Screen Research MC2 Installation Manual

Installation Manual

Motorized Classic 2 Drop Down Screens

On-Ceiling / On-Wall Mounting

Tools & Storage
Model Mounting Options
Ceiling Mounting
Wall Mounting
Screen Casing Mounting
Screen Transit Locking System Removal
Motor Connection
End Travel Verification (Default set at factory)
MCS Installation
MCS Configuration - Testing
End Cap Fitting
Tab-tensioning Bar Adjustment
Manual adjustment of motor end-stops
IR Eye Recommended Localization
Motor Connection
Warranty
Legal Information

1
1
2
2
3
4
4
5
5
5
6
6
7
8
8
9

10

Table of Contents

Please read this manual before starting work.

Note :

MC2

MC2

Wall Mount
min 13 mm

(1/2")

min 13 mm
(1/2")

Ceiling Mount

Projection Surface

Recommendations

Leave suf ficient room to allow access to the end of the screen casing

Recommendations on minimum clearance for wall or ceiling mounting

Recommended

254 mm (10”)

Recommended

254 mm (10”)

Tools & Storage

Model Mounting Options

Do not store standing

MC2

Essential Tools Provided

Tip

-1-

MC2 Install Manual: Rev A 01 Aug 2009

MC2 (80-110")

This model has two mounting options :

Ceiling Mounting Wall Mounting

1

2

Use fixings appropriate to your

installation construction

Wall Mounting

Ceiling Mounting

Ensure the head of your chosen fixing system

fits within the indicated zone.

15 mm (

9

/

16

”) max

6.5 mm

(

1

/

4

”) max

6.5 mm

(

1

/

4

”) max

Ensure the

head of your

chosen fixing

system fits

within the

indicated zone.

-2-

4 x Ø8 mm (

5

/

16

”)

6.5 mm (

1

/

4

”) max

6.5 mm (

1

/

4

”) max

15 mm (

9

/

16

”) max

4 x Ø 8 mm

(

5

/

16

”)

MS2 4 x Ø8 (5/16”) 2

Model

Bracket Holes

per Bracket

Mounting

Brackets
Included

Use fixings appropriate to your

installation construction

110 mm

(4

11

/

32

”)

MC2 Install Manual: Rev A 01 Aug 2009

140 mm (5

1

/

2

”)

140 mm (5

1

/

2

”)

110 mm

(4

11

/

32

”)

3

Screen Casing Mounting

MC2 Install Manual: Rev A 01 Aug 2009

Ceiling Mounting

IMPORTANT: BRACKET SECURING SCREWS MUST BE USED.

NOT DOING SO RISKS CASING FALLING !

Wall Mounting

-3-

MIN: 110 mm (4

11

/

3

")

MAX: 155 mm (6

3

/

32

")

-4-

5

Screen Transit Locking System Removal

Motor Connection

MC2 Install Manual: Rev A 01 Aug 2009

4

Only carry out this

step once all transit

security fixings have

been removed

DOWN

UP
STOP

Unscrew

&

remove

Unscrew

&

remove

Repeat at each end of the screen

Connect the plug

-5-

6

7

MCS Installation

End Travel Verification (Default set at factory)

Refer to the MCS hardware guide in
order to connect your control devices
correctly.

Refer to the MCS software guide
should you wish to reprogram the
motor control system.

MCS-320 MCS-310

MCS-BRR

Receivers

Interfaces Motors

MCS-BIE

(Radio Frequency) (Infrared)

MCS-RR0

MCS-IR0

MCS-RR1

MCS-IR1

MCS-BRSMCS-SIP

UP

Remotes

MCS (Motor Control Systems) Manual

8

MCS Configuration - Testing

MCS (Motor Control Systems) Manual

Carefully deploy the screen to its maximum extent.

Verify that it stops automatically at the desired end of travel.

If this is not the case stop screen travel by
pressing stop button and proceed to step

Carefully stow the screen to its stored position.

Verify that it stops automatically at the desired end of travel.

If this is not the case stop screen travel by
pressing stop button and proceed to step

click

11 11

Do not pass the white line

drawn in the black drop zone.
After this point, deployment
of the fabric risks damage to

the product.

Important : As part of the installation procedure it is important that the motor end stops are

verified in order to prevent damage to the screen.
The end stop limits are set at the factory, but may have been released during shipping.
Failure to perform this procedure will void any subsequent claims made under the product
warranty. Please contact Screen Research if you have any questions.

MC2 Install Manual: Rev A 01 Aug 2009

click

9

-6-

End Cap Fitting

10

Tab-tensioning Bar Adjustment

Deploy the screen to its standard operating position before adjusting the tab-tensioningsystem.

1

2

Insert & push

Adjust

click

click

click

MC2 Install Manual: Rev A 01 Aug 2009

Screwing

Repeat at each end of the screen

-7-

11

Manual Adjustment of Motor End-stops

MC2 Install Manual: Rev A 01 Aug 2009

MAX

LIMIT !

click

click

1 -

Push the two buttons in order to free the screen stopping positions.

2 -

Carefully deploy the screen to the desired position.
Lock this position by releasing the correct button as shown in the table below.

3 -

Carefully define the desired closed position.
Lock this position by releasing the correct button as shown in the table below.

click

Pushed buttons = unlocked screen
No more stop position memorized

Released buttons = locked screen

Stop positions are memorized

Please, follow this step ONLY if the end of travel of the motors has moved during transit. If your screen
automatically stops at the desired full extension and full winding up, you do NOT need this step.

click

click

yellowMC2 white

Screen

Model

Screen

Lock UP

Screen

Lock DOWN

Refer to this table if the motor of your screen is mounted on the LEFT

click

click

-8-

IR Eye Recommended Localization

Motor Connection

MC2 Install Manual: Rev A 01 Aug 2009

1

2

Live (brown)
Neutral (Blue)
Earth (Yellow/green)

Screen Research Product Warranty

1.LIMITED WARRANTY

Screen Research warrants the product designated herein to be free of manufacturing defects in material and workmanship, subject to
the term and conditions hereinafter set forth.
Surface fabric(s) and frames are warranted for a period of five (5) years from the date of invoice by the original purchaser.
Motors, motor controllers, remote controls, and related assembly hardware are warranted for three (3) years parts and labor from date
of invoice by the original purchaser.

2.CONDITIONS AND LIMITATIONS

This Warranty is subject to the following conditions and limitations. The Warranty is void and inapplicable if the product has been used
or handled other than in accordance with the instructions in the owner’s manual, abused or misused, damaged by accident or neglect
or in being transported, or the defect is due to the product being repaired or tampered with by anyone other than Screen Research or
an authorized Screen Research dealer or installer. The product must be installed by a professional, duly-authorized Screen Research
dealer/custom installer, and maintained according to the written instructions.

3.RETURNS

No product returns accepted without a prior written return authorization from Screen Research.
Product must be packed in the original PACKAGE CONTENTS or equivalent packaging in order to avoid any damage during transporta­tion. The product(s) must be packed and returned to Screen Research or an authorized Screen Research repair center by the customer
at his or her sole expense. Screen Research will pay return freight of its choice.

A RETURNED PRODUCT MUST BE ACCOMPANIED BY A WRITTEN DESCRIPTION OF THE DEFECT AND A PHOTOCOPY OF THE
ORIGINAL PURCHASE RECEIPT. This receipt must clearly list model and serial number, the date of purchase, the name and address of

the purchaser and authorized dealer and the price paid by the purchaser. Screen Research reserves the right to modify the design of
any product without obligation to purchasers of previously manufactured products and to change the prices or specifications of any
product without notice or obligation to any person.

4.REMEDY

In the event the product fails to meet the above Warranty, the purchaser’s sole remedy under this Limited Warranty shall be to return
the product to Screen Research or an authorized Screen Research service center where the defect will be rectified without charge for
parts or labor, during the term of this Limited Warranty.

5.LIMITED TO ORIGINAL PURCHASER

This Warranty is for the sole benefit of the original purchaser of the covered product and shall not be transferred to a subsequent
purchaser of the product.

6.MISCELLANEOUS

Any implied warranties relating to Screen Research products shall be limited to the duration of this warranty. The warranty does not
extend to any incidental or consequential damages to the purchaser. Some states or countries do not allow limitations on how long an
implied warranty lasts, or an exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may
not apply to you. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state, or
country to country.

7.WARRANTOR

Enquiries regarding the above Limited Warranty may be sent to the following address, specific to country where purchased:

Purchases in North and South America:

Screen Research, 5604 Wendy Bagwell Parkway, Suite 512, Hiram, GA 30141 USA

Purchases in Europe, Asia, Middle East, Africa, India, Asia, Australia:

Screen Research, Parc d’Activité de Ragon - 16, rue Louis Pasteur - 44119 NANTES - Treillières - France

8.WARRANTY SUPPORT MANAGED BY AUTHORIZED DISTRIBUTORS

Screen Research has authorized distribution in many countries of the world. In each country, the authorized importing Distributor is
responsible for warranty support of products sold in the respective country by that retailer or distributor. Warranty service should be
obtained from the importing retailer or distributor from whom you purchased your product. In the unlikely event of service required
beyond the capability of the importer, Screen Research will fulfill the conditions of the warranty. No product returns will be accepted
without a prior written return authorization from Screen Research. All product returns must be shipped at the owner’s expense to the
Screen Research factory, together with a photocopy of the bill of sale for that product, a detailed description of the problem, and any
information necessary for return shipment.

-9-

MC2 Install Manual: Rev A 01 Aug 2009

-10-

© Copyright 2009 Screen Research. All rights reserved.

Screen Research products are covered by one or more of the following patents:
No. 00 07372 (France); No. 6,552,847 B2 (USA); No. 04787296.5 (Europe) pending; No. 03 10375 (France); No.
US-2008-0211972-A1 (USA) pending; No. PCT/FR04/02241 (International) pending; No. 200480025260.9 (China)
pending; No. 1126/CHGENP/2006 (India) pending; No. 2006-524397 (Japan) pending; No. 04787296.5-2217
(United Kingdom) pending; No. 0409574 (France) pending; No. PCT/IB05/003917 (International) pending; No.

05817119.0-1252 (Europe) pending; No. 08.02361 (France) pending; No. 08/05836 (France) pending; No. 03 07216
(France); No. 10/557 781 (USA) pending; No. 04742791.9 (Europe) pending; No. 6,785,047 (USA)

ClearPix, ClearPix2, SolidPix, SolidPix1, GrayPix, X-Mask, C-Mask, LeWing, TheaterCurve, Pi-Grip, FastGrip, TFX,
StopLight, DécorMask, TailorMade and the Screen Research logo are all trademarks of Screen Research.

All other trademarks are the property of their respective owners.
