Schaller Automation ACCOMOS Operating Instructions Manual

Operating Instructions

Version 1.0, 08/2018

ACCOMOS

Acceleration
Monitoring
System

Operating Instructions ACCOMOS Page 2

About these operating instructions

These operating instructions contain information about the
handling, operation and maintenance of the ACCOMOS
acceleration sensor. They contain details about repair and
servicing.

If your ACCOMOS acceleration sensor malfunctions or fails
during operation, please contact your local dealer (see

section 10 “Service partners”) or contact Schaller

Automation Industrielle Automationstechnik GmbH & Co.
KG directly, www.schaller-automation.com. Safe and
reliable operation of the device is only ensured if the
acceleration sensor is operated in accordance with the
instructions.

Please observe the following:

 Read these instructions through carefully and familiarize

yourself with the correct installation, operation and
maintenance of your ACCOMOS.

 ACCOMOS sensors should only be used for the

purpose described in the operating instructions.

 Improper maintenance and handling may lead to the

device malfunctioning or an unsafe operating
environment.

 These operating instructions must be available at the

installation location at all times.

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 3

Terms and conditions of sale
The respective general terms and conditions of sale of
SCHALLER AUTOMATION or the seller of the sensor apply
to all ACCOMOS sensors and associated products.

SCHALLER AUTOMATION Industrielle Automationstechnik
GmbH & Co. KG does not assume any liability for
malfunctions arising as a result of the following:

a) Normal wear, improper commissioning, improper

use/handling, use of an unsuitable power supply,
welding processes on the motor or failure to observe
instructions relating to commissioning, installation,
operation and maintenance as specified in these
operating instructions

b) Use of different components and designs that are not

ACCOMOS

c) Modifications and conversions to the ACCOMOS,

carried out by the customer/operator or a third party
without the written approval of SCHALLER
AUTOMATION Industrielle Automationstechnik GmbH
& Co. KG

d) Incorrect combination or operation of devices and/or

components, which are not recognized as being
compatible or have not been approved by the
manufacturer SCHALLER AUTOMATION Industrielle
Automationstechnik GmbH & Co. KG

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 4

Symbols used

Caution! The text in this box must be
observed. Failure to observe it may
jeopardize the safety of persons or result
in damage to the device.

Attention! This text contains important
information.

This text contains advice for more
efficient use.

Caution! During welding work on the
motor, the sensor should be disconnected
from the power supply.

Safety information

ACCOMOS sensors are manufactured to the high quality
standards of SCHALLER AUTOMATION and undergo strict
factory testing. To ensure smooth and problem-free
operation of the device, the safety information and warnings
should be observed by the operator. These are indicated in
the operating instructions by the following symbols.

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 5

EC declaration of conformity

We, the manufacturer

SCHALLER AUTOMATION

Industrielle Automationstechnik GmbH & Co. KG

Industriering 14

D-66440 Blieskastel

Germany

Tel.: [phone]

Fax: [phone]

declare under sole responsibility that the product:

Type of device: Acceleration sensor
Model designation: ACCOMOS

to which this declaration relates and which is used exclusively for recording 3-axis
mechanical vibrations on non-rotating machine parts, complies with the
requirements of EU Directives:

EMC Directive 2014/30/EU

RoHS Directive 20011/65/EU

and the following standards:

EN 60529:1991 +A1:2000 +A3:2013, EN 55022:2010,

EN 61000-4-2:2009, EN 61000-4-3:2011, EN61000-4-4:2013, EN 61000-4-6:2014, EN

ISO 12100:2010, DNVGL-CG-0339:2015

IEC 60068-2-1:2007, 2-2:2007, 2-6:2007, 2-30:2005

Full technical documentation is available. This is a translation of the original operating
instructions for the acceleration sensor.

D-66440 Blieskastel, 2017/08/01

Stephan Schaller

- CEO -

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 6

Contents

1 Introduction ............................................................ 7

2 Installation instructions ............................................ 9

2.1 Mechanical installation ....................................... 9

2.2 Electrical installation ......................................... 18

3 Commissioning ..................................................... 22

3.1 LED indication .................................................. 22

3.2 RS485 data transfer ......................................... 25

3.3 CAN data transfer: ........................................... 25

4 Troubleshooting .................................................... 26

5 Function test ......................................................... 27

6 Part numbers ........................................................ 28

7 Optional spare parts and accessories .................... 28

8 Technical data ...................................................... 29

9 Service partners .................................................... 31

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 7

Attention!

Never use this sensor as a safety device.
The sensor is only intended as a control
device.

1 Introduction

The ACCOMOS acceleration sensor developed by Schaller
Automation is used to monitor and measure mechanical
vibrations of machines on non-rotating parts in accordance
with DIN ISO 10816.

Scope of delivery:

 ACCOMOS sensor
 Sensor protective plate with push screw
 M8 plug-in connector with INBUS key
 GND connecting cable

 M8 to M12 sensor connecting cable (optional)
 Monitoring software (optional)

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 8

ACCOMOS function overview

 Detection of critical and non-permissible vibration

statuses on three axes

 Indication when parameterizable thresholds are

exceeded via 3-color LED

 Indication of vibration, acceleration and deflection in

real time with additional accessories possible

 Recording of static acceleration
 CAN or RS485 interface for digital connection to a

display device

 Simple installation using magnetic fixture

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 9

Attention!

The surface for sensor installation must be flat
and free from dust and grease.

The magnetic sensor fixture has a strong
magnetic force! Improper handling may result
in skin or fingers becoming crushed.

The strong magnetic field of the sensor fixture
can influence the function of pacemakers and
defibrillators:

- Pacemakers may switch to test mode

and cause discomfort

- Defibrillators may fail completely

If you are wearing such devices, maintain a
sufficient distance from the magnetic fixture.

Keep the magnetic fixture away from any
devices and objects that could be damaged by
strong magnetic fields.

2 Installation instructions

2.1 Mechanical installation

- To avoid injury by crushing skin and fingers, we

recommend wearing protective gloves during
installation and removal

- During installation and removal, it is necessary to

ensure adequate lighting and a stable base at the
workplace

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 10

Installation:

- Loosen the M8x16 INBUS screw in the center of

the sensor and replace it with the M8x30 INBUS
screw (Illustration 1)

- Use the M8x30 INBUS screw to press the sensor

off the sensor protective plate (Illustration 2)

- Place the sensor on a flat and clean magnetic base

(oil and dirt must be removed beforehand if
necessary)

- Remove the M8x30 INBUS screw again so that the

sensor sits flat on the installation base (protect the
screw with the sensor protective plate for
transportation purposes -
Illustration 3)

- To protect the screw opening, insert the M8x16

INBUS screw again and tighten it (Illustration 4)

- Connect the supplied ground cable to the next

ground point, making the distance as short as
possible (Illustration 5)

- Check that the sensor is correctly mounted

- Connect the sensor to the power supply (and data

bus) using the M8 plug-in connector (Illustration 6)

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 11

Attention!

Do not reuse sensors with faulty seals on
the magnetic mounting plate. Otherwise,
there is a possibility of cuts due to
splintering of magnetic parts.

Removal:

- Disconnect the sensor from the power supply (M8

plug-in connector) and the ground cable

- Remove the M8x16 INBUS screw from the center

of the sensor and replace it with the M8x30 INBUS
screw

- Use the M8x30 INBUS screw to press the sensor

off the surface

- Place the sensor on the sensor protective plate

- Remove the M8x30 INBUS screw again so that the

sensor sits flat on the sensor protective plate

- To protect the screw opening, insert the M8x16

INBUS screw again and tighten it

-

For safety reasons, never transport a sensor
without a sensor protective plate!

Typical installation points can be found in DIN ISO 10816-1
/ DIN ISO 10816-6.

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 12

Illustration 1: Removing the central screw

Remove central
screw first

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 13

Illustration 2: Removing the protective plate with the

M8x30 screw

Protective plate

Protective plate

M8x3

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 14

Illustration 3: Removing the M8x30 screw after

installation on the motor

Remove and
store with the
protective plate

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 15

Illustration 4: Fitting the central screw

Refit central screw

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 16

Illustration 5: Connecting the ground cable to the motor

Connect
ground cable

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 17

Illustration 6: Connecting the bus cable

Bus cable
(4-pin M8)

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 18

Illustration 7: Pin-side view

Pin

Description

1

24 V DC +

2

24 V DC GND

3

CAN-L or RS485 A

4

CAN-H or RS485 B

2.2 Electrical installation

Table 1: Assignment of the 4-pin M8 plug-in

connector (left terminal on sensor)

Pins 3 and 4 are connected internally to a 120 Ohm resistor;
therefore, the ACCOMOS should be the last sensor on the
bus line.

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 19

Warning!

The GND connection on the front of the
sensor must be connected to the ground
with the shortest possible cable length!

The right M8 connector is only intended
for internal purposes at Schaller! No
connection should be made here!

Power supply

9 – 36 V DC, max. 0.11 A

Nominal voltage

24 V DC

Table 2: Electrical specification

The data cable to be used must be twisted and shielded.
We recommend a cable with CAN bus/DeviceNet
specification:

2xAWG24/19+2xAWG22/19 (Illustration 9)

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 20

Illustration 8: Connecting the M8 connector (included in

the scope of delivery)

Hexagon wrench
supplied

Trim the shielding
and wrap around
shielding ring.

1. Thread parts

2. Strip insulation, trim shielding

and wrap around shielding ring

3. Connect wires

4. Screw in place housing with

connector or socket insert and
tighten with pressure screw.

Cable entry 6-8 mm

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 21

Illustration 9: Assembly of the M12 <-> M8 cable

(optional)

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 22

Illustration 10: Power-on

The maximum bus length is limited to 100 m.

When the sensor has been connected to a power supply, it
immediately and automatically transmits the measurement
data to the bus.

3 Commissioning

3.1 LED indication

When the power supply is connected, the LED on the front
of the sensor lights up green. The sensor transmits the
acceleration values immediately and automatically via
RS485 or CAN bus.

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 23

Illustration 11: Status yellow

The LED changes color to indicate when two
parameterizable thresholds are exceeded:

- LED lights up yellow (default):

Acceleration  4*9.81 m/s

- LED lights up red (default):

Acceleration  8*9.81 m/s

2

2

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 24

Illustration 12: Status red

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 25

3.2 RS485 data transfer

Baud rate: 500,000 bit/s
Data length: 8 bits
Stop bits: 2
Parity: none
Hardware flow control: none
Data rate: 1500 Msg/s

3.3 CAN data transfer:

Baud rate: 500,000 bit/s
ID for messages ­of sensor (Tx): 0x680
(parameterizable)
ID for parameterization (Rx): 0x681
(parameterizable)

Data rate: 1500 or 3000
messages/s

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 26

Fault

Cause

Remedy

LED off

No power supply

Power supply has
reverse polarity

Power supply too
low

1. Check

connection

2. Check

connection/
power supply

3. Check power

supply

LED green but
no bus
messages

Cable break

Connecting line has
reverse polarity

Incorrect bus
parameters

Incorrect bus system
(CAN/RS485)

1. Check cables

2. Check

connection

3. Check bus

parameters

4. Use correct

sensor version

Seals on
magnetic
mounting
plate faulty

Wear/cut in seal

1. Replace sensor

4 Troubleshooting

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 27

5 Function test

After commissioning and connection to a power supply, the
LED indicator on the front of the sensor lights up green.

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 28

Part
number

Description
273 400

ACCOMOS – CAN

273 410

ACCOMOS – RS485

Part
number

Description

Number per

ACCOMOS

151486

Spare parts kit

1

Part
number

Description
310289

Sensor cable M12 <-> M8, assembled

6 Part numbers

Table 3: Part numbers

7 Optional spare parts and accessories

Table 4: Optional spare parts

Table 5: Optional accessories

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 29

Mechanical data

Dimensions

Diameter:
Height:

89.5 mm

39.5 mm

Weight

400 g

Indication

3-color LED:
Green: Ready for operation
Yellow: Acceleration 
4000*9.8 mm/s2 (default)
Red: Acceleration 
8000*9.81 mm/s2 (default)

Electrical data

Power supply

9 V – 36 V DC, max. 0.11 A

Nominal voltage

24 V DC

Cable connection

1 x M8 connector, 4-pin

Communication interface

RS485, galvanically isolated
CAN, galvanically isolated

Cable recommendation for
communication interface

CAN bus/DeviceNet specified
2xAWG24/19+2xAWG22/19

8 Technical data

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 30

Measurement range

Acceleration

 16,000*9.81 mm/s

2

Frequency

0 – 750 Hz (1500 Hz for CAN
bus operation possible)

Sensitivity

4*9.81 mm/s2

Non-linearity

 0.5%

Crosstalk between axes

 1%

Deviation of sensitivity from
ideal

 1%

Ambient conditions

Operating temperature

-25 to +85°C

Storage temperature

-25 to +85°C

Humidity

Up to 95%

IP rating

IP67

Table 6: Technical data

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com

Operating Instructions ACCOMOS Page 31

9 Service partners

Schaller Automation has a global network of service
partners in more than 130 countries.

A current list of our representatives, including contact data,
can be found on our website:

http://www.schaller-automation.com/

Or call our Technical Support department at our head office
in Germany:

Tel. [phone]

SCHALLER AUTOMATION

D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280

Industrielle Automationstechnik GmbH & Co. KG Tel. [phone]

Fax -260 / Email: [e-mail] / www.schaller-automation.com
