en
IH: 15366
Applications
24 h + 7 d
1C
ARM
Function
Function: the time switch automatically opens and closes a circuit according to a
b
weekly and daily program established by plugging jumpers onto a moving dial. It is
designed to operate a load according to a daily program, only in half-days (morning
and afternoon) selected in the week.
7 d contact
1
status display
switch
24 h contact status
2
display switch
Inscription
3
in hours
Inscription in days
4
1 = Monday,
2 = Tuesday, etc.
Moving dial with
5
24 h jumpers
1
Fixed mark
6
7 d switch morning
7
(0 h-12 h)
off position
on position
7 d switch afternoon
8
(12 h-24 h)
off position
on position
2
For loads less than 2300 W.b For loads exceeding 2300 W, use in conjunction with a
Programming
Series connection of the 2 output contacts ensures
b
daily operation (24 h contact) repeated in time brackets
selected in half-days. The half days are in turn selected
in the week.
The yellow jumpers must be used for 24 h
b
programming (on/off in turn) (terminals 1-2-3).
The xed blue and red switches 7 and 8 must be
b
used for 7 d programming (on/off in turn)
(terminals 4-5-6).
Setting limits:
b
Gap between 2 slots = 15 min
v
Gap between 2 jumpers = 45 min.
v
3
Setting
Turn the graduated
b
dial in the direction
shown to bring the
gures for the required
day and hour opposite
the xed mark 6.
Check proper
b
operation of switching
by rotating the switches
and 2.
1
The quartz motion
b
(ARM) starts after a few
minutes.
4
Schneider Electric Industries SAS
35 rue Joseph Monier
CS 30323
F-92506 Rueil Malmaison Cedex (France)
tel : +33 (0)1 41 29 70 00
http://www.schneider-electric.com
Modifying
You can manually
reverse the existing
program by reversing the
position of switches 7
and/or 8.
Caution!
b
Do not forget to put the
switches back in their
initial position to recover
the existing program.
5
This product must be installed, connected and used in compliance with prevalling standards and/or installation regulations.
As standards, specications, designs and dimensions develop from time to time, always ask for conrmation of the information given in this publication.
b
contactor.
no switching
Sunday afternoon
In the above example the load will operate every Friday
b
morning from 3 a.m. to 6 a.m. and every Saturday afternoon
from 3 p.m. to 6 p.m.
Characteristics
Supply voltage: 230 V ±10 %
b
Frequency: 50/60 Hz
b
Rating: 10 A/250 Va cosφ = 1; 4 A/250 Va cosφ = 0.6
b
Consumption: 2.5 VA
b
Quartz motion
b
Operating reserve: 150 hours
b
Minimum time between 2 switchings: 45 min
b
Type of setting: 1 B STU according to EN 60730
b
Operating temperature: -10°C to +50°C
b
Terminal capacity: 6 mm
b
Overall dimensions: 6 modules of 9 mm.
b
Acceptable power
incandescent lamp 230 V 1100 W
halogen lamp 230 V 1100 W
non compensated uorescent tube/serial compensated
uorescent tube with conventional ballast
6
parallel compensated uorescent tube with
conventional ballast
dual-mounted uorescent tube with conventional ballast
parallel compensated sodium vapour lamp relay by contactor CT
parallel compensated HQL uorescent balloon relay by contactor CT
2
15 x 40 W - 10 x 58 W - 6 x 100 W
2 x 40 W (4.7 µF) - 1 x 58 W (7.0 µF)
5 x (2 x 58 W) - 3 x (2 x 100 W)
switching
Sunday morning
no switching
Friday afternoon
Rotation direction
switching
Friday morning
