typical.

• Read/write power and current

Read/write power is measured with the heads on track, based on three 63 sector read or write operations every 100 msecs.

• Idle mode power

Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track
location.

• Standby mode

During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write electronics
are in power-down model

Table 5 DC power

POWER DISSIPATION +5V INPUT AVERAGE (25° C)

Spinup (max) 1 amp
Seek 1.54 watts
Read 1.40 watts
Write 1.78 watts
Idle, performance* 1.40 watts
Idle, active* 0.78 watts
Idle, low power mode* 0.67 watts
Standby** 0.20 watts
Sleep 0.20 watts

*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational

levels.

**Standby power is measured at steady state (after 200ms from transition)

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 12

2.9.1.1 Typical current profile

Figure 1. Typical +5V only startup and operation current profile

2.9.2 Deferred spinup

Momentus 5400.6 SATA drives do not support the deferred spinup option. If you require this option, refer to the Momentus

5400.3 SATA Blade Server family of drives.

2.9.3 Conducted noise

Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt
line.

Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at
up to 10 MHz.

Note. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current.

2.9.4 Voltage tolerance

Voltage tolerance (including noise):
5V ± 5%

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 13

2.9.5 Power-management modes

The drive provides programmable power management to provide greater energy efficiency. In most systems, you can control
power management through the system setup program. The drive features the following power-management modes:

Table 6 Power management modes

POWER MODES HEADS SPINDLE BUFFER

Active (operating) Tracking Rotating Full power
Idle, performance Tracking Rotating Self refresh—low power
Idle, active Floating Rotating Self refresh—low power
Idle, low power Parked Rotating Self refresh—low power
Standby Parked Stopped Self refresh—low power
Sleep Parked Stopped Self refresh—low power

• Active mode

The drive is in Active mode during the read/write and seek operations.

• Idle mode

The buffer remains enabled, and the drive accepts all commands and returns to Active mode any time disc access is
necessary.

• Standby mode

The drive enters Standby mode when the host sends a Standby Immediate command. If the host has set the standby timer,
the drive can also enter Standby mode automatically after the drive has been inactive for a specifiable length of time. The
standby timer delay is established using a Standby or Idle command. In Standby mode, the drive buffer is in Self Refresh
Low Power mode, the heads are parked and the spindle is at rest. The drive accepts all commands and returns to Active
mode any time disc access is necessary.

• Sleep mode

The drive enters Sleep mode after receiving a Sleep command from the host. In Sleep mode, the drive buffer is in Self
Refresh Low Power mode, the heads are parked and the spindle is at rest. The drive leaves Sleep mode after it receives a
Hard Reset or Soft Reset from the host. After receiving a reset, the drive exits Sleep mode and enters Standby mode with
all current translation parameters intact.

• Idle and Standby timers

Each time the drive performs an Active function (read, write or seek), the standby timer is reinitialized and begins count­ing down from its specified delay times to zero. If the standby timer reaches zero before any drive activity is required, the
drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all commands and returns to
Active mode when disc access is necessary.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 14

2.10 ENVIRONMENTAL SPECIFICATIONS

2.10.1 Ambient temperature

Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case
temperature should not exceed

70°C (158°F) within the operating ambient conditions.

Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet.

Operating: 0° to 60°C (32° to 140°F)
Nonoperating:

–40° to 70°C (–40° to 158°F)

Note. The recommended storage period:

• 1 year under controlled conditions of 34°C 90%RH or less

• 90 days in uncontrolled storage conditions

2.10.2 Temperature gradient

Operating 20°C per hour (68°F per hour max), without condensation
Nonoperating 35°C per hour (95°F per hour max), without condensation

2.10.3 Humidity

2.10.3.1 Relative humidity

Operating 5% to 95% noncondensing (30% per hour max)
Nonoperating 5% to 95% noncondensing (30% per hour max)

2.10.3.2 Wet bulb temperature

Operating 37.7°C (99.86°F max)
Nonoperating 40°C (104°F max)

2.10.4 Altitude

Operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft)
Nonoperating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft)

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 15

2.10.5 Shock

All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws.
Shock may be applied in the X, Y or Z axis.

Note. Additional shock protection is provided by the Free Fall Protection feature on ST9500325ASG, ST9320325ASG,

ST9250315ASG, ST9160314ASG, ST9120315ASG and ST980313ASG models. See Section 2.13.1 for addi­tional information about this feature.

2.10.5.1 Operating shock

These drives comply with the performance levels specified in this document when subjected to a maximum operating shock
of 350 Gs based on half-sine shock pulses of 2 msec. Shocks should not be repeated more than two times per second.

2.10.5.2 Nonoperating shock

The nonoperating shock level that the drive can experience without incurring physical damage or degradation in
performance when subsequently put into operation is 800 Gs based on a nonrepetitive half-sine shock pulse of 2 msec
duration.

The nonoperating shock level that the drive can experience without incurring physical damage or degradation in
performance when subsequently put into operation is 1000 Gs based on a nonrepetitive half-sine shock pulse of 1 msec
duration.

The nonoperating shock level that the drive can experience without incurring physical damage or degradation in
performance when subsequently put into operation is 600 Gs based on a nonrepetitive half-sine shock pulse of 0.5 msec
duration.

2.10.6 Vibration

All vibration specifications assume that the drive is mounted securely with the input vibration applied at the drive mounting
screws. Vibration may be applied in the X, Y or Z axis.

2.10.6.1 Operating vibration

The maximum vibration levels that the drive may experience while meeting the performance standards specified in this
document are specified below.

5–500 Hz 1.0 Gs (0 to peak). Max displacement may apply below 10 Hz.

2.10.6.2 Nonoperating vibration

The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in
performance when subsequently put into operation are specified below

5–500 Hz: 5.0 Gs (0 to peak). Max displacement may apply below 22 Hz.

.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 16

2.11 ACOUSTICS

Drive emission of sound is measured consistent with the ECMA-74 and its’ referenced standards. Testing is conducted at
room temperature (approximately 25°C). Emission levels are reported as the total A-weighted sound power levels for steady
state, idle, and active seek modes of operation.

Table 7 Drive A-weighted Sound Power Levels (SWL, BA)

IDLE*PERFORMANCE SEEK
ST9500325AS, ST9500325ASG,

ST9320325AS, ST9320325ASG,
ST9250315AS, ST9250315ASG,
ST9160314AS, ST9160314ASG,
ST9120315AS, ST9120315ASG,
ST980313AS, ST980313ASG

ST9500325AS, ST9500325ASG,
ST9320325AS, ST9320325ASG,
ST9250315AS, ST9250315ASG,
ST9160314AS, ST9160314ASG

ST9120315AS, ST9120315ASG,
ST980313AS, ST980313ASG

2.4 bels (typ)

2.6 bels (max)

*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational

levels.

2.6 bels (typ)

2.7 bels (max)

2.5 bels (typ)

2.6 bels (max)

Test for Prominent Discrete Tones (PDTs)

Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use
of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to
compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74
standards.

*Defined as the median curve given by ISO 389-7 (Tf curve) minus 10dB at all frequencies.

2.12 ELECTROMAGNETIC IMMUNITY

When properly installed in a representative host system, the drive operates without errors or degradation in performance
when subjected to the radio frequency (RF) environments defined in the following table:

Table 8 Radio frequency environments

TEST DESCRIPTION

Electrostatic discharge
Radiated RF immunity 80 to 2,000 MHz, 10 V/m,

Contact, HCP, VCP: ± 4

80% AM with 1 kHz sine
900 MHz, 3 V/m, 50% pulse modulation @ 200 Hz

kV; Air: ± 8 kV

PERFORMANCE

LEVEL

B EN 61000-4-2: 95
A EN 61000-4-3: 96

REFERENCE

STANDARD

ENV 50204: 95

Electrical fast transient ± 1 kV on AC mains, ± 0.5 kV on external I/O B EN 61000-4-4: 95
Surge immunity ± 1 kV differential, ± 2 kV common, AC mains B EN 61000-4-5: 95
Conducted RF immunity 150 kHz to 80 MHz, 3 Vrms, 80% AM with 1 kHz

sine

Power Frequency H-field
immunity

Voltage dips, interrupts 30% Reduction for 25 cycles

1 A/m, 50Hz/60Hz, 3 axes A EN 61000-4-8: 97

>95% Reduction for 250 cycles
>95%, 0.5 cycles

A EN 61000-4-6: 97

C
C
B

EN 61000-4-11: 94

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 17

2.13 RELIABILITY

MEASUREMENT TYPE SPECIFICATION

Nonrecoverable read errors
Annualized Failure Rate (AFR) <0.48%

Load/Unload (U/UL)
25°C, 50% relative humidity

32°C, 80% relative humidity
5°C, 80% relative humidity
5°C, 10% relative humidity
55°C, 16% relative humidity

Warranty For information regarding Warranty Support, visit:

1 per 10

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles

http://www.seagate.com/support/warranty-and-returns

14

bits read, max.

2.13.1 Free Fall Protection feature

The Free Fall Protection feature provides enhanced data protection against shock events that may occur while the drive is
operating.

This feature is designed to decrease the likelihood of data loss by detecting a free fall event and unloading the
actuator before a shock takes place in falls of >8 inches (nominal). The drive uses a 0 G sensor mounted on the printed
circuit board assembly (PCBA) to sense this event.

To enable the Free Fall Protection feature on ST9500325ASG, ST9320325ASG, ST9250315ASG, ST9160314ASG,
ST9120315ASG and ST980313ASG models, use Set Features command 41h. To disable this feature, use Set Features
command C1h.

Information about Free Fall Events that have occurred is available through SMART attribute FEh.
Note. Of the models documented in this product manual, the Free Fall Protection feature is provided only on

ST9500325ASG, ST9320325ASG, ST9250315ASG, ST9160314ASG, ST9120315ASG, and ST980313ASG
models.

2.14 AGENCY CERTIFICATION

2.14.1 Safety certification

The drives are recognized in accordance with UL 1950 and CSA C22.2 (950) and meet all applicable sections of IEC950 and
EN 60950 as tested by TUV North America.

2.14.2 Electromagnetic compatibility

Hard drives that display the CE mark comply with the European Union (EU) requirements specified in the Electromagnetic
Compatibility Directive (89/336/EEC). Testing is performed to the levels specified by the product standards for Information
Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN

55024.
Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph.

Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when
used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for
operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused
I/O ports. Computer manufacturers and system integrators should confirm EMC compliance and provide CE marking for their
products.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 18

Korean RRL

If these drives have the Korea Ministry of Information and Communication (MIC) logo, they comply with paragraph 1 of
Article 11 of the Electromagnetic Compatibility control Regulation and meet the Electromagnetic Compatibility (EMC)
Framework requirements of the Radio Research Laboratory (RRL) Ministry of Information and Communication Republic of
Korea.

These drives have been tested and comply with the Electromagnetic Interference/Electromagnetic Susceptibility (EMI/EMS)
for Class B products. Drives are tested in a representative, end-user system by a Korean-recognized lab.

• Certificate number: STX-54006 (B)

• Trade name or applicant: Seagate Technology LLC

• Date of Certification: October 01, 2008

• Manufacturer/nationality: USA, Singapore and China

Australian C-Tick (N176)

If these models have the C-Tick marking, they comply with the Australia/New Zealand Standard AS/NZS3548 1995 and meet
the Electromagnetic Compatibility (EMC) Framework requirements of the Australian Communication Authority (ACA).

2.14.3 FCC verification

These drives are intended to be contained solely within a personal computer or similar enclosure (not attached as an
external device). As such, each drive is considered to be a subassembly even when it is individually marketed to the
customer. As a subassembly, no Federal Communications Commission verification or certification of the device is required.

Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly
(enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device,
pursuant to Subpart J, Part 15 of the FCC rules. Operation with noncertified assemblies is likely to result in interference to
radio and television reception.

Radio and television interference. This equipment generates and uses radio frequency energy and if not installed and
used in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.

This equipment is designed to provide reasonable protection against such interference in a residential installation. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to
radio or television, which can be determined by turning the equipment on and off, you are encouraged to try one or more of
the following corrective measures:

• Reorient the receiving antenna.

• Move the device to one side or the other of the radio or TV.

• Move the device farther away from the radio or TV.

• Plug the computer into a different outlet so that the receiver and computer are on different branch outlets.
If necessary, you should consult your dealer or an experienced radio/television technician for additional suggestions. You

may find helpful the following booklet prepared by the Federal Communications Commission: How to Identify and Resolve
Radio-Television Interference Problems. This booklet is available from the Superintendent of Documents, U.S. Government
Printing Office, Washington, DC 20402. Refer to publication number 004-000-00345-4.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 19

2.15 ENVIRONMENTAL PROTECTION

Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting
certain chemical substances.

2.15.1 European Union Restriction of Hazardous Substances (RoHS)

Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting
certain
restricts the presence of chemical substances, including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE,
in electronic products, effective July 2006. This drive is manufactured with components and materials that comply with the
RoHS Directive..

2.15.2 China Restriction of Hazardous Substances (RoHS) Directive

This product has an Environmental Protection Use Period (EPUP) of 20 years. The following table contains
information mandated by China's "Marking Requirements for Control of Pollution Caused by Electronic
Information Products" Standard.

chemical substances. A new law, the European Union Restriction of Hazardous Substances (RoHS) Directive,

"O" indicates the hazardous and toxic substance content of the part (at the homogenous material level) is lower than the
threshold defined by the China RoHS MCV Standard.

"X" indicates the hazardous and toxic substance content of the part (at the homogenous material level) is over the threshold
defined by the China RoHS MCV Standard.

2.16 CORROSIVE ENVIRONMENT

Seagate electronic drive components pass accelerated corrosion testing equivalent to 10 years exposure to light industrial
environments containing sulfurous gases, chlorine and nitric oxide, classes G and H per ASTM B845. However, this
accelerated testing cannot duplicate every potential application environment.

Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals
as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold
films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur
is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the
surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. Materials
used in cabinet fabrication, such as vulcanized rubber, that can outgas corrosive compounds should be minimized or
eliminated. The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free
alternatives.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 20

3.0 CONFIGURING AND MOUNTING THE DRIVE

This section contains the specifications and instructions for configuring and mounting the drive.

3.1 HANDLING AND STATIC-DISCHARGE PRECAUTIONS

After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD)
hazards. Observe the following standard handling and static-discharge precautions:

Caution:

• Keep the drive in the electrostatic discharge (ESD) bag until you are ready for installation to limit the drive’s exposure to ESD.

• Before handling the drive, put on a grounded wrist strap, or ground yourself frequently by touching the metal chassis of a

computer that is plugged into a grounded outlet. Wear a grounded wrist strap throughout the entire installation procedure.

• Handle the drive only by its edges or frame.

• The drive is fragile—handle it with care. Do not press down on the drive top cover.

• Always rest the drive on a padded, antistatic surface until you mount it in the computer.

• Do not touch the connector pins or the printed circuit board.

• Do not remove the factory-installed labels from the drive or cover them with additional labels. Removal voids the warranty.

Some factory-installed labels contain information needed to service the drive. Other labels are used to seal out dirt and
contamination.

3.2 CONFIGURING THE DRIVE

Each drive on the Serial ATA interface connects in a point-to-point configuration with the Serial ATA host adapter. There is no
master/slave relationship because each drive is considered a master in a point-to-point relationships. If two drives are
attached on one Serial ATA host adapter, the host operating system views the two devices as if they were both “masters” on
two separate ports. This means both drives behave as if they are Device 0 (master) devices.

Serial ATA drives are designed for easy installation. It is normally not necessary to set any jumpers on this drive for proper
operation. If the host system does not support SATA 3Gb/s operation, place a jumper on pins 1 and 2 to limit the drive to

1.5Gb/s operation.

3.0 Gbits per second operation

Limit data transfer rate to

1.5 Gbits per second

Jumper block

SATA interface connector

Figure 2. Serial ATA connectors

SATA power connector

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 21

3.3 SERIAL ATA CABLES AND CONNECTORS

The Serial ATA interface cable consists of four conductors in two differential pairs, plus three ground connections. The cable
size may be 30 to 26 AWG with a maximum length of one meter (39.37 inches). See Table 9 for connector pin definitions.
Either end of the SATA signal cable can be attached to the drive or host.

For direct backplane connection, the drive connectors are inserted directly into the host receptacle. The drive and the host
receptacle incorporate features that enable the direct connection to be hot pluggable and blind mateable.

For installations which require cables, you can connect the drive as illustrated in Figure 3.

inter ace connector

Power connector

inter ace ca le

Power ca le

Figure 3. Attaching SATA cabling

Each cable is keyed to ensure correct orientation.

3.4 DRIVE MOUNTING

You can mount the drive using four screws in the side-mounting holes or four screws in the bottom-mounting holes. See
Figure Figure 4. for drive mounting dimensions. Follow these important mounting precautions when mounting the drive:

• Allow a minimum clearance of 0.030 inches (0.76 mm) around the entire perimeter of the drive for cooling.

• Use only M3 UNC mounting screws.

• Do not overtighten the mounting screws. Maximum torque: 4.0 inch-lb (0.4519 N-m).

• Four (4) threads (0.080 inches, 2.032 mm) minimum screw engagement recommended.

• Avoid excessive drive distortion when mounting. Refer to the following specifications for stiffness/deflection information:

TOP COVER STIFFNESS/DEFLECTION

Operating with no performance degradation, emitted noise,
mechanical damage, or hard errors

Non-operating with no hard errors 20 mm probe: 2kgf at any point of top cover

10 mm probe: 2.0kgf OR
5 mm probe: 0.92kgf

20 mm probe: 15kgf at top cover edges only

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 22

Measurements shown in Figure 4 are in inches.

Figure 4. Mounting dimensions—top, side and end view

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 23

4.0 SERIAL ATA (SATA) INTERFACE

These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed
input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6. The drive also supports the use of
the IORDY signal to provide reliable high-speed data transfers.

For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”
specification.

4.1 HOT-PLUG COMPATIBILITY

Momentus 5400.6 SATA drives incorporate connectors which enable you to hot plug these drives in accordance with the
Serial ATA: High Speed Serialized AT Attachment specification revision 2.0. This specification can be downloaded from http:/
/www.serialata.org. This device requires a COMRESET from the host after a hotplug event.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 24

4.2 SERIAL ATA DEVICE PLUG CONNECTOR PIN DEFINITIONS

Table 9 summarizes the signals on the Serial ATA interface and power connectors..

Table 9 Serial ATA connector pin definitions

SEGMENT PIN FUNCTION DEFINITION

S1 Ground 2nd mate
S2 A+ Differential signal pair A from Phy
S3 A­S4 Ground 2nd mate
S5 B- Differential signal pair B from Phy
S6 B+

Signal

S7 Ground 2nd mate

Key and spacing separate signal and power segments

Power

P1 V
P2 V
P3 V

33

33

33

3.3V power

3.3V power

3.3V power, pre-charge, 2nd mate

P4 Ground 1st mate
P5 Ground 2nd mate
P6 Ground 2nd mate
P7 V

P8 V
P9 V

5

5

5

5V power, pre-charge, 2nd mate
5V power
5V power

P10 Ground 2nd mate
P11 Reserved The pin corresponding to P11 in the backplane receptacle connector is also reserved

The corresponding pin to be mated with P11 in the power cable receptacle connector

shall always be grounded
P12 Ground 1st mate.
P13 V

P14 V
P15 V

12

12

12

12V power, pre-charge, 2nd mate

12V power

12V power

Notes:

1. All pins are in a single row, with a 1.27 mm (0.050”) pitch.

2. The comments on the mating sequence apply to the case of backplane blindmate connector only. In this case, the mat­ing sequences are:

• the ground pins P4 and P12.

• the pre-charge power pins and the other ground pins.

• the signal pins and the rest of the power pins.

3. There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind­mate backplane configuration.

4. All used voltage pins (Vx) must be terminated.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 25

4.3 SUPPORTED ATA COMMANDS

The fo llo win g tabl e lis ts Se rial A TA st and ard co mma nds t hat th e dri ve su ppo rts. F or a de tai led de scr ipt ion of t he AT A
commands, refer to the Serial ATA: High Speed Serialized AT Attachment specification. See “S.M.A.R.T . comma nds” on
page 33.for details and subcommands used in the S.M.A.R.T. implementation.

OMMAND NAME COMMAND CODE (IN HEX)

C
ATA-

STANDARD COMMANDS

Device Configuration Restore B1h/C0h
Device Configuration Freeze Lock B1h/C1h
Device Configuration Identify B1h/C2h
Device Configuration Set B1h/C3h
Download Microcode 92h
Execute Device Diagnostics 90h
Flush Cache E7h
Flush Cache Extended EAh
Identify Device ECh
Initialize Device Parameters 91h
Read Buffer E4h
Read DMA C8h
Read DMA Extended 25h
Read DMA without Retries C9h
Read Long with Retries 22h
Read Long without Retries 23h
Read Multiple C4h
Read Multiple Extended 29h
Read Native Max Address F8h
Read Native Max Address Extended 27h
Read Sectors 20h
Read Sectors Extended 24h
Read Sectors without Retries 21h
Read Verify Sectors 40h
Read Verify Sectors Extended 42h
Read Verify Sectors without Retries 41h
Seek 70h
Set Features EFh
Set Max Address F9h
Note: Individual Set Max commands are identi-

fied by the value placed in the Set Max Fea­tures register as defined to the right.

Address:
Password:
Lock:
Unlock:
Freeze Lock:

00
01
02
03
04

H
H
H
H
H

Set Multiple Mode C6h
S.M.A.R.T. Disable Operations B0h/D9h
S.M.A.R.T. Enable/Disable Autosave B0h/D2h

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 26

COMMAND NAME COMMAND CODE (IN HEX)

S.M.A.R.T. Enable Operations B0h/D8h
S.M.A.R.T. Enable/Disable Auto Offline B0h/DBh
S.M.A.R.T. Enable One Attribute Modification B0h/E0h
S.M.A.R.T. Execute Offline B0h/D4h
S.M.A.R.T. Read Attribute Thresholds B0h/D1h
S.M.A.R.T. Read Data B0h/D0h
S.M.A.R.T. Read Log Sector B0h/D5h
S.M.A.R.T. Return Status B0h/DAh
S.M.A.R.T. Save Attribute Values B0h/D3h
S.M.A.R.T. Write Attribute Thresholds B0h/D7h
S.M.A.R.T. Write Attribute Values B0h/E1h
S.M.A.R.T. Write Log Sector B0h/D6h
Write Buffer E8h
Write DMA CAh
Write DMA Extended 35h
Write DMA without Retries CBh
Write Long with Retries 32h
Write Long without Retries 33h
Write Multiple C5h
Write Multiple Extended 39h
Write Sectors 30h

Write Sectors Extended 34h
Write Uncorrectable 45h

ATA-STANDARD POWER-MANAGEMENT COMMANDS

Check Power Mode E5h
Idle E3h
Idle Immediate E1h
Sleep E6h
Standby E2h
Standby Immediate E0h

ATA-STANDARD SECURITY COMMANDS

,

31h

Security Set Password F1h
Security Unlock F2h
Security Erase Prepare F3h
Security Erase Unit F4h
Security Freeze Lock F5h
Security Disable Password F6h

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 27

4.3.1 Identify Device command

The Identify Device command (command code ECH) transfers information about the drive to the host following power up.
The data is organized as a single 512-byte block of data, whose contents are shown in the table on page 27. All reserved bits
or words should be set to zero. Parameters listed with an “x” are drive-specific or vary with the state of the drive.

The following commands contain drive-specific features that may not be included in the Serial ATA specification.

WORD DESCRIPTION VALUE

0

Configuration information:

• Bit 15: 0 = ATA; 1 = ATAPI

• Bit 7: removable media

0C5A

• Bit 6: removable controller

• Bit 0: reserved
1 Number of logical cylinders 16,383
2 ATA-reserved 0000

3 Number of logical heads 16
4 Retired 0000

5 Retired 0000
6 Number of logical sectors per logical track: 63 003F
7–9 Retired 0000
10–19 Serial number: (20 ASCII characters, 0000H = none) ASCII
20 Retired 0000
21 Retired 0400
22 Obsolete 0000
23–26 Firmware revision (8 ASCII character string, padded with

x.xx

blanks to end of string)

H

H

H

H

H

H

H

H

H

27–46 Drive model number: (40 ASCII characters, padded with

blanks to end of string)

ST9500325AS
ST9500325ASG
ST9320325AS
ST9320325ASG
ST9250315AS
ST9250315ASG
ST9160314AS
ST9160314ASG
ST9120315AS
ST9120315ASG
ST980313AS
ST980313ASG

47 (Bits 7–0) Maximum sectors per interrupt on Read multiple

8010

and Write multiple (16)

48 Reserved 0000
49 Standard Standby timer, IORDY supported and may be dis-

2F00

abled

50 ATA-reserved 0000
51 PIO data-transfer cycle timing mode 0200
52 Retired 0200
53 Words 54–58, 64–70 and 88 are valid 0007
54 Number of current logical cylinders xxxx
55 Number of current logical heads xxxx

H

H

H

H

H

H

H

H

H

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 28

WORD DESCRIPTION VALUE

56 Number of current logical sectors per logical track xxxx
57–58 Current capacity in sectors xxxx
59 Number of sectors transferred during a Read Multiple or

xxxx

Write Multiple command

60–61 Total number of user-addressable sectors

This field contains a value that is one greater than the total
number of user-addressable sectors. The maximum value
that shall be placed in this field is 0FFFFFFFh. The
0FFFFFFFh value applies to all capacities over 137Gbytes
(see Section 2.2 and 2.3 for related information).

ST9500325AS = 0FFFFFFFh
ST9500325ASG = 0FFFFFFFh
ST9320325AS = 0FFFFFFFh
ST9320325ASG = 0FFFFFFFh
ST9250315AS = 0FFFFFFFh
ST9250315ASG = 0FFFFFFFh
ST9160314AS = 0FFFFFFFh
ST9160314ASG = 0FFFFFFFh
ST9120315AS = 234,441,648
ST9120315ASG = 234,441,648
ST980313AS = 156,301,488
ST980313ASG = 156,301,488

62 Retired 0000
63 Multiword DMA active and modes supported

xx07

(see note following this table)

64 Advanced PIO modes supported (modes 3 and 4 supported) 0003
65 Minimum multiword DMA transfer cycle time per word

0078

(120 nsec)

H

H

H

H

H

H

H

66 Recommended multiword DMA transfer cycle time per word

0078

(120 nsec)

67 Minimum PIO cycle time without IORDY flow control

00F0

(240 nsec)

68 Minimum PIO cycle time with IORDY flow control (120 nsec) 0078
69–74 ATA-reserved 0000
75 Queue depth 001F
76 Serial ATA capabilities 0508
77 ATA-reserved 0000
78 Serial ATA features supported 0048
79 Serial ATA features enabled 0040
80 Major version number 003E
81 Minor version number 0028
82 Command sets supported 306B
83 Command sets supported 4001
84 Command sets support extension 6123
85 Command sets enabled 30xx
86 Command sets enabled 0001
87 Command sets enable extension 4000
88 Ultra DMA support and current mode

xx7F

(see note following this table)

H

H

H

H

H

H

H

H

H

H

H

H

H

H

H

H

H

H

89 Security erase time 0000
90 Enhanced security erase time 0000

H

H

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 29

WORD DESCRIPTION VALUE

92 Master password revision code FFFE
93 Hardware reset value

xxxx

H

H

(see description following this table)

94 Auto acoustic management setting xxxx
95–99 ATA-reserved 0000
100–

103

Total number of user-addressable LBA sectors available
(see Section 2.2 for related information)
These words are required for drives that support the 48-bit

addressing feature. Maximum value: 0000FFFFFFFFFFFFh.

H

H

ST9500325AS = 0FFFFFFFh
ST9500325ASG = 0FFFFFFFh
ST9320325AS = 0FFFFFFFh
ST9320325ASG = 0FFFFFFFh
ST9250315AS = 0FFFFFFFh
ST9250315ASG = 0FFFFFFFh
ST9160314AS = 0FFFFFFFh
ST9160314ASG = 0FFFFFFFh
ST9120315AS = 234,441,648
ST9120315ASG = 234,441,648
ST980313AS = 156,301,488
ST980313ASG = 156,301,488

104–

ATA-reserved 0000

H

118
119 Free Fall Protection support (bit 5) 1 = Free Fall Protection supported

0 = Free Fall Protection not supported

120 Free Fall Protection enable/disable (bit 5) 1 = Free Fall Protection feature is enabled

0 = Free Fall Protection feature is disabled

121–

ATA reserved 0000

H

127
128 Security status 0001

129–

Seagate-reserved xxxx

H

H

159
160–

ATA-reserved 0000

H

254
255 Integrity word xxA5

H

Note. See the bit descriptions below for words 63, 88, and 93 of the Identify Drive data:

Description (if bit is set to 1)

BIT WORD 63

0 Multiword DMA mode 0 is supported.
1 Multiword DMA mode 1 is supported.
2 Multiword DMA mode 2 is supported.
8 Multiword DMA mode 0 is currently active.
9 Multiword DMA mode 1 is currently active.
10 Multiword DMA mode 2 is currently active.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 30

BIT WORD 88

0 Ultra DMA mode 0 is supported.
1 Ultra DMA mode 1 is supported.
2 Ultra DMA mode 2 is supported.
3 Ultra DMA mode 3 is supported.
4 Ultra DMA mode 4 is supported.
5 Ultra DMA mode 5 is supported
6 Ultra DMA mode 6 is supported
8 Ultra DMA mode 0 is currently active.
9 Ultra DMA mode 1 is currently active.
10 Ultra DMA mode 2 is currently active.
11 Ultra DMA mode 3 is currently active.
12 Ultra DMA mode 4 is currently active.
13 Ultra DMA mode 5 is currently active.
14 Ultra DMA mode 6 is currently active.

BIT WORD 93

13 1 = 80-conductor cable detected, CBLID above VIH

0 = 40-conductor cable detected, CBLID below VIL

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 31

4.3.2 Set Features command

This command controls the implementation of various features that the drive supports. When the drive receives this
command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in
the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read
look-ahead and write caching features enabled. The acceptable values for the Features register are defined as follows:

Table 10 Set Features command values

02
03

55
82
AA
C1
F1

Enable write cache (default).

H

Set transfer mode (based on value in Sector Count register).

H

Sector Count register values:
00

Set PIO mode to default (PIO mode 2).

H

01

Set PIO mode to default and disable IORDY (PIO mode 2).

H

08

PIO mode 0

H

09

PIO mode 1

H

0A

PIO mode 2

H

0B

PIO mode 3

H

0C

PIO mode 4 (default)

H

20

Multiword DMA mode 0

H

21

Multiword DMA mode 1

H

22

Multiword DMA mode 2

H

40

Ultra DMA mode 0

H

41

Ultra DMA mode 1

H

42

Ultra DMA mode 2

H

43

Ultra DMA mode 3

H

44

Ultra DMA mode 4

H

45

Ultra DMA mode 5

H

46

Ultra DMA mode 6

H

Disable read look-ahead (read cache) feature.

H

Disable write cache

H

Enable read look-ahead (read cache) feature (default).

H

Disable the Free Fall Protection feature (41H above enables the Free Fall Protection feature)

H

Report full capacity available

H

Note. At power-on, or after a hardware or software reset, the default values of the features are as indicated above.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 32

4.3.3 S.M.A.R.T. commands

S.M.A.R.T. provides near-term failure prediction for disc drives. When S.M.A.R.T. is enabled, the drive monitors
predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is
likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable. S.M.A.R.T. predictability is
limited to the attributes the drive can monitor. For more information on S.M.A.R.T. commands and implementation, see the
Draft ATA-8 Standard.

SeaTools diagnostic software activates a built-in drive self-test (DST S.M.A.R.T. command for D4

) that eliminates

H

unnecessary drive returns. The diagnostic software ships with all new drives and is also available at:

http://seatools.seagate.com.

This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports
S.M.A.R.T. to enable this feature. The table below shows the S.M.A.R.T. command codes that the drive uses.

Table 11 S.M.A.R.T. commands

CODE IN FEATURES REGISTER S.M.A.R.T. COMMAND

D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
DA

H

H

H

H

H

H

H

H

H

H

H

S.M.A.R.T. Read Data
Vendor-specific
S.M.A.R.T. Enable/Disable Attribute Autosave
S.M.A.R.T. Save Attribute Values
S.M.A.R.T. Execute Off-line Immediate (runs DST)
S.M.A.R.T. Read Log Sector
S.M.A.R.T. Write Log Sector
Vendor-specific
S.M.A.R.T. Enable Operations
S.M.A.R.T. Disable Operations
S.M.A.R.T. Return Status

Note. If an appropriate code is not written to the Features Register, the command is aborted and 0x 04 (abort) is written

to the Error register.

MOMENTUS 5400.6 SATA PRODUCT MANUAL, REV. G 33

INDEX

A

ACA 19
acoustics 5, 7, 9, 17
Active mode 14
Address 26
AFR 18
Agency certification 18
Altitude 15
Altitude, nonoperating 5, 6, 8
Altitude, operating 5, 6, 8
Ambient temperature 4, 6, 8, 15
ambient temperature 11
Annualized Failure Rate 18
Annualized Failure Rate (AFR) 5, 7, 9
Areal density 4, 6, 8, 10
ATA commands 26
ATA data-transfer modes supported 4, 6, 8
Australia/New Zealand Standard AS/NZS3548 1995 19
Australian Communication Authority (ACA) 19
Australian C-Tick 19
Average seek time 11
Average seek, read 4, 6, 8

B

bels 5, 7, 9
BPI 4, 6, 8
buffer 4, 6, 8, 10
Bytes per sector 4, 6, 8, 9

C

cables and connectors 22
Cache 4, 6, 8
cache 10
capacity 9
case temperature 15
CE mark 18
certification 18
Check Power Mode 27
chemical substances 20
China RoHS directive 20
Class B computing device 19
compatibility 18
Conducted noise 13
Conducted RF immunity 17
Configuring the drive 21
connectors 22
CSA C22.2 (950) 18
current 4, 6, 8
cycles 18
Cylinders 10

D

data-transfer rates 2
DC power 12

Default logical geometry 10
density 4, 6, 8
Device Configuration Freeze Lock 26
Device Configuration Restore 26
Device Configuration Set 26
Diagnostics 26
dimensions 23
Discs 4, 6, 8
dissipation 12
Download Microcode 26

E

Electrical fast transient 17
Electromagnetic compatibility 18
Electromagnetic Compatibility Directive (89/336/EEC) 18
Electromagnetic immunity 17
Electrostatic discharge 17
electrostatic discharge (ESD) 21
EN 55022, Class B 18
EN 55024 18
EN 60950 18
Environmental protection 20
Environmental specifications 15
error-correction algorithms 2
errors 5, 7, 9, 18
ESD 21
EU 18
European Union (EU) requirements 18
European Union Restriction of Hazardous Substances 20
evice Configuration Identify 26
Execute Device Diagnostics 26

F

FCC verification 19
features 2
Federal Communications Commission 19
Flush Cache 26
Flush Cache Extended 26
Formatted capacity 9
Formatted Gbytes 4, 6, 8
Freeze Lock 26

G

Gbytes 9
geometry 10
gradient 4, 6, 8
Guaranteed sectors 4, 6, 8, 9
guaranteed sectors 9, 10

H

handling 21
Handling precautions 21
heads 10
Height 4, 6, 8

Momentus 5400.6 SATA Product Manual, Rev. G 34

height 11
Humidity 15
humidity 5, 6, 8

O

Operating shock 16
Operating vibration 16

I

I/O data-transfer rate 4, 6, 8, 10
Identify 26
Identify Device 26
Identify Device command 28
Idle 12, 27
Idle and Standby timers 14
Idle Immediate 27
Idle mode 4, 6, 8, 14
Idle mode power 12
IEC950 18
Information Technology Equipment (ITE) 18
Initialize Device Parameters 26
Input noise ripple 13
Interface 10
interface 24
Interleave 10
Internal data transfer rate 4, 6, 8
Internal data-transfer rate 10
ITE 18

K

Korean RRL 19

L

latency 4, 6, 8
LBA mode 9, 10
Length 4, 6, 8
length 11
Load/Unload 18
logical geometry 10

M

master/slave 3
Max Address 26
maximum temperature 15
Microcode 26
mounting 22
mounting screws 16
mounting the drive 21

N

noise 13
nominal power 11
Nonoperating shock 16
Nonoperating vibration 16
Nonrecoverable read errors 5, 7, 9
nonrecoverable read errors 18

P

Physical characteristics 11
Physical organization 10
Physical read/write heads 4, 6, 8
point-to-point 3, 21
Power consumption 12
power dissipation 12
power management 14
power on/off cycles 18
Power specifications 12
Power-management modes 14
Power-on to Ready 11
Power-on to ready 4, 6, 8
precautions 21, 22
programmable power management 14

Q

quick reference 4

R

Radiated RF immunity 17
Radio and television interference 19
radio frequency (RF) 17
random track location 12
Read Buffer 26
Read DMA 26
Read DMA Extended 26
Read DMA without Retries 26
read errors 5, 7, 9, 18
Read Long with Retries 26
Read Long without Retries 26
Read Multiple 26
Read Multiple Extended 26
Read Native Max Address 26
Read Native Max Address Extended 26
Read Sectors 26
Read Sectors Extended 26
Read Sectors without Retries 26
Read Verify Sectors 26
Read Verify Sectors Extended 26
Read Verify Sectors without Retries 26
Read/write heads 10
Read/write power 4, 6, 8
read/write power and current 12
Recording density 4, 6, 8, 10
Recording method 10
Recording technology 10
Relative humidity 5, 6, 8, 15
Reliability 18
resistance 13

Momentus 5400.6 SATA Product Manual, Rev. G 35

Retries 26
RF 17
RoHS 20
RPM 4, 6, 8
RRL 19

S

S.M.A.R.T. 27
S.M.A.R.T. implementation 26
Safety certification 18
SATA 10, 24
screws 16, 22
Seagate Technology Support Services 1
sector 9
sectors 9
Sectors per track 10
Security Disable Password 27
Security Erase Prepare 27
Security Erase Unit 27
Security Freeze Lock 27
Security Set Password 27
Security Unlock 27
Seek 26
seek mode 12
Seek power 4, 6, 8
Seek time 11
seek time 4, 6, 8
Seeking 12
Self refresh, low power 14
Serial ATA 10
Serial ATA (SATA) interface 24
serial ATA ports 3
servo electronics 12
Set Features 26
Set Max Address 26
Set Multiple Mode 26
Shock 16
Shock, nonoperating 5, 6, 7, 8, 9
Shock, operating 5, 6, 7, 8, 9
single-track seeks 11
Sleep 12, 27
Sleep mode 4, 6, 8, 14
sound power 5, 7, 9
Specification summary table 4
Spindle speed 4, 6, 8, 10
Spinup 12
spinup power 12
Standby 12, 27
Standby Immediate 27
Standby mode 4, 6, 8, 12, 14
Standby to Ready 11
Standby to ready 4, 6, 8
Start/stop times 11
Startup current 4, 6, 8
static-discharge 21

Surge immunity 17

T

temperature 4, 5, 6, 8, 11, 15
Temperature gradient 4, 6, 8, 15
timers 14
TPI 4, 6, 8
Track density 4, 6, 8, 10
Track-to-track seek time 4, 6, 8, 11
TUV North America 18

U

UL 1950 18

V

Vibration 16
Vibration, nonoperating 5, 7, 9
Vibration, operating 5, 7, 9
Voltage dips, interrupts 17
Voltage tolerance 4, 6, 8, 13

W

Warranty 18
Weight 4, 6, 8
weight 11
Wet bulb temperature 5, 6, 8, 15
Width 4, 6, 8
width 11
Write Buffer 27
Write DMA 27
Write DMA Extended 27
Write Long with Retries 27
Write Long without Retries 27
Write Multiple 27
Write Sectors 27
Write Sectors Extended 27
Write uncorrectable 27

Momentus 5400.6 SATA Product Manual, Rev. G 36

Seagate Technology LLC

AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000
ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888
EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00

Publication Number: 100528359, Rev. G
December 2012
