Page 1
CORINTH
BPD74232
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLE FINISHES
AB: Aged Brass BK: Black
DESCRIPTION
Adorned with large trillion-diamond shaped Schonbek optic haze crystals
composed of natural quartz gemstone. Corinth is a new statement on
crystal. Hidden light sources and powered aircraft cables elevate a
conservative prole with intrigue and technology. The solid double ring
body is nished in crystal haze and deploys ambient up lighting.
LINE DRAWING
10
a
s
1
"
"
8
2
"
9"
Model Size
BPD74232 32” 3000K/3500K/4000K
LED Color
Temp Finish Voltage Wattage Weight
Min 24"
Max 118"
8
"
Ø32
s
"
Ø28
ABBKAged Brass
Black
FEATURES
- Unique Optic Haze crystal diuser
- Each hand selected piece features unique variations
- Built-in color temperature adjustability switch from 3000K/3500K/4000K at
time of installation
- Thin powered aircraft cables provide an ultra clean look for adjustable
suspension height
- Spin-on round canopy with minimal hardware
- Thin canopy conceals a proprietary universal 120V-220V-277V driver
- Can be mounted on a sloped ceiling
SPECIFICATIONS
CRI 90
Dimming ELV, 0-10V, TRIAC
Standards ETL/cETL, Damp, Title 24
REPLACEMENT PARTS
- RPL-GLA-74232 - Optic Haze Crystal
LED
Lumens
120-277V 55W 44 lb 1589 1000
Delivered
Lumens
Example: BPD74232-BK
schonbek.com
Phone (800) 836.1892 | Fax: (518) 563.4228
Headquarters/Eastern Distribution Center
61 Industrial Blvd, Plattsburgh, NY 12901
