SCHUNK SRU-plus EDF 25, SRU-plus EDF 20, SRU-plus EDF 30, SRU-plus EDF 40, SRU-plus EDF 50 Assembly And Operating Manual
...
Pneumatic Swivel Unit plus with electrical
www.comoso.com
Translation of the original operating manual
feed-through
SRU-plus EDF 20 - 60
Assembly and Operating Manual
Superior Clamping and Gripping
Imprint
www.comoso.com
Imprint
Copyright:
This manual remains the copyrighted property of SCHUNK GmbH & Co. KG. It is solely
supplied to our customers and operators of our products and forms part of the product.
This documentation may not be duplicated or made accessible to third parties, in particular competitive companies,
without our prior permission.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 0389443
Edition: 01.05 |16/01/2014|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear customer,
congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have opted for
the highest precision, top quality and best service.
You are going to increase the process reliability of your production and achieve best
machining results – to the customer's complete satisfaction.
SCHUNK products are inspiring.
Our detailed assembly and operation manual will support you.
Do you have further questions? You may contact us at any time – even after purchase.
Kindest Regards
Yours SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. +49-7133-103-0
Fax +49-7133-103-2399
info@de.schunk.com
www.schunk.com
2 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Table of contents
Table of contents
1 About this manual .................................................................................................... 5
1.1 Warnings ................................................................................................................... 5
2 Basic safety notes .................................................................................................... 9
3 Warranty ................................................................................................................. 13
4 Scope of delivery ..................................................................................................... 13
5 Technical data ......................................................................................................... 14
6 Assembly ................................................................................................................. 15
1.1.1 Key words ...................................................................................................... 5
1.1.2 Symbols ......................................................................................................... 5
1.2 Variants ..................................................................................................................... 6
1.3 Applicable documents .............................................................................................. 8
2.1 Intended use ............................................................................................................. 9
2.2 Not intended use ...................................................................................................... 9
2.3 Environmental and operating conditions ................................................................. 9
2.4 Product safety......................................................................................................... 10
2.4.1 Protective equipment ................................................................................. 10
2.4.2 Constructional changes, attachments, or modifications ............................ 10
2.5 Personnel qualification ........................................................................................... 10
2.6 Using personal protective equipment .................................................................... 11
2.7 Notes on particular risks ......................................................................................... 11
6.1 Mechanical connection .......................................................................................... 15
6.1.1 Assembly of the unit on an adapter plate (robot-side) .............................. 15
6.1.2 Assembly of the unit on an adapter plate (tool-side) ................................. 16
6.2 Air connection ........................................................................................................ 17
6.3 Adjusting the limit positions ................................................................................... 20
6.3.1 Basic setting 0° and 180° ............................................................................. 20
6.3.2 Shock absorber stroke fine adjustment 0° and 180° .................................. 21
6.3.3 Adjusting the center position (variant M) .................................................. 23
6.3.4 Adjusting the center position (variant VM) ................................................ 24
6.4 Sensors .................................................................................................................... 25
6.4.1 Magnetic switch MMS 22 ........................................................................... 26
6.4.2 Inductive proximity switch IN 80 ................................................................ 26
6.5 Cable assignments .................................................................................................. 30
6.5.1 Connection overview, SRU-plus 20-60 EDF ................................................ 30
6.5.2 Pin allocation for SRU-plus 20-60 EDF ........................................................ 31
6.5.3 Connection overview, SRU-plus 20-35 Version D ....................................... 32
01.05|SRU-plus EDF 20 - 60|en
3
www.comoso.com
Table of contents
6.5.4 Pin allocation for SRU-plus 20-60 EDF Version D ........................................ 33
7 Function and handling ............................................................................................. 35
7.1 Base unit ................................................................................................................. 35
7.2 Center position (variant M) .................................................................................... 36
7.3 Locked center position (variant VM) ...................................................................... 37
7.3.1 Mounting the separating sleeve ................................................................. 39
7.3.2 Version VM with separate piston chambers .............................................. 40
8 Troubleshooting ...................................................................................................... 43
8.1 Module does not move? ........................................................................................ 43
8.2 The module does not travel through the entire stroke? ....................................... 43
8.3 Torque drops? ........................................................................................................ 44
8.4 The module rotates abruptly? ................................................................................ 44
8.5 Module does not move smoothly to the limit positions? ...................................... 44
9 Maintenance and care ............................................................................................. 45
9.1 Notes....................................................................................................................... 45
9.1.1 Maintenance and lubrication interval for EDF ............................................ 45
9.2 Lubricants/Lubrication points (basic lubrication) ................................................. 46
9.3 Dismantling the module ......................................................................................... 46
9.3.1 Dismantling the rotary actuator ................................................................. 46
9.3.2 Disassembling the center position (variant M and VM) ............................. 47
9.3.3 Replacing a shock absorber ........................................................................ 47
9.3.4 Shock absorber types and shock absorber overlap (h) .............................. 52
9.3.5 Servicing and assembling the module ........................................................ 54
9.3.6 Maintaining the module ............................................................................. 54
10 Assembly drawing ................................................................................................... 55
10.1 Basic components and media feed-through .......................................................... 56
10.2 EDF with distributor plate 20-60 ........................................................................... 59
11 Sealing kit ................................................................................................................ 64
12 Accessory pack ........................................................................................................ 65
13 Wear parts SRU-plus 20 - 60 .................................................................................... 66
14 Translation of original declaration of incorporation ................................................. 68
4 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
About this manual
About this manual
1
This instruction is an integral part of the product and contains important information for a safe and proper assembly, commissioning, operation, maintenance and help for easier trouble shooting.
Before using the product, read and note the instructions, especially the chapter "Basic safety notes".
1.1
Warnings
The following key words and symbols are used to highlight dangers.
1.1.1
Key words
DANGER Dangers for persons.
Non-compliance will inevitably cause irreversible injury or death.
WARNING Dangers for persons.
Non-compliance may cause irreversible injury or death.
CAUTION Dangers for persons.
Non-observance may cause minor injuries.
NOTICE Information about avoiding material damage
1.1.2
Symbols
Warning about a danger point
Warning about hand injuries
General mandatory sign to prevent material damage
01.05|SRU-plus EDF 20 - 60|en
5
About this manual
www.comoso.com
1.2
Variants
This operating manual applies for the following variations
• SRU-plus
• SRU-plus Rotating angle 90°
• SRU-plus Rotating angle 180°
• SRU-plus End position adjustability 3°
• SRU-plus End position adjustability 90°
• SRU-plus With media feed-through
• SRU-plus With pneumatic center positioning
• SRU-plus With locked center position
6 01.05|SRU-plus EDF 20 - 60|en
Distributor plate (version
www.comoso.com
About this manual
Fig. 1 Type designation
Fig. 2 Overview of SRU-plus EDF
1 SRU-plus with MDF 4 Sensor holder with sen-
2 EDF flange (standard) 5 Monitoring with
3 EDF flange (version "D") 6 Monitoring with fixed
sor
movable cam
cam
7 Distributor plate (stan-
dard)
8
"D")
01.05|SRU-plus EDF 20 - 60|en
7
About this manual
www.comoso.com
1.3
Applicable documents
• SCHUNK catalog Rotary modules
• Assembly and Operating manuals of the accessories
• General terms of business
The documents listed here, can be downloaded on our homepage
www.schunk.com
8 01.05|SRU-plus EDF 20 - 60|en
Basic safety notes
www.comoso.com
Basic safety notes
2
Intended use
2.1
The product was designed to swivel permissible attachments or
workpieces.
For use with the robot for applications with endless movement
and feed-through of electrical signals and pneumatics
The product is intended for installation in a machine/system. The
requirements of the applicable guidelines must be observed and
complied with.
The product may be used only in the context of its defined applica-
tion parameters ( 5
, Page 14).
The product is designed for industrial use.
To use this unit as intended, it is also essential to observe the
technical data and installation and operation notes in this manual
and to comply with the maintenance intervals.
2.2
Not intended use
Use which is not specified as an intended use is for instance when
the product is for example used as a pressing tool, stamping tool,
lifting tool, guide for tools, cutting tool, tensioning mean, boring
tool.
2.3
Environmental and operating conditions
• The module may be used only in the context of its defined ap-
plication parameters. ( 5
, Page 14)
• Make sure that the module is a sufficient size for the application.
• Make sure that the environment is clean and the ambient temperature corresponds to the specifications per the catalog. Ob-
serve Maintenance and lubrication intervals ( 9
, Page 45).
• Make sure that the environment is free from splash water and
vapors as well as from abrasive or processing dust. Exceptions
are modules that are designed specially for contaminated environments
01.05|SRU-plus EDF 20 - 60|en
9
Basic safety notes
www.comoso.com
2.4
Product safety
Dangers arise from the module, if e.g.:
• the module is not used in accordance with its intended purpose.
• the module is not installed or maintained properly.
• the safety and installation notes are not observed.
Avoid any manner of working that may interfere with the function
and operational safety of the module.
2.4.1
2.4.2
NOTE
More information is contained in the relevant chapters.
Protective equipment
Provide protective equipment per EC Machinery Directive.
Constructional changes, attachments, or modifications
Additional drill holes, threads, or attachments that are not offered
as accessories by SCHUNK may be attached only with permission
Wear protective equipment.
of SCHUNK.
2.5
Personnel qualification
The assembly, initial commissioning, maintenance, and repair of
the product may be performed only by trained specialist personnel. Every person called upon by the operator to work on the
product must have read and understood the complete assembly
and operating manual, especially the chapter "Basic safety notes"
( 2
, Page 9). This applies particularly to personnel only used oc-
casionally, such as maintenance personnel.
10 01.05|SRU-plus EDF 20 - 60|en
Basic safety notes
www.comoso.com
2.6
Using personal protective equipment
When using this product, observe the relevant industrial safety
regulations and use the personal protective equipment (PPE) required!
• Use protective gloves, safety shoes and safety goggles.
• Observe safe distances.
• Minimal safety requirements for the use of equipment.
Notes on particular risks
2.7
Generally valid:
• Remove the energy supplies before installation, modification,
maintenance, or adjustment work.
• Make sure that no residual energy remains in the system.
• Do not move parts by hand when the energy supply is connected.
• Do not reach into the open mechanism or the movement area
of the unit.
• Perform maintenance, modifications, and additions outside the
danger zone.
• Secure the product during all operations against uncontrolled
activation.
• Take a precautionary approach by maintenance and disassembly.
• Only specially trained staff should disassemble the product.
01.05|SRU-plus EDF 20 - 60|en
11
Basic safety notes
www.comoso.com
WARNING
Risk of injury from objects falling and being ejected
• The danger zone must be surrounded by a safety fence during
operation.
WARNING
Risk of injury when the machine/system moves unexpectedly
due to failure of the energy supply or malfunction of the controller.
WARNING
Risk of injury due to rotating components!
Avoidance: The danger zone must be surrounded by a safety
fence during operation.
WARNING
Risk of injury due to loosened parts and destruction of the swivelling unit due to damaged shock absorbers!
Avoidance: Regular inspection of the individual components on
wear and damage.
WARNING
Note that suitable emergency-off strategies (e.g. controlled shut
down) and restarting strategies (e.g. pressure build-up valves,
appropriate valve switching sequences) are needed for all
pneumatic actuators.
Cutting off the pressure in an uncontrolled manner could lead to
undefined states and behavior.
12 01.05|SRU-plus EDF 20 - 60|en
4
www.comoso.com
Warranty / Scope of delivery
Warranty
3
The warranty is valid for 24 months from the delivery date to the
production facility under the following conditions:
• Intended use in 1-shift operation
• Observe the mandatory maintenance and lubrication intervals
• Observe the environmental and operating conditions
Parts touching the work piece and wear parts are not part of the
warranty.
Scope of delivery
The scope of delivery includes:
• Electrical feed-through SRU-plus in the ordered model.
• Accessory pack
01.05|SRU-plus EDF 20 - 60|en
13
www.comoso.com
Technical data
Technical data
5
Basical data
Designation Value
Noise emission [dB(A)] ≤70
Pressure medium Compressed air, compressed air quality according to
ISO 8573-1:7 4 4
Min. pressure [bar] See data sheet
Max. pressure [bar] See data sheet
Basic data of the EDF
Designation Value
Ambient temperature
Min. [°C]
Max. [°C]
5
60
Connection possibility Drive side
• 4x/8x sensors M8 (3-pin)
• 2x/1x sensors M8 (4-pin)
Screw-on side
• Feed line M16 (12-pin)
U max. [V] 24
I max per wire [A] 1
Transmission rate for profibus Max. 1.5 Mbaud
Further technical data can be found in the catalog data sheet.
The most recent version applies.
14 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly
Assembly
6
Mechanical connection
6.1
6.1.1
Assembly of the unit on an adapter plate (robot-side)
Fig. 3 Mounting of the SRU-plus with EDF-plus at the adapter plate
1 Use thread on the base side of the rotary actuator SRU-plus.
2 The centering sleeves from the accessory pack have to be used
for positioning the unit.
Mounting material (*provided by customer / ** contained in the accessory pack)
Item Designation 20 25 30 35 40 50 60
1 * Screw M8 M8 M8 M8 M10 M12 M12
2 ** Centering
Ø12 Ø12 Ø12 Ø12 Ø14 Ø16 Ø16
sleeve
3 ** Adapter plate
01.05|SRU-plus EDF 20 - 60|en
15
Assembly
1
3 1
2
4
2
www.comoso.com
6.1.2
Assembly of the unit on an adapter plate (tool-side)
Fig. 4 Connections at the rotating distributor
1 In case the direct air acceptance is used, the
set-screws (2) have to be removed and the hose connections
have to be replaced by
seal plugs (accessory pack) at the lateral
air connections (1).
2 Place O-rings Ø4.5x1 (accessory pack) into the counterbores
(2).
3 Two centering sleeves (accessory pack) have to be used
for positioning the unit. Position the adapter plate
with the two centering sleeves (3) and fasten with four
screws (4).
The screws are not included in the scope of delivery.
Thread size of the four mounting screws
EDF 20-25 EDF 35 EDF 40 EDF 50-60
M5 M6 M8 M10
16 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly
• The electronics can now be connected.
6.2
Air connection
DANGER
Danger of explosion in explosion risk areas!
• Follow the instructions in supplementary sheet "Installation
and operating instructions - EX" for modules in explosionresistant versions (EX)!
WARNING
Risk of injury when the machine/system moves unexpectedly!
Remove the energy supplies.
Make sure that no residual energy remains in the system.
NOTICE
Observe the requirements for the air supply.
( 5
, Page 14) "Technical Data"
• Only open the air connections required.
• Seal air connections not required using
the locking screws from the enclosed pack.
• For hose-free direct connections use the two O-rings from the
enclosed pack.
01.05|SRU-plus EDF 20 - 60|en
17
Assembly
1
2
3
4
6
5
7
8
www.comoso.com
Fig. 5 compressed air connections A, B, C and D
Item Designation Description Function
1 b Hose-free
2 a Swiveling 0° -90° / 0° - 180°
direct connection
Swiveling 90° - 0° / 180° - 0°
3 d Approach center position (M)
4 c
Extend locking piston (VM)
5 C Hose connection Approach center position (M)
6 D
Extend locking piston (VM)
7 A Swiveling 0° -90° / 0° - 180°
8 B Swiveling 90° - 0° / 180° - 0°
Pay attention to the following table when using throttles.
18 01.05|SRU-plus EDF 20 - 60|en
(
The operating pressure of the lock must be between 4 and 6 bar.
Air connection for
variants with
Air connection for
variants with
locked
Variant with
www.comoso.com
Assembly
center position (M)
center position (VM)
1 The air connections labeled "C" and "D" must be pressurized
together (with intersection).
NOTICE
In the variant with locked center position, this can cause
malfunctions!
• Do not install an exhaust air throttle.
• Observe table
NOTE
1 In addition, air connections that are marked "C" and "D"
are available ( 6.2
6.2, Page 19).
, Page 18).
2 The lock can be engaged smoothly using a supply
air throttle. Table ( 6.2
, Page 19)
1 Connections marked with numbers are provided for feed-
media feed-through
through of the media on the pinion (19) and the flange (20) --FEHLENDER LINK ---.
Use of throttles
Module variant A B C D
Without center position
With center position
(M)
With locked center
position (VM)
With locked
center position (VM)
and separate
main piston chambers
Exhaust air
throttle
Exhaust air
throttle
Exhaust air
throttle
Exhaust air
throttle
- -
Supply air
throttle
Supply air throttle Supply air throttle Supply air
throttle
A1
Exhaust
air
throttle
A2
Supply
air
throttle
B1
Exhaust
air
throttle
B2
Supply
air
throttle
Supply air
throttle
Supply air
throttle
Supply air
throttle
Supply air
throttle
01.05|SRU-plus EDF 20 - 60|en
19
Assembly
Basic setting 0°
www.comoso.com
6.3
Adjusting the limit positions
6.3.1
Basic setting 0° and 180°
Fig. 6 Basic setting
1 Stop A 2 Hexagon socket
screw
3 Stop B
1 Unscrew the screw (2) with hexagon socket wrench (SRU-
plus20-40:
4; SRU-plus50-60: 5) about one rotation.
2 Actuate air connection "B". The module swivels to stop A (1).
3 Set the desired end position by turning stop A (1).
(For SRU-plus 50-60; reduce pressure before adjusting)
4 Check the setting: Ventilate air connection "B" and actuate it
again.Adjust the end positions if necessary.
( 7.1
, Page 35)Base unit
NOTICE
Components can come loose if the limit positions are not adjusted properly:
• Only trained staff may perform these actions.
• Use a
apply to the hexagon screw on the limit stop cover.
19 (SRU-plus 20-25) or 32 (SRU-plus 30-60) and
20 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Basic setting 180°
Assembly
1 Ventilate air connection "B" and actuate air connection "A".
The module swivels to stop B (3).
2 Set the desired end position by twisting stop B (3). (For the
SRU-plus 50-60, reduce pressure before adjusting)
3 Check the setting: ventilate air connection "A" and actuate it
again. Adjust the end positions if necessary.
4 Tighten screws (2) fully.
(SRU-plus 20-40: 10 Nm; SRU-plus50-60: 24 Nm)
5 Swivel repeatedly to test the limit position setting.
6.3.2
Shock absorber stroke fine adjustment 0° and 180°
NOTICE
The module can leak if the maximum adjustment range is exceeded:
• Note the maximum adjustment range of the fine adjustment.
Size 20 25 30 35 40 50 60
Max. adjustment range [mm] 7.5 7.5 7.5 6.5 6.5 10.5 10.5
Fig. 7 Shock absorber fine adjustment
1 Stop A 2 Stop B
01.05|SRU-plus EDF 20 - 60|en
21
Assembly
ing for end position
ing for end position
www.comoso.com
Setting the dampen-
1 Remove the cover (5).
2 Secure stop A (1) with
0°
(SRU-plus 30-60) and loosen the nut (3) on the stop pin with
(4) A with
3 Secure A (1) with
14 (SRU-plus 20-25) or 24 (SRU-plus 30-60).
19 (SRU-plus 20-25) or 32
19 (SRU-plus 20-25) or 32
(SRU-plus 30-60) and screw out the stop pin A (4) with
hexagon socket wrench
(SRU-plus 30-40) or
5 (SRU-plus 20-25) or 6
8 (SRU-plus 50-60).
One turn shortens the dampening stroke by 1.5 mm.
4 Test the dampening effect by rotating the loaded
module. (The end positions must be approached gently.)
5 Secure stop pin A (5/4) with the hexagon socket wrench
(SRU-plus 20-25) or
(SRU-plus 30-40) or
6
8
(SRU-plus 50-60) and apply the nut (3) with
(SRU-plus 20-25) or
6 Secure stop A (1) with
(SRU-plus 30-60) and tighten the nut with
(SRU-plus 20-25) or
24 (SRU-plus 30-60).
19 (SRU-plus 20-25) or 32
14
24 (SRU-plus 30-60).
5
14
Setting the dampen-
180°
7 Mount the cover (6) again.
1 Remove the cover (6).
2 Secure stop B with
19 (SRU-plus 20-25) or 32 (SRU-
plus 30-60) and loosen the nut (3) at the stop pin (5/4) B with
14 (SRU-plus 20-25) or 24 (SRU-plus 30-60).
3 Secure stop B with
19 (SRU-plus 20-25) or 32
(SRU-plus 30-60) and screw out stop pin B (5/4) with
hexagon socket wrench
(SRU-plus 30-40) or
5 (SRU-plus 20-25) or 6
8 (SRU-plus 50-60).
One turn shortens the dampening stroke by 1.5 mm.
4 Test the dampening effect by rotating the loaded
module. (The end positions must be approached gently.)
5 Secure stop pin B (5/4) with the hexagon socket wrench
(SRU-plus 20-25) or
(SRU-plus 50-60) and apply the nut (3) with
(SRU-plus 20-25) or
6 (SRU-plus 30-40) or 8
14
24 (SRU-plus 30-60).
5
22 01.05|SRU-plus EDF 20 - 60|en
6 Secure stop B with
(SRU-plus 30-60) and tighten the nut with
(SRU-plus 20-25) or
19 (SRU-plus 20-25) or 32
14
24 (SRU-plus 30-60).
7 Mount the cover (6) again.
www.comoso.com
Assembly
6.3.3
Adjusting the center position (variant M)
Fig. 8 Adjusting the center position
1 Stop B 3 Interior
5 Limiting sleeve
screw
2 Stop A 4 Stop C 6 Stop D
1 Loosen the screw (3) about one turn with hexagon socket
wrench (SRU-plus 20-40:
4; SRU-plus 50-60: 5).
2 Unscrew stops C (4) and D (6) to the
limit sleeve (5).
3 Actuate air connections "C" and "D".
The module swivels to about 90° and has about 6° of
play in this position.
4 Turn the pinion clockwise and press it
against stop C (4).
5 Turn stop C (4) to the required center position.
6 Turn stop D (6) until the pinion no longer has play in the cen-
ter position.
7 Re-tighten the screw (3) again (SRU-plus 20-40: 10 Nm,
SRU-plus 50-60: 24 Nm).
8 Swivel repeatedly to test the center position setting.
01.05|SRU-plus EDF 20 - 60|en
23
Assembly
www.comoso.com
6.3.4
Adjusting the center position (variant VM)
NOTICE
The lock could be damaged!
• Pay attention to the description of ( 7.3
Depending on the start-up direction of (stop A (2) or stop B (1)),
the center position can be set the same or differently.
, Page 37).
Fig. 9 Adjusting of the center position locking
1 Stop B 5 Stop C
2 Stop A 6 Limiting sleeve
3 Bore hole for
hexagon socket wrench
4 Internal screw 7 Stop D
24 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly
1 Ventilate all air connections.
2 Loosen the screw (4) about one turn with hexagon socket
wrench (SRU-plus 20-40:
4; SRU-plus 50-60: 5).
3 Actuate air connection "B". The module swivels to
stop A (2).
4 Ventilate air connection "B" and pressurize air
connection "C". Stop C (5) locks.
5 Actuate air connection "A". The module swivels to
stop C (5) (basic setting 90°).
6 Turn stop C (5) to the required center position.
7 Ventilate air connection "C". The module swivels to
stop B (1).
8 Ventilate air connection "A" and actuate
air connection "D". Stop D (7) locks.
9 Actuate air connection "B". The module swivels to
stop D (7) (basic setting 90°).
10 Turn stop D (7) to the required center position.
11 Re-tighten the screw (4) again (SRU-plus 20-40: 10 Nm,
SRU-plus 50-60: 24 Nm).
12 Swivel repeatedly to test the center position setting. ( 7.3
,
Page 38)
6.4
Sensors
The module is prepared for the use of the sensors IN 80 and MMS
22.
1 For modules with an explosion-protected design (EX), the sup-
plementary sheet "Installation and operation notes - EX"
included in delivery must also be observed.
2 If you require further information on sensor operation, con-
tact your SCHUNK contact person or download information
from our homepage.
3 Technical data of the sensors are contained in the data sheets
(included in the scope of delivery).
01.05|SRU-plus EDF 20 - 60|en
25
Assembly
We recommend the use of four magnetic switches to monitor the
www.comoso.com
6.4.1
Magnetic switch MMS 22
The magnetic switches can be mounted via four grooves in the
module housing. The setting of the switching positions
must be done as follows:
1 Turn the unit to the required swivel angle.
2 Push the magnetic switch into the groove.
3 Move the magnetic switch along the groove until it actuates.
4 Secure the magnetic switch. (see enclosed data sheet)
5 Check the switch position of the magnetic switch by swiveling
the module repeatedly.
NOTE
locked center position:
• One sensor each to monitor the two limit positions
• For monitoring approach to the center position from
end position 0°
• For monitoring approach to the center position from
6.4.2
end position 180°
Inductive proximity switch IN 80
Fig. 10 Connection example for IN 80
1 brown 2 black 3 blue
The inductive proximity switches used are equipped with reverse
polarity protection and are short-circuit-proof.
Make sure that you handle the proximity switches properly:
26 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly
• Do not pull on the cable.
• Do not allow the sensor to dangle from the cable.
• Do not overtighten the mounting screw or mounting clip.
• Please adhere to the permitted bend radius of the cable.
(☞ catalog)
• Avoid contact of the proximity switches with hard objects and
with chemicals, in particular nitric acid, chromic acid and sulphuric acid.
The inductive proximity switches are electronic components,
which can react sensitively to high-frequency interference or electromagnetic fields.
• Check to make sure that the cable is fastened and installed correctly. Provide for sufficient clearance to sources of
high-frequency interference and their supply cables.
• Parallel switching of several sensor outputs of the same type
(npn, pnp) is permissible, but does not increase the permissible
load current.
• Note that the leakage current of the individual sensors
(ca. 2 mA) is cumulative.
01.05|SRU-plus EDF 20 - 60|en
27
Assembly
92 / 99
92 / 99
93 / 100
94-1
94-2
91
90
98
1
2
3
4
5
6
7
8
9/10
11/12
13
Assembly of the
www.comoso.com
proximity switches
NOTICE
When swiveling, ensure that the switch cams do not collide with
the sensors.
The proximity switches can be secured in three different
positions:
• Stop A
• Center position
• Stop B
The following assembly steps are the same for all three
mounting positions:
Fig. 11
1 Stop A 2 Center position 3 Stop B
28 01.05|SRU-plus EDF 20 - 60|en
1 Remove the corresponding cover disk on the housing of the
SRU-plus.
2 Secure the bracket (5) in the countersink provided for it in the
housing, using a hexagon socket screw (8).
Caution: Only tighten the hexagon socket screw (7) far enough
that the clamping sleeve (6) can still be turned.
3 Turn the pinion counter-clockwise to the corresponding
stop/center position.
Adjusting the
www.comoso.com
Assembly
Note
The following steps 4 and 5 only apply for washers with mov-
able cams.
4 Undo set-screws (10 and 12) of the control cams (9 and 13).
Move the switch cams (9 and 11) until they are positioned to
the same height as the corresponding clamping sleeve.
5 Turn the pinion back to the output position and secure the
switch cams
(9 and 11).
1 Turn the pinion back counter-clockwise to the corresponding
switching gap
stop / center position. (possibly supported by
actuating the corresponding air connection)
2 Push the proximity switch into the clamping sleeve (6)
as far as possible, and unscrew the sleeve until the
proximity switch responds.
3 Tighten the hexagon socket screw (7) until the clamping sleeve
(6) no longer turns. The hexagon socket screw (7) grips the
clamping sleeve (6) and simultaneously secures the bracket (5)
on the rotary actuator.
4 The switching distance has now been set: Tighten the clamp-
ing screws (4)
until the proximity switch is secured.
5 To change the proximity switches, loosen the clamping screws
(4),
replace the proximity switches and tighten the clamping
screws (4) again.
01.05|SRU-plus EDF 20 - 60|en
29
Assembly
www.comoso.com
6.5
Cable assignments
6.5.1
Fig. 12 SRH-plus 20-35 standard
Connection overview, SRU-plus 20-60 EDF
Fig. 13 SRH-plus 40-60 standard
Bending radius
Minimum bending radius for constant movement:
10 x cable diameter
30 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly
6.5.2
Pin allocation for SRU-plus 20-60 EDF
Fig. 14 Pin allocation, connection plug M16
Pin
Connec-
Pin sensor connection
EDF for SRU-plus 20-35 EDF for SRU-plus 40-60
tion plug
M16
A Switching signal, sensor 3 Switching signal, sensor 3
B GND (common) GND (common)
C Switching signal, sensor 2 Switching signal, sensor 2
D Switching signal, sensor 4 Switching signal, sensor 4
E Switching signal, sensor 1 Switching signal, sensor 1
F Switching signal 1, sensor 5 Switching signal, sensor 5
G Switching signal 2, sensor 5 Switching signal, sensor 6
H +24 V (common) +24 V (common)
J Switching signal 1, sensor 6 Switching signal, sensor 7
K Switching signal 2, sensor 6 Switching signal 1, sensor
9
L - not connected - Switching signal 2, sensor
9
M - not connected - Switching signal, sensor 8
Shielding SHD SHD
01.05|SRU-plus EDF 20 - 60|en
31
Assembly
www.comoso.com
NOTE
The allocation of the housing receptacles on the output side for
connecting sensors can be found in the documentation of the
6.5.3
Schunk sensors.
Connection overview, SRU-plus 20-35 Version D
Fig. 15 SRH-plus 20-35 Version "D"
Fig. 16 SRH-plus 40-60 Version "D"
Bending radius
Minimum bending radius for constant movement:
10 x cable diameter
32 01.05|SRU-plus EDF 20 - 60|en
Switching signal, sensor
Switching signal, sensor
Switching signal, sensor
Switching signal, sensor
www.comoso.com
Assembly
Fig. 17
Pin
Connection
plug
6.5.4
Pin allocation for SRU-plus 20-60 EDF Version D
Pin sensor connection, version D
EDF for SRU-plus 20-35 EDF for SRU-plus 40-60
Shielding SHD SHD
1 A +24 V (common) C +24 V (common)
2
Switching signal 1, sensor 9
1
3 GND (common) GND (common)
4
Switching signal 2, sensor 9
4
1 B +24 V (common) D / E Switching signal,
sensor 1
2
+24 V (common) +24 V (common)
2
3 GND (common) Switching signal,
sensor 2
4
3
Switching signal,
sensor 3
5 Switching signal,
sensor 4
Switching signal, sensor 5
Switching signal, sensor 6
Switching signal, sensor 7
Switching signal, sensor 8
01.05|SRU-plus EDF 20 - 60|en
33
Assembly
www.comoso.com
Pin
Con-
Pin sensor connection, version D
EDF for SRU-plus 20-35 EDF for SRU-plus 40-60
nection
plug
6 - not connected - - not connected -
7 GND (common) GND (common)
8 - not connected - - not connected -
NOTE
The allocation of the housing receptacles on the output side for
connecting sensors can be found in the documentation of the
Schunk sensors.
34 01.05|SRU-plus EDF 20 - 60|en
Basic setting 0°
www.comoso.com
Basic setting 180°
Function and handling
7
Base unit
7.1
1 Pressurize air connection A.
The pinion turns clockwise up to the stop B.
Function and handling
1 Pressurize air connection B.
The pinion turns back to the stop A.
Setting ranges
of the Variants
Fig. 18 end position adjustability 3°
Fig. 19 end position adjustability 90°
Fig. 20 Variant swivel angle 90°
01.05|SRU-plus EDF 20 - 60|en
35
Function and handling
Basic setting 90°
Circuit diagram
www.comoso.com
7.2
Center position (variant M)
control (example)
Fig. 21 Position of the air connections
1 Actuate air connection C and D together.
The pinion rotates on the center position.
The center position can be adjusted by ± 3°. By design, overshooting can occur in the center position.
Fig. 22 Actuation with one 5/3 and one 3/2 directional control valve
36 01.05|SRU-plus EDF 20 - 60|en
NOTICE
Before actuating C and D, connections A and B must be completely
www.comoso.com
Function and handling
7.3
Locked center position (variant VM)
WARNING
Risk of injury is the machine/system moves
unexpectedly!
In an EMERGENCY STOP situation, the center position
lock can come loose.
• Swivel the module to one of the limit positions to restart.
The pistons can be damaged if incorrectly controlled.
• The locking pistons must be free to extent without striking the
drive pistons.
• Note the circuit diagram ( 7.3
, Page 38).
If this option is selected, the locking pistons can
stop the rotating motion in the center position and
enable it again. The center position can be adjusted by ± 3°.
Move from the 0° position to the center position
1 Extent locking piston C.
2 Actuate connection A.
Move from the 180° position to the center position
1 Extent locking piston D.
2 Actuate air connection B.
NOTE
ventilated.
01.05|SRU-plus EDF 20 - 60|en
37
Function and handling
Circuit diagram
www.comoso.com
control (example)
Fig. 23 Actuation with two 5/3 directional control valves
38 01.05|SRU-plus EDF 20 - 60|en
B1
A1
A2
B2
www.comoso.com
Function and handling
7.3.1
Mounting the separating sleeve
NOTICE
The O-ring in the groove could be damaged!
• Screw the separating sleeve (2) very carefully until the
end of the threads.
Fig. 24 Mounting the separating sleeve
1 Unscrew the locking screws 2x (1).
2 Screw the separating sleeve 2x (2) from the
3 Mount hose connections A1, A2, B1 and B2.
4 Control SRU-plus as shown in ( 7.3.2
accessory pack into hose connection holes A and B until the
end of the threads. (If necessary, turn the set screw (3)
back a little.)
Position of the hose connections ( 7.3.2
, Page 40)
, Page 41).
01.05|SRU-plus EDF 20 - 60|en
39
Function and handling
B
A
www.comoso.com
7.3.2
Version VM with separate piston chambers
WARNING
Risk of injury is the machine/system moves
unexpectedly!
In an EMERGENCY STOP situation, the center position
lock can come loose.
WARNING
Risk of injury is the machine/system moves
unexpectedly!
When ventilating the drive pistons, the module can
start to rotate unintentionally (e.g. horizontal rotating
axes loaded on one side).
• Screw the separating sleeves from the accessory pack
into air connections A1 and B1. ( 7.3.1
linder chambers
of connections A and B can then be activated
separately.
, Page 39)The two cy-
40 01.05|SRU-plus EDF 20 - 60|en
Fig. 25 Position of the air connections
Wiring diagram for
www.comoso.com
holding the load at 0°
Function and handling
1 Actuate B1 until C is locked.
Fig. 26 Holding the load at 0°
WARNING
Risk of injury is the machine/system moves
unexpectedly!
When installing the SRU-plus horizontally, secure locking
is not guaranteed during the ventilation stage when a pivoting
movement is being performed from 9 o'clock (0°) via 6 o'clock
(90°)
to 3 o'clock (180°).
• Screw the separating sleeves from the accessory pack
into air connections A1 and B1. ( 7.3.1
, Page 39)The two cy-
linder chambers
of connections A and B can then be activated
separately. (for purposes of holding torque)
• Control ( 7.3.2
, Page 41)
The following actuation is advantageous for modules from size 35
and larger depending on the application:
A brief ventilation ( 7.3.2
, Page 41) while the lock is being re-
leased ensures smooth travel to the limit position.
01.05|SRU-plus EDF 20 - 60|en
41
Function and handling
www.comoso.com
Exhaust air throttles can also be used for
connections A1 and B1 by installing separating sleeves. A2 and B2
then remain unthrottled.
42 01.05|SRU-plus EDF 20 - 60|en
Proximity switch defective or set
order to SCHUNK. Ensure that the module was only used
y
Components have become loose
www.comoso.com
Troubleshooting
8
Module does not move?
8.1
Possible cause Corrective action
Pressure drops below minimum. Check the air supply. ( 6.2, Page 17)
Compressed air lines switched Check compressed air lines.
Repair the proximity switch.
incorrect.
Troubleshooting
Unused air connections not
closed.
Component is broken, e.g.
Close the unused air connections.
( 6.2, Page 17)
Replace component or send the module with a repair
through overloading
within its defined application parameters. ( 5, Pa-
ge 14) and catalog, if necessary, have SCHUNK check the
application.
8.2
The module does not travel through the entire stroke?
Possible cause Corrective action
Dirt deposits between the stop /
sleeve and the
Remove the cover.
Clean the module and relubricate it. ( 9, Page 45)
piston
The end positions are incorrectl
Readjust the end positions ( 6.3, Page 20)
adjusted
Pressure drops below minimum. Check the air supply. ( 6.2, Page 17)
Send the module to SCHUNK with a repair order or dis-
e.g. through over-loading.
assemble module.
Shock absorber defective Check or, if necessary, replace the shock absorber ( 9,
Page 45)
01.05|SRU-plus EDF 20 - 60|en
43
(
(
www.comoso.com
Troubleshooting
8.3
Torque drops?
Possible cause Corrective action
Compressed air can escape Test seals and, if need be, disassemble the module
and replace the seals ( 9, Page 45)
Too much grease in the mechan-
Clean the module and relubricate it. ( 9, Page 45)
ical motion spaces of the module
Pressure drops below minimum. Check the air supply. ( 6.2, Page 17)
8.4
The module rotates abruptly?
Possible cause Corrective action
Too little grease in the mechanical guiding areas of the module
Compressed air lines are
Clean the module and relubricate it.
9, Page 45)
Check the compressed air lines for crushing or damage.
blocked
Module does not move smoothly to the limit positions?
8.5
Possible cause Corrective action
Fine adjustment of the
shock absorber stoke incorrect
Check the shock absorber stroke and, if need be, readjust
6.3, Page 20)
Shock absorber defective Check or, if need be, replace the shock absorber ( 9,
Page 45)
44 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Maintenance and care
Maintenance and care
9
9.1
Notes
DANGER
Danger of explosion in explosion risk areas!
• Follow the instructions in supplementary sheet "Installation
and operating instructions - EX" for modules in explosionresistant versions (EX)!
NOTICE
At ambient temperature above 60°C the lubricants can
harden faster.
• Interval decrease accordingly.
Size 20 25 30 35 40 50 60
Visual inspection of shock absorber
Regular
function
Recommended replacement of the
2 1
shock absorber after [million cycles]
9.1.1
Maintenance and lubrication interval for EDF
NOTICE
The lubricants harden faster at ambient temperatures above
60°C.
• Reduce the interval accordingly.
Size 20 25 30 35 40 50 60
Interval [million swivels] 1
01.05|SRU-plus EDF 20 - 60|en
45
Maintenance and care
www.comoso.com
9.2
Lubricants/Lubrication points (basic lubrication)
We recommend the lubricants listed.
During maintenance, treat all greased areas with lubricant. Thinly
apply lubricant with a lint-free cloth.
Lubricant point Lubricant
the teeth and the pinion Molykote BR 2 plus
Metallic sliding surfaces microGLEIT GP 360
All seals Renolit HLT 2
9.3
Dismantling the module
9.3.1
Dismantling the rotary actuator
Position of the position numbers ( 10
, Page 55)
1 Remove all pressure and energy lines.
2 Unscrew screw (35) and remove both stop covers.
Without center position:
- Remove the curved cover (5).
With center position:
- Unscrew the screw (35) on stops C and D
one turn.
- Remove the fastening screw (58) of the limit
sleeve (25).
- Unscrew stops C and D until the
centering housing (14) can be removed.
3 Mark the installation position of the pinion (2/19) and the pis-
tons (24).
4 Remove the protective cover (22) and disassemble the safety
ring (49) on the pinion.
5 Media feed-through option:
- Remove the flange (20).
6 Pull the pinion (2/19) out of the housing.
46 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Maintenance and care
9.3.2
Disassembling the center position (variant M and VM)
WARNING
Risk of injury due to spring forces!
There is a pre-loaded compression spring in the interior.
• Carefully disassemble the module.
Position of the position numbers ( 10, Page 55)
1 Pull stops C and D out of the housing (14).
2 Remove the cover (18) of the adjusting sleeve (16).
3 Remove the stop piston (17).
4 Locked center position only:
9.3.3
Remove the locking ring (51) on the stop piston (17).
Replacing a shock absorber
The shock absorbers are specially tested and can only be acquired
from SCHUNK. The shock absorbers have a limited service life, depending on the load.
1 Regularly test the shock absorbers for function. The shock ab-
sorbers function correctly when the module moves smoothly
into the end positions.
01.05|SRU-plus EDF 20 - 60|en
47
Maintenance and care
www.comoso.com
Replacing the
shock absorbers
Base unit with internal shock absorbers:
Position of the position numbers ( 10
, Page 55)
1 Unscrew the screws (1).
2 Pull off the stop cover (2).
3 Remove the safety rings (4) on the pistons.
4 Pull out the shock absorbers (54).
5 Insert the new shock absorbers. CAUTION: Note the shock ab-
sorber distance ( 9.3.3
, Page 50); if need be, insert or re-
move the fitting disks.
6 Add fitting discs to the fitting disks (4) until they can be
mounted free from play.
7 Reattach the stop cover (2) and screw it into place.
8 Secure stop with
19 (SRU-plus 20-25) or 32 (SRU-plus
30-60) and loosen the nut (101) at the stop pin with
(SRU-plus 20-25) or
9 Secure the stop with
24 (SRU-plus 30-60).
19 (SRU-plus 20-25) or 32 (SRUplus 30-60) and screw in the stop pin with the hexagon socket
wrench
5 (SRU-plus 20-25) or 6 (SRU-plus 30-40) or 8
(SRU-plus 60) up to the stop pin limit.
10 Readjust the dampening as
described in ( 6.3, Page 20).
14
48 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Maintenance and care
Replacing the
shock absorbers
Locked center position option (variant VM) with
external absorbers:
Position of the position numbers ( 10
, Page 55)
1 Secure the stop with
19 (SRU-plus 20-25) or 32 (SRUplus 30-60) and unscrew the sealing nuts (74) of the
shock absorber.
2 Remove the shock absorber from the threads.
3 Screw in the new shock absorber as far as possible.
4 Mount the O-ring (47) on the shock absorber.
5 Adjust the shock absorber stroke by unscrewing the
shock absorber.
6 Secure the stop with
19 (SRU-plus 20-25) or 32 (SRUplus 30-60) and tighten the sealing nuts (74) of the shock absorber.
7 Swivel repeatedly to test the setting.
( 7.3
Replacing the
shock absorbers
Locked center position option (variant VM) with
internal absorbers
, Page 38)
Position of the position numbers ( 10
, Page 55)
1 Unscrew the countersunk screw (35) on stops C and D by one
turn.
2 Remove the countersunk screw (58).
3 Unscrew stops C and D until the centering housing (14)
can be removed.
4 Remove the safety rings (4) on the pistons (24).
5 Pull out the shock absorbers (54).
NOTICE
During mounting, it is possible to damage the
O-rings (41).
• Mount the shock absorbers carefully.
6 Insert the new shock absorbers. CAUTION:
Note the shock absorber distance ( 9.3.4
if need be, insert or remove the fitting disks.
, Page 52);
7 Add fitting discs to the safety rings until they can be mounted
without play.
01.05|SRU-plus EDF 20 - 60|en
49
Maintenance and care
Observe the sequence! ( 10, Page 55)
Replacement of the
spring elastomer
www.comoso.com
dampening
Shock absorber maintenance for SRU-plus 20 with elastomer
dampening ( 9.3.3
NOTE
, Page 50)
Fig. 27 Replacing the spring-elastomer dampening
1 Unscrew the screws (1).
2 Pull off the stop cover (2).
3 Remove the safety ring (4) from the piston.
4 Pull out the piston rod (3) and remove the compression spring
(5).
5 Pull out the piston (7) with the guide sleeve (6) and
dampening ring (8).
6 Replace the dampening ring (8).
7 Reinsert the piston (7) with the guide sleeve (6) and dampen-
ing ring (8) using the piston rod (3) as far as
possible.
8 Check the shock absorber overlap (h), ( 9.3.4
necessary, added fitting discs on base side until the desired
shock absorber overlap (h) is reached.
, Page 52). If
9 Remove the piston rod (3) again.
10 Grease and insert the compression spring (5).
11 Grease the piston rod (3) from the inside and outside
12 Remount the safety ring (4) again. When doing this, pay atten-
13 Mount the stop cover (2) with screws (1).
50 01.05|SRU-plus EDF 20 - 60|en
and insert it.
tion to the correct
installation position of the safety ring.
Observe the sequence! ( 10, Page 55)
e spring elastomer
www.comoso.com
Maintenance and care
Replacement of
th
dampening
Shock absorber maintenance for SRU-plus 20 with elastomer
dampening ( 9.3.3
, Page 51)
NOTE
Fig. 28 Replacing the damper-elastomer dampening
1 Unscrew the screws (1).
2 Pull off the stop cover (2).
3 Remove the safety ring (4) from the piston.
4 Pull out the piston rod (3) and remove the absorber (5).
5 Use the M5 thread to pull out the cover (7) and dampening
ring (6).
6 Replace the dampening ring (6).
7 Reinsert the cover (7) with the dampening ring (6) using the
piston rod (3) as far as possible.
8 Remove the piston rod (3) again.
9 Grease and insert the absorber (5).
10 Grease the piston rod (3) from the inside and outside
and insert it.
11 Remount the safety ring (4) again. When doing this, pay atten-
tion to the correct
installation position of the safety ring.
12 Mount the stop cover (2) with screws (1).
01.05|SRU-plus EDF 20 - 60|en
51
Maintenance and care
www.comoso.com
Typ
SRUplus
9.3.4
Basic Locked center position
Shock absorber
Shock absorber types and shock absorber overlap (h)
Shock absorber overlap h
[mm]
20 W FED 14 4.6
(without
spring)
20 S DED (to put sth.
under is not
necessary)
20 W
VM
FED 14 4.6
(without
spring)
25 W WP-M
14 -0.1 --- --- ---
0.4-266
Toleranc
e [mm]
Shock absorber
Shock absorber overlap h
Toleranc
e [mm]
[mm]
-0.2 --- --- ---
--- --- --- ---
-0.2 WP-M 0.25-
9.5 ± 0.05
356
25 H WP-M
0.4-366
25 W
VM
WP-M
0.4-266 VM
30 W WP-M
0.6-466
30 H WP-M
0.6-566
30 W
VM
WP-M
0.6-566 VM
35 W WP-M
0.6-366
35 H WP-M
0.6-366
35 W
VM
WP-M
0.6-466 VM
40 W WP-M
1.0-266
40 H WP-M
1.0-466
14 -0.1 --- --- ---
10 -0.1 WP-M
14 -0.1
0.4-266 G
19.5 -0.1 --- --- ---
16 -0.1 --- --- ---
12 -0.1 WP-M
19 -0.1
0.6-466 G
19.5 -0.1 --- --- ---
19.5 -0.1 --- --- ---
17.2 -0.1 WP-M
19 -0.1
0.6-366 G
Add fitting discs at posi-
--- --- --tion (2) until the shock
absorber (4) is scope-
--- --- --free inserted into the
piston (5).
40 W WP-M 19.4 -0.1 WP-M 22 -0.1
52 01.05|SRU-plus EDF 20 - 60|en
put fitting discs underneath
www.comoso.com
Maintenance and care
Typ
SRUplus
Basic Locked center position
Shock absorber
Shock absorber overlap h
Toleranc
e [mm]
Shock absorber
[mm]
VM 1.0-266 1.0-266 G
50 W WP-M
1.0-266
50 H WP-M
1.0-466
Add fitting discs at position (2) until the shock
absorber (4) is scopefree inserted into the
--- --- ---
--- --- ---
piston (5).
50 W
VM
60 W WP-M
60 W
VM
WP-M
1.0-266
1.25x2-266
WP-M
1.25x2-266
VM
20.4 -0.1 WP-M
1.0-266 G
Add fitting discs at posi-
--- --- --tion (2) until the shock
absorber (4) is scopefree inserted into the
WP-M
1.0-266 G
piston (5).
Shock absorber overlap h
Toleranc
e [mm]
[mm]
22 -0.1
23 -0.1
Fig. 29 Shock absorber overhang
1/2
4 Shock absorber
if required
3 Safety ring 5 Piston
h Shock absorber overlap
1 Add fitting disks (1/2) to the shock absorber until the shock
absorber overlap (h) is reached and the shock absorber is in
contact with the safety ring (3) without play.
01.05|SRU-plus EDF 20 - 60|en
53
Maintenance and care
www.comoso.com
9.3.5
Servicing and assembling the module
Position of the position numbers ( 10
WARNING
, Page 55)
Risk of injury due to spring forces!
• Carefully disassemble the module.
Servicing
• Thoroughly clean all parts and check for damage or
wearing parts.
• Replace all wear parts / seals.
• Treat all lubrication points with lubricant.
• Oil and grease bright, external steel parts.
Assembly
Assembly takes place in the opposite order to
disassembly. Observe the following:
• Do not damage the O-rings (41) during assembly.
• Unless otherwise specified, secure all screws and nuts with Loc-
9.3.6
Disassembly
Checking
Assembly
tite no. 243 and tighten with the appropriate tightening torque.
Maintaining the module
Position of the position numbers ( 10.2
, Page 59)
• Undo 2x screws (13) and remove the flange (3).
• Check the cable for damage and output.
• Before the assembly, the flange (3) (interior) and the cable
spiral (19) have to be rubbed again in milking grease.
54 01.05|SRU-plus EDF 20 - 60|en
(
(
(
(
(
Separation of the "standard" version and the "D" version for dis-
www.comoso.com
Assembly drawing
Assembly drawing
10
Fig. 30 Component overview
1 Basic components and media feed-
10.1, Page 56)
through
2 Electrical feed-through (standard)
10.2, Page 59)
3 Electrical feed-through (version "D") ( 10.2, Page 59)
4 Sensor holder with sensor
5 Distributor plate (version "D")
6 Distributor plate (standard)
6.4.2, Page 26)
10.2, Page 59)
10.2, Page 59)
NOTE
tributor plate and electrical feed-through
• "Standard" version includes all position numbers with and
without the a designation on the respective illustrations.
• "D" version includes all position numbers with and without the
b designation on the respective illustrations.
01.05|SRU-plus EDF 20 - 60|en
55
Assembly drawing
www.comoso.com
10.1
Basic components and media feed-through
Fig. 31 Basic components and media feed-through
* Contained in sealing kit.
** Contained in accessory pack.
56 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly drawing
Fig. 32 Stop side, end position adjustability 3°
Fig. 33 Stop side, end position adjustability 90°
Fig. 34 Stop-side, locked center position (variant VM)
* Contained in sealing kit.
** Contained in accessory pack.
01.05|SRU-plus EDF 20 - 60|en
57
Assembly drawing
www.comoso.com
Fig. 35 Attachment, locked center position (variant VM)
Fig. 36 Center position attachment (M variant)
Fig. 37 Pistons and cover of basic unit
* Contained in sealing kit.
** Contained in accessory pack.
58 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly drawing
10.2
EDF with distributor plate 20-60
Fig. 38 Distributor plate 20-25 (standard + "D" version)
Fig. 39 Electrical feed-through 20-25 (standard + "D" version)
01.05|SRU-plus EDF 20 - 60|en
59
Assembly drawing
www.comoso.com
Fig. 40 Distributor plate 30 (standard + "D" version)
Fig. 41 Electrical feed-through 30 (standard + "D" version)
60 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly drawing
Fig. 42 Distributor plate 35 (standard + "D" version)
Fig. 43 Electrical feed-through 35 (standard + "D" version)
01.05|SRU-plus EDF 20 - 60|en
61
Assembly drawing
www.comoso.com
Fig. 44 Distributor plate 40 (standard + "D" version)
Fig. 45 Electrical feed-through 40 (standard + "D" version)
62 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Assembly drawing
Fig. 46 Distributor plate 50-60 (standard + "D" version)
Fig. 47 Electrical feed-through 50-60 (standard + "D" version)
01.05|SRU-plus EDF 20 - 60|en
63
www.comoso.com
Sealing kit
Sealing kit
11
ID.-No. of the seal kit SRU-plus
Seal kit for
SRU-plus 20 SRU-plus 25 SRU-plus 30 SRU-plus 35 SRU-plus 40 SRU-plus 50 SRU-plus 60
Basic seal kit
0371000 0371004 5518598 0371008 0371012 0371016 0371020
with center position
5519788 5519792 5519798 5519800 5519804 5519808 5519812
with locked center position
5519789 5519793 5519799 5519801 5519805 5519809 5519813
with media feed-through
0371003 0371007 5518599 0371011 0371015 0371019 0371023
with center position and media feed-through
5519790 5519794 5519796 5519802 5519806 5519810 5519814
with locked center position and media feed-through
5519791 5519795 5519797 5519803 5519807 5519811 5519815
ID.-No. of the seal kit für EDF
Seal kit for
SRU-plus 20 SRU-plus 25 SRU-plus 30 SRU-plus 35 SRU-plus 40 SRU-plus 50 SRU-plus 60
Basic seal kit
5521583 5521853 5521585 5521587 5521589 5521591 5521591
Basic sealing kit + monitoring set
5521584 5521584 5521586 5521588 5521590 5521592 5521592
Contents of the seal kit ( 10
, Page 55).
64 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Accessory pack
Accessory pack
12
ID.-No. of the accessory pack SRU-plus
Accessory pack for
SRU-plus 20 SRU-plus 25 SRU-plus 30 SRU-plus 35 SRU-plus 40 SRU-plus 50 SRU-plus 60
without media feed-through
5514981 5518653 5514989 5514993 5514997 5515001
with media feed-through
5514982 5518654 5514990 5514994 5514998 5515002
with center position
5516590 5518657 5516594 5516596 5516598 5516600
with locked center position
5514983 5518655 5514991 5514995 5514999 5515003
with media feed-through and center position
5516591 5518658 5516595 5516597 5516599 5516601
with media feed-through and locked center position
5514984 5518656 5514992 5514996 5515000 5515004
Contents of the accessories pack ( 10
, Page 55).
01.05|SRU-plus EDF 20 - 60|en
65
www.comoso.com
Wear parts SRU-plus 20 - 60
Wear parts SRU-plus 20 - 60
13
Shock absorber
Item Designation SRU-plus 20 SRU-plus 25 SRU-plus 30 SRU-plus 35
Size designation / Quantity x Id-No.
Shock absorber for soft damping (W)
54 FED 14 2 x 5518862 - - -
54 WP-M - 0.4-266 /
2 x 9949490
0.6-466 /
2 x 9951813
54 FED14 2x 5518862 - - -
54-4 Damping ring
2x 9952652 - - -
FED 14
Shock absorber for soft damping and locked middle position (W-VM)
54 FED 14 2 x 5518862 - - -
54 WP-M - 0.4-266 VM / 2
x 9952276
57 WP-M 0.25-356 / 2 x
9941662
0.4-266 G / 2 x
9952277
0.6-566 VM / 2
x 9952279
0.6-466 G / 2 x
9952277
Shock absorber for hard damping (H)
54 WP-M - 0.4-366 / 2 x
9949491
0.4-566 / 2 x
9952278
0.6-366 /
2 x 9951816
0.6-466 VM / 2
x 9952832
0.6-366 G / 2 x
9952847
-
Shock absorber for speed damping (S)
54 DED 14 2x 5521380 - - -
54-4 Damping ring
2x 9952652 - - -
DED 14
54-5 Shock absorber
DED 14
2x 0.15–266/
9957455
- - -
66 01.05|SRU-plus EDF 20 - 60|en
www.comoso.com
Wear parts SRU-plus 20 - 60
Shock absorber
Item Designation SRU-plus 40 SRU-plus 50 SRU-plus 60
Size designation / Quantity x Id-No.
Shock absorber for soft damping (W)
54 FED 14 - - -
54 WP-M 1.0-266 /
2 x 9952272
1.0-266 / 2 x
9952272
54 FED14 - - -
54-4 Damping ring
- - -
FED 14
Shock absorber for soft damping and locked middle position (W-VM)
54 FED 14 - - -
54 WP-M 1.0-266 / 2 x
9952272
57 WP-M 1.0-266 G / 2 x
9952281
1.0-266 / 2 x
9952272
1.0-266 G / 2 x
9952281
Shock absorber for hard damping (H)
54 WP-M 1.0-466 / 2 x
9952273
1.0-466 / 2 x
9952273
1.0-266 / 2 x
9952272
On request
On request
-
Shock absorber for speed damping (S)
54 DED 14 - - -
54-4 Damping ring
- - -
DED 14
54-5 Shock absorber
- - -
DED 14
01.05|SRU-plus EDF 20 - 60|en
67
in terms of the Directive 2006/42/EG, Annex II, Part 1.B of the European Parliament and of
The manufacturer agrees to forward on demand the relevant technical documentation for
p.p. Ralf Winkler, Head of Gripping
www.comoso.com
Translation of original declaration of incorporation
14
the Council on machinery.
Manufacturer/
Distributor
SCHUNK GmbH & Co. KG Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
We hereby declare that on the date of the declaration the following incomplete machine
complied with all basic safety and health regulations found in the directive 2006/42/EC of
the European Parliament and of the Council on machinery. The declaration is rendered
invalid if modifications are made to the product.
Product designation: Electrical feed-through / SRU-plus 20 - 60 / pneumatic
ID number 0361403…0362765, 37361407, 37361727, 37361437,
37361447, 37361627, 37361637, 37361647, 37362007,
37362027, 37362037, 37362047, 37362207,
The incomplete machine may not be put into operation until conformity of the machine
into which the incomplete machine is to be installed with the provisions of the Machinery
Directive (2006/42/EC) is confirmed.
Applied harmonized standards, especially:
EN ISO
12100:2011-03
Safety of machinery - General principles for design - Risk assessment
and risk reduction
the partly completed machinery to state offices.
The special technical documents according to Appendix VII, Part B belonging to the incomplete machine have been compiled.
Person authorized to compile the technical documentation:
Robert Leuthner, Address: see manufacturer's address
Lauffen/Neckar, January 2014
Systems Development
68 01.05|SRU-plus EDF 20 - 60|en
Loading...
