Schenker XMG A500,XMG A700 User Manual

V10.1.00

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication. This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes. Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer. ©August 2010

Trademarks

Intel, Pentium and Intel Core are trademarks/registered trademarks of Intel Corporation.

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE Marking. A notified body has determined that this device has properly demonstrated that the requirements of the directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product. Secondly, CE Marking is mandatory for the product it applies to, whereas mo st q uality marking s are voluntary.

III

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for comp liance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienced radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference. And

2. This device must accept any interference, including interference that may cause undesired operation of the

device.

Preface

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-l ocated or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environ ment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the equipment.

If your purchase option includes both Wirele ss LAN and 3.75G modules, then the appropriate antennas will be installed. Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate in conjunction with any other antenna or transmitter.

Important Notice - 3.75G/HSPA & Bluetooth/Wireless LAN Modules

In order to comply with FCC regulations you should NOT operate the 3.75G/HSPA module and the Bluetooth/Wireless LAN modules at the same time as this may disrupt radio frequency, and cause interference. When the 3.75G/HSPA module is powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC

Output of 19V, 4.74A (90 Watts) minimum AC/DC Adapter.

This Computer’s Optical Device is a Laser Class 1 Product

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.

Do not expose the computer to any shock or vibration.

Do not place it on an unstable surface.

Do not place anything heavy on the computer.

Do not expose it to excessive heat or direct sunlight.

Do not leave it in a place where foreign matter or moisture may affect the system.

Don’t use or store the computer in a humid environment.

Do not place the computer on any surface that will block the Vents/Fan Intakes.

VII

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g proc edur es for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

5. Take care when using peripheral devices.

Do not turn off the power until you properly shut down all programs.

Do not turn off any peripheral devices when the computer is on.

Do not disassemble the computer by yourself.

Perform routine maintenance on your computer.

Use only approved brands of peripherals.

Unplug the power cord befor e attaching peripheral devices.

VIII

Preface

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still re quires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company.

• The power adapter may have either a 2-pr ong or a 3-prong grou nded plug. The third prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord , be sure to disconnect it by the plug head, not by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power cord if you ar e wet.

Do not use the power cord if it is broken.

Do not place heavy objects on the power cord.



Power Safety

Warning

Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on.

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansio n or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient temperature environments, and do not store unused batteries for extended per iods.

See also the general battery precautionary information overleaf for further information.

Preface

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replac ement to your service repre sent ative or qualified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.

Preface

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before turning the computer on.

XII

Preface

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapte r. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any peripherals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or r equire proof of ownersh ip for both ha rd-

ware and software. Make sure your documents are prepared.



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To pre vent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

XIII

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note: Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies) charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer. Wait a few minutes before turning it on so that any moisture can evaporate.

XIV

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods o f time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent and short breaks are better than fewer and longer breaks.

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

XVI

Preface

XVII

Preface

Contents

Notice .................................................................................I

FCC Statement ................................................................III

FCC RF Radiation Exposure Statement: ........................IV

Instructions for Care and Operation ...............................VI

Power Safety ................................................................ VIII

Polymer Battery Precautions ..........................................IX

Battery Precautions ..........................................................X

Cleaning .......................................................................... XI

Servicing .........................................................................XI

Travel Considerations ....................................................XII

Quick Start Guide

Overview ........................................................................1-1

Advanced Users .............................................................1-2

Beginners and Not-So-Advanced Users ........................1-2

Warning Boxes ............................................ ..................1-2

Not Included .................................................................. 1-3

System Startup ...............................................................1-4

System Software ...................................................... .... ..1-5

Model Differences .........................................................1-6

System Map: LCD Panel Open - Model A ....................1-7

System Map: LCD Panel Open - Model B ....................1-8

LED Indicators ...............................................................1-9

Hot Key Buttons & Keyboard .....................................1-10

Keyboard ......................................................................1-11

Function/Hot Key Indicators .......................................1-12

System Map: Front & Left Views ................................1-13

System Map: Right & Rear Views ..............................1-14

System Map: Bottom View - Model A ........................1-15

System Map: Bottom View - Model B ........................1-16

3.75G/HSPA Module USIM Card Installation ............1-17

Video Features .............................................................1-19

NVIDIA® Optimus™ Technology .............................1-19

Power Options ........................................ ......................1-23

MOFA LCD Back Covers - Model A ..........................1-24

Features & Components

Overview ........................................................................2-1

Hard Disk Drive .............................................................2-2

Optical (CD/DVD) Device ............................................2-3

Loading Discs ................................................................2-3

Handling CDs or DVDs .................................................2-4

DVD Regional Codes ............................................... .....2-5

Multi-In-1 Card Reader .................................................2-6

Touchpad and Buttons/Mouse .......................................2-7

Gestures and Device Settings ........................................2-8

XVIII

Preface

Audio Features .............................................................2-11

Adding a Printer ...........................................................2-13

USB Printer ..................................................................2-13

Parallel Printer .............................................................2-13

Power Management

Overview ........................................................................3-1

The Power Sources ........................................................3-2

AC/DC Adapter .............................................................3-2

Battery ............................................................................3-2

Turning On the Computer .............................................. 3-3

Power Plans ...................................................................3-4

Power-Saving States ......................................................3-7

Sleep ..............................................................................3-7

Hibernate ........................................................................3-8

Shut down ......................................................................3-8

Configuring the Power Buttons .....................................3-9

Resuming Operation ....................................................3-10

Energy Star Power Saving ...........................................3-11

Battery Information .....................................................3-12

Conserving Battery Power ...........................................3-13

Battery Life ..................................................................3-14

New Battery .................................................................3-14

Recharging the Battery with the AC/DC Adapter .......3-14

Proper handling of the Battery Pack ............................3-15

Battery FAQ .................................................................3-16

Drivers & Utilities

What to Install ................................................................4-1

Module Driver Installation ............................................. 4-1

Windows 7 Driver Installation .......................................4-2

Updating/Reinstalling Individual Drivers ......................4-4

User Account Control ....................................................4-5

Windows Security Message ...........................................4-5

New Hardware Found ....................................................4-5

Driver Installation Procedure ......................................... 4-6

Chipset ...........................................................................4-6

Video (VGA) .................................................................4 -6

NVIDIA Video (VGA) ..................................................4-6

MEI Driver .....................................................................4-6

LAN ...............................................................................4-6

CardReader ....................................................................4-6

Touchpad .......................................................................4-7

Hot Key ..........................................................................4-7

USB 3.0 ..........................................................................4-7

Audio .............................................................................4-7

Windows Experience Index ...........................................4-8

Optional Drivers ............................................................4-9

PC Camera Module ......................................................4-10

Wireless LAN Module .................................................4-10

XIX

Preface

3.75G/HSPA Module ...................................................4-10

BIOS Utilities

Overview ........................................................................5-1

The Power-On Self Test (POST) ................................... 5-2

Failing the POST ........................................................... 5-3

Fatal Errors ....................................................................5-3

Non-Fatal Errors ............................................................5-3

The Setup Utility ............................................................5-4

Entering Setup ...............................................................5-4

Setup Screens .................................................................5-5

Main Menu .....................................................................5-6

System Time & Date (Main Menu) ...............................5-6

SATA Port 1/2/3 (Main Menu) ......................................5-7

System/Extended Memory (Main Menu) ......................5-7

BIOS Revision/KBC/

EC Firmware Revision (Main Menu) ............................5-7

GPU Card/GPU VBIOS Revision/

GPU VBIOS Build Date (Main Menu) .........................5-7

Advanced Menu .............................................................5-8

Advanced Chipset Control (Advanced Menu) ..............5-8

On Board JMicron Power Saving (Advanced Menu >

Advanced Chipset Control) ...........................................5-9

Total Graphics Memory (Advanced Menu >

Advanced Chipset Control) ...........................................5-9

Bluetooth Power Setting (Advanced Menu >

Advanced Chipset Control) ...........................................5-9

SATA Mode (Advanced Menu) ....................................5-9

Legacy USB Support: (Advanced Menu) ....................5-10

Boot-time Diagnostic Screen (Advanced Menu) .........5-10

Legacy OS Boot: (Advanced Menu) ...........................5-10

Power on Boot Beep (Advanced Menu) ......................5-10

Battery Low Alarm Beep (Advanced Menu) ...............5-10

Security Menu ..............................................................5-11

Set Supervisor Password (Security Menu) ..................5-11

Set User Password (Security Menu) ............................5-12

Password on boot: (Security Menu) .............................5-12

Boot Menu ...................................................................5-13

Exit Menu ....................................................................5-14

Upgrading The Computer

Overview ........................................................................6-1

When Not to Upgrade ....................................................6-2

Removing the Battery ....................................................6-3

Upgrading the Hard Disk Drive .....................................6-4

Upgrading the Optical (CD/DVD) Device ....................6-7

Upgrading the System Memory (RAM) ........................6-9

Changing the Optional LCD Back Covers ..................6-12

Preface

Modules & Options

Overview ........................................................................7-1

PC Camera Module ........................................................7-2

PC Camera Driver Installation .......................................7-3

Wireless LAN Module .................................................7-10

802.11b/g/n Driver Installation ....................................7-11

Intel® Wi-Fi Link Series Driver Installation ...............7-11

Connecting to a Wireless Network in Windows 7 .......7-12

Intel® My WiFi Configuration ....................................7-15

Windows Mobility Center ...........................................7-27

3.75G/HSPA Module ...................................................7-28

Mobile Partner .............................................................7-31

Mobile Partner Application Installation ......................7-31

Mobile Partner Application .........................................7-32

Profile Management .....................................................7-32

Text Messaging Service ...............................................7-36

BandLuxe HSDPA Utility ...........................................7-37

BandLuxe HSDPA Utility Installation ........................7-37

BandLuxe HSDPA - Connection Manager ..................7-38

Creating a Profile .........................................................7-41

Choosing a Profile .......................................................7-44

Editing a Profile ...........................................................7-45

Text Messaging Service (SMS) ...................................7-46

Setting ..........................................................................7-49

Statistics & Information ...............................................7-55

Fingerprint Reader Module ..........................................7-56

Fingerprint Reader Driver Installation .........................7-57

User Enrollment ...........................................................7-58

Fingerprint Control Center Features ............................7-60

Bluetooth Module ........................................................7-61

Bluetooth Combo Driver Installation ..........................7-62

Bluetooth & WLAN Combo Settings ..........................7-63

Bluetooth Networking Setup .......................................7-66

Bluetooth & WLAN Combo Module Configuration ...7-67

Troubleshooting

Overview ........................................................................8-1

Basic Hints and Tips ......................................................8-2

Backup and General Maintenance .................................8-3

Viruses ...........................................................................8-4

Upgrading and Adding New Hardware/Software .......... 8-5

Problems and Possible Solutions ...................................8-7

Bluetooth Connection Problems ..................................8-13

Wake On LAN Setup ...................................................8-17

Interface (Ports & Jacks)

Overview .......................................................................A-1

Notebook Ports and Jacks .............................................A-2

XXI

Preface

Video Driver Controls

Video Driver Installation ..............................................B-2

Video (VGA) ................................................................B-2

NVIDIA Video (VGA) .................................................B-2

NVIDIA® Optimus™ Technology .............................. B-3

Dynamic Video Memory Technology ......................B-6

Intel® Graphics & Media Control Panel ...................... B -7

Display Devices & Options ...................................... B-9

Attaching Other Displays ...........................................B-10

Configuring an External Display in Windows 7 .........B-12

HDMI Audio Configuration .......................................B-15

NVIDIA Control Panel ...............................................B-18

Optimus™ Customization Options .............................B-20

Set PhysX® Configuration .........................................B-24

Video Settings .............................................................B-25

Specifications

Processor .......................................................................C-2

Core Logic ................................................................... .C-3

Display .......................................................................... C-3

Memory .........................................................................C-3

Video .............................................................................C-3

BIOS .............................................................................C-3

Storage ..........................................................................C-3

Audio ............................................................................C-3

Keyboard, Pointing Device & Buttons ......................... C-4

Interface ........................................................................C-4

Card Reader ..................................................................C-4

Slots ..............................................................................C-4

Communication .............................................................C-4

Communication (Cont’d) ..............................................C-5

Power Management .................................................. ....C-5

Power ............................................................................C-5

Security ......................................................................... C-5

Operating System ..........................................................C-5

Design Feature ..............................................................C-5

Environmental Spec ......................................................C-5

Dimensions & Weight ..................................................C-5

XXII

Preface

Overview 1 - 1

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk, optical device, card reader), Touchpad & Mouse, Audio & Printer.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s PC Camera, Wireless LAN, 3.75G/HSPA, Bluetooth, and Fin- gerprint modules (some of which may be optional depending on your purchase configuration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external devices.

• Appendix B Information on the video driver controls.

• Appendix C The computer’s specification.

1 - 2 Overview

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on

page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the information contained in the Quick Start Guide should be enough to get you up and running. Eventually you should try to look through all the documentation (more detailed descriptions of the functions, setup and system controls are covered in the remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.



Notes

Check the light colored boxes with the mark above to find detailed information about the computer’s features.

Overview 1 - 3

Quick Start Guide

Not Included

Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

Ports and Jacks

See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.

1 - 4 System Startup

Quick Start Guide

System Startup

1. Remove all packing materials.

2. Place the computer on a stable surface.

3. Securely attach any pe ripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

4. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC adapter.

5. Use one hand to raise the

lid/LCD to a comfortable viewing angle (

do not exceed 120 degrees

);

use the other hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by the lid/LCD).

Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In



Shutdown

Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows. This will help prevent hard disk or system problems.

System Startup 1 - 5

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system.



Windows OS

In order to run Windows 7 without limitations or decreased performance, your computer requires a minimum 1GB of system memory (RAM), however if you are running Windows 7 64 bit your computer requires a minimum 2GB of system memory (RAM).

1 - 6 Model Differences

Quick Start Guide

Model Differences

This notebook series includes two different model types that mainly differ as indicated in the table below. Note that your model may appear slightly different from those pictured in this manual.

Table 1 - 1 - Model Differences

Feature Model A Model B

Display Type Supported

15.6” (39.62cm) HD (1366 * 768) / HD+ (1600 *

900) / FHD (1920 * 1080) 16:9 LCD Panel

17.3” (43.94cm) HD+ (1600 * 900) / FHD (1920 *

1080) 16:9 LCD Panel

MOFA LCD Back Cover Factory Option N/A

3.75G Module

UMTS/HSPDA-based 3.75G Module

with USB Mini-Card Interface

(Factory Option)

N/A

Fingerprint Module Factory Option N/A

Dimensions & Weight

374mm(w) * 250mm(d) * 25-37.2mm(h)

2.6 kg with ODD & 48.84WH Battery

413mm(w) * 277.5mm(d) * 25.1-38.9mm(h) -

w/o MOFA

3.1 kg with ODD & 48.84WH Battery

System Map: LCD Panel Open - Model A 1 - 7

Quick Start Guide

System Map: LCD Panel Open - Model A

Figure 1 - 2

LCD Panel Open -

Model A

1. Built-In PC Camera (

Optional

)

2. LCD

3. Power Button

4. GPU Button

5. LED Indicators

6. Hot Key Buttons

7. Keyboard

8. Built-In Microphone

9. Touchpad & Buttons

10. Fingerprint Reader (Factory Option)

Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines above.



Wireless Device

Operation Aboard

Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.

Use the key combinations to toggle power to the 3.75G/

HSPA/WLAN/Bluetooth

modules, and check the LED indicator or on-screen icon to see if the modules are powered on or not (see Table 1 -

5, on page 1 - 12/ Table 1 3, on page 1 - 9).

1 - 8 System Map: LCD Panel Open - Model B

Quick Start Guide

System Map: LCD Panel Open - Model B

Figure 1 - 3

LCD Panel Open

Model B

1. Built-In PC Camera (

Optional

)

2. LCD

3. Power Button

4. GPU Button

5. LED Indicators

6. Hot Key Buttons

7. Keyboard

8. Built-In Microphone

9. Touchpad & Buttons

Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines above.



Wireless Device

Operation Aboard

Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.

Use the key combinations to toggle power to the WLAN/ Bluetooth modules, and check the LED indicator or on-screen icon to see if the modules are powered on or not (see Table 1 - 5, on

page 1 - 12/ Table 1 - 3, on page 1 - 9).

LED Indicators 1 - 9

Quick Start Guide

LED Indicators

The LED indicators on the computer display helpful information about the current status of the computer.

Table 1 - 2 - Front Left LED Indicators

Table 1 - 3 - Top Case LED Indicators

Icon Color Description

Orange DC Power is Plugged In

Green The Computer is On

Blinking Green

The Computer is in Sleep

Mode

Orange The Battery is Charging

Green The Battery is Fully Charged

Blinking Orange

The Battery Has Reached

Critically Low Power Status

Green Number Lock Activated

Green Caps Lock Activated

Green

Scroll Lock Activated (to

activate press Fn & Scr Lk)

Icon Color Description

Green UMA Mode Activated

Orange Optimus Mode Activated

Green Intel Integrated GPU (iGPU) Activated

Orange NVIDIA Discrete GPU (dGPU) Activated

Green

The (optional) WLAN Module is

Powered On

Orange

The (optional) Bluetooth Module is

Powered On

White Hard Disk Activity

White The Computer is Powered On

1 - 10 Hot Key Buttons & Keyboard

Quick Start Guide

Hot Key Buttons & Keyboard

Press the hot key buttons on the computer to toggle the appropriate function on/off.

Table 1 - 4 - Hot Key Buttons

Icon Color Description

Green UMA Mode Activated

Orange Optimus Mode Activated

The (optional) Wireless LAN Module is Powered On

Volume Mute is Enabled

The (optional) PC Camera is Powered On

White The Computer is Powered On



Other Keyboards

If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot-keys unique to the system’s regular keyboard may not work.

NumLk & ScrLk

Hold down the Fn Key and either NumLk or ScrLk to enable number or scroll lock, and check the LED indicator for status.



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special characters. These special characters can only be produced by using the numeric keypad. Regular number keys (in the upper row of the keyboard) will not work. Make sure that NumLk is on.

Keyboard 1 - 11

Quick Start Guide

Keyboard

The keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 5, on page 1 - 12 for full function key combina- tion details.

Figure 1 - 4 - Keyboard

Numerical Keypad

Play/Pause Key

Function Keys

NumLk & ScrLk Keys

Fn Key

1 - 12 Function/Hot Key Indicators

Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed.

Table 1 - 5 - Function & Hot Key Indicators

*Make sure that Wireless is ON in the Windows Mobility Center to ensure proper wireless function key behavior (see “Wireless Hot

Keys” on page 3 - 13).

Keys Function Keys Function

Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F5/F6

Volume Decrease/Increase

Fn +

3.75G Module Power Toggle*

Fn + F7 Display Toggle

Fn + F1

Touchpad Toggle

Fn + F8/F9

Brightness Decrease/Increase

Fn + F2

Turn LCD Backlight Off

(Press a key to or use Touchpad to turn on)

Fn + F10

PC Camera Power Toggle

Fn + F3

Mute Toggle

Fn + F11

*WLAN Module Power Toggle

Fn + F4 Sleep Toggle Fn + F12

Bluetooth Module Power Toggle

System Map: Front & Left Views 1 - 13

Quick Start Guide

System Map: Front & Left Views

Figure 1 - 5

Front & Left Views

1. LED Indicators (see

Table 1 - 2, on page 1 - 9)

2. External Monitor Port

3. RJ-45 LAN Jack

4. HDMI-Out Port

5. 2 * USB 2.0 Ports

6. e-SATA Port

7. Vent/Fan Intake

8. 1 * USB 3.0 Port or USB 2.0 Port (Factory Option)

9. Multi-In-1 Card Reader



Multi-In-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / RS MMC

SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible

MS (Memory Stick) / MS Pro / MS Duo

USB 3.0 Port OR USB 2.0 Port

Some models in this series have a single USB 3.0 port (Factory Option) on th e left side of the computer, other models will have a USB 2.0 port. The USB 3.0 port is denoted by its blue color; USB 2.0 ports are colored black.

Note that the USB 3.0 port requires a driver installation (see “USB 3.0” on page 4 - 7) and does not support wake on USB.

5 5

1 - 14 System Map: Right & Rear Views

Quick Start Guide

System Map: Right & Rear Views

Figure 1 - 6

Right & Rear Views

1. Headphone-Out Jack

2. Microphone-In Jack

3. S/PDIF-Out Jack

4. USB 2.0 Port

5. Optical Device Drive Bay

6. Security Lock Slot

7. Battery

8. DC-In Jack

1 253 4



CD/DVD Emergency Eject

If you need to manually eject a CD/DVD (e.g. due to an unexpected power in terruption) you may push the end of a straightened paper clip into the emergency eject hole. Do not use a sharpened pencil or any object that may break and become lodged in the hole. Don’t try to remove a floppy disk/CD/DVD while the system is accessing it. This may cause the system to “crash”.

Disk Eject Warning

Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop the disk first then eject it, or press the stop button twice.

System Map: Bottom View - Model A 1 - 15

Quick Start Guide

System Map: Bottom View - Model A

Figure 1 - 7

Bottom View

Model

1. Battery

2. Component Bay Cover

3. Fan Intake

4. Hard Disk Bay Cover

5. Speakers



Battery Information

Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery

Information” on page 3 12 for full instructions.



CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.

1 - 16 System Map: Bottom View - Model B

Quick Start Guide

System Map: Bottom View - Model B

Figure 1 - 8

Bottom View

Model B

1. Battery

2. Component Bay Cover

3. Fan Intake

4. Hard Disk Bay Cover

5. Speakers



CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.



Battery Information

Information” on page 3 12 for full instructions.

3.75G/HSPA Module USIM Card Installation 1 - 17

Quick Start Guide

3.75G/HSPA Module USIM Card Installation

If you have included an optional 3.75G/HSPA module in your purchase option (Factory Option for Model A Computers Only), follow the instructions below to install the USIM card (which will be provided by your ser-

vice provider), and then run the Mobile Partner application. See “Mobile Partner” on page 7 - 31 for instruc- tions on installing the program etc.

1. Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated below and slide the battery out).

2. Insert the USIM card (a t the rea r of the batter y comp artment ) as ill ustrated below until it clicks fully into position, and replace the battery.

Figure 1 - 9 - Battery Removal & USIM Card Insertion



USIM Card

Orientation

Note that the USIM card’s readable side (with the gold-colored contacts) should face upwards as illustrated.

1 - 18 3.75G/HSPA Module USIM Card Installation

Quick Start Guide

Windows 7 Start Menu & Control Panel

Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu icon , and then select Properties if you want to customize the appearance of the Start menu.

In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel is accessed from the Start menu, and it allows you to configure the settings for most of the key features in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features, however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all controls it may be necessary to toggle off Category View to view the control panel icons.

Figure 1 - 10 - Start Menu & Control Panel

Click here to toggle Category View

Video Features 1 - 19

Quick Start Guide

Video Features

NVIDIA® Optimus™ Technology

NVIDIA® Optimus™ technology is a seamless technology designed to get best performance from the graphics system while allowing longer battery life, without having to manually change settings. When the computer is in Optimus Mode it will automatically switch between the integrated UMA (Unified Memory Architecture) GPU (iGPU) and the discrete GPU (dGPU) when required by the applications in use. This switch is seemless to the user and does not require any use of the GPU button (see “NVIDIA® Optimus™ Technology” on page B - 3).

The GPU button allows you to switch between the Optimus Mode (where GPU switching is automatically handled) and UMA Mode (for constant power-saving with the integrated GPU only).

Table 1 - 6 - GPU Modes & GPU LED Indicators

You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 7 (see over). For more detailed video information see “Video Driver Con-

trols” on page B - 1.

Icon Color Description Note

Green UMA Mode Activated

The GPU LED indicators will display which GPU is currently in use.

Orange Optimus Mode Activated

Green Integrated GPU (iGPU) Activated

Orange Discrete GPU (dGPU) Activated

1 - 20 Video Features

Quick Start Guide

To access Display (Control Panel) and Screen Resolution in Windows:

1. Click Start and click Control Panel.

2. Click Display (icon) - In the Appearances and Personalization category.

3. Click Adjust Screen Resolution/Adjust resolution.

4. Alternatively you can right-click the desktop and select Screen resolution.

5. Use the dropbox to select the screen Resolution (Figure 1 - 11).

6. Click Advanced settings (Figure 1 - 11) to bring up the Advanced properties tabs.

Figure 1 - 11 - Screen Resolution

Video Features 1 - 21

Quick Start Guide

To access the Intel(R) Graphics and Media Control Panel:

1. Click Advanced settings (Figure 1 - 11 on page 1 - 20) in the Display Settings control panel in Windows.

2. Click Graphics Properties (button) (Figure 1 - 12) in the Intel Graphics & Media Control Panel tab.

3. Right-click the desktop and select Graphics Properties from the menu.

4. Click the icon (Figure 1 - 12) in the taskbar and select Graphics Properties from the menu.

5. Access the Intel(R) Graphics and Media Control Panel from the Windows control panel in Classic View.

Figure 1 - 12 - Intel Graphics and Media Control Panel

234

1 - 22 Video Features

Quick Start Guide

To access the NVIDIA Control Panel:

1. Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 13).

2. Double-click the icon (Figure 1 - 13) in the Windows control panel.

Figure 1 - 13 - NVIDIA Control Panel

Power Options 1 - 23

Quick Start Guide

Power Options

The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 16 ) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu. Note that the Power saver plan may have an affect on computer performance.

Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to create a new plan. Click Change plan settings and click Change advanced power settings to access further configuration options.

Pay attention to the instructions on battery care in “Battery Information” on page 3 - 12.

Figure 1 - 14 - Power Options

1 - 24 MOFA LCD Back Covers - Model A

Quick Start Guide

MOFA LCD Back Covers - Model A

MOFA (Magic of Film Art) technology allows fashionable and unique pictorial designs to be printed on the specially designed changeable LCD back covers. If your purchase option includes the specially designed changeable LCD back cover option (Model A Computers Only), then follow the instructions in “Changing the

Optional LCD Back Covers” on page 6 - 12 to change the covers (note these covers are not applicable to all

models in this series - consult your service center for details).

Figure 1 - 15 - Magic Of Film Art Optional LCD Back Covers

Features & Components

Overview 2 - 1

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components of the computer:

•Hard Disk Drive

• Optical (CD/DVD) Device

• Multi-In-1 Card Reader

• Touchpad and Buttons/Mouse

• Audio Features

• Adding a Printer

Features & Components

2 - 2 Hard Disk Drive

Hard Disk Drive

The hard disk drive is used to store your data in the computer. The hard disk can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.

The hard disk is accessible from the bottom of your computer as seen below. For further details see “Upgrading the Hard Disk Drive” on page 6 - 4.



Power Safety

Before attempting to access any of the internal components of your computer please ensure that the machine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral cables, including phone lines, are disconnected from the computer.

Figure 2 - 1

Hard Disk Location

HDD Bay

Model A

Model B

Features & Components

Optical (CD/DVD) Device 2 - 3

Optical (CD/DVD) Device

There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page C - 3). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu” on page 5 - 13).

Loading Discs

To insert a CD/DVD, press the open button and carefully place a CD/DVD onto the disc tray with label-side facing up (use just enough force for the disc to click onto the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you are ready to start. The busy indicator will light up while data is being accessed, or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole

to open the tray.



Sound Volume

Adjustment

How high the sound volume can be set depends on the setting of the volume control within Win- dows. Click the Volume icon on the taskbar to check the setting (see

“Audio Features” on page 2 - 11).

Figure 2 - 2

Optical Device

123

Features & Components

2 - 4 Optical (CD/DVD) Device

Handling CDs or DVDs

Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be accessed.

Note the following:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.



CD Emergency Eject

If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break and become lodged in the hole.

Disk Eject Warning

Don’t try to remove a CD/DVD while the system is accessing it. This may cause the system to “crash”.

Features & Components

Optical (CD/DVD) Device 2 - 5

DVD Regional Codes

To change the DVD regional codes:

1. Go to the Control Panel

2. Double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives.

3. Double-click on the DVD-ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control p anel to allow yo u to adjust the regional code.



DVD Region Note

DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer.

Figure 2 - 3

DVD Region Codes

• Region 1 - USA & Canada

• Region 2 - Western Europe, Japan,

South Africa, Middle East & Egypt

• Region 3 - South-East Asia, Taiwan,

South Korea, The Philippines, Indonesia, Hong Kong

• Region 4 - South & Central Amer-

ica, Mexico, Australia, New Zealand

• Region 5 - N Korea, Russia, Eastern

Europe, India & Most of Africa

• Region 6 - China

Features & Components

2 - 6 Multi-In-1 Card Reader

Multi-In-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s). Make sure you install the card reader driver (see

“CardReader” on page 4 - 6.

Note: Some of these cards require PC adapters that are usually supplied with the cards.



Card Reader Cover

Make sure you keep the rubber cover provided in the card reader when not in use. This will help prevent foreign objects and/or dust getting in to the card reader.

Figure 2 - 4

Left View

1. Card Reader

• MMC (MultiMedia Card) / RS MMC

• SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible

• MS (Memory Stick) / MS Pro / MS Duo

Features & Components

Touchpad and Buttons/Mouse 2 - 7

Touchpad and Buttons/Mouse

The Touchpad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse.

Once you have installed the Touchpad driver (see “Touchpad” on page 4 - 7) you can configure the functions by double-clicking the Touchpad driver icon on the taskbar. You may then configure the Touchpad tapping, buttons, scrolling (see sidebar), pointer motion and sensitivity options to your preferences.



Touchpad Scrolling

This computer model series may feature different Touchpad versions.

These Touchpads may differ in their vertical scrolling function in most scrollable windows.

Some Touchpads require sliding the finger up and down on the right of the Touchpad to scroll the window. Other versions require tapping/holding down the finger at the top right or bottom right of the Touchpad to scroll the window.

Figure 2 - 5

Mouse Properties

Features & Components

2 - 8 Touchpad and Buttons/Mouse

Gestures and Device Settings

The Synaptics Gestures Suite application allows you to use a specific gesture (action) on the surface of the Touchpad to perform specific actions to manipulate documents, objects and applications.

You can configure the settings from the Device Settings tab in Mouse Properties:

1. Click

Start

, and click

Control Panel

(or point to

Settings

and click

Control Panel

2. Click Mouse (Hardware and Sound).

3. Click Device Settings (t ab) and click Settings.

4. Use the menu tree on the left to access the user configurable settings.



Show Video

You can get a clearer view of the gestures involved by clicking the Show Video option for each gesture item.

Select the gesture (Pinch

Zoom, Rotating, Three Fingers Down and Three Finger Flick) in the Device Settings > Settings left tree menu

and click the Show Video button to see the demonstration video.

For more details on any of the gestures see the help in the lower part of the right menu window.

Figure 2 - 6

Mouse Properties -

Device Settings

Features & Components

Touchpad and Buttons/Mouse 2 - 9

Scrolling

The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight continuous motion).

Zooming

The Pinch Zoom gesture can be used to perform the same function as a scroll wheel in Windows applications that support CTRL + scroll wheel zoom functionality. Place two fingers on the Touchpad (for best results use the tips of the fingers) and slide them apart to zoom in, or closer together to zoom out.

Figure 2 - 7

Scrolling Gesture



Mouse Driver

If you are using an external mouse your operating system may be able to auto-configure your mouse during its installation or only enable its basic functions. Be sure to check the device’s user documentation for details.

Figure 2 - 8

Zooming Gesture

Features & Components

2 - 10 Touchpad and Buttons/Mouse

Rotating

Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.

Three Finger-Flick/Three Fingers Down (Press)

The Three Finger-Flick gesture may be used to enhance navigation with a variety of applications such as browsing the Internet or scrolling through a photo viewer. The Three Fingers Down gesture may be used to launch user-selectable applications.

Figure 2 - 9

Rotating Gesture

Figure 2 - 10

Flick/Press

Gesture

Features & Components

Audio Features 2 - 11

Audio Features

You can configure the audio options on your computer from the Sound control panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Deck control panel .

The volume may also be adjusted by means of the Fn + F5/F6 key combination.



Sound Volume

Adjustment

The sound volume level is set using the volume control within Windows (and the volume function keys on the computer). Click the volume icon in the taskbar to check the setting.

Figure 2 - 11

VIA HD Audio Deck

Click Expert Mode to access the Advanced menus

Features & Components

2 - 12 Audio Features

Expert Mode will allow you to access more advanced configuration menus.

See “HDMI Audio Configuration” on page B - 14 for more information on the audio settings for HDMI.

Figure 2 - 12

VIA HD Audio Deck

(Expert Mode)

Features & Components

Adding a Printer 2 - 13

Adding a Printer

The most commonly used peripheral is a printer. The following conventions will help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.

USB Printer

Most current printers have a USB interface connection. You may use any one of the ports to connect the printer.

Install Instructions:

1. Set up the printer according to its instructions (u npacking, p aper tr ay, toner/ink cartridge etc.).

2. Turn ON the computer.

3. Turn ON the printer.

4. Connect the printer’s USB cable to one of the USB port s on the computer.

5. Windows will identify the printer and either load one of its own drivers or ask you to supply one. Follow the on-screen instructions.

Parallel Printer

This is still a very common type of printer. The install instructions are in the sidebar, however you will need to purchase a parallel to USB converter.



Parallel Printer

After setting up the printer attach the parallel cable to the printer.

Connect the printer’s parallel cable to the Parallel to USB converter, and then plug the converter into the USB port.

Turn ON the printer, then turn ON the computer.

Windows will identify the printer and either load one of its own drivers or ask you to supply one. Follow the on-screen instructions.

Features & Components

2-14

Power Management

Overview 3 - 1

Chapter 3: Power Management

Overview

To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer (the LCD and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Energy Star Power Saving

• Battery Information

The computer uses enhanced power saving techniques to give the operating system (OS) direct control over the power and thermal states of devices and processors. For example, this enables the OS to set devices into low-power states based on user settings and information from applications.



OS Note

Power management functions will vary slightly depending on your operating system. For more information it is best to refer to the user’s manual of your operating system.

(Note: All pictures used on the following pages are from the Windows 7 OS.)

Power Management

3 - 2 The Power Sources

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components.

1. Attach the AC/DC adapter to the DC-in jack at the rear of the computer.

2. Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the AC/DC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging (see “How do I completely discharge the battery?”

on page 3 - 16).

We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 12.

Power Management

Turning On the Computer 3 - 3

Turning On the Computer

Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down). Use Power Options in the Windows control panel to configure this feature.



Forced Off

If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t work, press the power button for 4 seconds, or longer, to force the system to turn itself off.

Power Button as

Stand by or

Hibernate Button

You can use the OS’s Power Options control panel to set the power button to send the system into Stand by or Hibernate mode (see your OS’s documentation, or

“Configuring the Power Buttons” on page 3

- 9 for details).



Shut Down

Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows. This will help prevent hard disk or system problems.

Power Management

3 - 4 Power Plans

Power Plans

The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one.

The settings may be adjusted to set the display to turn off after a specified time, and to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.



Resuming Operation

See Table 3 - 1, on

page 3 - 10 for informa-

tion on how to resume from a power-saving state.

Password

It is recommended that you enable a password on system resume in order to protect your data.

Figure 3 - 1

Power Plan

Advanced Settings

(Win 7)

Power Management

Power Plans3-5

Each Windows power plan will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this scheme may slow down the overall performance of the computer in order to save power) for maximum power saving when the computer is battery (DC power) powered. The recommended Balanced power plan will balance power saving and performance.

Figure 3 - 2

Power Plans

Click to Show/Hide additional power plans

Power Management

3 - 6 Power Plans

An additional power plan will be available when you switch the computer to UMA Mode (for constant power-saving with the integrated GPU only). As UMA mode is

usually used to save the maximum amount of power through the integrated graphics system, the UMA Mode power plan’s standard settings are also configured to save the maximum amount of power if selected.

When the system is switched to Optimus mode, the UMA Mode power plan will return to Balanced.

Figure 3 - 3

Power Plans

in UMA Mode

Power Management

Power-Saving States 3 - 7

Power-Saving States

You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the system sleeps. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left off (what was on your desktop) without reopening the application(s) and file(s) you last used.

If your mobile PC in Sleep is running on battery power the system will use only a minimum amount of power. After an extended period the system will save all the information to the hard disk and shut the computer down before the battery becomes depleted.

Power Management

3 - 8 Power-Saving States

Hibernate

Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hi- bernate will also return you to where you last left off within seconds. You should put your mobile PC into Hibernate if you will not use the computer for a period of time, and will not have the chance to charge the battery.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan to be away from the computer for several days, or you do not need it to wake up and run a scheduled task. Returning to full operation from Shut down takes longer than from Sleep or Hibernate.

Figure 3 - 4

Start Menu Power

Power Management

Configuring the Power Buttons 3 - 9

Configuring the Power Buttons

The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power-saving state. Click Choose what the power buttons do on the left menu in Power Options to bring up the menu.



Password

Protection

It is recommended that you enable a password on wake up in order to protect your data.

However you can disable this setting from the Power Options menu by clicking Require a

password on wakeup

in the left menu, and selecting the options (click

Change settings that are currently unavailable).

Figure 3 - 5

Power Options

Define Power

Buttons

Power Management

3 - 10 Configuring the Power Buttons

Resuming Operation

You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo).

Power Status

Icon Color

To Resume

Power Off Off Press the Power Button

Sleep Blinking Green

Press the Power Button

Press the Sleep Button (Fn + F4 Key Combo)

Hibernate

Off (battery)

Press the Power Button

Orange (AC/DC adapter)

Display Turned Off Green Press a Key or Move the Mouse/Touchpad



Closing the Lid

If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.

Table 3 - 1

Resuming Operation



3.75G/HSPA

Modules & System

Wake Up

Note that the 3.75G modules

DO NOT

support

system wake up on

3.75G/HSPA modem activity.



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down hot key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down).

Power Management

Energy Star Power Saving 3 - 11

Energy Star Power Saving

This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. If you want to enable Energy Star power saving then follow these instructions:

1. Right-click the taskbar icon (see sidebar).

2. Select Power Conservation Modes.

3. Select Energy Star to use the Energy Star power management and override other power saving settings.



Taskbar Icon

If the taskbar icon does not appear then click the taskbar arrow and select

Customize.

Select Show icon and notifications alongside

the Hot key icon and click OK. The icon will now appear in the taskbar.

Figure 3 - 6

Energy Star Menu



Conservation Modes

The default Energy Star setting will result in maximum power saving, but with the possible loss of some performance. Setting the mode to Balance will give power saving matched with performance. Performance will give optimum computer performance but with less power conservation.

Power Management

3 - 12 Battery Information

Battery Information

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from power plan Change plan settings > Change advanced power settings (see Figure

3 - 1 on page 3 - 4).

Click the battery icon in the taskbar to see the current battery level and charge status.



Low Battery

Warning

When the battery is critically low, immediately connect the AC/DC adapter to the computer or save your work, otherwise, the unsaved data will be lost when the power is depleted.

Figure 3 - 7

Battery Icon

(Taskbar) & Battery

Advanced Settings

Power Management

Battery Information 3 - 13

Conserving Battery Power

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or communication applications when they are not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices, ExpressCards etc.



Wireless Hot Keys

The computer’s wireless function keys will not function properly if Wireless is turned OFF in the Win-

dows Mobility Center

control panel.

The wireless indicators

may show that the WLAN module is powered on, however if wireless is OFF in the Mobility Center, the module will not be powered on.

Make sure that Wireless is ON in the Mobility Center to ensure proper function key behavior.

Figure 3 - 8

Windows Mobility

Center



Windows Mobility

Center

The Windows Mobility Center control pan-

el provides an easy point of access for information on battery status, power plans used and wireless device status etc.

Make sure Wireless is ON to ensure proper function key behavior.

Power Management

3 - 14 Battery Information

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days.

We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see “Removing the Battery”

on page 6 - 3.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 16 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it will take several hours to fully recharge the battery. When the computer is turned off but plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-

tors” on page 1 - 9 for information on the battery charge status, and to “Battery Information” on page 3 - 12 for more information on how to maintain and properly

recharge the battery pack.)

Power Management

Battery Information 3 - 15

Proper handling of the Battery Pack

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

• DO NOT connect the metal terminals (+, -) to each other



Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your service center. If the battery has been d roppe d we do not recommend using it any further, as even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire . It is recommended that you replace your computer battery every two years.

Power Management

3 - 16 Battery Information

Battery FAQ

How do I completely discharge the battery?

Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.

1. Save and close all files and applications.

2. Create a power plan for discharging the battery and set all the options to Never.

Figure 3 - 9

Power Plan Create

Power Management

Battery Information 3 - 17

3. Click Change plan sett ings (after creating it) and click Change plan settings > Change advanced power settings.

Figure 3 - 10

Change Plan

Settings / Change

Advanced Power

Settings

Power Management

3 - 18 Battery Information

4. Scroll down to Battery and click + to expand the battery options.

5. Choose the options below (click Yes if a warning appears):

• Low battery levels = 0%

• Critical battery Levels = 1%

• Low battery action = Do Nothing

• Critical battery action (On battery) = Shut Down

• Critical battery action (Plugged in) = Do Nothing

Figure 3 - 11

Power Options

Advanced Settings -

Battery

Power Management

Battery Information 3 - 19

How do I fully charge the battery?

When charging the battery, don’t stop until the LED charging indicator light changes from orange to green.

How do I maintain the battery?

Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

Power Management

3-20

Drivers & Utilities

What to Install 4 - 1

Chapter 4: Drivers & Utilities

This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during operating system installation. Instead, you need to manually install some system-required drivers and utilities.

What to Install

The Devic e Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper operation of the computer. Table 4 - 1, on page 4 - 3 lists what you need to install and it is very important that the drivers are installed in the order indicated.

Module Driver Installation

The procedures for installing drivers for the PC Camera, Wireless LAN, 3.75G/HSPA, Fingerprint and Bluetooth Combo modules are provided in “Modules & Options” on page 7 - 1.

Drivers & Utilities

4 - 2 Windows 7 Driver Installation

Windows 7 Driver Installation

Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers/Option Drivers (butto n).

Figure 4 - 1 - Drivers Installer Screen 1

1. Check the driver installation order from Ta ble 4 - 1, on page 4 - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below.

2. Click to select the driver you wish to install, (you should note down the drivers as you install them).

3. Follow the instructions for each individual driver installation procedure as listed on the following pages.

Drivers & Utilities

Windows 7 Driver Installation 4 - 3

Figure 4 - 2 - Drivers Installer Screen 2

Table 4 - 1 - Driver Installation

Driver for Windows 7 Page #

Chipset Page 4 - 6

Video (VGA) Page 4 - 6

NVIDIA Video (VGA) Page 4 - 6

MEI Driver Page 4 - 6

LAN Page 4 - 6

CardReader Page 4 - 6

Touchpad Page 4 - 7

Hot Key Page 4 - 7

USB 3.0 Page 4 - 7

Audio Page 4 - 7

PC Camera Module Page 7 - 3

Wireless LAN Module

Page 7 - 11

3.75G/HSPA Module (Model A Only)

Page 7 - 28

Fingerprint Reader Module (Model A Only)

Page 7 - 56

Bluetooth Module (Driver for Combo Module Only)

Page 7 - 62

Drivers & Utilities

4 - 4 Windows 7 Driver Installation

Manual Driver Installation

Click Bro wse CD/DVD (button) in the Drivers Installer application and browse to the executable file in the

appropriate driver folder.

Windows Update

After installing all the drivers make sure you enable Windows Update in order to get all the latest securi ty updates etc. (all updates will include the latest hotfixes from Microsoft). See “Windows Update” on page 4 -

8 for instructions.

Updating/Reinstalling Individual Drivers

If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go to the Control Panel in the Windows OS and double-click the Programs and Features icon (Pro- grams > Uninstall a program). Click to select the driver (if it is not listed see below) and click Uninstall, and then follow the on screen prompts (it may be necessary to restart the computer). Reinstall the driver as outlined in this chapter.

If the driver is not listed in the Programs and Fea- tures menu:

1. Click Start, and click Control Panel (or point to Settings and click Control Panel).

2. Double-click Device Manager (Hardware and Sound > Device Manager).

3. Double-click the device you wish to update/reinstall the driver for (you may need to click “+” to expand the selection).

4. Click Driver (tab) and click the Update Driver or Uninstall button and follow the on screen prompts.

Drivers & Utilities

Windows 7 Driver Installation 4 - 5

User Account Control

If a User Account Control prompt appears as part of the driver installation procedure, click Continue or Allow, and follow the installation procedure as directed.

Windows Security Message

If you receive a Windows security message as part of the driver installation process. Just click “Install this driver software anyway” or “Install” to continue the installation procedure.

You will receive this message in cases where the driver has been released after the version of Windows you are currently using. All the drivers provided will have already received certification for Windows.

New Hardware Found

If you see the message “New Hardware Found” during the installation procedure (other than when out- lined in the driver install procedure), click Cancel to close the window, and follow the installation procedure.



Driver Installation General Guidelines

The driver installation procedure outlined in this Chapter (and in Chapter 7 Options & Modules), are accurate at the time of going to press.

Drivers are always subject to upgrade and revision so the exact procedure for certain drivers may differ slightly. As a general guide follow the default on screen instructions for each driver (e.g. Next > Next > Finish) unless you are an advanced user. In many cases a restart is required to install the driver.

Make sure any modules (e.g. PC Camera, WLAN or

3.75G/HSPA) are ON before installing the appropriate driver.

Drivers & Utilities

4 - 6 Windows 7 Driver Installation

Driver Installation Procedure

Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button).

Chipset

1. Click 1.Install Chipset Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer .

Video (VGA)

1. Click 2.Install VGA Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer.

NVIDIA Video (VGA)

1. Click 3.Install nVIDIA VGA Driver > Yes.

2. Click Next > Next.

3. Click Finish to restart the computer.

Note: After installing the video driver go to the Display/Display Settings control panel to adjust the vid-

eo settings to the highest resolution.

MEI Driver

1. Click 4.Install MEI Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish.

LAN

1. Click 5.Install LAN Driver > Yes.

2. Click Install.

3. Click Finish.

CardReader

1. Click 6.Install Cardreader Driver > Yes.

2. Click Install.

3. Click Finish.

Drivers & Utilities

Windows 7 Driver Installation 4 - 7

Touchpad

1. Click 7.Install Touchpad Driver > Yes.

2. Click Next.

3. Click the button to accept the license agreement

and click Next.

4. Click Finish > Restart Now to restart the com-

puter.

Hot Key

1. Click 8.Install Hotkey AP > Yes.

2. Click Next > Next.

3. Click Finish > Finish to restart the computer.

USB 3.0

1. Click 9.Install USB 3.0 Driver > Yes.

2. Click Next.

3. Click the button to accept the license agreement

and click Next.

4. Click Next > Install.

5. Click Finish.

Audio

1. Click 10.Install Audio Driver > Yes.

2. Click Next.

3. Click the button to agree to the license and click Next.

4. Click Next > Next > Next.

5. Click Finish to restart the computer.

(See Over) Note that after installing the audio driver the system will not return to the Drivers Installer screen. To in- stall any of the optional drivers listed overleaf, eject the Device Drivers & Utilities + User’s Manual disc and then reinsert it (or double-click the disc icon in My Computer), and click Option Drivers (button) to ac- cess the optional driver menu.

Drivers & Utilities

4 - 8 Windows 7 Driver Installation

Windows Experience Index

After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- ence Index (make sure the AC/DC adapter is plugged in):

1. Click Start, and click Control Panel.

2. Click Performance Information and Tools (System and Security > System > Check the Windows Experience Index).

3. Click “Rate this computer/Refresh Now/Re- run the assessment”.

4. The computer will take a few minutes to assess the system performance.

5. Close the control panel.



Windows Update

After installing all the drivers make sure you enable Windows Update in order to get all the latest security up-

dates etc. (all updates will include the latest hotfixes from Microsoft).

To enable Windows Update make sure you are con- nected to the internet:

1. Click Start, and click Control Panel (or point to Settings and click Control Panel).

2. Click Windows Update (System and Security/ Security).

3. Click Check for updates (button).

4. The computer will now check for updates (you need to be connected to the internet).

5. Click Install now (button) to begin checking for the updates.

6. Click Install updates (button) to install the updates.

Drivers & Utilities

Windows 7 Driver Installation 4 - 9

Optional Drivers

See the pages indicated for the driver installation procedures for any modules included in your purchase option.

Figure 4 - 3 - Drivers Installer - Option Drivers Menu

Model A

Computers

Model B

Computers

Drivers & Utilities

4 - 10 Windows 7 Driver Installation

PC Camera Module

See the introduction in “PC Camera Module” on

page 7 - 2, and check the installation procedure.

Wireless LAN Module

See the introduction in “Wireless LAN Module” on

page 7 - 10, and check the installation procedure.

3.75G/HSPA Module

Model A Computers Only See the introduction in “3.75G/HSPA Module” on

page 7 - 28, and check the installation procedure.

Fingerprint Module

Model A Computers Only See “Fingerprint Reader Module” on page 7 - 56 for configuration instructions.

Bluetooth Module

A driver is only required for the Combination Wireless LAN & V3.0 Bluetooth. See “Bluetooth

Combo Driver Installation” on page 7 - 62.

The operating system is the default setting for Bluetooth control for the standard V2.0 Bluetooth module in Windows 7 and does not require a driver. See

“Bluetooth Module” on page 7 - 61 for configuration

instructions.

BIOS Utilities

Overview 5 - 1

Chapter 5: BIOS Utilities

Overview

This chapter gives a brief introduction to the computer’s built-in software:

Diagnostics: The POST (Power-On Self Test)

Configuration: The Setup utility

If your computer has never been set up, or you are makin g important changes to the system (e.g. hard disk setup), then you should review this chapter first and note the original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make. This information could be useful if your system ever needs servicing.

There is one general rule: Don’t make any changes unless you are sure of what you are doing. Many of the settings are required by the system, and changing them could cause it to become unstable or worse. If you have any doubts, consult your service representative.



BIOS Screens

Note that the BIOS screens pictured on these pages are intended for guidance in setting up your system’s BIOS.

BIOS versions are subject to constant change and revision, therefore your computer’s actual screens may appear slightly different from those pictured on these pages.

BIOS Utilities

5 - 2 The Power-On Self Test (POST)

The Power-On Self Test (POST)

Each time you turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory).

As the POST proceeds, the computer will tell you if there is anything wrong. If there is a problem that prevents the system from booting, it will display a system summary and prompt you to run Setup.

If there are no problems, the Setup prompt will disappear and the system will load the operating system. Once that starts, you can’t get into Setup without rebooting.



POST Screen

1.BIOS information

2.CPU type

3.Memory status

4.Enter Setup prompt appears only during

POST

Note:

The

POST

screen as pictured right is for guideline purposes only. The

POST

screen on your computer may appear slightly different. If you disable the

Boot-

time Diagnostic Screen

, the POST screen will not appear.

Figure 5 - 1

POST Screen

BIOS Utilities

The Power-On Self Test (POST) 5 - 3

Failing the POST

Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”.

Fatal Errors

These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

Non-Fatal Errors

This kind of error still allows you to boot. You will get a message identifying the problem (make a note of this message!) followed by the prompt:

• Press <F1> to resume

• <F2> to enter Setup

Press F1 to see if the boot process can continue. It may work, without the correct configuration.

Press F2 to run the Setup program and try to correct the problem. If you still get an error message after you change the setting, or if the “cure” seems even worse, call for help.



BIOS Settings

Warning

Incorrect settings can cause your system to malfunction. To correct mistakes, return to Set-

up and restore the Setup Defaults with <F9>.

BIOS Utilities

5 - 4 The Setup Utility

The Setup Utility

The Phoenix SecureCore(tm) Setup Utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration).

Entering Setup

To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds after you turn on the system. If you get a “Keyboard Error”, (usually because you pressed F2 too quickly) just press F2 again.

If the computer is already on, reboot using the Ctrl + Alt + Delete combination and then hold down F2 when prompted. The Setup main menu will appear.

BIOS Utilities

The Setup Utility 5 - 5

Setup Screens

The following pages contain additional advice on portions of the Setup.

Along the top of the screen is a menu bar with menu headings. When you select a heading, a new screen appears. Scroll through the features listed on each screen to make changes to Setup.

Instructions on how to navigate each screen are in the box along the bottom of the screen. If these tools are confusing, press F1 to call up a General Help screen, and

then use the arrow keys to scroll up or down the page.

The Item Specific Help on the right side of each screen explains the highlighted item and has useful messages about its options.

If you see an arrow next to an item, press Enter to go to a sub-menu on that subject. The sub-menu screen that appears has a similar layout, but the Enter key may execute a command.



Setup Menus

The Setup menus shown in this section are for reference only. Your computer’s menus will indicate the configuration appropriate for your model and options.

BIOS Utilities

5-6Main Menu

Main Menu

System Time & Date (Main Menu)

The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings. Some applications may also alter data files to reflect these changes.

Figure 5 - 2

Main Menu

BIOS Utilities

Main Menu 5 - 7

SATA Port 1/2/3 (Main Menu)

Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Port 1/2/3. Use the Auto (Type:) setting to have the items configured automatically for you.

System/Extended Memory (Main Menu)

This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.

BIOS Revision/KBC/EC Firmware Revision (Main Menu)

This item contains information on the current BIOS and firmware versions.

GPU Card/GPU VBIOS Revision/GPU VBIOS Build Date (Main Menu)

This item contains information on the current video card and video BIOS.

BIOS Utilities

5 - 8 Advanced Menu

Advanced Menu

Advanced Chipset Control (Advanced Menu)

The sub-menu here allows you to enable/disable the JMicron Power Saving (as used by the card reader) control, to adjust the amount of Total Graphics Memory used by the system and adjust the Bluetooth Power Setting.

Figure 5 - 3

Advanced Menu

Schenker XMG A500,XMG A700 User Manual
