Seagate ST902504EXA101-RK, ST903204EXA101-RK, ST905004EXA101-RK, ST906404EXA101-RK, ST907504EXA101-RK Specifications

Seagate® Expansion™ Portable Drive

Portable Add-on Storage

Interface USB 2.0
Capacities 250GB, 320GB, 500GB, 640GB, 750GB, 1TB

Perfect for when you need to:

• Instantly add more storage
space to your computer

• Take large files with you on­the-go

Seagate external portable drives are compact and perfect for on-the-go. Instantly add more storage space to
your computer and take large files with you when you travel.

Set-up is straightforward, simply connect a single USB cable and you are ready to go. The drive is powered
from the USB cable, so there is no need for an external power supply. Plus, it is automatically recognized by
Windows® operating system, so there is no software to install and nothing to configure. Saving files is easy too,
just drag-and-drop.

It’s not just easy to use, but it’s fast and energy efficient too. Enjoy fast data transfer speed with USB 2.0
connectivity. Built-in power management ensures energy efficient operation.

Quality and Reliability

Seagate has delivered proven, reliable storage solutions for over 30 years. As of 2008, Seagate has shipped
over one billion hard drives. Seagate continues to stand behind its quality by including a 1-year limited
warranty.

Storage Calculator*

250GB 320GB 500GB 640GB 750GB 1TB

Hours of digital video

Number of 2-hour DVD movies

Number of digital photos

Hours of digital music

250 320 500 640 750 1,000

62 80 125 160 186 250

80,000 102,400 160,000 204,800 240,000 320,000

4,165 5,330 12,497 10,660 12,495 25,000

Highlights

• Plug n’ play — no software to install

• Simply drag-and-drop to save files

• USB powered

• Built-in power management ensures energy-efficient operation

• 1-year limited warranty

* Quantitative usage examples for various applications are for illustrative purposes.

Actual quantities will vary based on various factors including file size, file format, features and application software.

Seagate® Expansion™ Portable Drive

Portable Add-on Storage

Product Dimensions

Product Dimensions
(750GB, 1TB)

Retail Packaging Specs

Retail Packaging Specs
(750GB, 1TB)

Software Requirements

Inside the Box

3.15” x 0.69” x 5.56” (80.01mm x 17.60mm x 141.29mm)
Weight: 0.35 lbs (0.16kg)

3.31” x 1.06” x 5.97” (84.07mm x 26.92mm x 151.64mm)
Weight: 0.69 lbs (0.31kg)

Box dimensions: 5.20” x 1.73” x 6.54” (132.08mm x 43.94mm x 166.12mm)
Box weight: 0.64 lbs (0.36kg)
Master carton dimensions: 11.30” x 7.48” x 6.06” (287.02mm x 189.99mm x 153.92mm)
Master carton weight: 4.41 lbs. (2.00kg)
Master carton quantity: 6
Master cartons per pallet: 140
Pallet dimensions: 45.28” x 39.37” x 48.43” (1,150.11mm x 1,000.00mm x 1,230.12mm)
Pallet weight: 679.82 lbs. (308.36kg)
Pallet layers: 7

Box dimensions: 5.20” x 2.20” x 6.85” (132.08mm x 55.88mm x 173.99mm)
Box weight: 1.03 lbs (0.47kg)
Master carton dimensions: 9.13” x 7.95” x 5.55” (231.90mm x 201.93mm x 140.97mm)
Master carton weight: 4.65 lbs. (2.11kg)
Master carton quantity: 4
Master cartons per pallet: 140
Pallet dimensions: 47.99” x 40.00” x 47.64” (1,218.95mm x 1,016.00mm x 1,210.06)
Pallet weight: 699.92 lbs. (317.48kg)
Pallet layers: 7

• Works with Windows Vista, Windows XP, or Mac OSX 10.4.8 or higher

• External portable hard drive

• USB cable

• Quick start guide

• 1-year limited warranty

Region Capacity Model Number UPC Code EAN Code Multi-pack UPC

PANAM 250GB ST902504EXA101-RK 763649015155 10763649015152

PANAM 320GB ST903204EXA101-RK 763649015209 10763649015206

PANAM 500GB ST905004EXA101-RK 763649015216 10763649015213

PANAM 640GB ST906404EXA101-RK 763649017401 10763649017408

PANAM 750GB ST907504EXA101-RK 763649018415 10763649018412

PANAM 1TB ST910004EXA101-RK 763649018132 10763649018139

EMEA 250GB ST902504EXD101-RK 7636490013867 10763649015312

EMEA 320GB ST903204EXD101-RK 7636490013874 10763649015329

EMEA 500GB ST905004EXD101-RK 7636490013881 10763649015336

EMEA 640GB ST906404EXD101-RK 7636490015977 10763649017422

EMEA 750GB ST907504EXD101-RK 7636490016981 10763649018436

EMEA 1TB ST910004EXD101-RK 7636490016691 10763649018146

APAC 250GB ST902504EXM101-RK 763649015377 10763649015374

APAC 320GB ST903204EXM101-RK 763649015384 10763649015381

APAC 500GB ST905004EXM101-RK 763649015391 10763649015398

APAC 640GB ST906404EXM101-RK 763649017432 10763649017439

APAC 750GB ST907504EXM101-RK 763649018446 10763649018443

APAC 1TB ST910004EXM101-RK 763649018156 10763649018153

© 2010 Seaga te Technology LLC. All rights reserv ed. Seagate, Seagate Technology, the Wave logo and Expansio n are trademarks or registe red
trademarks o f Seagate Technology LLC or one of its affiliat ed companies in the United States a nd/or other countries. All other tr ademarks or registered
trademarks a re the property of their respective owners. When referring to hard drive capaci ty, one gigabyte, or GB, equals one billion bytes and one
terabyte, or TB, equals one thousand billion by tes. Your computer’s operating s ystem may use a different s tandard of measurement and report a lowe r
capacity. In addition , some of the listed capacity is us ed for formatting and other functio ns and will not be available for da ta storage. Quantitative
usage exampl es for various applications are for illustrative purposes. A ctual quantities will vary based on various factors, including file siz e, file format,
features, and application software. Sea gate reserves the right t o change, without notice, product offerings or specifications. Seagate Technology LLC,
920 Disc Dri ve, Scotts Valley CA 95066 U.S.A. www.seagate. com DS1674.7-1004PANAM
