1743234 03/2009

TeSys

U LULC032-033 Modbus

Communication Module

User’s Manual

03/2009

1743234

www.schneider-electric.com

Schneider Electric assumes no responsibility for any errors that may appear in this document. If you have any suggestions for improvements or amendments or have found errors in this publication, please notify us.

No part of this document may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission of Schneider Electric.

All pertinent state, regional, and local safety regulations must be observed when installing and using this product. For reasons of safety and to help ensure compliance with documented system data, only the manufacturer should perform repairs to components.

When devices are used for applications with technical safety requirements, the relevant instructions must be followed.

Failure to use Schneider Electric software or approved software with our hardware products may result in injury, harm, or improper operating results.

Failure to observe this information can result in injury or equipment damage.

2 1743234 03/2009

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About the Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Part I Hardware Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 1 Installing the LULC032-033 Modbus Module . . . . . . . . . . . . . . . . . . . . . . . 11

Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Presentation of the LULC032-033 Modbus Communication Module . . . . . . . . . . . . . . . . . . . . 13

Description of the Module and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Electrical Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connection to the RS485 Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Chapter 2 Technical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Conditions of Use and Technical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Replacing an LULC031 Module with an LULC032-033 Module . . . . . . . . . . . . . . . . . . . . . . . . 35

Part II Software Implementation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Chapter 3 Starting up the Module via the Registers . . . . . . . . . . . . . . . . . . . . . . . . . . 41

General Information on Start-up via the Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Data-Exchange Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Factory Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Customizing Your Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Modbus Requests and Programming Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Use of the Main Registers for Simplified Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Chapter 4 Fault and Warning Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Displaying Faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Application Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Warnings - Loss of Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Internal Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Chapter 5 Configuration of Predefined Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Description of Reflex Stop Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Use of Reflex1 and Reflex2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

1743234 03/2009 3

4 1743234 03/2009

Safety Information

Important Information

NOTICE

Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

PLEASE NOTE

Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Schneider Electric for any consequences arising out of the use of this material.

A qualified person is one who has skills and knowledge related to the construction and operation of electrical equipment and the installation, and has received safety training to recognize and avoid the hazards involved.

1743234 03/2009 5

6 1743234 03/2009

At a Glance

Document Scope

Validity Note

About the Book

This Manual describes the implementation, functions and operation of the LULC032-033 Modbus communication module.

Area of application: mainly control system applications in the Industry and Building sectors.

Firmware version compatibility:

Product versions

LULC03• LUTM LUCM LUCMT

V1.1 V1.1 --- V2.06

LULC032

LULC033 V2.2 V1.2* V1.10* V2.11*

V1.2 V1.2* --- V2.10*

V1.3 V1.2* --- V2.11*

Hardware Implementation

This section describes the LULC032-033 Modbus communication module installation and technical characteristics.

This part contains the following chapters:

Chapter Chapter Name Page

1 Installing the LULC032-033 Modbus Module 11

2 Technical Characteristics 31

1743234 03/2009 9

Hardware Implementation

1743234 03/2009

nsta

lling the LULC032-033 Modb

1743234 03/2009

Installing the LULC032-033 Modbus Module

Introduction

This chapter introduces the LULC032-033 Modbus communication module and describes the various steps involved in the physical installation of the product.

What's in this Chapter?

This chapter contains the following topics:

Safety Instructions 12

Presentation of the LULC032-033 Modbus Communication Module 13

Description of the Module and Installation 15

Electrical Connection 18

Connection to the RS485 Bus 23

us Module

Topic Page

1743234 03/2009 11

Installing the LULC032-033 Modbus Module

Safety Instructions

General Instructions

HAZARDOUS OPERATION

These devices must be installed, configured and used by qualified staff only.

Users must follow all current instructions, standards and regulations.

Check the function settings before starting the motor.

Do not downgrade or modify these devices.

Failure to follow these instructions can result in injury or equipment damage.

PRECAUTIONS WHEN USING COMMUNICATION VARIABLES

Only use the serial link for transmitting data that is not critical to the application.

There is some delay in the transmission of data relating to motor-starter states and load-current values. This data must not therefore be used in the management of safety devices and emergency stops.

Data such as Forward, Reverse and Stop must not be used in safety and emergency-stop circuits.

Failure to follow these instructions can result in injury or equipment damage.

CAUTION

1743234 03/2009

Presentation of the LULC032-033 Modbus Communication Module

Receiving the Product

On opening the box containing the LULC032-033 Modbus communication module, you should find the following items:

- An Instruction Sheet (IS), providing brief pictorial information about the standard installation of the module

- An LULC032-033 Modbus communication module with connectors.

NOTE: Check that you actually have all the items described above. Make sure that the Quick Reference Guide is included, along with the correctly inserted connectors.

Functions offered

The communication module is used to control a motor-starter remotely, via Modbus, from:

LULC032 LULC033

TeSys U starter-controller LUB••/LU2B••  TeSys U starter LUS••/LU2S••  TeSys U controller LUTM•• 

NOTE: Modbus LULC032 communication modules should be used exclusively with LUTM10BL or LUTM20BL controllers.

Using the communication module, you can:

 Read the motor-starter states  Control the motor-starter (reversing or non-reversing)  Adjust the protection functions  Read the data processed in the advanced and multifunction control units  Read the state of the I/O (controller base)

Installing the LULC032-033 Modbus Module

DANGER

CONTROL VOLTAGE

The LULC032 Modbus communication module must only be used with 24 V control units (LUC•••BL).

Failure to follow these instructions will result in death or serious injury.

NOTE: For information on the Modbus protocol, please refer to the following website: www.Modbus.org.

1743234 03/2009 13

Installing the LULC032-033 Modbus Module

Data Available

The available protection and control data depend on the control unit with which the Modbus communication module is used.

There are 3 types of control unit:

 Standard (reference LUCA)  Advanced (references LUCB/C/D, LUCBT/DT)  Multifunction (references LUCM/MT)

The table below can be used to check the data and commands you can access with each type of control unit:

Data - Commands

Start and stop commands  

Status (ready, running, fault condition)

Warning 

Automatic reset and remote reset via the bus

Indication of the motor load  Differentiation of faults 

Remote parameter setting and viewing of all functions

'Log' function  'Monitoring' function 

Control unit

Standard (LUCA)

 

Advanced (LUCB/C/D, LUCBT/DT)



Multifunction (LUCM/MT)



1743234 03/2009

Description of the Module and Installation

Diagram of the Module

Connectors and indicator lights (LEDs) on the LULC032-033 Modbus communication module :

Installing the LULC032-033 Modbus Module

NOTE: The pinout differs from that on the LULC031 Modbus communication module.

1 Green "COMM" Modbus communication status LED. 2 Red "ERR" Modbus communication module fault indication LED. 3 Green "24V " LED indicating voltage presence at outputs OA1, OA3, LO1. 4 RJ45 connector for the Modbus RS485 link. 5 Connection of the module power supply. 6 Connection of the 24 V power supply for outputs OA1, OA3, LO1. 7 Discrete input 2. 8 Discrete input 1. 9 Discrete output 1, assignable depending on the configuration register (685 LSB). 10 24 V prewired coil connector for the power base.

 The assignment of OA1 depends on the configuration register (686 LSB).  The assignment of OA3 depends on the configuration register (686 MSB).

11 Connector for communication with the advanced or multifunction control unit.

1743234 03/2009 15

Installing the LULC032-033 Modbus Module

Description of Indicator Lights (LEDs)

Description of the various states of the indicator lights (light-emitting diodes, LEDs) on the LULC032-033 Modbus communication module.

Light-emitting diodes (LEDs)

Green "COMM" LED

Flashing (alternately with the "ERR" LED)

Flashing during communication with the Module address

Off

Red "ERR" LED

Flashing (alternately with the "COMM" LED)

Off On Normal operation

Off Off

On On

Flashing On

Green "24V

" LED

Meaning

Bus parameter initialization in progress

Faulty: 24 V DC voltage missing on the 24 V DC terminal. Check the connection between the power supply and the communication module.

Internal fault on the LULC032033 Internal Faults, page 59

Loss of communication on the Modbus network

NOTE: During startup, because the default fallback mode is "forced stop", if no communication has previously been established, the red "ERR" LED will flash after one minute (default timeout value).

Addressing Using Switches

The Modbus communication module address is defined by switches located on the underside of the module. Simply turn the module over to access them:

The range of accepted values is between 1 and 31.

The address coding is in binary format.

The least significant bit is on the right, indicated by .

Address 0 is not taken into account by the module, since it is used by the Master for a broadcast request.

Caution: Address selection differs from that on the LULC031 Modbus communication module.

NOTE: Addressing is only taken into account when the communication module is powered up.

1743234 03/2009

Order of Mounting on a Base

The LULC032 module is installed in a controller base, the LULC033 module is installed in a power base or a controller base (on the underside of the control unit which locks it in position).

To install the module in the power base or controller base:

Step Action

1 Choose the prewired coil connection terminals.

2 Insert the LULC032-033 Modbus communication module.

3 Insert the control unit which locks the module.

The diagram below illustrates these steps. Installation of the LULC032-033 Modbus communication module corresponds to step (2). The numbers indicate both the order of mounting for the components and their location.

Installing the LULC032-033 Modbus Module

1743234 03/2009 17

Installing the LULC032-033 Modbus Module

Electrical Connection

24 V and 24 V Aux Power Supply

Diagram for 24 V and 24 V Aux power supplies.

1743234 03/2009

Power-up with an LUCM Multifunction Control Unit

LUCM and Power Base

The power-supply source must be the same for the LULC032-033 Modbus communication module and the LUCM multifunction control unit.

It is essential that the LUCM multifunction control unit and the LULC032-033 Modbus communication module are powered up simultaneously. Indeed, monitoring of the internal dialog between the LUCM and the LULC032-033 will produce two error messages depending on the order in which these objects were powered up.

When the A1-A2 terminals are not yet powered up (24V ), there are 3 possible scenarios for powering up the 24V Aux:

Installing the LULC032-033 Modbus Module

Powering up the LUCM ...

Simultaneously Recommended

1st 2nd

2nd 1st

Powering up the LULC032-033 ...

Comment

The "M15" fault is displayed. This only occurs when the LULC032-033 Modbus communication module has already been used with the LUCM multifunction control unit.

The LUCM control unit is identified by the LULC032-033 Modbus communication module when the 24 V Aux for the LULC032-033 Modbus communication module is switched on. If the 24 V Aux for the LUCM control unit is switched on for longer than twice the duration of the timeout (i.e., more than 1 s), the "M101" fault is displayed (register 451, communication module internal faults).

NOTE: Both these faults are reset by powering down and then powering up the LULC032-033 Modbus communication module (power cycle) and the LUCM control unit.

LUCM and Controller Base

The 24 V module power supply is provided by the LUTM controller.

1743234 03/2009 19

Installing the LULC032-033 Modbus Module

Power Supply for the LULC032 and Outputs OA1, OA3 and LO1

In order to operate, the LULC032-033 Modbus communication module must be powered by a 24 V source:

 With a power base, the LULC033 must be powered by an external source.  With a controller base, the LULC032 or LULC033 is powered directly.

Power Supply for LUB••/LUS•• /LU2B••/LU2S•• Power Bases

1 24 V Aux: Power-supply terminal for the LULC033 Modbus communication module. 2 24 V ==: Power-supply terminal for outputs OA1 OA3 and LO1. 3 Prewired link for connecting outputs OA1 and OA3 to terminals A1/A3/A2 on the starter.

Power Supply for an LUTM Controller Base

1 24 V ==: Power-supply terminals for the LUTM and the LULC032-033 Modbus communication module via an

internal link.

2 The 24 V == power supply for the LULC032-033 Modbus communication module is only required when using

outputs OA1, OA3 and LO1.

1743234 03/2009

Power Base: Terminal Power Supply

The user has two options for connecting the power-base terminals:

 Power supply via the LULC033 Modbus communication module with a prewired link  Direct power supply with a wire-to-wire link

Prewired Link

Catalog numbers for the two prewired coils:

Designation With a power base Catalog number

Prewired coil

Illustration for both types of power base:

Installing the LULC032-033 Modbus Module

LUB••/LUS•• LU9B N11C

LU2B••/LU2S•• LU9M RC

Wire-to-Wire Link (Power Supply to Outputs OA1, OA3 and LO1)

This type of link is compulsory in the case of a reversing starter-controller created from an LU6M reversing unit, for separate assembly.

The wire-to-wire link can also be used to insert a local or external stop command, for example.

1743234 03/2009 21

Installing the LULC032-033 Modbus Module

Connection Capacities of the LULC032-033 Terminals

The table below shows the conductor cross-sections to be used:

Connection Type of conductor Cross-section (min. - max.)

Solid conductor

Stranded conductor

1 conductor

2 conductors (same cross-section)

Connectors 3 and 6 pts

Increment 3.81 mm 0.15 in.

Tightening torque 0.2/0.25 N.m. 28.3/35.4 lb-in.

Flat screwdriver 2.5 mm 0.10 in.

Stranded conductor with cable end:

- Non-insulated

- Insulated

2 solid conductors

2 stranded conductors

2 stranded conductors with cable end:

- Non-insulated

- Insulated

0.14 ... 1 mm

0.25 ... 1 mm

0.25 ... 0.5 mm

0.14 ... 0.5 mm

0.14 ... 0.75 mm

0.25 ... 0.34 mm

0.50 mm

AWG 26 ... AWG 18

AWG 24 ... AWG 18

AWG 24 ... AWG 20

AWG 26 ... AWG 20

AWG 24 ... AWG 22

AWG 20

1743234 03/2009

Connection to the RS485 Bus

General

There are several ways in which the user can connect the communication module to the RS 485 bus:

 Direct connection to the bus via a VW3A8306TF•• T-junction box  Connection to the bus via a splitter box  Connection to the bus via SCA type junction boxes

For Interference Protection:

Use the Schneider Electric cable with 2 pairs of shielded twisted conductors (references: TSXCSA100, TSXCSA200, TSXCSA500, VW3A8306TF••).

Keep the Modbus cable away from the power cables (at least 30 cm).

Create crossovers of the Modbus cable and the power cables at right-angles, if necessary.

NOTE: For more information, consult guide TSX DG KBL F: "Electromagnetic Compatibility of Industrial Networks and Fieldbuses".

The RS 485 standard allows variants of some characteristics:

 Polarization  Line terminator  Number of slaves  Length of bus

The new Modbus specification, published in 2002 on the Modbus.org site, defines all these characteristics precisely. All new Schneider Electric devices conform to this specification.

Installing the LULC032-033 Modbus Module

Connection to the Bus via a Tee

The standard diagram corresponds to the Modbus specification published in 2002 on the Modbus.org site (Modbus_over_serial_line_V1.pdf, Nov 2002) and in particular to the 2-wire multidrop serial bus diagram.

The LULC032-033 Modbus communication module conforms to this specification.

The simplified diagram is as follows:

Master

Slave 1 Slave 2

1743234 03/2009 23

Installing the LULC032-033 Modbus Module

The characteristics for direct connection to the bus are as follows:

Designation Description

Type of trunk cable Single shielded twisted pair cable and at least a 3rd conductor

Maximum length of bus 1000 m at 19,200 bps with the Schneider Electric TSX CSA•• cable

Maximum number of stations (without repeater)

Maximum length of tap-offs

Bus polarization

Line terminator A 150 ohm resistor +/- 5%

Common polarity Yes (Common), connected to the protective ground in at least one point on the bus

Connection to the Bus via a Splitter Box

The connection diagram for connection to the bus via a splitter box is as follows:

32 stations, i.e., 31 slaves

 20 m for one tap-off  40 m divided by the number of tap-offs on the multiple junction box

 A 450 to 650 ohm pulldown resistor at the 5 V  A 450 to 650 ohm pulldown resistor at the Common

This polarization is recommended for the master. There is no polarization at the RS 485 terminal on the communication module.

1 Master (PLC, PC or communication module) 2 Modbus cable depending on the type of master (with polarization integrated on the master side or on another part

of the bus)

3 Modbus splitter box LU9 GC3 4 Modbus drop cables VW3 A8 306 R•• 5 Line terminators VW3 A8 306 R 6 Modbus T-junction boxes VW3A8306TF•• (with cable) 7 Modbus cable (to another splitter box) TSX CSA•00 (replaces (5))

NOTE: It is advisable to place a line terminator at each end of the bus to avoid malfunctions on the

communication bus. This means that a tee should not have a free connector. It is either connected to a slave or to the master, or there is a line terminator.

NOTE: It is important to connect the bus to the "IN" input (or the screw terminals on the bottom) of the splitter box. Connection to another splitter box is made via the "OUT" output.

1743234 03/2009

Connection Diagrams (PLC <=> Splitter Box)

The two diagrams below describe the connection between:

 Channel 0 of the TSX CSY 21601 module and the LU9 GC3 splitter box using cable

TSX SCY CM6030

 PCMCIA card TSX SCP 114 and the LU9 GC3 splitter box using cable TSX SCP CX4030

NOTE: Ensure that the 470 ohm resistors are connected to the 0 V and 5 V polarities correctly.

Connection between TSX SCY 21601 module (channel 0) and splitter box LU9 GC3 using cable TSX SCY CM6030:

Installing the LULC032-033 Modbus Module

1 Green/White 2 White/Green

3 Orange/White 4 White/Orange

5 Brown/White

1743234 03/2009 25

Installing the LULC032-033 Modbus Module

Connection between PCMCIA/TSX SCP 114 card and LU9 GC3 splitter box using cable TSX SCP CX4030:

1 Green/White 2 White/Green

3 White/Orange 4 Orange/White

5 Brown/White

List of connection accessories:

Designation Catalog number

Modbus splitter box 10 RJ45 connectors and 1 screw terminal LU9 GC3

Modbus T-junction boxes With 0.3 m integrated cable VW3 A8 306 TF03

With 1 m integrated cable VW3 A8 306 TF10

Line terminators For RJ45 connector R = 150 ohms VW3 A8 306 R

List of connection cables:

Designation Length (meters) Connectors Catalog number

Cables for Modbus bus 3 1 RJ45 connector and 1 stripped end VW3 A8 306 D30

RS 485 double shielded twisted pair cables

0,3

1VW3A8 306R10

3VW3A8 306R30

100

200 TSX CSA 200

300 TSX CSA 500

2 RJ45 connectors

Supplied without connector

VW3A8 306R03

TSX CSA 100

1743234 03/2009

Installing the LULC032-033 Modbus Module

List of Modbus connection accessories for RJ45 wiring system:

Type of master Interface with the master Description Catalog number

Twido PLC Mini-DIN RS 485 adaptor or

interface module

Screw terminal RS 485 adaptor or interface module

TSX Micro PLC Mini-DIN RS 485 terminal

port

PCMCIA card (TSX SCP114)

TSX Premium PLC TSX SCY 11601 or TSX

SCY 21601 module (25-pin SUB-D port)

PCMCIA card (TSX SCP114)

Fipio (LUFP1) or

RS 485 RJ45 Cable, equipped with 2 RJ45 connectors, Profibus DP (LUFP7) or DeviceNet (LUFP9) gateway

Serial port PC PC with 9-pin male SUB-D

RS 232 serial port

3 m cable equipped with a mini-DIN

TWD XCA RJ030

connector and an RJ45 connector

3 m cable equipped with an RJ45

VW3 A8 306 D30

connector and stripped at the other end

3 m cable equipped with a mini-DIN

TWD XCA RJ030

connector and an RJ45 connector

Stripped cable TSX SCP CX4030

Cable equipped with a 25-pin SUB-D

TSX SCY CM6030 connector and stripped at the other end (for connection to the screw terminals on the LU9GC3 splitter box)

Stripped cable TSX SCP CX4030

of the following length:

- 0.3 m VW3 A8 306 R03

- 1 m VW3 A8 306 R10

- 3 m VW3 A8 306 R30

- RS 232/RS 485 converter TSX SCA 72

- 3 m cable equipped with an RJ45

VW3 A8 306 D30 connector and stripped at the other end (for connection to the screw terminals on the LU9GC3 splitter box)

1743234 03/2009 27

Installing the LULC032-033 Modbus Module

Connection to the Bus via SCA Junction Boxes

The connection diagram for connection to the bus via SCA junction boxes is as follows:

1 Master (PLC, PC or communication module). 2 Modbus cable depending on the type of master (with polarization integrated on the master side or on another part

of the bus).

3 Modbus cable TSX CSA•00. 4 TSX SCA 50 junction box (without line polarization). 5 TSX SCA 62 subscriber port (without line polarization). 6 Modbus drop cable VW3 A8 306. 7 Modbus drop cable VW3 A8 306 D30.

List of connection accessories:

Designation Catalog number

Junction box 3 screw terminals and RC line terminator, connected with cable VW3 A8 306 D30

Subscriber port 2 15-pin female SUB-D connectors, 2 screw terminals, and RC line terminator, connected with cable VW3 A8 306 or VW3 A8 306 D30

TSX SCA 50

TSX SCA 62

List of connection cables:

Designation Length

(meters)

Cables for Modbus bus 3 1 RJ45 connector and 1 stripped end VW3 A8 306 D30

5 1 RJ45 connector and 1 15-pin male SUB-

RS 485 double shielded twisted pair cables

100

200 TSX CSA 200

300 TSX CSA 300

Connectors Catalog number

VW3 A8 306

D connector for TSX SCA 62

TSX CSA 100

Supplied without connector

1743234 03/2009

Installing the LULC032-033 Modbus Module

List of Modbus connection accessories for junction box on screw terminals:

Type of master Interface with the master Description Catalog number

Twido PLC Screw terminal RS 485

adaptor or interface module

TSX Micro PLC Mini-DIN RS 485 terminal

port

PCMCIA card (TSX SCP114)

TSX Premium PLC TSX SCY 11601 or TSX

SCY 21601 module (25-pin SUB-D port)

PCMCIA card (TSX SCP114)

Profibus DP (LA9P307) gateway

Fipio (LUFP1) or Profibus DP (LUFP7) or DeviceNet (LUFP9) gateway

Serial port PC PC with 9-pin male SUB-D

RS 485 RJ45 3 m cable equipped with an RJ45

RS 232 serial port

Modbus cable TSX CSA100 or

TSX CSA200 or

TSX CSA500

Junction box TSX P ACC 01

Cable equipped with a special connector and stripped at the other end

Cable equipped with a 25-pin SUB-D connector and stripped at the other end

Cable equipped with a special connector and stripped at the other end

connector and stripped at the other end

RS 232/RS 485 converter and Modbus cable

TSX SCP CX4030

TSX SCY CM6030

TSX SCP CX4030

VW3 A8 306 D30

TSX SCA 72 and

TSX CSA100 or

TSX CSA200 or

TSX CSA500

RJ45 Connector Pinout

The communication module is connected to the Modbus network with an RJ45 connector in compliance with the following wiring:

Pin no. Signal

1 Do not connect

2 Do not connect

3 Do not connect

4 D(B) or D1

5 D(A) or D0

6 Do not connect

7 Do not connect

80 V.L

1743234 03/2009 29

Installing the LULC032-033 Modbus Module

1743234 03/2009

Technical Ch

1743234 03/2009

Technical Characteristics

Introduction

In addition to information about the module's conditions of use and technical characteristics, this chapter provides instructions on how to replace an LULC031 module with an LULC032-033.

What's in this Chapter?

This chapter contains the following topics:

Conditions of Use and Technical Characteristics 32

Replacing an LULC031 Module with an LULC032-033 Module 35

aracteristics

Topic Page

1743234 03/2009 31

Technical Characteristics

Conditions of Use and Technical Characteristics

The characteristics of the LULC032-033 Modbus communication module are as follows:

 Conditions of Use  Characteristics of the 24V and 24V Aux power supply circuits  Characteristics of the outputs (OA1, OA3 and LO1) and logic inputs (LI1 and LI2)

The communication characteristics (module Modbus port) are also described.

Conditions of Use

The conditions of use for the LULC032-033 Modbus communication module are as follows:

Certification UL, CSA

Conformity to standards

European Community Directives

Temperature of the ambient air around the device

IEC/EN 255-6, UL 508, CSA C22-2 No. 14

marking. Satisfies the essential requirements of the low voltage (LV) machinery and electromagnetic compatibility (EMC) directives.

Storage C - 40 ... + 85

Operation C - 25 ... + 55

24V Power Supply Circuit

The characteristics of the LULC032-033 Modbus communication module 24 V power supply circuit are as follows:

Supply voltage

Maximum current drawn

Resistance to microbreaks

24 V Aux power-supply circuit

The characteristics of the LULC032-033 Modbus communication module 24 V Aux power supply circuit are as follows:

Supply voltage

Maximum current drawn

Resistance to microbreaks

nominal

Operating range V 20 ... 28

nominal

Operating range V 20 ... 28

V24 V

ms 2

V24 V

mA 30

ms 3

1743234 03/2009

Logic Outputs OA1, OA3 and LO1

The characteristics of the LULC032-033 Modbus communication module outputs are as follows:

Technical Characteristics

Nominal output values

Output limit values

Coincidence factor of the 3 outputs

Output response time (register 704)

(Time between the request start bit and the change in the output state)

Protection

Number of operating cycles

Maximum rate In operating cycles per hour 3600

Logic inputs LI1 and LI2

The characteristics of the LULC032-033 Modbus communication module inputs are as follows:

Nominal input values

Input limit values

Response time

Type of input Resistive

Protection gl fuse A 1

Voltage V 24 V

Current mA 500

Voltage V 20 ... 28

Current mA 500

%66

5 (LUCA/B/C/D) 15 (LUCM)

Against overvoltage Yes

Against inversions Yes

Against short-circuits and overloads

In millions of operating cycles 15

Voltage V

Current mA 7

At state 1

At state 0

Change to state 1 ms 10 +/- 30 %

Change to state 0 ms 10 +/- 30 %

Voltage V 16

Current mA 6

Voltage V 5

Current mA 2

30 (LUCBT/DT) 45 (LUCMT) with stop bit

Electronic circuitbreaker with automatic reset

20 ... 28 (positive logic)

1743234 03/2009 33

Technical Characteristics

Communication (Modbus Port)

The technical characteristics of the LULC032-033 Modbus communication module Modbus port are as follows:

Factory configuration

Physical interface 1 Multidrop RS 485

Connections RJ45 on the front panel

Connection pinout

Protocol Modbus RTU

Physical address Range 1 to 31 (address 0 not permitted) 1

Logical address Range

Transmission speed Bps

Parity

Turnaround time ms

Schneider standard

D1 (DB) <--> pin 4 D0 (DA) <--> pin 5 OVL <--> pin 8

1 to 31 (addresses 32 to 247 not accessible)

1200, 2400, 4800, 9600, 19200 (automatic configuration up to this value)

Even, Odd (1 stop bit). No parity (1 or 2 stop bits)

5 (LUCA/B/C/D) 130 (LUCM) 7 (LUCBT/DT) 140 (LUCMT)

19200

Even*

* All versions (except LULC032 < V1.3: factory-configured with "No parity").

1743234 03/2009

Replacing an LULC031 Module with an LULC032-033 Module

Mounting

The section below presents the LULC031, LULC032 and LULC033 module characteristics in the form of tables.

Mounting modules in different types of base:

LULC031 LULC032 LULC033

Starter-controller LUB••/LU2B••

Controlling the I/O

Starter LUS••/LU2S••

Controller LUTM•0BL

Combining modules with a control unit:

LULC031 LULC032-033

LUC•••BL only

LUC•••BL only with code date > 0406

(Hardware locating device)

Control of outputs OA1 and OA3on LULC031 and LULC032-033:

Yes No Yes

No Yes Yes

Technical Characteristics

LUC•T1BL only (Hardware locating device)

LULC031 LULC032-033

Starter-controller LUB••/LU2B••

Yes Yes Yes

Starter-controller LUB••/LU2B••

Control of output LO1 on LULC031 and LULC032-033:

LULC031 LULC032-033

Yes Yes Yes

Reading inputs LI1 and LI2 on LULC031 and LULC032-033:

LULC031 LULC032-033

No Yes Yes

Control of outputs 13 and 23 on LULC031 and LULC032-033:

LULC031 LULC032-033

No Yes Yes

Controller LUTM•0BL

1743234 03/2009 35

Technical Characteristics

Electrical Connection

The LULC031 and LULC032-033 module terminals look like this:

LULC031

LULC032 LULC033

Communication Configuration

The address is selected using switches:

2 additional inputs, reduction in the number of commons

LULC031

Speed: 19200 baud - Parity: none/1 stop bit

(1) Least significant bit

LULC032 LULC033

Speed: 19200 baud - Parity: even*/1 stop bit

* All versions (except LULC032 < V1.3: factory-configured with "No parity").

NOTE: The speed and the parity are calculated automatically by the module. The speed indicated is a maximum value.

1743234 03/2009

Software Configuration

Fallback mode on loss of communication (value of default register):

Technical Characteristics

Starter-controller LUB• •/LU2B••

Starter LUS••/LU2S••

LULC031 682 = 0

No detection of loss of communication

LULC032 -

LULC033

681 = 6000 (timeout = 60 seconds) 682 = 2 (fallback mode = forced stop)

Controller LUTM• 0BL

681 = 6000 (timeout = 60 seconds) 682 = 2 (fallback mode = forced stop)

Indication of communication losses according to the fallback modes:

LULC031 LULC032-033

Forced stop mode: Fault indicated Other modes: Alarm indicated

Any mode: Alarm indicated Acknowledgment via register 703 bit 3

Firmware version number:

LULC031 LULC032-033

NOTE: If you are combining an LULC033 module with a multifunction control unit (LUCM) on a power base, you must reinitialize the LUCM on first use.

1743234 03/2009 37

Technical Characteristics

1743234 03/2009

Sof

Introduction

What's in this Part?

tware Implementation

1743234 03/2009

Software Implementation

Once the LULC032-033 Modbus communication module hardware implementation phase is complete, the software implementation can begin. It focuses on configuration (the various operating modes), and the function parameters to be set (e.g., protection, current measurement, etc.).

This part contains the following chapters:

Chapter Chapter Name Page

3 Starting up the Module via the Registers 41

4 Fault and Warning Management 55

5 Configuration of Predefined Functions 61

1743234 03/2009 39

Software Implementation

1743234 03/2009

tarting up the Module via the Registers

1743234 03/2009

Starting up the Module via the Registers

Introduction

This chapter describes how to start up the LULC032-033 communication module by means of the Modbus registers. It provides general information, describes the data-exchange format, the product’s factory configuration and how it can be customized, and also the Modbus read and write requests.

What's in this Chapter?

This chapter contains the following topics:

General Information on Start-up via the Registers 42

Data-Exchange Format 43

Factory Configuration 45

Customizing Your Configuration 46

Modbus Requests and Programming Examples 52

Use of the Main Registers for Simplified Management 53

Topic Page

1743234 03/2009 41

Starting up the Module via the Registers

General Information on Start-up via the Registers

All the LULC032-033 communication module settings are implemented - or simply displayed - via the Modbus registers.

Access to Parameters

The module I/O parameters are set by one of the following three methods:

 The Modbus RJ45 port, via the application PLC  The LUCM multifunction control unit’s terminal port  Locally, via the LUCM multifunction control unit’s keypad

1743234 03/2009

Data-Exchange Format

Modbus Format

Communication is based on the slave Modbus RTU protocol.

The data format is as follows:

1 start bit 8 data bits 1 parity bit 1 stop bit

NOTE: The detailed format of these requests is explained on the www.Modbus.org site.

Initialization

Initialization consists of two phases:

Starting up the Module via the Registers

When the auxiliary 24 V is powered up, the LULC032-033 Modbus communication module is initialized:

 The addressing is taken into account.  The type of control unit is taken into account.

At the end of the initialization phase, the LULC032-033 Modbus communication module automatically identifies the configuration parameters (speed and parity) of the RS 485 link as soon as traffic is detected on the network. After analysis of up to 20 frames at a speed of 19,200 baud, initialization continues (at 1200 baud, the number of frames is higher):

 The default or configured speed is taken into account.  The Master parity is taken into account.

Read-Write Zones

Exception Code

The memory zone from 0 to 19,999 can be accessed by the client.

- Reading the zone of a 'Reserved' register (or non-set) causes a correct response (value 0).

- Writing to the zone of a 'Reserved' register causes a correct response (value 0). The write operation is not taken into account and the contents remain equal to 0.

- Writing to the zone of a 'Read only' register causes a response with an exception code (code 03).

The memory zone 2000 is private and therefore reading/writing is not authorized. All accesses will be signaled by an exception code (code 02).

The presence of an exception code is indicated by the report from the PLC (refer to the Modbus master module documentation).

The Modbus exception codes supported are as follows:

Value of the exception code Name Comment

Hexadecimal Decimal

0x01 1 Illegal function Unknown request code

 Register address invalid  Access to the private memory

0x02 2 Illegal data address

0x03 3 Illegal data value

zone (address  20000)

 Writing to a "read-only" register

The memory zone is prohibited in both read and write modes

 Invalid value

The write command is interrupted

1743234 03/2009 43

Starting up the Module via the Registers

Speed and Parity

The recognized values are as follows:

Possible values Factory value

Speed 1200, 2400, 4800, 9600 and 19,200 baud. 19,200 baud

Parity Even, odd, no parity (parity bit deleted). Even*

* All versions (except LULC032 < V1.3: factory-configured with "No parity").

TSX Micro or Premium Platform

Applications for Micro and Premium PLCs are designed and implemented using PL7 software.

READ_VAR or WRITE_VAR requests (see Modbus Requests and Programming Examples) are used to read or write respectively the value of one or more consecutive objects of the same type (bit, word), in PL7 language.

NOTE: For more details concerning Modbus communication programming within a TSX platform, refer to the PL7 online help, Communication Volume 2/Modbus communication.

1743234 03/2009

Factory Configuration

The communication module parameters are set in order to determine:

 The operating mode  The reset mode for thermal overload faults  The correspondence between the communication module outputs and the LUTM controller inputs

The parameter registers (Modbus protocol) are accessible in read/write mode. The factory-set values are as follows:

Starting up the Module via the Registers

Topic Register Factor

y value

Reset mode for thermal

overload fault

Enable communication between LUCM/MT and LULC032

Fallback mode for control outputs on loss of communication

Local operating mode or via the bus with the LUTM and LULC032

Inversion of the LULC032 outputs

On power base, assignment of:

- Output LO1

- Output OA1

- Output OA3

On controller base, assignment of:

- Output 13

- Output 23

Recovery mode after stopping

Control unit ID 690 0 The control unit is identified automatically

602.0 1 "Manual" mode

602.4 1 Communication active

682 2

683 0

684 0

685 LSB 686 LSB 686 MSB

687 LSB 687 MSB1213

688 0

2 12 13

Meaning

Forced stop

Power base: OA1 and OA3 at 0 Controller base: 13 and 23 at 0

Mode for controlling the LUTM controller outputs "remotely via the bus"

The state of the outputs is the image of the control bits

LO1 is the state of control bit 700.0 OA1 is the state of control bit 704.0 OA3 is the state of control bit 704.1

13 is the state of control bit 704.0 23 is the state of control bit 704.1

The outputs revert to the state they were in before the power cut.

NOTE: For more information, refer to the "TeSys U Communication Variables" User’s Manual.

1743234 03/2009 45

Starting up the Module via the Registers

Customizing Your Configuration

You can use the factory settings (see Factory Configuration) or customize your configuration.

The following parameters can be set:

 Control unit configuration  Control unit ID  Timeout duration  Fallback mode  Control mode with a LUTM controller.  Inversion of the output states  Assignment of outputs LO1, OA1, OA3, 13 and 23  Recovery after stopping  Control unit forcing

UNEXPECTED OPERATION

A configuration can be loaded or edited via both Modbus ports (via the communication module or via the control unit LUCM). One configuration can then overwrite another, as the system does not prevent such an action. The result is not certain.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

WARNING

Control unit configuration (Reg 602)

Register 602 (accessible in read/write mode) is used to configure the control unit (reset mode 602.0-2, and communication 602.4).

Reg• Value Comment

602.0 1 Resetting is manual (by default). Bits 1 and 2 are at 0.

0 You have activated either bit 1 (remote reset) or bit 2

602.4 1 Communication with the LUCM/MT multifunction control

0 When forced to 0, this bit inhibits communication

Control unit configuration (Reg 680)

The control unit is identified each time the communication module is powered up.

However, the multifunction control unit memorizes the reference of the communication module assembled with it.

To use a multifunction control unit on its own, once it has been used with a communication module, identification register 680 is reinitialized locally via the keypad in the menu (Id = 0) or via the remote LUCM Modbus terminal port (value 0 written to register 680).

Timeout Duration (Reg 681)

Register 681 (accessible in read/write mode) is used to set or read the value of the timeout on loss of communication with the PLC. Following loss of communication, the timeout corresponds to the time before switching to fallback mode. Loss of communication results in a warning, which is signaled by register 460 = 109.

(automatic reset)

unit has been activated.

between the LUCM/MT multifunction control unit and the LULC032-033 Modbus communication module.

Reg• Value Range Unit

681 - 0 - 65535 10 ms 6000 Value of timeout

Factor y value

Comment

The value 0 represents a time of zero.

1743234 03/2009

Fallback mode (Reg 682)

Register 682 (accessible in read/write mode) is used to configure the fallback mode in the event of loss of communication with the PLC.

0 Ignored

1 Freeze outputs

2Stop

3 Signal comm loss warning

4 Force run forward

5 Force run reverse

AUTOMATIC RESTART OF THE MOTOR

When communication stops,outputs OA1-OA3 take the status corresponding to the selected fallback mode (register 682), but command bits 704.0 and 704.1 are not modified.

During the loss of communication warning (register 703 or push button on the controller), the motor will restart automatically if command bits 704.0 or 704.1 have not been reset to zero first by the PLC application.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Starting up the Module via the Registers

WARNING

1743234 03/2009 47

Starting up the Module via the Registers

Description of the different fallback modes:

Fallback Mode Loss of Communication Communication Recover Loss of Communication

Ignored (reg 682 = 0)

Freeze outputs (reg 682 = 1)

Stop (reg 682 = 2)

Signal comm loss warning (reg 682 = 3)

Force run forward (reg 682 = 4)

Force run reverse (reg 682 = 5)

Acknowledgement

No detection of the loss of communication

OA1 and OA3 keep their status

ERR LED blinking on the front face

OA1 and OA3 are forced to 0 OA1 and OA3 are forced to 0 On rising edge by bit 703.3

ERR LED blinking on the front face

OA1 and OA3 keep their status

ERR LED blinking on the front face

OA1 is forced to 1 OA3 is forced to 0

ERR LED blinking on the front face

OA1 is forced to 0 OA3 is forced to 1

ERR LED blinking on the front face

No detection of the loss of communication

OA1 and OA3 keep their status

ERR LED blinking on the front face

Every new On/Off command is stored but with no impact on OA1 and OA3

ERR LED blinking on the front face

Every new On/Off command is stored but with no impact on OA1 and OA3

OA1 and OA3 keep their status

ERR LED blinking on the front face

Every new On/Off command is considered and has an impact on OA1 and OA3

OA1 is forced to 1 OA3 is forced to 0

ERR LED blinking on the front face

Every new On/Off command is stored but with no impact on OA1 and OA3

OA1 is forced to 0 OA3 is forced to 1

ERR LED blinking on the front face

Every new On/Off command is stored but with no impact on OA1 and OA3

No acknowledgement of the loss of communication

On rising edge by bit 703.3 (do not leave set to 1)

Once the acknowledgement is done, the last command stored in register 704 is enabled

ERR LED switches off

(do not leave set to 1)

Once the acknowledgement is done, the last command stored in register 704 is enabled

ERR LED switches off

On rising edge by bit 703.3 (do not leave set to 1)

ERR LED switches off

On rising edge by bit 703.3 (do not leave set to 1)

Once the acknowledgement is done, the last command stored in register 704 is enabled

ERR LED switches off

On rising edge by bit 703.3 (do not leave set to 1)

Once the acknowledgement is done, the last command stored in register 704 is enabled

ERR LED switches off

NOTE: The red 'ERR' LED flashes to indicate a loss of communication (fault on timeout).

1743234 03/2009

Control Mode (Local/Bus) with an LUTM Controller (Reg 683)

Control of outputs 13 and 23 on the LUTM controller depends on the operating mode selected in register

683.

Value Operation Comment

'Remote via

1'Local' mode

the bus' mode

'Mixed' mode (input I.10 has priority)

Outputs 13 and 23 are only controlled by the bus.

The state of inputs I.1 and I.2 does not affect outputs 13 and 23.

Outputs 13 and 23 are only controlled by inputs I.1 and I.2.

Commands via the bus are not taken into account.

'Local' mode if I.10 = 1

'Remote via the bus' mode if I.10 = 0

NOTE: Commands transmitted during communication are passed directly to the output relays, without wiring between the communication module outputs and inputs I.1 and I.2.

Inversion of output states (Reg 684)

Depending on requirements (signaling, run, stop, etc.), it is possible to assign NO or NC behavior to outputs OA1, OA3 and LO1, by configuring register 684.

To do this, define the output concerned ==> register 684.

Starting up the Module via the Registers

Outputs 13 and 23 are only controlled by inputs I.1 and I.2.

Commands via the bus are not taken into account.

Outputs 13 and 23 are only controlled via the bus, from the PLC.

The state of inputs I.1 and I.2 does not affect outputs 13 and 23.

Power base Bit

Invert output OA1 Invert output OA3 Invert output LO1

Modifying Output Assignments

The tables below show how the assignments of outputs LO1, OA1, OA3, 13, and 23 can be modified. To modify the assignments (factory values), write a different value (0 to 45), referring to the 'TeSys U Communication Variables' User’s Manual.

UNEXPECTED OPERATION

Before modifying an output's assignment by means of parameterization, you must note the following information. Otherwise, you run the risk of unexpected operation.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Register 704 is used for controlling the motor-starter. The following are associated with this register: functions for monitoring loss of communication, fallback mode (register 682), reflex functions or recovery mode after stopping (register 688). Only the outputs activated by bits 704.0 and 704.1 benefit from these functions.

In addition, command bits 704.0 and 704.1 are independent and can be activated simultaneously.

Using register 700 to activate outputs is comparable with unconditional forcing.

Setting the parameters of output LO1 (Reg 685 LSB)

Assignment/control (factory value) of output LO1 on the LULC032 Modbus communication module is as follows:

_.0 = 1 _.1 = 1 _.2 = 1

WARNING

Reg• Bit Value Factory value Comment

685 0 to 7 0 to 45 2 Output LO1 = state of register 700.0

1743234 03/2009 49

Starting up the Module via the Registers

Setting the Parameters of Output OA1 (Reg 686 LSB)

Assignment/control (factory value) of output OA1 on the LULC032-033 Modbus communication module is as follows:

Reg• Bit Value Factory value Comment

686 0 to 7 0 to 45 12 Output OA1 = state of register 704.0

Setting the Parameters of Output OA3 (Reg 686 MSB)

Assignment/control (factory value) of output OA3 on the LULC032-033 Modbus communication module is as follows:

Reg• Bit Value Factory value Comment

686 8 to 15 0 to 45 13 Output OA3 = state of register 704.1

Setting the Parameters of Output 13 (Reg 687 LSB)

Assignment/control (factory value) of output 13 on the LUTM controller is as follows:

Reg• Bit Value Factory value Comment

687 0 to 7 0 to 45 12 Output 13 = state of register 704.0

Setting the Parameters of Output 23 (Reg 687 MSB)

Assignment/control (factory value) of output 23 on the LUTM controller is as follows:

Reg• Bit Value Factory value Comment

687 8 to 15 0 to 45 13 Output 23 = state of register 704.1

Recovery mode (Reg 688)

If you use register 704 to control outputs OA1-OA3, writing the value 1 to register 688 allows you to lock the motor and prevent it restarting following the occurrence of certain events:

 Loss followed by restoration of 24V DC (outputs OA1-OA3)  Change in position of rotary knob on power base followed by return to Ready position.

When one of these events occurs, command bits 704.0 and 704.1 (outputs OA1-OA3) are forced to 0 automatically. As long as one of these events remains pending, if values are written to register 704, the module will return exception code 02. Once these conditions have disappeared, control of the motor can be restored by sending a new run command.

AUTOMATIC RESTART OF THE MOTOR

In the case of cyclic writing to register 704 (e.g., an LUFP• gateway in its predefined configuration), this monitoring function must be used with caution. The application program must take this state into account and request that bits 704.0 or 704.1 are written to 0. Otherwise, when this event disappears, the motor will restart automatically.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

WARNING

1743234 03/2009

Forcing control unit (Reg 690)

The control unit is identified automatically, but identification can be forced.

Value Comment

0 Default value. The system automatically identifies the type of control unit

1 If the value is set to 1, this deactivates automatic identification and forces

2 If the value is set to 2, this deactivates automatic identification and forces

NOTE: (Read/Write) registers 681 to 690 can also be accessed via the LUCM keypad.

Starting up the Module via the Registers

connected (standard, advanced, multifunction).

identification of a standard or advanced control unit.

identification of a multifunction control unit.

1743234 03/2009 51

Starting up the Module via the Registers

Modbus Requests and Programming Examples

Modbus Requests

The recognized Modbus requests are as follows:

Code value

Hexadecimal Decimal

0x03 3 Read multiple registers Read mode

0x06 6 Write single register

0x10 16 Write multiple registers

0x2B 43 Read register identification

Name Comment

Write mode

Read mode for identifying the LULC032-033 Modbus communication module

The maximum number of registers per request is limited to 100.

NOTE: The "Broadcast" function is supported. To use it, a write operation (code 6 or 16) to address 00 is necessary.

WARNING

UNEXPECTED OPERATION

Use of this device on a Modbus network that uses the broadcast function should be considered with caution.

This device has a large number of registers that must not be modified during normal operation.

Unintended writing of these registers by the broadcast function may cause unexpected and unwanted product operation.

For more information, refer to the "Internal Communication Variables" User’s Manual.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Example of a Read Operation

The example below describes a READ_VAR request, within a TSX Micro or Premium platform, in order to read the motor-starter states at address 4 (slave no. 4) contained in internal word MW0:

1 Address of the module with which you wish to communicate: 3 (module address), 0 (channel), 4 (module address

on the bus)

2 Type of PL7 objects to be read: MW (internal word) 3 Address of the first register to be read: 455 4 Number of consecutive registers to be read: 1 5 Word table containing the value of the objects read: MW0:1 6 Read report: MW100:4

Example of a Write Operation

The example below describes a WRITE_VAR request, within a TSX Micro or Premium platform, in order to control a motor-starter by sending the content of internal word MW 502:

1 Address of the module with which you wish to communicate: 3 (module address), 0 (channel), 4 (module address

on the bus)

2 Type of PL7 objects to be written: MW (internal word) 3 Address of the first register to be written: 704 4 Number of consecutive registers to be written: 1 5 Word table containing the value of the objects to be sent: MW502:1 6 Write report: MW200:4

1743234 03/2009

Use of the Main Registers for Simplified Management

Before implementing a motor-starter, it is useful to know which of the main registers are invoked, and in what order.

Diagram of Register Usage

The diagram below provides basic implementation information, using the following registers: configuration, control and monitoring (system state, measurements, faults and warnings, acknowledgment). Starting with the factory configuration (predefined), you will easily be able to follow or anticipate how your system behaves.

Starting up the Module via the Registers

1743234 03/2009 53

Starting up the Module via the Registers

1743234 03/2009

Fault and Warning Management

1743234 03/2009

Fault and Warning Management

This chapter shows how to manage the various types of fault and warning that may occur.

What's in this Chapter?

This chapter contains the following topics:

Displaying Faults 56

Application Faults 57

Warnings - Loss of Communication 58

Internal Faults 59

Topic Page

1743234 03/2009 55

Fault and Warning Management

Displaying Faults

The presence of a fault is signaled by various indicators:

 State of the LEDs on the LULC032-033 Modbus communication module

With a power base:

 State of the power base rotary knob (0 or "trip")  State of the output relays

With a controller base:

 State of the LEDs on the controller base  State of the output relays

With a standard or advanced control unit:

 Internal signals sent to the LULC032-033 Modbus communication module

With a multifunction control unit:

 Warning  Message(s) displayed on-screen  Internal dialog with the LULC032-033 Modbus communication module

 Presence of an exception code (report from the PLC). See Exception Code, page 43.

NOTE: The warning and the fault are taken into account in the relevant registers. For more information, refer to the "TeSys U Communication Variables" User’s Manual: fault monitoring registers (450 to 452) and warning monitoring registers (460 to 461).

1743234 03/2009

Application Faults

Acknowledgement of Application Faults

The possible application faults are listed below. Their reset (or acknowledgment) method can be: manual/automatic/remote.

Fault and Warning Management

Application faults

Short-circuit fault 1 _.0 = 1

Overcurrent fault 2 _.1 = 1 I>> -

Thermal overload fault 4 _.3 = 1 Overload -

Application fault in the LUCM• multifunction control unit

Overload Fault with LU•B•/LU•S• Power Base

Following a thermal overload fault, either the rotary knob or the blue pushbutton on the front panel can be used, irrespective of which reset mode has been configured.

Configuration register

602.0 = 1

602.1 = 1 "Remote"

602.2 = 1 "Automatic" Managed by the control unit

Reset (acknowledgment)

"Direct "manual"

"Remote "manual"

Registers

451 Fault number

3 and 5 to 12

LULC032 LULC033

452 Fault bit

"ERR" (line 2) "FAULT"

Off

Refer to the User’s Manual for the LUCM••BL or LUCMT1BL multifunction control unit

Method

With the rotary knob on LU•B• With the blue pushbutton on LU•S•

With the LU9 AP•• kit on LU•B• With the LU9 •• kit on LU•S•

Acknowledgment by bit 704.3 This bit is active on rising edge and must be reset to 0 by programming.

LUCM• LUTM

DC -

Fault acknowledgment

Manual reset

According to the reset mode configured in register 602

Overload Fault with LUTM Controller Base

Following a thermal overload fault, either the blue pushbutton on the front panel or input I.5 can be used, irrespective of which reset mode has been configured.

Configuration register

602.0 = 1

602.1 = 1 "Remote"

602.2 = 1 "Automatic" Managed by the control unit

Reset (acknowledgment)

"Local "manual" With the blue pushbutton on the front panel

"Remote "manual"

Method

With the reset button on the front of the rack or control panel (via Input I.5)

Acknowledgment by bit 704.3 This bit is active on rising edge and must be reset to 0 by programming.

NOTE: The reset mode must be configured.

1743234 03/2009 57

Fault and Warning Management

Warnings - Loss of Communication

Warning Acknowledgment

List of possible warnings.

Warnings

Thermal overload warning

Loss of communication with the master warning

LUCM• multifunction control unit warning

Warnings

Registers

460 Warning number

4 _.3 = 1 -

109 _.15 = 1 Comm Loss -

2 and 4 to 13

Registers

460 Warning number

461 Warning bit

Refer to the User’s Manual for the LUCM••BL or LUCMT1BL multifunction control unit.

461 Warning bit

LULC032 LULC033

"ERR" (Line 1) "FAULT"

LULC032 LULC033

LUCM• LUTM

Overload warning

LUCM• LUTM

Acknowledgment of a warning

Automatic when the

overload is less than 85%

Acknowledgement by bit 703.3 This bit is active on rising edge and must be reset to 0 by programming.

Acknowledgment of a warning

LUTM external warning indicated by I.6 changing to 0

Recovery After Loss of Communication

After acknowledgment by setting bit 703.3 to 1, recovery occurs according to the states of control bits

704.0 and 704.1.

"ERR" (Line 2) "FAULT"

201 _.15 = 1 - Warn-M201

Automatic with I.6 returning to 1

1743234 03/2009

Internal Faults

Acknowledgment of Internal Faults

List of possible internal faults.

Fault and Warning Management

Registers

451

Internal faults

Fault on the LULC032-033 Modbus communication module

LULC032-033 Modbus communication module not installed or not supplied with power, or loss of communication with the module

Internal fault in the LUC•• control unit

Fault in the LUCM• multifunction control unit

Write-to-EEPROM fault 100 _.13 = 1 On M100 -

Communication fault with the LUCM• multifunction control unit

Checksum fault in EEPROM 102 _.13 = 1 On M102

EEPROM configuration fault 104 _.13 = 1 On M104

Communication fault with the LUTM controller base

Communication fault with the LULC032-033 module

Fault number

14 -

15 - M15 -

54 _.11 = 1 M54 -

51 to 53, 55 to 63Refer to the User’s Manual

101 _.12 = 1 On M101

105 _.13 = 1 On M105

205

452 Fault bit

for the LUCM••BL or LUCMT1BL multifunction control unit.

LULC032 LULC033

"ERR" (Line 2) "FAULT"

Off

LUCM• LUTM

M14 -

Fault acknowledgment

Power down and then power up the LULC032-033 and the LUCM•

Power down and then power up the LULC032-033

Rising edge on

704.3=1

Rising edge on

704.3=1

Power down and then power up the LULC032-033

Power down and then power up the LUTM

_.13 = 1 On -

No control unit 206

1743234 03/2009 59

Power down and then power up the LUTM

Fault and Warning Management

1743234 03/2009

Config

uration of Predefined Functions

1743234 03/2009

Configuration of Predefined Functions

This chapter describes the predefined functions.

What's in this Chapter?

This chapter contains the following topics:

Description of Reflex Stop Functions 62

Use of Reflex1 and Reflex2 64

Topic Page

1743234 03/2009 61

Configuration of Predefined Functions

Description of Reflex Stop Functions

The reflex stop ensures accurate repeated position control, unhindered by the bus and PLC scan times.

There are two types of reflex stop function:

 Reflex1: "Reflex stop 1" function  Reflex2: "Reflex stop 2" function

Description of Reflex1

Sensor no. 1 (logic input LI1) directly controls motor stopping.

After a new run command (stop command then run command), the motor restarts even if something is still detected (LI1=1).

1 Bus 2 Sensor no. 1 (LI1)

NOTE: In the case of a reversing starter, the reflex stop works in both directions.

Data sequence

1743234 03/2009

Description of Reflex2

Sensor no. 1 (logic input LI1) controls motor stopping in forward mode.

Sensor no. 2 (logic input LI2) controls motor stopping in reverse mode.

After a new run command (stop command then run command), the motor restarts even if something is still detected (LI1 or LI2 = 1).

NOTE: Sensor no. 2 (LI2) does not affect forward mode and sensor no. 1 (LI1) does not affect reverse mode.

Configuration of Predefined Functions

1 Bus 2 Sensor no. 1 (LI1) 3 Sensor no. 2 (LI2)

1743234 03/2009 63

Configuration of Predefined Functions

Use of Reflex1 and Reflex2

To use a "reflex stop" function, it must be selected in the register of the output to be monitored.

Reflex1.Fw

Reflex function

Reflex1

Reflex2

Direction of motor rotation

Reflex1.Fw = forward 8

Reflex1.Rev = reverse 9

Reflex2.Fw = forward 10

Reflex2.Rev = reverse 11

Value of Reg•

LUB••/S•• LU2B••/2S•• base

Output LO1

Reg685 (LSB)

Outputs OA1 OA3

Reg686 (LSB) (MSB)

LUTM•• base

Outputs 13 23

Reg687 (LSB) (MSB)

NOTE: Before using the "reflex stop" functions, outputs OA1/OA3 must first be assigned to the forward/reverse directions. This selection is made in register 686. By default, OA1 is assigned to forward and OA3 to reverse.

This function is active on a rising edge and not on the level.

LI1 = 1 stops the motor, irrespective of the chosen direction of operation.

.Fw

After a new run command (stop command followed by a run command),

even if logic input LI1 = 1,

the motor restarts in the chosen direction.

NOTE: Logic input LI2 is not used.

Reflex1.Rev

Reflex2.Fw

Reflex2.Rev

This function is active on a rising edge and not on the level.

LI1 = 1 stops the motor, irrespective of the chosen direction of operation.

.Rev

After a new run command (stop command followed by a run command),

even if logic input LI1 = 1,

the motor restarts in the chosen direction.

NOTE: Logic input LI2 is not used.

This function is active on a rising edge and not on the level.

Logic input LI1 = 1 stops the motor in forward mode. Logic input LI2 = 1 stops the motor in reverse mode.

.Fw

After a new run command (stop command followed by a run command),

even if logic input LI2 = 1,

the motor restarts.

NOTE: Logic input LI2 does not affect forward mode and logic input LI1 does not affect reverse mode.

This function is active on a rising edge and not on the level.

Logic input LI2 = 1 stops the motor in reverse mode.

.Rev

Logic input LI1 = 1 stops the motor in forward mode.

After a new run command (stop command followed by a run command),

even if logic input LI2 = 1,

the motor restarts.

NOTE: Logic input LI2 does not affect forward mode and logic input LI1 does not affect reverse mode.

1743234 03/2009

Ind

1743234 03/2009

Index

Acknowledgement

Application Fault, 57

Acknowledgment

Internal Fault, 59

Warning, 58 Addressing, 16, 36 Application Faults, 57

Cables, 26, 28 Conductor, 22 Connection, 15

SCA Junction Box, 28

Splitter Box, 24

Tee (Direct), 23 Connectors, 15 Control Mode, 49 Control unit

configuration, 46

Forcing, 51

Identification, 46 Control unit (LUC...), 14 Controller Base, 17, 19 Cords, 26, 28

Data Exchange

Exception Code, 43

Format, 43

Initialization, 43 Diagram of the Module, 15

Electrical Connection, 18 Exception Code, 43

Fallback mode, 47 Faults, 56 Forcing

Control unit, 51

Identification

Control unit, 46 Indicator Lights, 15, 16

Input, 33 Input (on Diagram), 15 Internal Faults, 59 Inversion

Output State, 49

Junction Box, 29

LEDs, 15, 16 Link

Prewired, 21

Wire-to-Wire, 21 Loss of communication, 47 Loss of Communication, 58 LUCA, 14 LUCB/C/D, 14 LUCM, 14, 19 LULC031, 15, 35

Modbus Format, 43 Modbus Port, 34 Modbus Request, 52

Read, 52

Write, 52 Module, 25 Module Functions, 13

Order of Mounting, 17 Output, 33

Setting, 49 Output (on Diagram), 15 Output State

Inversion, 49

Parameters, 42 Parity, 44 PCMCIA Card, 25 Pinout (RJ45), 29 PL7, 44 Power Base, 17, 19 Power Supply, 18, 20, 21, 32 Power-up, 19

1743234 03/2009 65

Index

Read-Write Zones, 43 Receiving the Product, 13 Recovery after stopping, 50 Reflex Stop, 62 Reflex1, 62, 64 Reflex2, 63, 64 Registers, 42, 45 RJ45, 26, 26, 28, 29 RJ45 Wiring, 26 RS 485 Bus, 23

Setting

output, 49 Speed, 44 Switches, 16, 36

Timeout

Duration, 46

Warning, 58

1743234 03/2009

Schneider LU9BN11C User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Safety Information

About the Book

Hardware Implementation

Installing the LULC032-033 Modbus Module

Safety Instructions

Presentation of the LULC032-033 Modbus Communication Module

Description of the Module and Installation

Electrical Connection

Connection to the RS485 Bus

Technical Characteristics

Conditions of Use and Technical Characteristics

Replacing an LULC031 Module with an LULC032-033 Module

Software Implementation

Starting up the Module via the Registers

General Information on Start-up via the Registers

Data-Exchange Format

Factory Configuration

Customizing Your Configuration

Modbus Requests and Programming Examples

Use of the Main Registers for Simplified Management

Fault and Warning Management

Displaying Faults

Application Faults

Warnings - Loss of Communication

Internal Faults

Configuration of Predefined Functions

Description of Reflex Stop Functions

Use of Reflex1 and Reflex2

Index
