Scotsman Ice Machine ADS User Manual

S A N I T A T I O N S O L U T I O NS A N I T A T I O N S O L U T I O N

S A N I T A T I O N S O L U T I O N

S A N I T A T I O N S O L U T I O NS A N I T A T I O N S O L U T I O N

Assisting in the ice machine sanitation battle, Scotsman Ice
Systems’ AquaDefenseTM sanitation system is a commonsense,
multi-method approach to defending your ice machine against
undesirable microbes, bacteria, mold, and algae. The AquaDefense
sanitation system features three advanced defensive means:

AquaPatrolTM, water filtration system designed specifically for ice

machines that leaves the bacteria fighting chlorine in the water yet
insures the unit produces crystal-clear, taste-free and odor-free ice
and provides a phosphate feed to inhibit scale build-up.

AquaBulletTM, a sophisticated, anti-microbial media placed directly in the sump water to reduce the

growth of undesirable microorganisms.

AquaArmor with AgION

TM

antimicrobial, a progressive, silver based compound, molded directly into

key components.

It takes a leader like Scotsman to provide a commonsense solution to ice machine sanitation.

Water Filtration Optimized for Scotsman Ice Machines

Scotsman’s AquaPatrol filtration system is specifically designed to provide the

best possible water conditions for optimal ice machine sanitation. It’s unique

combination of media leaves chlorine in the water to keep the ice machine

cleaner longer. The Scotsman ice making process then removes all noticeable

chlorine insuring refreshing, clear, taste and odor free cubes. At the same time,

the AquaPatrol reduces dirt and rust particles and supplies phosphate to inhibit

mineral buildup that could damage the icemaker.

ADS-AP1

FEATURES:

• 10 Micron filtration reduces particulates that may harm the ice machine.

• Utilizes the chlorine already in municipal water systems to keep

the ice machine clean.

• Polyphosphate feed to inhibit scale build-up

• Standard Scotsman SSM system interconnect

BENEFITS:

• Protects the ice machine and extends its life by lowering unscheduled,

water related maintenance calls with semiannual replacement.

• Decreases mineral deposit formation extending machine life.

• Easy to install and maintain in both new and existing icemakers.

ADS-AP2

ADS-AP3

Anti-microbial Wand for Cube Ice Machines

Scotsman’s AquaBullet contains an advanced, EPA registered, anti-

microbial media custom-designed to inhibit the growth of a wide

variety of mold, bacteria, and algae that cause slime in ice machines.

The technology utilizes the known anti-microbial properties of various minerals, along with other metal oxides, to

interfere with the microorganisms’ cell replication, electron transport, and overall organism function. This technology is

incorporated into a drop-in device, which is placed directly into the sump water, providing treatment of the machine in

one easy step.

FEATURES:

• Award-winning, patented technology containing an advanced anti-microbial media.

• One-step, drop-in installation for easy use and replacement.

• More effective when used in combination with Scotsman’s AquaPatrol filtration system.

• Suggested replacement every three months for standard water conditions.

• Media is EPA Registered and Listed under NSF Standard 42.

BENEFITS:

• Reduces the growth of a wide variety of mold, bacteria, and algae that cause

slime in ice machines decreasing cleaning time and lowering maintenance costs.

• Insures low cost installation and proper function.

• Chlorine enhances the anti-microbial action resulting in greater efficacy than the

sum of AquaBullet and AquaPatrol capabilities.

• Longer life than anti-microbial sachets for low-cost performance.

• Creates no off-taste or odor in ice.

• Safe to handle, non-toxic, environmentally safe, and easily disposed

of with normal trash.

ADS-AB1

Built-in Anti-microbial Protection for CM3 Cubers

Scotsman’s AquaArmor contains the progressive, inorganic, AgION

anti-microbial compound molded directly into key ice machine compo-

nents. AquaArmor utilizes the known anti-microbial property of silver to

prevent microorganisms by disrupting their vital functions. A unique

controlled release mechanism keeps AquaArmor’s protection effective

for the life of the ice machine, inhibiting the growth of a wide variety of mold, bacteria, and algae.

FEATURES:

• Patented anti-microbial media from AgION, the leader in anti-microbial compounds.

• More surface contact and high anti-microbial media reservoir.

• Included in Scotsman CM3 cube ice machines only.

• More effective when used in combination with Scotsman’s AquaPatrol filtration system.

• FDA listed, NSF certified and EPA registered.

BENEFITS:

• Field proven to reduce the growth of potentially damaging microbes, bacteria, mold, and algae.

• Faster and greater anti-microbial action against elevated microbe counts with longer effective lifetime.

• Non-toxic protection which is environmentally safe.

AgION is a Trademark of AgION Technologies, Inc.

AQUADEFENSE SYSTEM MODEL NUMBERS

AquaArmor with AgION

TM

Antimicrobial

Standard on all CM3 & Eclipse Modular Ice Machines

AquaBullet

TM

Cubers Flakers Nugget

ADS-AB6 Bullet 6 Pack x
ADS-AB1 Single Bullet x

AquaPatrol

TM

Cubers Flakers Nugget

ADS-AP1 Single System x x x
ADS-AP2 Twin System x x x
ADS-AP3 Triple System x x x
ADS-APRC6 6 Pack Replacement Cartridge x x x

SSM-A Water Filters Cubers Flakers Nugget

SSM1-A Single System x x x
SSM2-A Twin System x x x
SSM3-A Triple System x x x
SSMRC1 Single Replacement Cartridge x x x
SSMRC6 6 Pack Replacement Cartridge x x x
SC10-A 10" Coarse Prefilter x x x
SC20-A 20" Coarse Prefilter x x x
SC10RC40 E10 Replacement Filter x x x
SC20RC20 E20 Replacement Filter x x x

WARRANTY

• AquaPatrol Filters - 5 year parts only

• SSM-A Water Filters - 5 year parts only

775 Corporate Woods Parkway • Vernon Hills, IL 60061 • (800)SCOTSMAN • Fax [phone]

Website:www.scotsman-ice.com • Email:[e-mail]

BAD-2003 Scotsman reserves the right to make product improvements at any time. Specifications and design are subject to change without notice. Printed in U.S.A. .5M 9/03
