Scanreco D3DRC10 Operating Instructions

Operating/assembly instructions

DRC-10 D3 hand-held transmitters

151014 enGB

F1

211 266 44

F2

42658144.eps

719 IS 975

Manufacturer’s address:

Contents

Original operating/assembly instructions

Terex MHPS GmbH

Forststrasse 16

40597 Düsseldorf, Germany

www.demagcranes.com

[e-mail]

1 General 4

1.1 Information on DRC-10 hand-held transmitters 4

1.2 Information on the operating/assembly instructions 4

1.3 Symbols/signal words 5

1.4 Liability and warranty 6

1.5 Copyright 6

1.6 Spare parts 6

1.7 Definitions 7

1.8 After-sales service 8

1.9 Disposal of machine parts 8

2 Safety 9

2.1 General 9

2.2 Intended use 9

2.3 Responsibility of the owner 11

2.4 Operating personnel requirements 11

2.5 Personal protection equipment 12

2.6 Regular inspections 12

2.7 Safety instructions for installation and disassembly 12

2.8 Safety instructions when first putting the unit into service
after completing installation 12

3 Device selection 13

3.1 DRC-10 scope of delivery 13

3.2 Available radio receivers 13

3.3 Accessories for DRC-10 hand-held transmitters 13

3.4 Accessories for crane identification 13

3.5 Casing seal/seal breakage 13

4 Technical data 14

4.1 Dimensions 14

4.2 International postal approval 15

5 Transport, packing, storage 16

5.1 Transport inspection 16

5.2 Packing 16

5.3 Storage 16

6 Design and function 17

6.1 Transmitter/receiver interface 17

6.2 Transmission method 17

6.3 Power supply for DRC-10 hand-held transmitters 18

6.4 Identification and display functions 21

2

211 266 44.indd/151014 © Terex MHPS GmbH

P FCC and Industry Canada Information 22

3

Further documents:

DRC-MP operating instructions 211 270 44
DRC-DR operating instructions 211 267 44

719 IS 975
719 IS 975

1 General

1.1 Information on DRC-10
hand-held transmitters

1.2 Information on the
operating/assembly
instructions

You have purchased a Demag product.

These operating/assembly instructions are designed to provide the owner and
operators with appropriate instructions for safe and correct operation and for
commissioning.

Every individual given the task of transporting, installing, commissioning, operat­ing, maintaining and repairing our products and additional equipment must have
read and understood

• the operating/assembly instructions

• the safety regulations and

• the safety instructions in the individual chapters and sections.

The operating/assembly instructions must be available to operating personnel at
all times in order to prevent operating errors and to ensure smooth and trouble-free
operation of our products.

These operating/assembly instructions are an integral part of the DRC-10 hand­held transmitter.

They must be kept available in the immediate vicinity at all times.

DRC-10 hand-held transmitters may only be operated by personnel who are fully
familiar with the operating/assembly instructions.

If special designs or additional options are ordered or the latest technical
modifications are incorporated, the actual scope of supply may differ from the data
and information as well as from the illustrations described here.

If you have any questions, please contact the manufacturer.

4

211 266 44.indd/151014 © Terex MHPS GmbH

1.3 Symbols/signal words

Important safety information and instructions are marked by corresponding
symbols and signal words in these operating/assembly instructions.

Safety instructions and information must be followed. Follow these instructions with
care to avoid any accidents, injuries or damage.

Any locally applicable accident prevention regulations and general safety
regulations must also be followed.

The following symbols and instructions warn against possible injuries or damage
and are intended to assist you in your work.

DANGER.

This symbol indicates an immediate hazard which can result in serious injury
or death.

WARNING.

This symbol indicates a possibly hazardous situation which might result in
serious injury or death.

CAUTION.

This symbol indicates a possibly hazardous situation which might result in
medium to light injury.

NOTE

i

Operating hazard for the DRC-10 hand-held transmitter.

• This symbol indicates information on the appropriate use of DRC-10 hand­held transmitters.

• Failure to follow these instructions may result in malfunctions, damage or
pollution of the environment.

211 266 44.indd/151014 © Terex MHPS GmbH

5

1.4 Liability and warranty

All information included in these operating/assembly instructions has been
compiled on the basis of the relevant regulations, state-of-the-art engineering
principles and our many years of experience.

NOTE

i

These operating/assembly instructions must be read carefully before starting
any work on and with the DRC-10 hand-held transmitter, especially before
the unit is put into operation for the first time. The manufacturer assumes no
liability for any damage which results from the following:

• Non-compliance with the operating/assembly instructions

• Inappropriate use of the DRC-10 hand-held transmitter

• Operation by insufficiently trained personnel

• Unauthorised conversions

• Any technical modifications

Wearing parts are not subject to liability for defects.

We reserve the right to incorporate technical modifications within the scope of
improving the operating characteristics and further development of the DRC-10
hand-held transmitters.

1.5 Copyright

1.6 Spare parts

These operating/assembly instructions must be treated confidentially. They are
only intended to be used by people who work with or on DRC-10 hand-held
transmitters.

Any and all content, texts, drawings, images and any other information are
protected within the sense of copyright law and are subject to further industrial
rights. Any misuse is an offence.

No part of this documentation, in whole or in part, may be reproduced, distributed,
shown in public or used in any other way without specific prior consent.
Infringements are an offence resulting in obligatory compensatory damages.
Further rights reserved.

All industrial rights reserved.

Only genuine Terex MH spare parts may be used.

CAUTION. Defective spare parts

Incorrect or defective spare parts may cause damage, malfunctions or
complete failure of DRC-10 hand-held transmitters.

Only use genuine spare parts or parts approved by Terex MH.

For safety-relevant wear parts, genuine Demag spare parts must always be
used.

Safety-relevant wear parts are, for example, brake linings, ropes, etc.

The use of unauthorised spare parts renders null and void any claims for warranty,
service, damages or liability against the manufacturer or his appointed personnel,
dealers and representatives.

6

211 266 44.indd/151014 © Terex MHPS GmbH

1.7 Definitions

Owner

Owners (employer, company) are defined as persons who own a radio control
system and who use it as intended or allow it to be operated by suitable and
instructed persons.

Operating personnel/operator

Operating personnel are defined as persons entrusted by the owner of a radio
control system with operation of the radio control system.

Specialist personnel

Specialist personnel are defined as persons assigned by the owner of the
radio control system to carry out special tasks such as installation, setting-up,
maintenance and fault elimination.

Qualified electrician

Qualified electricians are defined as persons who, owing to their technical training,
knowledge and experience of electric equipment as well as knowledge of the
relevant standards, codes of practice and regulations, are able to assess the tasks
given to them and to identify and eliminate potential hazards.

Trained person

Trained persons are defined as persons who have been instructed and trained for
the tasks assigned to them and on the possible hazards resulting from incorrect
handling and who have been informed about the required protective devices,
protective measures, relevant regulations, codes of practice, accident prevention
regulations and operating conditions and who have proven their qualifications.

Experienced technician

Experienced technicians are defined as persons, who, owing to their technical
training and experience, have sufficient knowledge of radio control systems
and are familiar with the relevant national industrial safety regulations, codes
of practice, accident prevention regulations, directives and generally accepted
engineering standards enabling them to judge the safe operating condition of radio
control systems.

Radio control system

Radio control systems are systems used for controlling the lifting, lowering and
travel motions of loads on cranes, crabs, machinery and installations.

211 266 44.indd/151014 © Terex MHPS GmbH

7
