Schweigen CL6272 Installation Guide

HOME APPLIANCES

RANGEHOOD & INSTALLATION GUIDE

CL6272

For Household Outdoor Use Only

Revision V5

www.schweigen.com.au

Index

1. Welcome ____________________________________________________________________________________________________ 3

2. Your Safety

Safety Advice _______________________________________________________________________________________________ 4
Before Installation __________________________________________________________________________________________ 5
Product Use ______________________________________________________________________________ 8
Maintenance and Service ________________________________________________________________________________ 8
Electrical Cord ______________________________________________________________________________________________ 8

3. Tips and Suggestions

For Users _________________________________________________________________________________ 7
For Installers and Users ____________________________________________________________________ 7

4. Description
Main Rangehood __________________________________________________________________________________________ 8
Speed Controls _____________________________________________________________________________________________ 8

5. Operation
Control Panel _____________________________________________________________________________ 9

6. Cleaning and Maintenance
Surfaces ______________________________________________________________________________________________________ 10
Filters _________________________________________________________________________________________________________ 10
Cleaning the Interior _______________________________________________________________________________________ 11
Cleaning the Exterior _______________________________________________________________________________________ 11
Replacing the Light Bulb __________________________________________________________________ 13

7. Installation

Mounting Laws and Regulations ___________________________________________________________ 14
Wall Mount Installation ____________________________________________________________________ 15
Installation Guide _________________________________________________________________________ 16
BBQ Installation ___________________________________________________________________________ 17
Flexible Ducting __________________________________________________________________________ 17
Back Draft Fins ____________________________________________________________________________ 17
Installation Advice ________________________________________________________________________ 18

8. Maintenance
Condensation Information ________________________________________________________________ 20
Troubleshooting _____________________________________________________________________________________________ 22
Technical Specications __________________________________________________________________ 22
Faulty Installation _________________________________________________________________________ 23

9. Specication
CL6272 _______________________________________________________________________________________________________ 24

10. Disclaimer ___________________________________________________________________________________________________ 25

Page 2

1. Welcome

Thank you for purchasing your new Schweigen rangehood.

To get the maximum output from this unit, please thoroughly read this guide before installation and
use.

The guide contains important information on the use and maintenance of the unit, as well as
important safety notes. This will ensure your personal safety and the lasting value of your rangehood.

We trust that you will enjoy your new Schweigen rangehood.

Please always retain your proof of purchase to aid in any warranty queries.

If you are unable to locate your warranty card, one is available to download from our website
www.schweigen.com.au.

This appliance and its packaging are produced by processes that minimise waste and respect the
environment.

Please help us to continue this effort to protect the environment by using the appliance efciently

and dispose of any packaging in a responsible manner.

Model

Purchase Date

Purchase Location

Page 3

2. Your Safety

WARNING

Please read this section thoroughly before attempting to operate the
appliance. Inspect your product upon receipt. Any damages or defects
MUST be reported within 48 hours of purchase, or no claim will be
recognised.

DO NOT INSTALL THIS APPLIANCE IF IT IS FOUND TO BE DAMAGED.

If this product is installed damaged, neither the supplier, nor the retailer,
will be responsible for any costs associated with the repair, replacement,
removal or re-installation of the appliance.

Safety Advice

1. There shall be adequate ventilation in the room when the rangehood is used at the same time

as appliances burning gas or other fuels.

2. There is a re risk if cleaning is not carried out in conjunction with the instructions.

3. Do not ambé under the rangehood. This will damage the rangehood and will not be covered

by warranty.

4. Do not ignite burners that give off intense, uncontrolled ames beneath the rangehood.

5. Flames beneath the pan must be contained at all times and cannot exceed the width of the

pan in use.

6. Do not leave any packaging material (bags, corner brackets etc.) within reach of children.

7. This appliance is not intended for use by person/s (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and/or knowledge. Unless, the person
is given supervision or instruction concerning the safe usage of the appliance by person/s
responsible for their safety. Children must be supervised to ensure that they do not play with the
appliance, it is not a toy.

8. The air must not be discharged into a ue that is used for exhausting fumes from appliances

burning gas or other fuels (not applicable to appliances that only discharge the air back into the
room).

9. Accessible parts may become hot when used with cooking appliances.

10. Before performing any cleaning or maintenance operation, disconnect the rangehood from the

mains using the respective mains or sector switch or by unplugging it.

11. Do not use the rangehood without the grease lters.

12. Keep the grease lters clean and respect the recommended cleaning frequencies.

13. The rangehood motor must be switched on before commencing cooking.

14. Turn the rangehood motor off about 10-15 minutes after you nish cooking.

15. It is forbidden to use the rangehood as an aspirator.

Page 4

2. Your Safety

16. Never cook foodstuff directly over the ame or have the gas burners on under the rangehood

without using cookware.

17. To be installed in an undercover alfresco area and/or indoor kitchen only.

18. If the unit is not adequately covered or sheltered from the outside elements the warranty will be

null and void.

Before Installation

1. We recommend this appliance be installed or repaired by a qualied Schweigen Home

Appliances technician.

2. Please see our website www.schweigen.com.au for a list of our recommended installers.

3. It is dangerous to modify any part of this appliance. Modication of any kind, will immediately

void the warranty.

4. The manufacturer declines all responsibility in case of failure to adopt proper safety measures.

5. Ensure that the location in which this appliance is installed, has good and permanent ventilation.

6. Please consult local laws and regulations and install in accordance.

7. Please use an earthed electrical connector that coincides with relevant local laws and

regulations.

8. Check that the power voltage in your area corresponds to the appliance voltage indicated on

the rating label.

9. This appliance must be connected to an electrical supply that has a grounded connection.

10. Check that the installation and electrical connections are carried out by a qualied technician

and that the indicated instructions and local regulations in force are met, using materials that
are compliant with the applicable legislation.

11. The company will not be responsible for installations executed by non-qualied staff and

installations that fail to heed the applicable legislation on electrical safety (with regard to both
modes and materials).

12. The electrical technical data can be found inside the rangehood, after removing the grease lters.

13. The exible power cable supplied is already connected internally and emerges from the

rangehood near the air outlet tube.

14. Before installing the electrical connections, you should:

• Verify that the indicated electrical data coincides with the voltage values and frequency of
the electrical circuit in the house where the rangehood is to be installed;

• Check that the premises has electrical protection against short circuits and electrocution,
pursuant to the applicable legislation;

• Always switch off the current using the double-pole switch before maintenance and turn the
power on again for normal use only when the operation has been completed.

Page 5

2. Your Safety

Product Use

This product is designed for household use and should not be used for commercial applications.

After use, always ensure that all controls are in the “OFF” position.

When frying with a gas ame, take particular care not to allow the oil or grease in the pan to catch
re. (Flambé)

Maintenance and Service

The rangehood surface should be cleaned with soft cloth and non-corrosive detergent. Do not leave
the rangehood wet after cleaning or use, please keep rangehood dry.

IMPORTANT: Never attempt to repair this appliance by yourself. Always refer to a qualied Service

Technician.

Always switch off the electricity and unplug the connection before conducting maintenance or
cleaning.

Electrical Cord

Ensure the supply cord is not exposed to heat, chemicals or sharp objects. If the supply cord is

damaged, it must be replaced by the manufacturer, service agent or a similarly qualied person in

order to avoid a hazard.

Page 6

3. Tips & Suggestions

The Rangehood has one mode of operation:

Air extraction: The air is drawn in and cleaned by the grease lters and directed outside. Please
check the cleaning and maintenance section for the lters’ cleaning periods.

For Users

1. Do not leave the frying pan or fryer unattended, as the oil could overheat and catch re.

2. Never ambé any foods beneath the rangehood. The ames could cause a re.

3. Before carrying out any operation inside the rangehood, unplug the appliance from the
electrical mains.

4. Respect the cleaning frequencies and intervals for changing the lters, as otherwise the

accumulated grease could cause a re or damage the product.

5. Changes made to the steel surface will render the warranty invalid.

For Installers and Users

1. In addition to the size, the height of the rangehood above the cooktop is important to obtain the
best performance.

2. For recommended height, please refer to Mounting Laws and Regulations.

OPTIMAL

Rangehood bigger than the

cooking area.

ADEQUATE

Rangehood equal to the

cooking area.

INADEQUATE

Rangehood smaller than the

cooking area.

Page 7

4. Description

Main Rangehood

1

Mounting Bracket

2

Extension Flue

3

Main Flue

4

Male Plug (Main Power 240V)

5

Two 150mm Outlet

Two Drip Trays (attached to the

6

bottom of the motors)

7

Filters

8

Lamp (For GU10 ttings, please twist to remove)

NOTE: Filter and light quantity may vary from model
to model.

1

2

3

4

5

6

7

Speed Control

This rangehood is equipped with a 3 speed mechanical control.

Speed control usage suggestions:

• Low speed for simmering.

• Medium speed for light cooking.

• High speed for heavy frying or heavy cooking.

8

Page 8

Push Button Control Panel

1 2 3

Turn on/off the rangehood

High speed setting

Medium speed setting

Low speed setting

Turn on/off the lamp

5. Operation

Page 9

6. Cleaning & Maintenance

WARNING

Always switch off and disconnect power before cleaning.

Surfaces

Wash with warm soapy water and a soft sponge. Never use abrasive detergent, scouring pads, steel
wool or solvents on any part of this appliance, Always make sure to dry the appliance after cleaning
and never leave wet, as this will cause irreparable damage.

Filters

• For this appliance to function effectively, regular maintenance is a must.

• The function of the lter is to absorb the grease particles emitted during cooking.

• Blocked lters and heavy oil deposits restrict airow and may cause the motor to overheat and

become a re hazard.

• Filters should be cleaned every 3-6 weeks or after 40 hours of use.

• Disconnect the electrical connection before any maintenance or cleaning processes are carried out.

• To remove the lter pull the clip gently down until it disengages. To replace, perform the same

operation but in reverse, making sure the back two tabs of the lter are lined up with the rangehood.

• In ceiling-mounted rangehoods, the doors or glass must be opened before accessing the lters.

• For an induction cooktop, please aim to clean them at least every 10 days, depending on use.

• The lters can be washed by hand or in the dishwasher

Washing by hand - Immerse the lter in hot water and a suitable detergent and when clean, rinse

with plenty of hot water.

Dishwasher - Put the lter in the dishwasher and select a short program at low temperature.
NOTE: The colour of the metal mesh lters may change after several washes. This is normal and it is

not necessary to change the lters.

Page 10

6. Cleaning & Maintenance

WARNING

• If the grease lters are very dirty, the motor will extract only a small
quantity of air, which reduces its efciency;

• The grease deposits that build up on the lter are highly ammable and

COULD EASILY CATCH FIRE.

• The manufacturer is exonerated from all responsibility in the event of re
due to poor maintenance of the grease lters.

Cleaning the Interior

Clean the interior of the rangehood with a damp cloth and a neutral detergent or denatured alcohol.

NOTE: Do not use denatured alcohol on the exterior of the rangehood. Do not clean the electric
parts or the motor with liquids or solvents

Page 11

6. Cleaning & Maintenance

Cleaning the Exterior

We recommended using a soft cloth, warm water and a liquid soap to clean the exterior. Rinse with
clean water and ensure that the appliance is completely dry after cleaning. For better results, you
can use high quality cleaning and protection products (eg. Steel Kleen) to clean your rangehood.

WARNING

• Make sure that the electrical power is off.

• The recommended detergent is a solution of water and a neutral liquid

soap.

• It is very important for the liquid soap to not contain granules that could

scratch the surface.

• First apply the solution to a soft cloth and then rub the cloth over the

rangehood. It is important to follow the direction of the stained surface

with the cloth (refer to gure on left).

OK

• Do not pour any liquid directly on to the rangehood.

• The cloth must have no buttons, zips or fasteners that could scratch the

surface.

• It is strictly forbidden to use chemical solvents, aggressive, grainy or

abrasive products, naphtha, alcohol or similar products that could
damage the surface of the rangehood.

• The manufacturer will not be held responsible for functional or aesthetic

damage caused by cleaning with products which are not suitable or
using inadequate cleaning methods.

Page 12

Replacing the Light Bulb

DANGER

Always switch off and disconnect the power cord before replacing any light bulbs.
Failure to do so may cause serious injury. Please be aware that the light bulb will
retain heat for a short period of time after being switched off.

6. Cleaning & Maintenance

Step 1

Remove the lters from
the rangehood.

Step 2

Gently turn light bulb anti­clockwise, pull the light bulb
down and remove it from the
light holder.

Step 3

Insert a new light bulb by lining
up the pins of the light bulb
with the larger holes inside the
light holder. Once the pins
are in place, turn clockwise to
secure the light bulb.

Page 13

7. Installation

DANGER

Always switch off and disconnect power before installing the rangehood. Failure to
do so may cause serious injury.

*IMPORTANT: Please check all State and Federal Laws in relation to the minimum - maximum
heights, regulations concerning the expelling of air and install your rangehood in accordance
with local laws and regulations.

Mounting Laws and Regulations

To be installed in an undercover alfresco area and/or indoor kitchen only. If the unit is not
adequately covered or sheltered from the outside elements the warranty will be null and void.

The rangehood must be located at the correct distance from the work plane.

Outdoor Alfresco Area

• Minimum height 800mm*

• Maximum height 1200mm*

For indoor kitchen area:

The minimum safety installation distance between the top of a cooktop and the lowest part of the
rangehood are as follows:

Minimum installation height for electric and gas cooktops is 650mm*.

For rangehoods 90cm wide or larger: Distances above 800mm can compromise the extraction

performance.

For 60cm wide rangehoods: Distances above 750mm can compromise the extraction performance.

Suggested height above a Induction Cook top is 720mm to 800mm. For more information please see

section Maintenance - Condensation Information*.

The location of the installation must have permanent openings for ventilation.

Regulations concerning the expelling of air have to be fullled.

It is strongly recommended that the rangehood be installed centrally over the cooktop.

Page 14

See Mounting Laws
and Regulations

7. Installation

WARNING

If the user decides to install the
rangehood at a distance of less
than minimum height above the
cooking surface, the company
declines responsibility for damages
suffered by the rangehood due to
excess heat or damage to objects,
people and others caused directly
or indirectly by a malfunction,

breakage or re.

Wall Mount Installation

Every wall mounted rangehood has two primary mounting

points and several secondary mounting points to rmly x the

rangehood in its place.

Please ensure that the holes for the two primary mounting
points are level before installation.

DANGER

Always switch off and disconnect power before
installing the rangehood. Failure to do so may
cause serious injury.

Primary mounting points*

Secondary mounting points*

*Note: Picture is for illustration
purposes only. The actual
product may have different
mounting points position.

Page 15

7. Installation

Step 1

Secure rangehood to the wall using only primary mounting
points. Check the level of the rangehood and adjust
accordingly if necessary. Once level, continue to secure
the rangehood via the secondary mounting points.

Step 2

Feed through aluminium exi duct from the outlet block to

the kitchen ceiling.

Step 3

Place ue covers on.

Step 4

Attach inside ue cover to the wall mounting bracket.

NOTE: Please make sure that all plastic protection on the

rangehood and lters are removed before use.

Page 16

7. Installation

BBQ Installation

When installing the rangehood over a BBQ , please be aware that the lid will obstruct the rangehoods
effectiveness to extract smoke, steam and odours. Where possible, remove the lid of the BBQ unit when
in use to allow for effective rangehood extraction.

Flexible Ducting / Ducting

Please do not crush or kink any of the ducting, this will reduce the air ow and may cause noise

throughout the system. Ducting needs to be kept taut at all times.

Back Draft Fins (Applicable to some models only)

Should your Back Draft Fins get stuck, this is not a warranty issue.

If installing Back Draft Fins, please ensure that you insert the Back Draft Fins onto the back draft base,
which is attached to the top of the motor outlet before installation.

NOTE: Please make sure when ducting is installed, that it does not impede the Back Draft Fins
from operation.

Flexible ducting

should t rmly

on the back draft
base / reducer

Back Draft Fins

Back Draft Base

Page 17

7. Installation

Installation Advice

• Never reduce ue diameter right next to the rangehood outlet tting, refer to gure 1.

• Never t reductions next to curves or bends in the installations. They must always be in straight
sections and as far as possible from the rangehood, refer to gure 2.

• Avoid exccessive reduction of the ue size, as this drastically reduces extraction capacity, refer to
gure 3.

• Use an air extraction ue which is as short as possible.

• You should not have more than one blend in the installation, refer to gure 4.

• If they are unavoidable, keep the curves or bends to a minimum. Try to keep the angles as open as
possible, refer to gure 5.

Page 18

7. Installation

Figure 1

Figure 3 Figure 4

Figure 2

Figure 5

Page 19

8. Maintenance

Condensation Information

The induction cooktop is designed to provide rapid heating, improved thermal efciency and greater heat

consistency. For some customers with an induction cooktop, condensation can form on their rangehood

lters while using their cooktop.

The induction cooktops’ heat source is contained in the conductive base of the pot. When compared with

a gas, electric or wok burner, the heat is not isolated or contained to one area and therefore gradually

rises up on all sides of the pot or frypan. This combination allows the rangehood lters to warm up slowly

and eliminate the formation of condensation. For induction cooktops, the immediate and contained heat

source can produce vapours rapidly. This prevents the lters from gradually warming up and increases the

chance of condensation forming.

There are many variables that can contribute to the condensation problem associated with induction
cooktops and rangehoods. Some of these variables include, but are not limited to:

• The Country or State you live in (example, WA versus VIC, and the variables in daily temperatures)

• The position of your home and kitchen (morning/afternoon sun)

• The quality of pots and cookware you are using

• Height of rangehood

• Rapid heating

• Ducting angle

• Filter size

If induction, vitro-ceramic hobs and the like are not used correctly, they can lead to problems with the
condensation of liquids due to temperature differences. After some time in use, these condensed liquids

can build up and possibly appear on the metal lters or the bottom of the rangehood.

For advice to avoid condensation, please refer to next page.

Page 20

8. Maintenance

User advice to avoid condensation in the rangehood:

• The rangehood should be switched on approx. 10 minutes prior to cooking and the delay shut
down timer set after cooking has stopped in order to clear the fumes held in the ue. These steps
will help clear the ue out fully.

• Do not cook at full power straight away, i.e. start on low or medium power for a while so that the

steel in the rangehood can warm up.

• Filters must be kept clean. For induction cooktop users, aim to clean lters at least every 10 days,
and replace the lters if their condition begins to deteriorate.

• There must be a constant ow of air into the cooking area to avoid the creation of a depression

which can affect the rate of aspiration.

• Follow the advice from the instructions for induction systems with regards to the condensation
effect.

• Suggested height for induction cooktop is approx. 750mm above the cooking surface.

Each person’s circumstances are different, but the vast majority of induction cooktop owners have

had no problems with condensation. However, it is important to understand that:

Neither the rangehood nor the induction cooktop are faulty. That in some circumstances, the
combination of the rangehood, the induction cooktop and the many variables within your home,

can lead to condensation forming on your rangehood lters. With a gas or standard electric

cooktop, you should not have any condensation.

Page 21

8. Maintenance

Troubleshooting

If the product does not work:

Before you contact the technical service department, make sure that the product is plugged in,
the electric fuse (on selected models) is in correctly and electric wiring is connected. (Fuses can be
purchased from your local electrical dealer or hardware store). Weak air suction may be caused by

back draft ns remaining closed. Do not take any action that will damage the product.

Check electric connection. Voltage of the

electric network should be between 220 -

240V, rangehood should be connected to

grounded plug and turned on.

Check motor switch. Please ensure that

there is power to the rangehood and the

rangehood is switched on.

Check lamp switch. Lamp switch should be

at on position.

Check metal lter. Metal lter should be

washed regularly, see lter cleaning.

Check lamps. Lamps should be rm.

Check outlet. Outlet should be open.

Check lamps and fuse. Make sure they are

not broken or faulty.

Please make sure there is no obstruction

in ducting or back draft ns.

Rangehood does not work X X

Light does not work X X X X

Rangehood air suction is weak X X X X

Rangehood does not direct air out
(through chimney)

Loud noise from the rangehood X

X X

Technical Specications

Model CL6272
Feeding Voltage 220-240V 50Hz
Lamp Power — Halogen (W) 2 x 35W (supplied)
Lamp Power — LED (W) 2 x 1.8-7W (optional)

Check the outlet, make sure it is not

blocked and you have the correct

diameter ducting installed.

Page 22

8. Maintenance

Calling the Technical Assistance Service Hotline

In the event that the failure is not due to the faults mentioned in Trouble Shooting, contact the
Technical Service 1300 829 066.

A service request will require the following information:

• The purchase date

• The rangehood model and motor type (eg. Isodrive 650)

• The rangehood serial number or batch number (this number is on a sticker inside the rangehood)

Faulty Installation

It is not the responsibility of Schweigen Home Appliances to rectify any incorrect installations. A
service call out fee will be charged for any Schweigen technician that attends a call, whereby

it’s established that the fault is due to an incorrect installation or non-manufacturing fault. Should

the appliance be installed in such a way that the service agent is unable to gain access to the
appliance, the person/s who own the premises or the appliance where the appliance resides — will
be responsible to provide access to the appliance at their expense.

Page 23

9. Specication

225

40

550550

670

284

Page 24

600

1200

10. Disclaimer

Under our policy of continuous product development, product specications may change without

notice. Prospective purchasers should therefore check with the retailer to ensure this publication
correctly describes the products being offered for sale. All information supplied is to be used for
general reference purposes only and is on the understanding that Schweigen Home Appliances will
not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon
such information. All pictures used in the guide are for illustrative purposes only.

The symbol on the product or its packaging indicates that it cannot
be treated as normal household waste. Take this product to your
nearest electrical and electronic equipment waste point for recycling.
By correctly disposing of this product, you will be helping to prevent
potentially negative consequences for the environment and public
health, which could arise if this product is not handled in the appropriate
way. For more details about the recycling of this product please contact
the authorities of your city or town, your local household waste service or
the store where you purchased the product.

Page 25

Notes

Page 26

Page 27

HOME APPLIANCES

Distributed by:

Unit 102/45 Gilby Road,
Mt Waverley 3149 Victoria.

1300 881 693 (EST)

www.schweigen.com.au
