SCHURTER UMT 0,315A Datasheet

Non Resettable Fuses

https://www.schurter.com /PG01_2

Surface Mount Fuse, 3 x 10.1 mm, Time-Lag T, 250 VAC, 125 VDC

IEC 60127-4 · 250 VAC · 125 VDC · Time-Lag T

UMT 250

Description

- High current range from 80 mA to 10 A

- High breaking capacity of 200 A @ 250 VAC (IEC)

- UL approval for 277 VAC and 250 VDC

Unique Selling Proposition

- Compact design

- Maximum breaking capacity at minimal footprint

- Suitable for pulse-shaped continuous currents

Standards

- IEC 60127-4/2

- UL 248-14

- CSA C22.2 no. 248.14

- Qualification according to AEC-Q200 on request

Applications

- Primary protection on SMD PCBs

- Medical equipment

- Battery protection

References

Packaging Details

Fuse Kit Fuse Kit UMT 250 / UMZ 250

Weblinks

pdf datasheet, html-datasheet, General Product Information, Packaging details, Approvals, CE declaration of conformity, RoHS, CHINA-RoHS, REACH, Distributor-Stock-Check, Detailed request for product, Microsite

Approvals

- Approval Reference Type: UMT 250

- VDE Certificate Number: 40013121

- UL File Number: E41599

Application Note Primary Protection in Equipmentwith further information on increased Pulse Strength and their test conditions according to inter-

national standards see Impulse Withstand Voltage

Technical Data

Rated Voltage 250 VAC, 125 VDC Rated current 0.08 - 10 A Breaking Capacity 35 A - 200 A Characteristic Time-Lag T Mounting PCB,SMT Admissible Ambient Air Temp. -55 °C to 125 °C Climatic Category 55/125/21 acc. to IEC 60068-1 Material: Housing Ceramic Material: Terminals Tin-Plated Copper Alloy Unit Weight 0.23 g Storage Conditions 0 °C to 60 °C, max. 70% r.h. Product Marking , Rated current, Voltage, Cha-

racteristic, Breaking Capacity

Soldering Methods Reflow, Wave

Soldering Profile

Solderability 245 °C / 3 sec acc. to IEC 60068-2-58,

Test Td

Resistance to Soldering Heat 260 °C / 40 sec acc. to IPC/JEDEC J-

STD-020D, 1 cycle

Life Test MIL-STD-202, Method 108A

(1000h @ 0.42*In @ 70°C)

Moisture Resistance Test MIL-STD-202, Method 106E

(50 cycles in a temp./mister chamber)

Terminal Strength MIL-STD-202, Method 211A

(Deflection of board 1 mm for 1 minute)

Mechanical Shock MIL-STD-202, Method 213B

(Shock 50g, half sine wave, 11 ms) Resistance to Solvents MIL-STD-202, Method 215A Flammability min. UL 94V-1

(acc. to EIA/IS-722, Test 4.12)

Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in General Product

Information

Fuses

1

UMT 250

10000

0

.1 10 1 100

Non Resettable Fuses

https://www.schurter.com /PG01_2

Dimension [mm]

10.1 mm

0.4

1.43

3

1.6

10.1

Pre-Arcing Time

Rated Current In 1.0 x In min. 1.25 x In min. 2.0 x In max. 10.0 x In min. 10.0 x In max.

0.08 A - 6.3 A - 60 min 120 s 10 ms 100 ms

8 A - 10 A 4 h - 120 s 10 ms 100 ms

Time-Current-Curves

Soldering pads

6.5

3.75

2

Time in Seconds

All Variants

Rated Cur-

80 mA 100 mA 125 mA

6.3 A

160 mA 200 mA 250 mA 315 mA 400 mA 500 mA 630 mA 800 mA 1 A

1.25 A

1.6 A 2 A

2.5 A

3.15 A 4 A 5 A

8 A

10 A

1000

100

10

1

0.1

0.01

0.001

0.0001

Current in Amperes

rent [A]

tage [VAC]

0.08 250 125 1) 1300 1030 200 0.022

0.1 250 125 1) 1300 870 200 0.04

0.125 250 125 1) 1000 700 200 0.055

Rated Vol

-

Rated Vol

tage [VDC]

-

Breaking Capacity

Voltage Drop

1.0 In max. [mV]

Voltage Drop

1.0 In typ. [mV]

Power Dissi

pation 1.25 In

max [mW]

-

Melting I²t

10.0 Intyp. [A²s]

Order Number

l

l l

3403.0155.11

3403.0155.24

3403.0156.11

3403.0156.24

3403.0157.11

3403.0157.24

█

2

Fuses

Non Resettable Fuses

https://www.schurter.com /PG01_2

UMT 250

Rated Cur-

rent [A]

Rated Vol tage [VAC]

-

Rated Vol

tage [VDC]

-

Breaking Capacity

Voltage Drop

1.0 In max. [mV]

Voltage Drop

1.0 In typ. [mV]

Power Dissi

pation 1.25 In

max [mW]

-

Melting I²t

10.0 Intyp.

0.16 250 125 1) 1000 540 240 0.057

0.2 250 125 1) 1000 460 500 0.092

0.25 250 125 1) 800 395 500 0.2

0.315 250 125 1) 750 343 500 0.27

0.4 250 125 1) 700 290 500 0.4

0.5 250 125 1) 600 257 500 0.54

0.63 250 125 1) 500 216 500 1.1

0.8 250 125 1) 400 190 500 1.4

1 250 125 2) 300 164 500 2.8

1.25 250 125 2) 300 138 1000 4.5

1.6 250 125 2) 300 124 1000 6.9

2 250 125 2) 300 102 1000 7.3

2.5 250 125 2) 300 90 1200 7.5

3.15 250 125 2) 300 95 1500 14

4 250 125 2) 300 78 2000 26

5 250 125 3) 300 76 2500 38

6.3 250 125 3) 300 71 3000 66

8 250 125 4) 220 72 3000 113

10 250 125 4) 220 73 3500 166

[A²s]

l

l l l

l l l l l l

l

l l l l

l l

3403.0175.11

3403.0175.24

3403.0176.11

3403.0176.24

Order Number

3403.0158.11

3403.0158.24

3403.0159.11

3403.0159.24

3403.0160.11

3403.0160.24

3403.0161.11

3403.0161.24

3403.0162.11

3403.0162.24

3403.0163.11

3403.0163.24

3403.0164.11

3403.0164.24

3403.0165.11

3403.0165.24

3403.0166.11

3403.0166.24

3403.0167.11

3403.0167.24

3403.0168.11

3403.0168.24

3403.0169.11

3403.0169.24

3403.0170.11

3403.0170.24

3403.0171.11

3403.0171.24

3403.0172.11

3403.0172.24

3403.0173.11

3403.0173.24

3403.0174.11

3403.0174.24

█

█ Most Popular.

Availability for all products can be searched real-time:https://www.schurter.com/en/Stock-Check/Stock-Check-SCHURTER

1) IEC: 200 A @ 250 VAC, p.f. ≥ 0.95 / 100 A @ 125 VDC

1) UL: 200 A @ 277 VAC / 100 A @ 125 VDC / 35 A @ 250 VDC / 200 A @ 63 VAC/DC

2) IEC: 200 A @ 250 VAC, p.f. ≥ 0.95 / 100 A @ 125 VDC

2) UL: 200 A @ 277 VAC / 100 A @ 125 VDC / 35 A @ 250 VDC / 200 A @ 63 VAC/DC

2) PSE: 100 A @ 250 VAC

3) IEC: 100 A @ 250 VAC, p.f. ≥ 0.95 / 100 A 125 VDC

3) UL: 100 A @ 250 VAC / 100 A @ 125 VDC / 35 A @ 250 VDC / 200 A @ 63 VAC/DC

3) PSE: 100 A @ 250 VAC

4) UL: 35 A @ 250 VAC / 35 A @ 125 VDC / 200 A @ 63 VAC/DC

4) PSE: 100 A @ 250 VAC

Fuses

3

UMT 250

Non Resettable Fuses

https://www.schurter.com /PG01_2

Rated Cur-

rent [A]

The 80 mA variant may not be to replace the 80 mA used with gold caps UMT (Au).

Rated Vol tage [VAC]

Packaging Unit

-

Rated Vol

tage [VDC]

-

Breaking Capacity

Voltage Drop

1.0 In max.

.xx = .11 Plastic Bag (100 pcs.)

[mV]

Voltage Drop

1.0 In typ. [mV]

.xx = .24 Blister Tape 33 cm Reel (2000 pcs.)

Power Dissi

pation 1.25 In

max [mW]

-

Melting I²t

10.0 Intyp. [A²s]

Order Number

01.10.2017

The specifications, descriptions and illustrations indicated in this document are based on current

4

Fuses

information. All content is subject to modifications and amendments. Information furnished is believed to be accurate and reliable. However, users should independently evaluate the suitability and test each product selected for their own applications.
