OWNER’S MANUAL

SAFETY INSTRUCTIONS

Please read and keep these instructions with the fan.

MODEL: VAF8000A/A-3/B-3

For use in Non-Explosive/Non-Flammable environments only.

Purchase Date: ___________________ Serial No. ___________________

Dealer: ______________________________________

1.800.779.3267 • www.schaeferfan.com

PROBLEM
U

nit will not run.

Unit runs but fan
makes loud scraping
noise.

Unit runs but
vibrates
excessively.

Unit runs but fan
does not turn.

Unit runs briefly,
then shuts off on
overload.

CAUSE

1

No power to unit.

2) Switch not on.

3) Switch is faulty.
4

) Faulty / Broken cord or motor wire.

1) Unit has been severely jolted causing fan to
rub against housing.

2) Unit has been severely jolted causing
housing to deform.

1) Severe jolt has bent motor shaft causing
unit to be out of balance.

2) Fan blade damaged.

3) Dirt build up on one side of fan blade.

1) Fan is jammed against housing.

2) Capacitor wire has broken/come loose,
capacitor has failed.

3) Housing has been damaged such that it
presses on the fan blade.

1) Motor bearings are failing, or motor has
developed an internal electric fault.

2) Intake grill and/or exhaust grill is obstructed.

3) Excessive duct length.

SOLUTION

1

) Plug unit in. Check circuit breaker.

2) Place in "ON" position.

3) Replace switch.
4

) Perform continuity check, using volt/amp meter,

Repair/replace faulty/broken wire.

1) Remove motor and replace damaged motor
mounts.

2) Replace housing/unit as necessary.

1) Remove and replace motor. Replace fan blade if
necessary.

2) Replace fan blade.

3) Clean fan blade.

1) Remove motor and replace damaged motor
mounts. Replace fan blade if necessary.

2) Repair/replace wires/capacitor as necessary.

3) Replace housing/unit as necessary.

1) Replace motor.

2) Remove obstruction.

3) Reduce duct length to recommended maximum.

AMERIC AXIAL FAN TROUBLESHOOTING

CAUTION: All service procedures should be executed with the unit unplugged.

©2012 Schaefer Ventilation Equipment. All rights reserved.

M-VAF8000A/A-3/B-3

Item Part# Each Description

1 RING-VAF8000 2 Duct Ring 20" ABS

2 Guard-VAF8000 2 Wire Guard 20"

4 HSG-VAF8000 1 Housing Blue VAF8000

5 CS253 1 Motor 5HP 3Ph

CS251 1 Motor 5HP 1Ph

6 BLD-VAF8000-60 1 60 Hz Fan Blade Assembly

BLD-VAF8000-50 1 50 Hz Fan Blade Assembly

7 MTRVN-VAF8000 2 Motor Mount Primary Vane

8 SECVN-VAF8000 4 Secondary Vane

9 0B51624X1HZ 12 Bolt 5/16"-24 x 1" Hex Zinc

10 0B1420X114HZ 24 Bolt 1/4"-20x1-1/4" Hex Zinc

11 SWPNL-VAF8000 1 Switch Mount Panel

12 0RF212OD 4 Rubber Foot

13 0RIVET6-8A-B 20 Rivet 3/16"x1/2"G ABA

14 CORD-12/4-20 1 Power Cord Black 20'

15 0MS-KTA725S10A 1 Motor Starter 440V 10A 3Ph

0MS-KTA725S16A 1 Motor Starter 220V 16A 3Ph

0MS-KTA725S25A 1 Motor Starter 220V 25A 1Ph

16 0W1132X114Z 6 Washer 11/32"x1-1/4"x1/8" Z

17 0W14X1Z 4 Washer 1/4" x 1" Zinc

18 0GSKT-8000KTA7 1 Gasket Power Panel

19 0S-KT7AYTG2 1 Operator Switch

20 0FLEXPVC12 3 1/2" Flexible PVCConduit

Item Part# Each Description

21

SHACKLE58-6500G 1 Shackle 5/8" Screw Pin

22 0WNJ1420R 4 Well Nut J1420 Rubber

23 0NY51624Z 12 Nylock 5/16"-24 Zinc

24 MSBOX-VAF8000 1 Motor Starter Box

25 0B1420X112HZ 12 Bolt 1/4"-20x1-1/2" Hex Zinc

26 DINRAIL-3 1 DIN Rail 35mm x7.5mm Zinc

27 0NY1420Z 32 Nylock 1/4"-20 Zinc

28 0W14STDZ 48 Washer 1/4" USS

29 0W14SAE 40 Washer 1/4" SAE

30 0CFLT12 2 Conduit Fitting 1/2" Snap In

31 CONNECTOR34 1 Cordgrip Liq. Tight 3/4" NPT

0LNROMEX34 1 Lock Nut for 3/4" Cord Grip

0ORING214SQ 1 O-Ring 214 Square

32 0WIL10STDZ 2 Washer Internal Lock #10 Z

0RGTERM1210-10 1

Ring Terminal #10 12-10 AWG

33 0B1032X58PHRHZ 4 Bolt 10-32x5/8" Rnd Head Z

0B1032X12SCS 2 Bolt 10-32x1/2" SC Screw Z

0W10X58SS 2 Washer Fender #10

0NY1032Z 3 Nylock 10-32 Zinc

LABELVAF8000440 1 Label VAF8000 440V

SCHAEFER LIMITED WARRANTY

If you are the original purchaser of a new Americ Vane Axial Fan from Schaefer, then you are entitled to a
limited warranty subject to the terms and conditions set forth herein. To qualify for the limited warranty you
must complete the enclosed registration card and mail it to Schaefer within (30) days of the purchase, so that
there is a record of your purchase. Schaefer's limited warranty is for the replacement or repair of any part that
proves to be defective in workmanship or materials for a period of one (1) year from the date of purchase by
the original purchaser. During the first year, Schaefer will provide all parts necessary to correct any defects,
free of charge. This limited warranty extends only to the original purchaser who retains ownership of the Fan.
This limited warranty is not transferable to any subsequent purchaser or second-hand user.

The limited warranty extends only to the repair or replacement of parts found upon Schaefer's examination to
be defective. Unless any part or assembled unit replaced hereunder is returned, freight pre-paid, together with
a letter describing the problem to Schaefer or an authorized Schaefer dealer, this limited warranty will be void
and of no effect.

This warranty is limited to ninety (90) days for labor from the date of the purchase. Thereafter, any labor costs
incurred will be charged to the customer at the prevailing hourly rate.

This limited warranty shall not extend to a product that has been used in an improper manner, or that has been
disassembled, altered or improperly maintained. Nor shall this limited warranty apply if the Fan has been
subjected to corrosive chemicals, improper voltage, unauthorized repairs, fire, flood, abnormal wear or any
causes beyond Schaefer's control.

This limited warranty does not apply if the serial number has been removed, obliterated or defaced.

Schaefer Ventilation reserves the right to make changes to the Vane Axial Fan in design, materials or
specifications as necessary and without prior notice. Schaefer shall not be obliged to make alterations or
modifications to existing products previously manufactured.

To obtain replacement parts pursuant to this limited warranty, you must write to Schaefer or call
[phone] to receive an authorization number. Replacement parts will not be provided unless the

customer first provides the serial number of the Fan and also receives an authorization number from

Schaefer.

OTHER THAN THE FOREGOING LIMITED WARRANTY, THERE ARE NO FURTHER WARRANTIES OR
ANY AFFIRMATIONS OF FACT OR PROMISES BY SCHAEFER WITH RESPECT TO THE VANE AXIAL FAN.
THE DURATION OF ANY IMPLIED WARRANTIES ARE LIMITED TO THE TERMS OF THE ABOVE LIMITED
WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
MAY LAST, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. WITHOUT LIMITING THE
GENERALITY OF THE FOREGOING, SCHAEFER EXPRESSLY DISCLAIMS ANY INFRINGEMENT OR ANY
AFFIRMATIONS OF FACT OR QUALITY NOT EXPRESSLY CONTAINED HEREIN. SCHAEFER
VENTILATION AND ITS AFFILIATES NEITHER ASSUME NOR AUTHORIZE ANY PERSON TO ASSUME
FOR THEM ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. THERE
ARE NO OTHER WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
IN NO EVENT SHALL SCHAEFER VENTILATION BE LIABLE FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR FOR LOSS OF PROFITS OF ITS CUSTOMERS OR USERS OF
PRODUCT. SOME STATES/JURISDICTIONS DO NOT ALLOW THE EXCLUSIONS OR LIMITATIONS OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.

1

2

6

4

27

29

25

21

27

28

10

9

28

23

8

13

7

30

30

5

16

20

22

14

31

33

19

26

33

24

15

18

11

12

25

17

VAF8000 PICTORIAL BREAKDOWN

INTRODUCTION

Congratulations...on your selection of a new Vane Axial Fan from Schaefer Ventilation. Our goal is to provide
you with the very best in high performance air ventilators. Reading this Owner's Manual will help you achieve
the maximum benefit from your portable air ventilator. If you do not understand any portion of this Manual
please contact Schaefer or your authorized Schaefer dealer for proper assistance prior to operating this Fan.

Do not allow anyone to operate the Vane Axial Fan without first reading the Operator's Manual and becoming familiar with its
operation. Schaefer has endeavored to provide you with the finest equipment available for providing air for portable
ventilation purposes. The possibility does exist, however, that the Vane Axial Fan can be subjected to applications not
intended by Schaefer. Misuse and/or misapplication of the Vane Axial Fan can lead to the possibility of serious
damage, injury or even death. Anyone operating the Vane Axial Fan should refer to current OSHA job safety and health
rules and regulations pertaining to the construction industry, with a particular emphasis on 29 CFR 1910, which contains
rules governing Permit-Required Confined Spaces for General Industry.

Record the Vane Axial Fan model and serial number in the space provided below.

Model No.____________________ Serial No. ________________________ Date Purchased ______________________

All specifications are general in nature and are not intended for specific application purposes. Schaefer accepts no
responsibility for variations which may be evident in actual products, specifications, pictures and descriptions contained in

this publication.

MAINTENANCE

DANGER

ALWAYS SHUT OFF THE FAN AND UNPLUG IT FROM ITS POWER SOURCE TO PREVENT ACCIDENTAL STARTING
AND THE POSSIBILITY OF ELECTRICAL SHOCK AND/OR ELECTROCUTION. BE SURE THE FAN BLADE HAS
STOPPED ROTATING BEFORE PLACING ANY OBJECTS OR FINGERS NEAR THE FAN GRILL.

1. Visually check all fasteners and individual components for loose or broken parts. Tighten or replace items as required,
with genuine, factory approved replacement parts only.

2. Keep the Fan blade clean from debris. Accumulation of dust, dirt, paint, etc. on the Fan blade will throw the blade rotation
out of balance, resulting in damage. To clean the Fan blade, be sure the plug is disconnected and the blade has stopped
rotating. Remove one grill and wipe blade and interior shell housing clean of debris with a damp cloth and mild liquid soap.
Dry all parts thoroughly. DO NOT PRESSURE WASH THE FAN. Replace grill prior to next operation.

DANGER

DO NOT OPERATE THE FAN WITHOUT THE INLET AND OUTLET GRILL PROPERLY IN PLACE.

3. Contact Schaefer directly for Fan maintenance or repair not described in this manual (or if you are unsure whether main­tenance is required.) at Tel# [phone] or at www.schaeferfan.com.

SERVICE

1) Refer to the TROUBLESHOOTING GUIDE in this Manual.

MOTOR SPECIFICATIONS GENERAL INFORMATION & DIMENSIONS

(A) (A-3) (B-3)
Voltage 230V AC-- 230V AC-- 440V AC-- Type Axial
Frequency 60/50 Hz 60/50 Hz 60/50 Hz Duct adapter 20.5" dia. (52 cm)
Phase Single Three Three Height 27.5" (69.8 cm)
Electric Motor 5 HP 5 HP 5 HP (.75kw) Width 25.5" (64.7 cm)
Current (amps) 21.2 13.0 6.5 Length 27.5" (69.8 cm)
R.P.M 3250 3450 3450 Weight 119 lbs (53.97 kg)
Free Air (cfm) N/A 9968 9968 (282.3 M³)
Max S.P. 6.1" 6.1" 6.1" (68mmlaq)

AIR FLOW RATES

(A-3) (B-3)

Feet Description CFM M³/Min CFM M³/Min

Free Air 9968 282.3 9968 282.3
25' duct Straight 9379 265.6 9379 265.6
25' duct 1-90° bend 7193 203.7 7193 203.7
25' duct 2-90° bends 6726 190.5 6726 190.5
50' duct Straight 8664 245.3 8664 245.3
75' duct Straight 8313 235.4 8313 235.4

The published flow rates are intended to serve only as a reference. Manufacturing tolerances, duct type and specific
operat-ing parameters will affect the overall flow rate(s) for each particular Fan.

CAUTION

THE AIR FLOW RATE DECREASES AS THE LENGTH OF DUCT INCREASES FOR BOTH BLOWING AND
SUCTION APPLICATIONS. AIR FLOW RATES WILL VARY WITH SPECIFIC DUCT TYPES AND
MANUFACTURES.

SAFETY PRECAUTIONS

DANGER

THE FAN IS DESIGNED FOR PORTABLE AIR VENTILATION PURPOSES ONLY. THE FAN IS NOT DESIGNED
F

OR TRANSPORTING LIQUID OR SEMI-SOLID MATERIALS. THE ELECTRIC MOTOR AND FAN HOUSING ARE

N

OT DESIGNED FOR OPERATION IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE. OPERATION OF

THE FAN IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE MAY RESULT IN PROPERTY DAMAGE,
PERSONAL INJURY OR EVEN DEATH. INCORRECT USE OF THE FAN CAN RESULT IN AN ELECTRICAL

S

HOCK AND/OR ELECTROCUTION. ALWAYS OPERATE THE FAN IN COMPLIANCE WITH CURRENT OSHA

AND NATIONAL ELECTRIC CODE REGULATIONS.

D

ANGER

I

NCORRECT USE OF THE FAN CAN RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR EVEN DEATH.
TO REDUCE THIS RISK, GIVE COMPLETE AND UNDIVIDED ATTENTION TO THE JOB AT HAND. AN
ENVIRONMENT ATMOSPHERE CONSTANTLY CHANGES; THEREFORE, IT'S RECOMMENDED THAT AIR
MONITORING/ GAS DETECTION EQUIPMENT BE USED FREQUENTLY. IF TESTS SHOW THAT THE
ATMOSPHERE QUALIFIES AS A HAZARDOUS LOCATION (AN AREA WHERE THE POSSIBILITY OF
EXPLOSION AND FIRE IS CREATED BY THE PRESENCE OF COMBUSTIBLE LIQUIDS, FLAMMABLE GASES,
VAPORS, DUST, FIBERS, FLAMES OR FILINGS.) DO NOT USE THIS FAN. READ AND UNDERSTAND THE
FOLLOWING PREPARATION ITEMS AND GENERAL SAFETY INFORMATION.

PREPARATION

1) Become familiar with the Fan operations before utilizing this Fan. Read and understand all Cautions and Warn­ings in this Manual. Refer to current OSHA publications for complete job safety and health rules and regulations
(CFR 1926 and 1910).

2) Confirm that the Fan is in its original, factory configuration and has not been modified in any manner.

3) Minors should not be allowed to operate the Fan. Close attention is necessary when used, especially when used
near children or animals.

4) Guard against the possibility of back-related injuries. Always lift the Fan with leg muscles and not with the back.

5) Periodically inspect the Fan visually for damaged or worn parts. Check for loose and/or broken parts. Be sure that
the Fan and accessories are in good working condition before operating.

6) Know how to stop the Fan quickly in an emergency. Turn unit off at (on/off) switch located on side of unit or
unplug Fan from power supply.

7) Based upon customer country standards, customer to supply suitable plug to conform to their specific country’s
requirement.

GENERAL SAFETY INFORMATION

1) Never place the Fan in standing water because of extreme shock hazard.

2) Never allow air intake grill to become blocked.

3) Never discharge flammable solvents or kerosene based chemicals through the Fan air intake grill.

4) Do not use the Fan in areas where flammable or combustible liquids, gases, vapors, dust, fibers or filings
may be present.

5) Never put any object in the air intake grill.

6) Never run the Fan outside when it is raining. Never store the Fan outdoors.

7) Do not use the Fan as a toy.

8) Use the Fan only with a properly grounded outlet.

9) Unplug the Fan from outlet when not in use and before servicing.

WARNING: To reduce the risk of fire or electric shock, do not use this fan with any
solid state speed control device.

GENERAL SAFETY INFO. (Continued)

10) Do not use the Fan with a damaged cord or plug. Do not pull or carry the Fan by its cord, do not use cord as a
handle, do not close a door on the cord and do not pull cord around sharp edges or corners. Keep cord away from
heated surfaces. Do not unplug the Fan by pulling on cord, grasp the plug and not the cord. Do not handle the plug
or cord with wet hands.

11) Keep hair, loose clothing, fingers and all parts of the body away from the air intake grill.

12) Do not allow water inside the motor. If the motor becomes wet for any reason, unplug the Fan and thoroughly
dry it before using again.

13) Never remove the ground from the power cord or plug, as this may result in electrical shock or electrocution.
R

emoving the ground would void the warranty.

1

4) If the Fan has been dropped, left outdoors, dropped into water, etc...,please thoroughly inspect it prior to use.
If the Fan is not working or if you have a question about its safe operation, do not operate it. Contact Schaefer
Ventilation directly at [phone] or at www.schaeferfan.com.

OPERATION

1) Your new Fan comes to you completely assembled and ready to operate. Upon removing the Fan from its carton,
inspect it for any possible damage in transit.

2) Before operating the Fan, please read all the safety Precautions and General Safety Information about the proper
and safe use of the Fan.

3) Assess your job site. Certain job site locations are classified as being hazardous because the atmosphere may
contain gas vapor or dust in explosive quantities.

DANGER

THE ELECTRIC MOTOR AND FAN HOUSING ARE NOT DESIGNED FOR OPERATION IN AN EX­PLOSIVE AND/OR FLAMMABLE ATMOSPHERE OF ANY CLASS OR GROUP. OPERATION OF
THE FAN IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE MAY RESULT IN PERSONAL IN­JURY OR DEATH.

4) Locate a properly grounded outlet.

5) Prior to plugging the Fan into a grounded outlet, inspect the inlet and outlet grills and remove debris which may
restrict airflow movement. Never operate the Fan without the inlet and outlet grills properly secured and in place.
Never replace the grills with other than factory supplied replacement units.

6) Note the directional airflow indicator on the external shell. This is the way the air moves.

7) Place the Fan on secure footing to prevent it from shifting while in use.

8) ) Do not stand directly in front of and/or face the Fan outlet. Personal injury can result from
being struck by debris thrown at a relatively high velocity from the Fan blade.

9) When ducting is required, do not install duct while Fan is in operation. Place duct lip over
the Fan duct adapter, secure firmly, and note direction of the airflow.

10) When duct is used, be aware that the airflow rate decreases as the length of duct increases. Airflow rates will
vary with specific duct types and manufactures.

11 ) Position Fan air inlet away from walls and other obstructions to allow for maximum air intake.

12) For safe operation, use the Fan only in combination with thorough gas detection tests and continual
retesting.

DANGER

ALWAYS ASSUME A CONFINED SPACE WORK AREA IS CONTAMINATED UNTIL IT HAS BEEN
PROVEN SAFE FOR WORK PERSONNEL. NEVER ENTER A CONFINED SPACE WORK AREA
UNTIL IT HAS BEEN THOROUGHLY TESTED WITH APPROPRIATE GAS DETECTION
EQUIPMENT AND PROVEN SAFE FOR WORK PERSONNEL.
