Page 1
MARTINI
5d"
BPD20207
BPD20207
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLE TRIM
O: Optic Crystal OH: Optic Haze
AVAILABLE FINISHES
AB: Aged Brass BK: Black PN: Polished Nickel
LINE DRAWING
5"
d
"
MIN 12"
MAX 135"
7"
2w"
REPLACEMENT PARTS
- RPL-GLA-20207O - Optic Crystal
- RPL-GLA-20207OH - Optic Haze
Model Size
BPD20207 1 light 3000K/3500K/4000K
Example: BPD20207OH-BK
LED Color
Temp Trim Option Finish Voltage Wattage Weight
O Optic Crystal
OH Optic Haze
DESCRIPTION
Suspended in mid-air, a jewel of Schonbek optic or optic haze crystal
composed of natural quartz gemstone illuminates to entice. The chiseled
metal tting is congruent with the faceted crystal to confer elegance in
design continuity.
FEATURES
- Built-in color temperature adjustability switch from 3000K/3500K/4000K at
time of installation
- Thin powered aircraft cables provide an ultra clean look for adjustable
suspension height
- Thin canopy conceals a proprietary 120/277V driver
- Spin-on round canopy with minimal hardware
- Optional decorative diamond texture diuser is included to be installed to
customer preference
- Can be mounted on a sloped ceiling
SPECIFICATIONS
CRI 90
Dimming ELV, TRIAC
Standards ETL/cETL, Damp, Title 24
LED
Lumens
AB
Aged Brass
BK
Black
PN
Polished Nickel
120/277V 8W 4 lb 657 UP TO 506
Delivered
Lumens
schonbek.com
Phone (800) 836.1892 | Fax: (518) 563.4228
Headquarters/Eastern Distribution Center
61 Industrial Blvd, Plattsburgh, NY 12901
