SDI Technologies HWL83 User Manual
HWL83
Sta Quick Start Guide
Included
• HWL83 system
• Universal AC adaptor
Set Up
Remove thumbscrew and
remove back security cover to
access sta controls (volume
limit switch, DST switch, time
set button, time zone button),
and DC jack.
Connect the universal voltage
AC adapter to the wall outlet
and the DC jack on the back
panel of the unit.
Charging Devices
Connect USB cable (not included) to USB port and the other
end to your device to charge.
outlet
volume limit
DC 9V 3A
dst
o on
time settime zone
+1 -1 auto
Setting the Time Zone and Clock
(Factory Preset Clock)
The rst time you connect your new preset clock to the AC outlet,
the unit will automatically show the correct Eastern Standard
time, which is the default setting. If you are not in the Eastern time
zone, you must change the default setting to match your time
zone (see Time Zone Setting below). Once the correct time zone is
set, if the time displayed is not correct, follow steps under Manual
Clock Setting to set the correct hour, minute, year and date.
Time Zone Setting
Press and hold the time zone button. The default EASTERN time
zone will ash in the bottom of the display.
time zone
Press and release the – or + button as needed until your time
zone is displayed. The time display will also change.
