SDI Technologies IKN100 User Manual

iKN100 IB (English) Size: 130 x 102 mm Color: 1C + 1C (Black text on white paper) 20 pages,100gsm2 WF PAPER

Date: July 27, 2015

Model: iKN100

portable stereo speaker system

with speakerphone and removable power

請留意排版

CHARGE

BEFORE

USE

Questions?

Contact Customer Service at 1-800-288-2792

instruction manual

Introduction

Thank you for purchasing the iHome Kineta K3. This product is designed to provide high quality wireless sound for your iPad, iPhone, iPod, computer, tablet or other Bluetooth audio device and mobile charging on the go with the included removable K-Cell rechargeable battery.

This unit features NFC (Near Field Communication) technology which allows you to wirelessly connect your NFC–enabled device to instantly ‘pair and play’. See your device’s user manual for details on how to interact with NFC devices. If your Bluetooth device does not support NFC, you can pair it manually with this unit.

This instruction booklet explains the basic operation and care of the unit. Please read it carefully and keep for future reference.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as thinner or similar materials can damage the surface of the unit.

Long-term Storage of Your Product

• Store in a cool, dry place.

• Unit should be charged before storing.

• If stored for a long period of time, unit may be unresponsive until charged for a number of hours (depending on discharge level)

• Do not store for more than a year without charging as this can permanently harm the battery.

• After long term storage, if unit is unresponsive after charging, RESET unit while connected to AC and recharge the unit.

Internal Rechargeable Lithium-ion Battery

This device uses an internal rechargeable lithium-ion battery that should last the lifetime of the device. If you suspect your battery may be dead, try charging it several times and try resetting the unit.

WARNING/DISPOSAL OF UNIT

Please do NOT attempt to change the battery yourself. If the battery has died and you do not want us to replace your battery, you should follow the disposal instructions below:

• Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances.

• Always dispose of used batteries/electronics in accordance with the prevailing community regulations that apply to the disposal of batteries/electronics. If there are no local regulations concerning battery/electronics disposal, please dispose of the device in a waste bin for electronic devices.

• Many electronics retailers now recycle batteries and other electronic components at no charge. Check to see which ones in your area do so.

GENERAL BATTERY PRECAUTIONS

• Never use or charge a battery if it appears to be leaking, discolored, deformed, or in any way abnormal.

• Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other electrolytic substance.

• Always confirm that the temperature is 5°C - 35° C (41° - 95° Fahrenheit) before you charge the battery. Leakage or deterioration of the battery may occur if this warning is not heeded.

• Never expose a battery to any liquid.

• Never expose a battery to excessive heat such as direct sunlight or fire. Never use a battery pack in an unventilated vehicle where excessive internal temperatures may be encountered.

• Always keep batteries out of the reach of infants and small children.

Table of Contents

Included / Meet Your K3................................................................................................. 4-5

Getting Started: Charging the Unit and K-Cell via AC Adaptor .................................................6

Battery Level Meters ..........................................................................................................7

Charging the K-Cell via USB...............................................................................................8

Charging Devices Using the K-Cell ......................................................................................9

Using Bluetooth: Pairing Your Device Using NFC ..................................................................10

Using Bluetooth: Pairing Your Device Manually.....................................................................11

Pairing with a Different Device

Speakerphone Operation ................................................................................................13

Playing Audio via Aux In ................................................................................................. 14

Consumer Product Safety Guide................................................................................... 15-16

FCC Information............................................................................................................. 17

Troubleshooting..............................................................................................................18

Warranty......................................................................................................................19

Playing Audio Via Bluetooth ................................................. 12

Included

• K3 system

• K-Cell

• AC adaptor

• USB charging cable

K-Cell

K3 system

USB cable AC adaptor

Meet Your K3

Mode Status

indicators:

Power

Bluetooth

Speakerphone

Microphone

Power Button

Bluetooth

Pairing

Button

Talk/End

Button

Top

Play/Pause Button

Volume Down

Button

External Battery

level meter

Volume Up

Button

K-Cell

Internal Battery level meter

Left Side Back Panel

Reset Port DC Jack

DC 10V 2.5A

K-Cell Eject

Button

NFC

Antenna Area

Splash-resistant

Jack Cover

(attached)

Aux-in Jack

Located

under

Jack Cover
