Scientech Electronics KP2 User Manual

ACCESSORIES

The LS-30 system includes a full range of accessories, so you can
customize many feature of your security system.
All the radio transmitters used in the LS-30 system, except the Remote
Controller, have a unique random code that is set by the factory with
16,777,216 combinations in total. Also with specially designed
transmission timing control, the LS-30 system can effectively prevent
mutual interference from other transmitters in the system. The Remote
Controller uses copy-preventing hopping-code technology, changing its
radio code every time you press the button. The combinations possible
through this hopping-code are up to 7.3 X 1019. To comply with the
regulations in most countries, radio power is limited to below 10mW, and
effective range is about 100 meters measured at open field. The range may
be somewhat less indoors, depending on the layout of building construction
and furniture.
You may enroll all the wireless accessories and change their related settings,
either through the guidance of the interactive LCD display on the Base Unit
explained in the “INSTALLATION” section that follows, or by using a
computer with the proprietary software “HyperSecureLink” through an
interface adapter, which offers a quicker and simpler way to perform the
installation in.

NOTE: The changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.
The comply with the FCC RF exposure compliance requirements, this
device and its antenna must not be co-located or operating to conjunction
with any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

WIRELESS KEYPAD KP-2S

INTRODUCTION

The KP-2S is the wireless keypad for the LS-30; it controls the Base Unit remotely.
With its backlight feature, you can operate it even in the dark. Its 4-digit password
will prevent unauthorized use.

INSTALLATION

1. Remove the battery hatch of the KP-2S, insert four AAA alkaline batteries and
replace the battery hatch.

2. Refer to next page ”CHANGE PASSWORD”, and change the factory password
on the KP-2S as below.

A) Enter default password 9999 (factory setting), and the green LED will light.
B) Press * for 3 seconds then release.
C) Enter your new password.

3. Enroll the KP-2S as a controller on the Base Unit

Select “Installer Mode” on the Base Unit, and enter Installer Password to gain
access authority. Then select \Set Device\Enroll Device\Controller\Zone No. to
enroll the ID of KP-2S by pressing “password, 3” on the KP-2S. You may
change its various attributes under \Set Device\Change Device Setting\Controller,
to fulfill different requirements.

Remarks: If theKP-2S is set with Latchkey attribute ON, the Base Unit will call

“Latchkey Number” (refer to Section 3-2-1) whenever the Disarm or
Away signal is sent from this KP-2S.
