Reference Manual – version 0.1
@MAXX lite
Multifunctional token (smartcard, flash, antenna)
Reference manual
@MAXX lite (contact smartcard reader,
masstorage, RF-antenna) USB-Stick
© SCM Microsystems
Oskar-Messter-Strasse, 13
85737 Ismaning
Germany
Phone +49 89 9595 5000 • Fax +49 89 9595 5555
Document history
Date Version Description of change Responsible
person
30/09/2009 0.1 Creation Stephan Rasch
Contact information
http://www.scmmicro.com/products-services/smart-card-readers-terminals/multifunctionaltoken.html
For sales information, please email sales@scmmicro.com
@MAXX L
ITE REFERENCE MANUAL
T
Table of Contents
1.
Legal information ...............................................................................................................6
1.1. Disclaimers.....................................................................................................................6
1.2. Licenses .........................................................................................................................6
1.3. Trademarks ....................................................................................................................6
2.
Introduction to the manual .................................................................................................7
2.1. Objective of the manual ................................................................................................. 7
2.2. Target audience .............................................................................................................7
2.3. Product version corresponding to the manual ...............................................................7
2.4. Definition of various terms and acronyms...................................................................... 7
2.5. References .....................................................................................................................8
2.6. Conventions ...................................................................................................................8
3.
General information about @MAXX lite........................................................................... 10
3.1. @MAXX lite key benefits..............................................................................................10
3.2. @MAXX lite key features .............................................................................................10
3.3. @MAXX lite ordering information................................................................................. 10
3.4. @MAXX lite customization options ..............................................................................10
3.5. Hardware features and their principle usage ............................................................... 11
3.5.1. Contact Smart Card Reader ................................................................................. 12
3.5.2. Internal RF antenna .............................................................................................. 13
3.5.3. Embedded Flash ................................................................................................... 14
3.6. Applications ..................................................................................................................14
3.6.1. General ................................................................................................................. 14
3.6.2. Applications provided by SCM Microsystems....................................................... 16
4.
@MAXX lite characteristics ............................................................................................. 17
4.1. @MAXX lite high level architecture.............................................................................. 17
4.1.1. Block diagram ....................................................................................................... 17
4.2. Quick reference data .................................................................................................... 19
4.2.1. @MAXX lite dimensions ....................................................................................... 19
4.2.2. LED behavior ........................................................................................................ 19
4.2.3. Other data ............................................................................................................. 19
5.
Software modules ............................................................................................................21
5.1. Installation .................................................................................................................... 21
5.2. Utilities..........................................................................................................................21
5.3. Driver............................................................................................................................21
5.3.1. @MAXX listing ...................................................................................................... 21
5.3.2. Supported operating systems ............................................................................... 21
5.4. Firmware ......................................................................................................................22
5.4.1. CCID transport protocol ........................................................................................ 22
List of CCID bulk messages supported............................................................................... 22
List of CCID bulk messages not supported......................................................................... 22
ABLE OF CONTENTS
4
@MAXX L
6.
6.1. Escape commands for the contact interface................................................................ 24
7.
7.1. Annex A – Status words table ...................................................................................... 30
7.2. Annex B – Sample code using escape commands through Escape IOCTL ............... 30
ITE REFERENCE MANUAL
Commands description ....................................................................................................24
6.1.1. Sending escape commands to @MAXX lite ......................................................... 24
6.1.2. Escape command codes....................................................................................... 24
6.1.3. CCID_ESC_GETINFO .......................................................................................... 25
6.1.4. CCID_ESC_SETMODE ........................................................................................ 25
6.1.5. CCID_ESC_GETMODE........................................................................................ 25
6.1.6. CCID_ESC_GET_FW_VERSION ........................................................................ 26
6.1.7. CCID_ESC_SET_POWER_ON_RESET_ORDER............................................... 26
6.1.8. CCID_ESC_EMV_LOOPBACK ............................................................................ 26
6.1.9. CCID_ESC_APDU_TRANSFER .......................................................................... 26
6.1.10. CCID_ESC_CLK_FREQUENCY .......................................................................... 27
6.1.11. CCID_ESC_GET_SET_ETU ................................................................................ 27
6.1.12. CCID_ESC_GET_SET_WAITTIME...................................................................... 27
6.1.13. CCID_ESC_GET_SET_GUARDTIME.................................................................. 28
6.1.14. CCID_ESC_GET_SET_EGT................................................................................ 28
6.1.15. CCID_ESC_GET_SET_ATR_TIMEOUT.............................................................. 28
6.1.16. CCID_ESC_POWER ............................................................................................ 28
6.1.17. CCID_ESC_ROUGH_TANSFER.......................................................................... 29
6.1.18. CCID_ESC_GET_SET_PROTOCOL ................................................................... 29
6.1.19. CCID_ESC_GET_SET_TA1_RFU ....................................................................... 29
Annexes ...........................................................................................................................30
T
ABLE OF CONTENTS
5
@MAXX
LITE REFERENCE MANUAL
6
1. Legal information
1.1. Disclaimers
The content published in this document is believed to be accurate. SCM Microsystems does
not, however, provide any representation or warranty regarding the accuracy or completeness
of its content and regarding the consequences of the use of information contained herein. If this
document has the status “Draft”, its content is still under internal review and yet to be formally
validated.
SCM Microsystems reserves the right to change the content of this document without prior
notice. The content of this document supersedes the content of previous versions of the same
document. The document may contain application descriptions and/or source code examples,
which are for illustrative purposes only. SCM Microsystems gives no representation or warranty
that such descriptions or examples are suitable for the application that the reader may want to
use them for.
Should you notice problems with the provided documentation, please provide your feedback to
support@scmmicro.com.
1.2. Licenses
If the document contains source code examples, they are provided for illustrative purposes only
and subject to the following restrictions:
•
You MAY at your own risk use or modify the source code provided in the document
in applications you may develop. You MAY distribute those applications ONLY in
form of compiled applications.
•
You MAY NOT copy or distribute parts of or the entire source code without prior
written consent from SCM Microsystems.
•
You MAY NOT combine or distribute the source code provided with Open Source
Software or with software developed using Open Source Software in a manner that
subjects the source code or any portion thereof to any license obligations of such
Open Source Software.
If the document contains technical drawings related to SCM Microsystems products, they are
provided for documentation purposes only. SCM Microsystems does not grant you any license
to its designs.
1.3. Trademarks
MIFARE is a registered trademark of NXP Semiconductors BV.
Windows is a trademark of Microsoft Corporation.
MAC is a trademark of Apple Corporation.
@MAXX
LITE REFERENCE MANUAL
7
2. Introduction to the manual
2.1. Objective of the manual
This manual provides an overview of the hardware and software features of the @MAXX lite
(contact smartcard reader, mass storage, RF-antenna) reader, hereafter referred to as
“@MAXX lite”.
This manual describes in details interfaces and supported commands available for developers
using @MAXX lite in their applications.
2.2. Target audience
This document describes the technical implementation of @MAXX lite.
The manual targets software developers.
Should you have questions, you may send them to support@scmmicro.com .
2.3. Product version corresponding to the manual
Item Version
Hardware SD-03-M-Ver-F
Firmware (SIM) 2.02
Windows Driver
(PC/SC)
MAC OS Driver
(PC/SC)
WinCE Driver for
SIM interface
Linux Driver for
SIM Interface
4.41
5.0.6
3.14
5.0.2
2.4. Definition of various terms and acronyms
Term Expansion
APDU Application Protocol Data Unit
ATR Answer to Reset, defined in ISO/IEC 7816
ATS Answer to select, defined in ISO/IEC 14443
Byte Group of 8 bits
CCID Chip Card Interface Device
CID Card Identifier
CL Contactless
DFU Device Firmware Upgrade
DR Divider receive: used to determine the baud rate between the reader to the card
DS Divider send: used to determine the baud rate between the card to the reader
LED Light emitting diode
MIFARE is the NXP Semiconductors (a spin-off company formed out of Philips Semiconductors)-
NA Not applicable
NAD Node Address
Nibble Group of 4 bits. 1 digit of the hexadecimal representation of a byte.
owned trademark of the reputedly most widely installed contactless smartcard
Example: 0xA3 is represented in binary as (10100011)b. The least significant nibble is 0x3
or (0011)b and the most significant nibble is 0xA or (1010)b
@MAXX
LITE REFERENCE MANUAL
PCD Proximity Coupling Device
PC/SC Personal Computer/Smart Card: software interface to communicate between a PC and a
PICC Proximity Integrated Chip Card
PID Product ID
Proximity Distance coverage in the range of 5cm
PUPI Pseudo unique PICC identifier
RFU Reserved for future use
RF Radio Frequency
STCII Smart card reader controller ASIC from SCM Microsystems
USB Universal Serial Bus
VID Vendor ID
(xyz)b
0xYY The byte value YY is represented in hexadecimal
smart card
Binary notation of a number x, y, z ∈{0,1}
8
2.5. References
Doc ref in the
manual
ISO/IEC 7816-3
ISO/IEC 7816-4 Identification cards - Integrated circuit(s) cards
ISO/IEC 144433
ISO/IEC 14443-4 Identification cards — Contactless integrated
PC/SC Interoperability Specification for ICCs and
CCID Specification for Integrated Circuit(s) Cards
USB Universal Serial Bus Specification 2.0 USB-IF
Description Issuer
Identification cards — Integrated circuit
cards — Part 3: Cards with contacts — Electrical
interface and transmission protocols
with contacts
Part 4: Interindustry commands for interchange
ISO/IEC 7816-4: 1995 (E)
Identification cards — Contactless
ISO / IEC
ISO / IEC
ISO / IEC
integrated circuit(s) cards — Proximity
cards — Part 3: Initialization and anticollision
circuit(s) cards — Proximity cards
Part 4: Transmission protocol ISO/IEC 144434:2001(E)
Personal Computer Systems v2.01
Interface Devices 1.1
ISO / IEC
PC/SC Workgroup
USB-IF
2.6. Conventions
Bits are represented by lower case ‘b’ where followed by a numbering digit.
Bytes are represented by upper case ‘B’ where followed by a numbering digit.
Example:
@MAXX
LITE REFERENCE MANUAL
163 decimal number is represented
9
•
•
The least significant nibble of 0xA3 is
•
•
The most significant nibble of =xA3 is
•
•
in hexadecimal as 0xA3
in binary as (10100011)b
0x3 in hexadecimal
(0011)b in binary
0xA in hexadecimal
(1010)b in binary
@MAXX
LITE REFERENCE MANUAL
10
3. General information about @MAXX lite
3.1. @MAXX lite key benefits
The @MAXX lite is an all-in-one device and belongs to SCM’s @MAXX token family. Designed
as a USB-stick the @MAXX lite is portable and can be connected to stationary PCs as well as
Laptops. In addition to the normal smartcard reader the internal RF antenna converts the
normal USB-stick together with a dual interface smartcard to a portable mobile passive NFC
token. The typical application field of the @MAXX lite is the combination of physical and logical
access within one device.
3.2. @MAXX lite key features
•
8-pin, ISO7816 compliant contact smart card reader for ID-000 smartcards
o PC/SC v2.0 compliant
o CCID compatible
•
Unique serial number for the Mass Storage interface
•
Can be plugged into any USB slot on a PC without having to re-install the driver.
•
embedded flash memory 2GB (other capacities on request)
•
internal passive RF-antenna connected to C4/C8 of the smartcard connector
3.3. @MAXX lite ordering information
Item Part number
@MAXX lite 905110
Contact SDK 905129 SDK for Contact SmartCard
3.4. @MAXX lite customization options
Upon request, SCM can customize:
•
The color of the casing
•
The logo
•
The product label
•
The USB strings for the Mass Storage Device
•
Flash memory capacity
Terms and conditions apply, please contact your local SCM representative or send an email to
sales@scmmicro.com.
@MAXX
LITE REFERENCE MANUAL
11
3.5. Hardware features and their principle usage
The @MAXX lite is a multifunctional token device, which can be used within a big application
field. It can be used for one application or for a combination of several applications. In the
following paragraphs the usage recommendations are outlined to ensure best user experience.
1. Contact Smart Card Reader for dual interface Smart Cards with antenna connection on
C4 / C8
2. Internal RF antenna
3. On board flash memory
@MAXX lite schematics:
@MAXX
Clock signal line through which a clock signal can be provided
LITE REFERENCE MANUAL
12
3.5.1. Contact Smart Card Reader
The contact smart card reader is an
000 smartcards. Its contacts C4 and C8 are connected with the internal RF antenna. Thus it is
possible to use beside normal smartcards (microprocessor and memory cards) also dual interface
smartcards with additional contacts on C4 / C8. Memory cards can be accessed using SCM’s
Memory Card DLL.
Note: Memory cards which supports C4 /C8 will not be able to work as these pins are used for the
RF antenna.
Within a Windows® environment the smart card reader can be used with the PC/SC driver or with a
preinstalled USB-CCID driver.
Windows® Vista and future Windows® operation systems have the USB-CCID driver as standard
driver already installed. If Windows® XP is used as operating system, the USB-CCID driver is
available as optional update.
8-pin, ISO7816 compliant contact smart card reader for ID-
Contact
C1 Vcc
C2 RST
C3 CLK
C4 Antena RF antenna
C5 GND
C6 Vpp
C7 I/O
C8 Antenna RF antenna
Designation
Use
Power connection through which operating power is supplied
to the microprocessor chip in the card
Reset line through which the IFD can signal to the smart
card's microprocessor chip to initiate its reset sequence of
instructions
to the microprocessor chip. This line controls the operation
speed and provides a common framework for data
communication between the IFD and the ICC
Ground line providing common electrical ground between the
IFD and the ICC
Programming power connection used to program EEPROM of
first generation ICCs.
Input/output line that provides a half-duplex communication
channel between the reader and the smart card
@MAXX
LITE REFERENCE MANUAL
Smart Card insertion:
13
3.5.2. Internal RF antenna
The internal RF antenna is connected with the pins C4 / C8 of the smartcard reader for the
usage of dual interface cards.
When a dual interface card is inserted in the @MAXX and the @MAXX is put in the magnetic
field of any contactless reader, the internal RF antenna couples with the reader and an
induction current appears in the antenna thus providing power to the integrated circuit. The
generated current is proportional to the magnetic flux going through the antenna of @MAXX
reader
The carrier frequency of the magnetic field is used as a fundamental clock signal for the
communication between the reader and the card. It is also used as a fundamental clock input
for the integrated circuit microprocessor to function.
To send data to the user token the reader modulates the amplitude of the field. There are
several amplitude modulation and data encoding rules defined in ISO/IEC 14443. The reader
should should be ISO 14443 compliant reader.
To answer to the reader, the integrated circuit card of the @MAXX modulates its way of loading
(impedance) the field generated by the reader. Here also further details can be found in
ISO/IEC 14443.
The best communication between the @MAXX (with inserted dual interface card) and a
contactless reader can be established if the @MAXX is placed on the contactless reader with
the @MAXX bottom side in direction to the contactless reader. The bottom side of the @MAXX
@MAXX
LITE REFERENCE MANUAL
is the side where the label and the smartcard insertion slot can be found. Depending on the
used contactless reader and the used dual interface card, the @MAXX lite establishes a read
out distance between 2cm – 3cm. A little bit bigger antenna within the @MAXX pime A results
to a bigger read out distance up to 3.5cm.
The communication between the reader and the @MAXX with dual interface card is sensitive to
the presence of material or objects interfering with the magnetic field generated by the reader.
The presence of conductive materials like metal in the vicinity of the reader and the user token
can severally degrade the communication and even make it impossible. The magnetic field of
the reader generates Eddy or Foucault’s currents in the conductive materials; the field is
literally absorbed by that kind of material.
The presence of multiple @MAXXs in the field of contactless readers also interferes with the
communication. When several @MAXXs are in the field of a contactless reader, load of the
field increases which implies that less energy is available for each of them and that the system
is detuned.
The communication between a contactless reader and the @MAXX is sensitive to the geometry
of the system {reader, @MAXX}. Parameters like the geometry and specially the relative size of
the reader and @MAXX antennas directly influence the inductive coupling and therefore the
communication.
14
3.5.3. Embedded Flash
Also the embedded flash memory is connected with the internal USB-hub over the flash
controller. The actual hardware design is able to support embedded flash memory up to 4GB.
Several different partitions can be created on the flash memory:
- CD-Rom partition (with Auto-run function)
- Secure partition (PIN protected)
It is also possible to upload data on the flash and to create different partitions on production
level.
3.6. Applications
3.6.1. General
@MAXX lite is a multifunctional device, designed to interface a personal computer host
supporting PC/SC interface or CCID interface with ISO7816 smartcards in ID-000 format.
Further the device can be used as a passive NFC tag by using a dual interface smartcard. And
the @MAXX can be used as USB Mass Storage device and Micro SD-card reader.
The following graphic shows the case study and the needed infrastructure if the @MAXX is
used as a passive NFC token.
@MAXX
LITE REFERENCE MANUAL
15
A similar use case is the door opener. In this case the host is not seen. The contactless reader
is installed beside the door.
@MAXX lite itself handles the communication protocol but not the application related to the
token. The application-specific logic has to be implemented by software developers on the host.
@MAXX
LITE REFERENCE MANUAL
16
3.6.2. Applications provided by SCM Microsystems
SCM Microsystems does not provide payment or transport applications.
SCM Microsystems provides a few applications for development and evaluation purposes that
can function with @MAXX lite. There are many tools provided; here are two of them:
•
The NFC forum tag reader/writer is a standalone application that enables the user to
read and write NFC forum compliant records into NFC forum compatible tags. It is an
easy to use tool to configure rapidly NFC forum tag demonstrations. Note: @MAXX
lite supports NFC forum tag type 2 and 4, only.
•
Smart card commander version 1.1 provides NFC forum record parsing functionality
of NDEF records in XML format as well as scripting functionality which can be very
useful for developers to develop and debug their applications. This tool can be used
for both the contact and the contactless interfaces of @MAXX lite
@MAXX
LITE REFERENCE MANUAL
17
4. @MAXX lite characteristics
4.1. @MAXX lite high level architecture
4.1.1. Block diagram
The link between @MAXX lite and the host to which it is connected is the USB interface
providing both the power and the communication channel.
@MAXX lite contains the SCM Mask ROM Controller for the SIM Interface. The Mask ROM
firmware can handle all the ISO7816 contact protocol and the PC/SC communication protocol
with the host.
@MAXX
LITE REFERENCE MANUAL
18
Software architecture
Applications can interface with the driver directly through the PC/SC interface.
The @MAXX lite driver implements PC/SC v2.0 API towards upper layers and full CCID for the
contact slot.
@MAXX
LITE REFERENCE MANUAL
19
4.2. Quick reference data
4.2.1. @MAXX lite dimensions
Item Characteristic Value
Weight 13,5 Grams
External dimensions
USB connector USB type A connector
Default color Black rubberized
@MAXX lite
Default label
Drawing with dimensions of the @MAXX lite and accessories can be found in annex.
L 71,0 mm × W 26,0mm × H 10,4mm
4.2.2. LED behavior
@MAXX lite is equipped with a red LED
@MAXX lite LED Indication (red)
Just after plug-in (with drivers
already installed)
@MAXX connected (Idle State)
Reader / card errors
Read or write on smartcard, flash storage Flashing
Suspend State OFF
4.2.3. Other data
4.2.3.1. General
Parameter Value/Description
Clock of the device
controller
API PC/SC 2.0, CCID
Operating temperature
range
Operating humidity
range
Certifications
24 MHz
-20ºC to 60ºC
Up to 95%RH non condensing
CE
FCC
VCCI
WEEE
RoHS
RoHS green (on request without rubberized casing)
flashing
ON
OFF
@MAXX
LITE REFERENCE MANUAL
20
4.2.3.2. USB
Parameter Value/Description
Electrical
Characteristics
USB specification
USB Speed High Speed Device (480Mbit/s), Tolerance +- 240kbit/s
PID 0417 (Flash) , 5116 (SIM) and 03F3 (Hub)
VID 04E6
High bus powered (@MAXX draws power from USB bus)
Voltage: 5V
Max. Current : 500mA
USB 2.0 Device
4.2.3.3. Contact interface
Parameter Value/Description
Smart card operating
frequency
Maximum supported
card baud-rate
Cards supported
ISO-7816 compliant
EMV’2000 compliant Not applicable (F/w. is EMV ready, but isn’t applicable for this product)
CT-API compliant Support Available
Number of slots Single smart card slot for smart cards ID-000
Ejection mechanism Manual
4.8Mhz
500Kbps
Class A, Class B, and Class C smart cards
Synchronous smart cards
Yes
@MAXX
LITE REFERENCE MANUAL
21
5. Software modules
5.1. Installation
SCM provides an installer for Windows.
The installer can be used to install the driver as well as some utilities.
5.2. Utilities
The following utilities are available:
•
A tool for testing the installation of the PC/SC driver
•
A tool for testing the resource manager
•
A tool called PC/SC Diag capable of providing basic information about the reader
and a card through PC/SC stack
.
5.3. Driver
5.3.1. @MAXX listing
@MAXX lite is listed
by PC/SC applications as
•
SCM Microsystems Inc. SCR33x USB Smart Card Reader 0
USB Mass Storage Device:
•
SCMMICRO @MAXX Lite FlashDrive
5.3.2. Supported operating systems
Operating systems supported by the driver:
•
Windows XP (32 & 64 bit)
•
Windows Vista (32 & 64 bit)
•
Linux (Kernel ver. 2.6.x) - 32bit
•
MAC OS 10.5 (Leopard) – 32bit
•
WinCE (32bit)
@MAXX
LITE REFERENCE MANUAL
22
5.4. Firmware
5.4.1. CCID transport protocol
@MAXX lite implements a transport protocol that is compliant with USB Device Class: Smart
Card CCID Specification for Integrated Circuit(s) Cards Interface Devices Revision 1.10 for the
contact smart card interface and CCID-like transport protocol for the contactless interface.
This paragraph describes the CCID specification features that are implemented and those that
are not implemented.
5.4.1.1. CCID class requests supported
•
Abort
5.4.1.2. CCID bulk messages supported
The following section provides information on the list of CCID bulk messages (10-byte header
followed by the message specific data) that have been implemented.
List of CCID bulk messages supported
• PC_to_RDR_IccPowerOn
• PC_to_RDR_IccPowerOff
• PC_to_RDR_GetSlotStatus
• PC_to_RDR_XfrBlock
• PC_to_RDR_GetParameters
• PC_to_RDR_SetParameters
• PC_to_RDR_Escape
• PC_to_RDR_Abort
• PC_to_RDR_SetDataRateAndClockFreqeuncy
• PC_to_RDR_T0APDU
• PC_to_RDR_ResetParameters
• PC_to_RDR_IccClock
List of CCID bulk messages not supported
• PC_to_RDR_Secure
• PC_to_RDR_Mechanical
5.4.1.3. CCID Error Codes
Extensive error codes are reported on many conditions during all CCID responses. Most of the
error messages are reported by the CCID appropriately. Some of the main error codes for the
contact interface are:
•
HW_ERROR
•
XFR_PARITY_ERROR
•
BAD_ATR_TS
•
BAD_ATR_TCK
•
ICC_MUTE
The following sub-sections discuss when and why these error codes are returned:
@MAXX
LITE REFERENCE MANUAL
23
5.4.1.3.1. HW_ERROR
This error code is returned when a hardware short circuit condition is detected, during
application of power to the card or if any other internal hardware error is detected. This error
code has been defined in the error code table 6.2-2 of the CCID specification.
5.4.1.3.2. ICC_MUTE
This error code is returned when the card does not respond until the reader time out occurs.
This error will be reported in the response to PC_to_RDR_XfrBlock message and
PC_to_RDR_IccPowerOn messages. This error code has been defined in the error code table
6.2-2 of the CCID specification.
@MAXX
LITE REFERENCE MANUAL
24
6. Commands description
6.1. Escape commands for the contact interface
6.1.1. Sending escape commands to @MAXX lite
A developer can use the following method to send escape commands to @MAXX lite for the
contact interface
•
SCardControl method defined in PC/SC API
6.1.2. Escape command codes
Escape commands can be used by an application to configure @MAXX lite to function in a
mode that is not its default configured mode or to get specific information. To put the @MAXX
lite back into its default mode, either the @MAXX lite has to be unplugged and plugged again
or the application can send again the same escape command.
The following escape commands are supported by @MAXX lite for the contact interface
S.No. Escape message ID Value
1 CCID_ESC_GETINFO 0x00
2 CCID_ESC_SETMODE 0x01
3 CCID_ESC_GETMODE 0x02
4 CCID_ESC_GET_FW_VERSION 0x03
5 CCID_ESC_SET_POWER_ON_RESET_ORDER 0x04
6 CCID_ESC_EMV_LOOPBACK 0x05
7 CCID_ESC_APDU_TRANSFER 0x08
8 CCID_ESC_CLK_FREQUENCY 0x1F
9 CCID_ESC_GET_SET_ETU 0x80
10 CCID_ESC_GET_SET_WAITTIME 0x81
11 CCID_ESC_GET_SET_GUARDTIME 0x82
12 CCID_ESC_GET_SET_EGT 0x83
13 CCID_ESC_GET_SET_ATR_TIMEOUT 0x84
14 CCID_ESC_POWER 0xC0
15 CCID_ESC_ROUGH_TANSFER 0xC1
16 CCID_ESC_GET_SET_PROTOCOL 0xC2
17 CCID_ESC_GET_SET_TA1_RFU 0xC3
@MAXX
LITE REFERENCE MANUAL
25
6.1.3. CCID_ESC_GETINFO
This escape message ID gets static reader specific information from firmware to the host.
Information includes the major and minor version, capabilities of the reader etc. The first byte of
input buffer of shall have just one byte that will contain this escape function’s value. The output
buffer shall point to an application allocated SCARD_READER_GETINFO_PARAMS structure
mentioned below.
typedef struct _SCARD_READER_GETINFO_PARAMS
{
uint8 MajorVersion;
uint8 MinorVersion;
uint8 SupportedModes;
uint16 SupportedProtocols;
uint16 InputDevice;
uint8 Personality;
uint32 Serial;
uint8 MaxSlots;
} SCARD_READER_GETINFO_PARAMS;
6.1.4. CCID_ESC_SETMODE
This escape message ID sets the current mode of the reader. Applications may call this
function, to set the desired mode. Typically, this call is used to switch between the EMV and
ISO7816 operation. The first byte of the input buffer will contain the escape function value and
the second one will contain the value for the desired mode of operation. The output buffer field
shall be NULL.
Following table gives the value of modes as interpreted by firmware
S.No. Mode Value Remarks
1 ISO 0x02 ISO 7816 mode
2 EMV 0x04 EMV
6.1.5. CCID_ESC_GETMODE
This escape message ID retrieves the current mode in which the reader. The input buffer shall
contain the escape function value. The output buffer shall point to a BYTE buffer.
Following table gives the value of modes as interpreted by firmware
S.No. Mode Value Remarks
1 ISO 0x02 ISO 7816 mode
2 EMV 0x04 EMV
@MAXX
LITE REFERENCE MANUAL
26
6.1.6. CCID_ESC_GET_FW_VERSION
This function code shall be used by the application / driver to retrieve the current firmware
revision of the reader.
The input buffer shall contain the escape code. The reader shall return a WORD parameter
containing the firmware revision.
typedef struct _FW_REV
{
uint8 byFirmwareMajor;
uint8 byFirmwareMinor;
} FW_REV;
6.1.7. CCID_ESC_SET_POWER_ON_RESET_ORDER
This code shall be used by the application / driver to change the smart card power-on
sequence i.e. it shall direct the reader to start the card reset by applying by “Class A” voltage
first and then retry sequentially with the other classes.
The input buffer shall contain the escape code followed by the RESET SEQUENCE data. The
output buffer shall point to a byte and shall return the current RESET SEQUENCE selected.
S.No. Mode Value Remarks
1 Class C 0x00 Starts with Class C voltage. This is
the default mode of the reader.
2 Class A 0x01 Starts with Class A voltage
3 QUERY 0xFF This is used to retrieve the current
mode of operation.
6.1.8. CCID_ESC_EMV_LOOPBACK
This escape message ID lets the host force the library to perform an EMV Loop-back
application.
The input buffer shall contain the escape function value. The output buffer field shall be NULL.
6.1.9. CCID_ESC_APDU_TRANSFER
This escape message ID exchanges an APDU with the smart card.
The input buffer shall contain the escape function value, followed by the APDU. The output
buffer field shall point to user allocated buffer to the maximum size of 259 bytes.
The maximum number of bytes that can be received / sent is given below.
Transmit:
Case 1, 2, 3 APDU: Max of 256 bytes per APDU
Case 4 APDU: Max of 255 bytes per APDU
Receive:
Max of 259 bytes per APDU
@MAXX
4
6
8
12
LITE REFERENCE MANUAL
27
6.1.10. CCID_ESC_CLK_FREQUENCY
In case when an application wants to change the clock frequency, this escape ID is used to
inform the reader about the change in clock. The first byte of the input buffer will contain the
escape function value; the next byte will contain the clock divisor value. The output buffer field
shall be NULL.
The possible clock divisor values and hence the clock frequency is given in the table below
CLK FREQUENCY (in MHz) CLOCK DIVISOR
VALUE
6
4
3
2
USB RS232
3.686
5.53
7.37
11.06
6.1.11. CCID_ESC_GET_SET_ETU
This function code shall be used by the reader to get and set the current ETU. The ETU is
specified in terms of smart card clock cycles.
The input buffer shall point to the escape code followed by a DWORD specifying the value to
be set. The output buffer shall point to NULL.
6.1.12. CCID_ESC_GET_SET_WAITTIME
This function code shall be used to set and get the character / block waiting time of the reader.
The wait time is specified in terms of smart card clock cycles.
The buffer shall point to the escape code followed by the wait time structure.
typedef struct _WAIT_TIME
{
uint8 byGetSetIdentifier;
uint8 byWaitTimeIdentifier;
uint32 dwWaitTime;
} WAIT_TIME;
@MAXX
LITE REFERENCE MANUAL
28
6.1.13. CCID_ESC_GET_SET_GUARDTIME
This function code shall be used to set and get the character / block guard time of the reader.
The guard time is specified in terms of etus.
The buffer shall point to the escape code followed by the guard time structure.
typedef struct _GUARD_TIME
{
uint8 byGetSetIdentifier;
uint8 byGuardTimeIdentifier;
uint32 dwGuardTime;
} GUARD_TIME;
6.1.14. CCID_ESC_GET_SET_EGT
This function code shall be used to set and get the extra guard time of the reader. The guard
time is specified in terms of etus.
The buffer shall point to the escape code followed by a structure given below.
typedef struct _EGT
{
uint8 byGetSetIdentifier;
uint32 dwEGT;
} EGT;
6.1.15. CCID_ESC_GET_SET_ATR_TIMEOUT
This function is used to change the delay (in ms) between the power-up attempts in the classA, class-B, and class-C sequence;
The buffer shall point to the escape code followed by a BYTE containing the timeout value.
6.1.16. CCID_ESC_POWER
This function code shall be used to change the VCC level for the reader. The input buffer shall
point to the escape code followed by a WORD containing VCC value. The ICC will be reset to
the value given in the buffer.
The supported smart card voltages are:
#define Vcc_AUTOMATIC 0x00
#define Vcc_5V 0x01
#define Vcc_3V 0x02
#define Vcc_1_8V 0x03
@MAXX
LITE REFERENCE MANUAL
29
6.1.17. CCID_ESC_ROUGH_TANSFER
This command is used to perform raw exchange of data with the card. The input buffer for this
command will contain the escape function value, low byte of the send length, high byte of the
send length, low byte of the expected length, high byte of the expected length and the
command. The output buffer field shall point to user allocated buffer.
6.1.18. CCID_ESC_GET_SET_PROTOCOL
This function code shall be used to set and get the transmission protocol for the reader.
The buffer shall point to the escape code followed by a BYTE.
The supported protocols are:
#define PROTOCOL_T0 0x00
#define PROTOCOL_T1 0x01
#define PROTOCOL_UNDEFINED 0xFF
6.1.19. CCID_ESC_GET_SET_TA1_RFU
Since the reader is compliant to ISO 7816-3 (1997), it will reject cards having a TA1 value
which is RFU in respect to this version of the specification. Using this escape function the
application can introduce such a card to the reader. If a card having this particular value of TA1
in the ATR is detected, it will be accepted by the reader and the maximum communication
speed (i.e. 115200 bps) will be applied. The buffer shall point to the escape code followed by a
BYTE.
@MAXX
LITE REFERENCE MANUAL
30
7. Annexes
7.1. Annex A – Status words table
SW1 SW2 Description
0x90 0x00 NO ERROR
0x67 0x00 LENGTH INCORRECT
0x6D 0x00 INVALID INSTRUCTION BYTE
0x6E 0x00 CLASS NOT SUPPORTED
0x6F 0x00 UNKNOWN COMMAND
0x63 0x00 NO INFORMATION GIVEN
0x65 0x81 MEMORY FAILURE
0x68 0x00 CLASS BYTE INCORRECT
0x6A 0x81 FUNCTION NOT SUPPORTED
0x6B 0x00 WRONG PARAMETER P1-P2
7.2. Annex B – Sample code using escape commands
through Escape IOCTL
File Name : T_hbr.H
#ifdef __cplusplus
extern "C" {
#endif
#define IOCTL_CCID_ESCAPE SCARD_CTL_CODE (0xDAC)
#define CCID_GET_848KBPS_STATUS 0xFF9D
#define CCID_SET_848KBPS_ON 0x019D
#define CCID_SET_848KBPS_OFF 0x009D
#define MINTIMEOUT 300
#ifdef __cplusplus
}
#endif
File Name : T_hbr.CPP
#include <windows.h>
@MAXX
LITE REFERENCE MANUAL
#include <winbase.h>
#include <stdio.h>
#include <conio.h>
#include "winscard.h"
#include "winerror.h"
#include "T_hbr.H"
VOID main(VOID)
{
SCARDCONTEXT ContextHandle;
SCARDHANDLE CardHandle;
BYTE OutByte;
WORD InWord,i;
DWORD ActiveProtocol; /* ICC protocol */
ULONG InBufLen,ResLen;
ULONG ret;
SCARD_READERSTATE Reader[1];
// please add the name of the used reader here or use SCardListReaders
// to find the right reader name
char *ReaderName[] = {"SCM Microsystems Inc. @MAXX lite Contactless Reader 0",
NULL};
/***************************************************************************************
*****************/
ContextHandle = -1;
ret = SCardEstablishContext(SCARD_SCOPE_USER, NULL, NULL, &ContextHandle);
if (ret == SCARD_S_SUCCESS)
{
ret = SCardConnect( ContextHandle,
ReaderName[0],
SCARD_SHARE_SHARED,
SCARD_PROTOCOL_T0 | SCARD_PROTOCOL_T1,
&CardHandle,
&ActiveProtocol);
if (ret == SCARD_S_SUCCESS)
{
31
@MAXX
LITE REFERENCE MANUAL
/* get actual 848kbps status: ON/OFF */
InBufLen = 2;
InWord = CCID_GET_848KBPS_STATUS;
ret = SCardControl (CardHandle,
IOCTL_CCID_ESCAPE,
&InWord,
&OutByte,
printf ("\n Get 848kbps status: %lx: %.2x", ret,OutByte);
Reader[0].dwCurrentState = SCARD_STATE_UNAWARE;
Reader[0].dwEventState = SCARD_STATE_UNAWARE;
Reader[0].szReader = ReaderName[0];
ret = SCardGetStatusChange( ContextHandle,
printf ("\nATR: ");
for (i=0; i<Reader->cbAtr; i++)
{
printf ("%.2x ",Reader->rgbAtr[i]);
}
printf ("\n----------------------------------------------\n");
/* enable 848KBPS: ON */
printf ("\nEnable 848kbps ");
InBufLen = 2;
InWord = CCID_SET_848KBPS_ON;
ret = SCardControl (CardHandle,
IOCTL_CCID_ESCAPE,
&InWord,
&OutByte,
ret = SCardDisconnect(CardHandle, SCARD_RESET_CARD);
32
InBufLen,
1,
&ResLen);
MINTIMEOUT,
Reader,
1);
InBufLen,
1,
&ResLen);
@MAXX
LITE REFERENCE MANUAL
ret = SCardConnect (ContextHandle,
ReaderName[0],
SCARD_SHARE_SHARED,
SCARD_PROTOCOL_T0 | SCARD_PROTOCOL_T1,
&CardHandle,
&ActiveProtocol);
/* get actual 848KBPS status: ON/OFF */
InBufLen = 2;
InWord = CCID_GET_848KBPS_STATUS;
ret = SCardControl (CardHandle,
&InWord,
&OutByte,
&ResLen);
printf ("\n Get 848kbps status: %lx: %.2x", ret,OutByte);
Reader[0].dwCurrentState = SCARD_STATE_UNAWARE;
Reader[0].dwEventState = SCARD_STATE_UNAWARE;
Reader[0].szReader = ReaderName[0];
ret = SCardGetStatusChange (ContextHandle,
MINTIMEOUT,
printf ("\nATR: ");
for (i=0; i<Reader->cbAtr; i++)
{
printf ("%.2x ",Reader->rgbAtr[i]);
}
printf ("\n----------------------------------------------\n");
/* Disable 848Kbps: OFF */
printf ("\nDisable 848KBPS ");
InBufLen = 2;
InWord = CCID_SET_848KBPS_OFF;
ret = SCardControl(CardHandle, IOCTL_CCID_ESCAPE,
&InWord, InBufLen,
&OutByte, 1, &ResLen);
33
IOCTL_CCID_ESCAPE,
InBufLen,
1,
Reader,
1);
@MAXX
LITE REFERENCE MANUAL
ret = SCardDisconnect(CardHandle, SCARD_RESET_CARD);
ret = SCardConnect(ContextHandle,
ReaderName[0],
SCARD_SHARE_SHARED,
SCARD_PROTOCOL_T0 | SCARD_PROTOCOL_T1,
&CardHandle,
&ActiveProtocol);
/* get actual 848KBPS status: ON/OFF */
InBufLen = 2;
InWord = CCID_GET_848KBPS_STATUS;
ret = SCardControl(CardHandle, IOCTL_CCID_ESCAPE,
&InWord, InBufLen,
&OutByte, 1, &ResLen);
printf ("\n Get 848KBPS status: %lx: %.2x", ret,OutByte);
Reader[0].dwCurrentState = SCARD_STATE_UNAWARE;
Reader[0].dwEventState = SCARD_STATE_UNAWARE;
Reader[0].szReader = ReaderName[0];
ret = SCardGetStatusChange(ContextHandle, MINTIMEOUT, Reader, 1);
printf ("\nATR: ");
for (i=0; i<Reader->cbAtr; i++)
{
printf ("%.2x ",Reader->rgbAtr[i]);
}
printf ("\n----------------------------------------------\n");
ret = SCardDisconnect(CardHandle, SCARD_RESET_CARD);
}
else
{
printf("\n SCardConnect failed with 0x%.8lX",ret);
}
ret = SCardReleaseContext(ContextHandle);
}
else
{
printf("\n SCardEstablishContext failed with %.8lX",ret);
}
printf("\npress any key to close the test tool\n");
getch();
}
34
