Translation of the original manual
Assembly and Operating Manual
GSP-P
2-Finger-parallel gripper
Imprint
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389033
Version: 02.00|06/06/2019|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. +49-7133-103-0
Fax +49-7133-103-2399
info@de.schunk.com
schunk.com
2
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Table of contents
Table of contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Applicable documents ..............................................................................6
1.1.3 Variants..................................................................................................... 6
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery ..................................................................................................6
1.4 Accessories ........................................................................................................... 6
2 Basic safety notes ................................................................................................... 7
2.1 Intended use......................................................................................................... 7
2.2 Not intended use.................................................................................................. 7
2.3 Constructional changes ........................................................................................7
2.4 Spare parts ........................................................................................................... 7
2.5 Gripper fingers ..................................................................................................... 8
2.6 Ambient conditions and operating conditions ..................................................... 8
2.7 Personnel qualification......................................................................................... 8
2.8 Personal protective equipment............................................................................ 9
2.9 Notes on safe operation ....................................................................................... 9
2.10 Transport .............................................................................................................. 9
2.11 Malfunctions....................................................................................................... 10
2.12 Disposal .............................................................................................................. 10
2.13 Fundamental dangers......................................................................................... 10
2.13.1 Protection during handling and assembly ..............................................11
2.13.2 Protection during commissioning and operation ...................................11
2.13.3 Protection against dangerous movements.............................................12
2.13.4 Protection against electric shock............................................................12
2.14 Notes on particular risks..................................................................................... 13
3 Technical data.........................................................................................................14
4 Assembly ................................................................................................................15
4.1 Mechanical connection ...................................................................................... 15
4.2 Air connection .................................................................................................... 17
4.3 Sensors ............................................................................................................... 19
4.3.1 Programmable magnetic switch (MMS-P)..............................................19
4.3.2 Proximity switch ST4 and ST4-2P............................................................25
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
3
Table of contents
5 Troubleshooting .....................................................................................................26
5.1 Product does not move ......................................................................................26
5.2 Product does not travel through the entire stroke ............................................26
5.3 Product opens or closes abruptly ....................................................................... 26
5.4 Magnetic switch does not work ......................................................................... 26
5.5 Gripping force drops........................................................................................... 27
5.6 Product does not achieve the opening and closing times.................................. 27
6 Maintenance and Care............................................................................................28
7 Translation of original declaration of incorporation ................................................29
7.1 Annex to Declaration of Incorporation............................................................... 30
4
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}6] are applicable.
1.1.1 Presentation of Warning Labels
General
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
5
General
1.1.2 Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
• Assembly and operating manuals of the accessories *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
1.1.3 Variants
This operating manual applies to the following variations:
• GSP-P without gripping force maintenance
• GSP-P with gripping force maintenance "O.D. gripping" (AS or NC)
• GSP-P with gripping force maintenance "I.D. gripping" (IS or NO)
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the specified maintenance and lubrication intervals
• Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• 2-Finger-parallel gripper GSP-P in the version ordered
• Assembly and Operating Manual
• Accessory pack
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
6
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Basic safety notes
2 Basic safety notes
2.1 Intended use
The product is designed exclusively for gripping and temporarily
holding workpieces or objects.
• The product may only be used within the scope of its technical
data, Technical data [}14].
• When implementing and operating components in safetyrelated parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• The product is intended for industrial and industry-oriented use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
It is not intended use if the product is used, for example, as a
pressing tool, stamping tool, lifting gear, guide for tools, cutting
tool, clamping device or a drilling tool.
• Any utilization that exceeds or differs from the appropriate use
is regarded as misuse.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
7
Basic safety notes
2.5 Gripper fingers
Requirements for the gripper fingers
Stored energy within the product creates the risk of serious
injuries and significant property damage.
• Arrange the gripper fingers in a way that the product reaches
either the position "open" or "closed" in a de-energized state.
• Only exchange the gripper fingers when no residual energy
remains in the product.
• Make sure that the product and the top jaws are a sufficient
size for the application.
2.6 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
• Make sure that the product is used only in the context of its
defined application parameters, Technical data [}14].
Trained electrician
Qualified personnel
2.7 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person
Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
8
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Basic safety notes
2.8 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot
surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.
2.9 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.10 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
9
Basic safety notes
2.11 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
2.12 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.13 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
10
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
2.13.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.
Basic safety notes
2.13.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
11
Basic safety notes
2.13.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
• Switch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
• Never rely solely on the response of the monitoring function to
avert danger. Until the installed monitors become effective, it
must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
• To avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective
fence must be rigid enough to withstand the maximum possible
movement energy. EMERGENCY STOP switches must be easily
and quickly accessible. Before starting up the machine or
automated system, check that the EMERGENCY STOP system is
working. Prevent operation of the machine if this protective
equipment does not function correctly.
2.13.4 Protection against electric shock
Possible electrostatic energy
Components or assembly groups may become electrostatically
charged. When the electrostatic charge is touched, the discharge
may trigger a shock reaction leading to injuries.
• The operator must ensure that all components and assembly
groups are included in the local potential equalisation in
accordance with the applicable regulations.
• While paying attention to the actual conditions of the working
environment, the potential equalisation must be implemented
by a specialist electrician according to the applicable
regulations.
• The effectiveness of the potential equalisation must be verified
by executing regular safety measurements.
12
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
2.14 Notes on particular risks
WARNING
Risk of injury from crushing and impacts!
Serious injury could occur during the base jaw procedure and
when breaking or loosening the gripper fingers.
• Wear suitable protective equipment.
• Do not reach into the open mechanism or the movement area
of the product.
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious
injury or death.
• Take appropriate protective measures to secure the danger
zone.
Basic safety notes
WARNING
Risk of injury from objects falling during energy supply failure
Products with a mechanical gripping force maintenance can,
during energy supply failure, still move independently in the
direction specified by the mechanical gripping force
maintenance.
• Secure the end positions of the product with SCHUNK SDV-P
pressure maintenance valves.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
13
Technical data
3 Technical data
Size 08 10 16 20 25 40
Stroke per jaw [mm] 2 3 5 6 8 13
Weight [kg] 0.04 0.07 0.15 0.25 0.46 1.48
Recommended workpiece weight [kg] 0.13 0.29 0.6 1.2 1.9 4.2
Max. permissible finger length [mm] 20 25 32 40 50 64
Max. permitted weight per finger [kg] 0.025 0.04 0.06 0.09 0.12 0.3
Ambient temperature [°C]
Min.
Max.
Spring force gripping force
maintenance [N]
Min.
Max.
Closing force [N]
without gripping force maintenance
with gripping force maintenance AS
with gripping force maintenance IS
3
6
26
32
-
8
13
58
74
-
10
25
120
140
-
+5
+60
20
50
240
280
-
40
80
380
460
-
125
125
840
1090
-
Opening force [N]
without gripping force maintenance
with gripping force maintenance AS
with gripping force maintenance IS
36
-
42
70
-
86
138
-
158
280
-
320
438
-
518
928
-
1178
IP rating 40
Pressure medium Compressed air, compressed air quality according to
ISO 8573-1:7 4 4
Min. pressure [bar]
without gripping force maintenance
with gripping force maintenance
2
4.5
Max. pressure [bar]
without gripping force maintenance
with gripping force maintenance
8
6.5
More technical data is included in the catalog data sheet.
Whichever is the latest version.
14
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
4 Assembly
4.1 Mechanical connection
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
Assembly
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
15
Assembly
Mounting
The module can be mounted from the rear or on the side.
Assembly options
Maximal screw-in depth of the fastening screws provided by the
customer.
Mounting material
Item Mounting 08 10 16 20 25 40
1 Module rear
mounting
M3 /
6.5 deep
M4 /
8.5 deep
M5 /
11.5
M8 /
15 deep
deep
2 Module side
mounting
M3 M3 /
6.5 deep
M4 /
8.5 deep
M5 /
11.5
M8 /
16 deep
deep
3 Top jaws M3 /
6.5 deep
M4 /
8.5 deep
M5 /
11.5
M8 /
16 deep
deep
99 Centering sleeve Ø2M6 Ø5K6 Ø7K6 Ø7K6 Ø12K6
NOTE
• Mount the module using the provided centering sleeves (99).
• Mount the module using the mounting bores.
• Mount the top jaws using the provided mounting bores .
16
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
4.2 Air connection
NOTICE
Damage to the gripper is possible!
If the maximum permissible finger weight or the permissible
mass moment of inertia of the fingers is exceeded, the gripper
can be damaged.
• A jaw movement always has to be without jerks and bounce.
• You must therefore implement sufficient reduction and/or
damping.
• Observe the diagrams and information in the catalog data
sheet.
NOTE
• Observe the requirements for the compressed air supply,
Technical data [}14].
• In case of compressed air loss (cutting off the energy line), the
components lose their dynamic effects and do not remain in a
secure position. However, the use of a SDV-P pressure
maintenance valve is recommended in this case in order to
maintain the dynamic effect for some time. Product variants
are also offered with mechanical gripping force via springs,
which also ensure a minimum clamping force in the event of a
pressure drop.
Assembly
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
17
Assembly
Air connections
Thread diameter of the air connections
Item Connection 08 10 16 20 25 40
1 Thread diameter of the air
connections
2 x M3 2 x M5 2 x
G1/8"
(A = open, B = close)
• Open only the air connections that are needed.
• Close unused main air connections using the screw plugs from
the enclosed pack.
• For a hose-free direction connection, use the O-rings from the
enclosed pack.
18
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
4.3 Sensors
brown
white
black
blue
The gripper is prepared for use of the following sensors:
• Sensor MMS-P:
– Information on handling sensors is available at schunk.com
or from SCHUNK contact persons
– Technical data for the sensors can be found in the data
sheets (included in the scope of delivery or at schunk.com).
• Sensor ST4/ST4-2P
– You can find information about the handling of sensors via
the Aventics company
– Technical data of the sensors are contained in the data
sheets.
4.3.1 Programmable magnetic switch (MMS-P)
NOTE
The MMS-P can be used only for sizes GSP-P 08 – GSP-P 40.
Assembly
Magnetic switch MMS-P 22
1 Mounting screw 4 Teach-button
2 Center sensor elements 5 LED display
3 LED display 6 Ribs for cable tires
Connection diagram PNP-4 conductor (MMS-P 22)
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
19
Assembly
Mounting of the
sensor
Types available for order (see catalog):
• MMS-P 22-S-M8-PNP
• MMSK-P 22-S-PNP
• V2-M8-4-2XM8-3
The MMSK-P 22-S-PNP features a cable with open strands so that
it can be connected via terminal contacts.
The V2-M8-4-2XM8-3 distributor is used to convert the 4-pin
connector plug of the MMS-P 22-S-M8-PNP sensor to two
standard M8 plugs with 3 pins each.
NOTICE
Sensor can be damaged during assembly.
• Do not exceed the maximum tightening torque of 10 Ncm for
the set screws!
NOTE
Ferromagnetic material changes the switching positions of the
sensor (e.g. Adapter plate made of ordinary steel).
For ferromagnetic adapter plates:
• The module must be first mounted on the adapter plate.
• Then, the position of the magnetic switchs has to be set.
Ø To relieve the cable, the electronics have to be fixed in place
using cable ties (7).
There are ribs (6) in place on the electronics for mounting
purposes.
20
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Assembly
Ø Turn in the sensor (1 - 4).
OR
Push the sensor axially into the slot until it contacts the stop (5).
Ø Fix the sensor with an Allen wrench (6).
If there is no terminal stop, then slide the magnetic switch
according to dimension l2 (bottom edge of gripper up to front side
of sensor) or according to dimension l1 (bottom edge of gripper up
to double arrow on sensor) and then clamp it with an Allen
wrench.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
21
Assembly
Type Dimension l
[mm]
Dimension l
1
[mm]
Type Dimension l
2
[mm]
Dimension l
1
[mm]
GSP-P 08 19.2 28.1 GSP-P 20-AS 22.1 31
GSP-P 08-AS 14.1 23.0 GSP-P 20-IS 27.1 36
GSP-P 08-IS 22.4 31.3 GSP-P 25 33.6 42.5
GSP-P 10 20.4 29.3 GSP-P 25-AS 25.6 34.5
GSP-P 10-AS 17.9 26.8 GSP-P 25-IS 33.6 42.5
GSP-P 10-IS 20.4 29.3 GSP-P 40 47.8 56.7
GSP-P 16 25.0 33.9 GSP-P 40-AS 31.8 40.7
GSP-P 16-AS 21.0 29.9 GSP-P 40-IS 47.8 56.7
GSP-P 16-IS 25.0 33.9
GSP-P 20 27.1 36
Setting up
the switching points
Ø Keep the Teach-Button (4) pressed for 2 seconds.
✓ After 2 seconds LED 1 (3) is flashing.
Ø Move the gripper into position 1 (e.g. "open").
Ø Press the Teach-Button (4) briefly.
2
✓ LED 1 (3) lights up and LED 2 (5) is flashing.
Ø Move the gripper manually into position 2 (z.B. „-2mm“).
✓ LED 1 (3) should turn off as soon as the switching point 1 is
left.
Ø The switching points are set.
✓ LED 2 (5) lights up.
✔ The switching points are set.
22
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Assembly
Adjusting the
hysteresis
The hysteresis to both switching points will be adjusted
automatically corresponding to the characteristics of the magnetic
field.
The user can set the switching and trigging points of each position
a little bit closer than for the automatic mode. The trigging point is
closer to the switching point. At the same time the susceptibility to
trouble and damage increases. In the mode of the lowest
hysteresis, an error signal (such as jitter or untimely switch off) can
be avoided, if the sensor is protected against all types of
disturbances (i.e. by shielding). Frequent types of disturbances are
change in temperature and electro-magnetic influences.
Within the closest fine-teach mode, SCHUNK cannot guarantee
EMC-compatibility any more.
The hysteresis adjustment is used for the manual adjustment of
the switching points (if necessary).
In case that the hysteresis automatically determined by the sensor
should be too high or too low after “the adjustment of the
switching points”, you may correct the value as follows.
The sensor avoids a too small hysteresis during hysteresis
adjustment.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
23
Assembly
Sensors MMS 22, MMS-P 22, MMS 22-PI1 and MMS 22-PI2
The smallest detectable difference in stroke is defined in the
following table:
The smallest detectable difference in stroke based on the nominal stroke
For grippers with X mm
nominal stroke per jaw
Min. query range per jaw/
min. queried stroke difference per jaw
X ≤ 5 mm 30% of the nominal stroke per jaw
X > 5 mm to X ≤ 10 mm 20% of the nominal stroke per jaw
X > 10 mm 10% of the nominal stroke per jaw
Example: Product with 7 mm nominal stroke per jaw
7 mm * 20% = 1.4 mm
Ø Press the Teach-Button (4) for 5 seconds.
✓ LED 1 (3) flashes from the 2nd to the 5th second.
✓ LED 1 will stop flashing once the 5 seconds are over.
Ø Teach-Knopf loslassen.
Ø Put the gripper to position „switch-off point of switching point 1”.
Ø Press the Teach-Button (4) briefly. LED 1(3) will flash twice.
Ø Put the gripper to position „switch-off point of switching point 2”.
Ø Press the Teach-Button (4) briefly.
✓ LED 2 (5) will flash twice.
✔ The mounting of the sensor MMS-P is completed.
24
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
4.3.2 Proximity switch ST4 and ST4-2P
The proximity switch ST4 or ST4-2 P by Aventics can be mounted
on the gripper. The proximity switches have to be ordered directly
from Aventics.
NOTE
For mounting using through bolts, V2A stainless steel bolts must
be used instead of ferromagnetic bolts.
Fix the proximity switch ST4 or ST4-2P with the provided centering
rings in the intended position, see documentation of the sensors.
Assembly
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
25
Troubleshooting
5 Troubleshooting
5.1 Product does not move
Possible cause Corrective action
Base jaws jam in housing, e.g. mounting
surface is not sufficiently even.
Pressure drops below minimum. Check air supply. Air connection [}17]
Compressed air lines switched. Check compressed air lines.
Proximity switch defective or set incorrect. Readjust or change sensor.
Unused air connections open. Close unused air connections.
Flow control valve closed. Open the flow control valve.
Component part defective. Exchange product
The aperture angle is limited to 0°. Check opening angle limitation.
Check the evenness of the mounting surface.
Mechanical connection [}15]
Loosen the mounting screws of the product
and actuate the product again.
5.2 Product does not travel through the entire stroke
Possible cause Corrective action
Pressure drops below minimum. Check air supply.
Air connection [}17]
Mounting surface is not sufficiently flat. Check the evenness of the mounting surface.
Mechanical connection [}15]
Component part defective. Exchange product
5.3 Product opens or closes abruptly
Possible cause Corrective action
Compressed air lines blocked. Check compressed air lines of damage.
Mounting surface is not sufficiently flat. Check the evenness of the mounting surface.
One-way flow control valve is missing or
adjustet incorrectly.
Loading too large. Check permissible weight and length of the
Install and adjust one-way flow control
valve.
gripper fingers.
Mechanical connection [}15]
5.4 Magnetic switch does not work
Possible cause Corrective action
Steel screws were used to mount the gripper Use VA-screws
Mounting plates, brackets, etc. from non-
magnetic materials
If possible, use aluminium or plastic
26
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Troubleshooting
5.5 Gripping force drops
Possible cause Corrective action
Compressed air can escape. Check seals, if necessary replace product.
Pressure drops below minimum. Check air supply.
Air connection [}17]
5.6 Product does not achieve the opening and closing times
Possible cause Corrective action
Compressed air lines are not installed
optimally.
If present: Open the flow control couplings
on the product to the maximum that the
movement of the jaws occurs without
bouncing and hitting.
NOTICE!The one way flow control valves
must not be removed even when the
product has reached the opening and
closing times.
Check compressed air lines.
Inner diameters of compressed air lines are
of sufficient size in relation to compressed
air consumption.
Keep compressed air lines between the
product and directional control valve as
short as possible.
Flow rate of valve is sufficiently large
relative to the compressed air consumption.
Loading too large. Check permissible weight and length of the
gripper fingers.
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
27
Maintenance and Care
6 Maintenance and Care
The product is not intended for maintenance.
Disassembly for maintenance or repair purposes is not possible.
A damaged product has to be replaced completely.
28
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Translation of original declaration of incorporation
7 Translation of original declaration of incorporation
in terms of the Directive 2006/42/EG, Annex II, Part 1.B of the European Parliament and of
the Council on machinery.
Manufacturer/
Distributor
SCHUNK GmbH & Co. KG Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
We hereby declare that on the date of the declaration the following partly completed
machine complied with all basic safety and health regulations found in the directive
2006/42/EC of the European Parliament and of the Council on machinery. The declaration
is rendered invalid if modifications are made to the product.
Product designation: 2-Finger-parallel gripper / GSP-P / pneumatic
ID number 311010, 311011, 311012, 311020, 311021, 311022,
311030,311031, 311032, 311050, 311051, 311052, 311060,
311061, 311062, 311080, 311081, 311082, 30040466
The partly completed machine may not be put into operation until conformity of the
machine into which the partly completed machine is to be installed with the provisions of
the Machinery Directive (2006/42/EC) is confirmed.
Applied harmonized standards, especially:
EN ISO 12100:2010 Safety of machinery - General principles for design -
Risk assessment and risk reduction
The manufacturer agrees to forward on demand the relevant technical documentation for
the partly completed machinery in electronic form to national authorities.
The relevant technical documentation according to AnnexVII, Part B, belonging to the
partly completed machinery, has been created.
Person authorized to compile the technical documentation:
Robert Leuthner, Address: see manufacturer's address
Lauffen/Neckar, June 2019 p.p. Ralf Winkler,
Manager for development
of gripping system components
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
29
Translation of original declaration of incorporation
7.1 Annex to Declaration of Incorporation
according 2006/42/EG, Annex II, No. 1 B
1.Description of the essential health and safety requirements pursuant to 2006/42/EC,
Annex I that are applicable and that have been fulfilled with:
Product designation 2-Finger-parallel gripper
Type designation GSP-P
ID number 311010, 311011, 311012, 311020, 311021, 311022, 311030,311031,
311032, 311050, 311051, 311052, 311060, 311061, 311062, 311080,
311081, 311082, 30040466
To be provided by the System Integrator for the overall machine ⇓
Fulfilled for the scope of the partly completed machine ⇓
Not relevant ⇓
1.1 Essential Requirements
1.1.1 Definitions X
1.1.2 Principles of safety integration X
1.1.3 Materials and products X
1.1.4 Lighting X
1.1.5 Design of machinery to facilitate its handling X
1.1.6 Ergonomics X
1.1.7 Operating positions X
1.1.8 Seating X
1.2 Control Systems
1.2.1 Safety and reliability of control systems X
1.2.2 Control devices X
1.2.3 Starting X
1.2.4 Stopping X
1.2.4.1 Normal stop X
1.2.4.2 Operational stop X
1.2.4.3 Emergency stop X
1.2.4.4 Assembly of machinery X
1.2.5 Selection of control or operating modes X
1.2.6 Failure of the power supply X
1.3 Protection against mechanical hazards
1.3.1 Risk of loss of stability X
1.3.2 Risk of break-up during operation X
1.3.3 Risks due to falling or ejected objects X
1.3.4 Risks due to surfaces, edges or angles X
30
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
Translation of original declaration of incorporation
1.3 Protection against mechanical hazards
1.3.5 Risks related to combined machinery X
1.3.6 Risks related to variations in operating conditions X
1.3.7 Risks related to moving parts X
1.3.8 Choice of protection against risks arising from moving parts X
1.3.8.1 Moving transmission parts X
1.3.8.2 Moving parts involved in the process X
1.3.9 Risks of uncontrolled movements X
1.4 Required characteristics of guards and protective devices
1.4.1 General requirements X
1.4.2 Special requirements for guards X
1.4.2.1 Fixed guards X
1.4.2.2 Interlocking movable guards X
1.4.2.3 Adjustable guards restricting access X
1.4.3 Special requirements for protective devices X
1.5 Risks due to other hazards
1.5.1 Electricity supply X
1.5.2 Static electricity X
1.5.3 Energy supply other than electricity X
1.5.4 Errors of fitting X
1.5.5 Extreme temperatures X
1.5.6 Fire X
1.5.7 Explosion X
1.5.8 Noise X
1.5.9 Vibrations X
1.5.10 Radiation X
1.5.11 External radiation X
1.5.12 Laser radiation X
1.5.13 Emissions of hazardous materials and substances X
1.5.14 Risk of being trapped in a machine X
1.5.15 Risk of slipping, tripping or falling X
1.5.16 Lightning X
1.6 Maintenance
1.6.1 Machinery maintenance X
1.6.2 Access to operating positions and servicing points X
1.6.3 Isolation of energy sources X
1.6.4 Operator intervention X
1.6.5 Cleaning of internal parts X
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
31
Translation of original declaration of incorporation
1.7 Information
1.7.1 Information and warnings on the machinery X
1.7.1.1 Information and information devices X
1.7.1.2 Warning devices X
1.7.2 Warning of residual risks X
1.7.3 Marking of machinery X
1.7.4 Instructions X
1.7.4.1 General principles for the drafting of instructions X
1.7.4.2 Contents of the instructions X
1.7.4.3 Sales literature X
The classification from Annex 1 is to be supplemented from here
forward.
2 Supplementary essential health and safety requirements for certain
categories of machinery
2.1 Foodstuffs machinery and machinery for cosmetics or pharmaceutical
products
2.2 Portable hand-held and/or guided machinery X
2.2.1 Portable fixing and other impact machinery X
2.3 Machinery for working wood and material with similar physical
characteristics
3 Supplementary essential health and safety requirements to offset
X
hazards due to the mobility of machinery
4 Supplementary essential health and safety requirements to offset
X
hazards due to lifting operations
5 Supplementary essential health and safety requirements for machinery
intended for underground work
6 Supplementary essential health and safety requirements for machinery
X
presenting particular hazards due to the lifting of persons
X
X
X
X
32
02.00 | GSP-P | Assembly and Operating Manual | en | 389033
